Asus GX810 User manual

User Manual
ASUS GX810 ROG Gaming Mouse
15G06S00XXXX

2
English
Contents
English ....................................................................................... 1-22
繁體中文 ....................................................................................23-38
󰒫󰚸 ....................................................................................39-54
Čeština.....................................................................................55-70
Français ...................................................................................71-86
Deutsch..................................................................................87-102
Magyar.................................................................................103-118
Italiano ................................................................................119-136
Polski ...................................................................................137-152
Português............................................................................153-168
Русский ...............................................................................169-184
Română ...............................................................................185-200
Slovensky ............................................................................201-216
Slovenščina .........................................................................217-232
Español................................................................................233-248
Türkçe ..................................................................................249-264
Українська..........................................................................265-279

English
3
Q6405
First Edition (V1)
February 2011
Copyright © 2011 ASUSTeK Computer Inc.All Rights Reserved.
No part of this manual, including the products and software described in it,may be reproduced,
transmitted,transcribed,stored in a retrieval system, or translated into any language in any form
or by any means,except documentation kept by the purchaser for backup purposes,without the
express written permission of ASUSTeK Computer Inc.(“ASUS”).
Product warranty or service will not be extended if: (1) the product is repaired,modified or altered,
unless such repair,modification of alteration is authorized in writing by ASUS;or (2) the serial
number of the product is defaced or missing.
ASUS PROVIDES THIS MANUAL“AS IS”WITHOUT WARRANTY OF ANY KIND,EITHER EXPRESS
OR IMPLIED,INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.IN NO EVENT SHALL ASUS, ITS
DIRECTORS,OFFICERS,EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT,SPECIAL,INCIDENTAL,
OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS, LOSS OF BUSINESS,
LOSS OF USE OR DATA,INTERRUPTION OF BUSINESS AND THE LIKE), EVEN IF ASUS HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY DEFECT OR ERROR IN THIS
MANUAL OR PRODUCT.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR
INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE,AND
SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS.ASUS ASSUMES NO RESPONSIBILITY OR
LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS MANUAL, INCLUDING THE
PRODUCTS AND SOFTWARE DESCRIBED IN IT.
Products and corporate names appearing in this manual may or may not be registered trademarks or
copyrights of their respective companies,and are used only for identification or explanation and to
the owners’benefit,without intent to infringe.

4
English
Contact Information
ASUSTeK COMPUTER INC.
Address 15 Li-Te Road,Peitou,Taipei,Taiwan 11259
Telephone [phone]
Fax [phone]
E-mail [email protected]
Web site www.asus.com.tw
Technical Support
Telephone [phone]
Online support support.asus.com
ASUS COMPUTER INTERNATIONAL (America)
Address 800 Corporate Way, Fremont, CA 94539, USA
Telephone [phone]
Fax [phone]
Web site usa.asus.com
Technical Support
Telephone [phone]
Support fax [phone]
Online support support.asus.com
ASUS COMPUTER GmbH (Germany and Austria)
Address Harkort Str. 21-23, D-40880 Ratingen, Germany
Fax [phone]
Web site www.asus.de
Online contact www.asus.de/sales
Technical Support
Telephone (Component) [phone]*
Telephone (System/Notebook/Eee/LCD) [phone]*
Support Fax [phone]
Online support support.asus.com
* EUR 0.14/minute from a German fixed landline; EUR 0.42/minute from a mobile phone.

English
5
Notices
Federal Communications Commission Statement
This device complies with Part 15 of the FCC Rules.Operation is subject to the following two
conditions:
• This device may not cause harmful interference, and
• This device must accept any interference received including interference that may cause
undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules.These limits are designed to provide reasonable protection
against harmful interference in a residential installation.This equipment generates,uses and can
radiate radio frequency energy and, if not installed and used in accordance with manufacturer’s
instructions, may cause harmful interference to radio communications.However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception,which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
CAUTION:Any changes or modifications not expressly approved by the grantee of this device could
void the user’s authority to operate the equipment.
FCC Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment.This equipment should be installed and operated with minimum distance 20cm
between the radiator & your body.
This transmitter must not be co-located or operating in conjunction with any other antenna or
transmitter. If the device is going to be operated in 5.15 ~ 5.25GHz frequency range,then it is
restricted to an indoor environment only.
RF Exposure warning
• The equipment complies with FCC RF exposure limits set forth for an uncontrolled
environment.
• The equipment must be co-located or operated in conjunction with any other antenna or
transmitter.

6
English
CE Mark Warning
This is a Class B product, in a domestic environment,this product may cause radio interference,in
which case the user may be required to take adequate measures.
Canadian Department of Communications Statement
This digital apparatus does not exceed the Class B limits for radio noise emissions from digital
apparatus set out in the Radio Interference Regulations of the Canadian Department of
Communications.
This class B digital apparatus complies with Canadian ICES-003.
NO DISASSEMBLY
The warranty does not apply to the products that
have been disassembled by users.
IC Radiation Exposure Statement for Canada
This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment.
To maintain compliance with IC RF exposure compliance requirements,please avoid direct contact
to the transmitting antenna during transmitting. End users must follow the specific operating
instructions for satisfying RF exposure compliance.
Operation is subject to the following two conditions:
• This device may not cause interference.
• This device must accept any interference,including interference that may cause undesired
operation of the device.
Declaration of Conformity (R&TTE directive 1999/5/EC)
The following items were completed and are considered relevant and sufficient:
• Essential requirements as in [Article 3]
• Protection requirements for health and safety as in [Article 3.1a]
• Testing for electric safety according to [EN 60950]
• Protection requirements for electromagnetic compatibility in [Article 3.1b]
• Testing for electromagnetic compatibility in [EN 301 489-1] & [EN 301]
• Testing according to [489-3]
• Effective use of the radio spectrum as in [Article 3.2]
• Radio test suites according to [EN 300 440]

English
7
󰗧󰁈
󰌈󰉻󰌍󰁊󰕨󰌷
󰉻󰉙󰚫󰌷󰚫
󰌷󰉻󰃣󰙅
󰑵󰍱󰑵󰗒󰘤
󰅿󰌷󰉻󰂋
󰉋󰓝󰎶󰌈󰉻󰑵
DO NOT throw this product in municipal waste.This product has been designed to
enable proper reuse of parts and recycling.This symbol of the crossed out wheeled bin
indicates that the product (electrical and electronic equipment) should not be placed in
municipal waste.Check local regulations for disposal of electronic products.
DO NOT throw the battery in municipal waste.This symbol of the crossed out wheeled
bin indicates that the battery should not be placed in municipal waste.
REACH
Complying with the REACH (Registration,Evaluation, Authorisation,and Restriction of Chemicals)
regulatory framework, we published the chemical substances in our products at ASUS REACH
website at http://csr.asus.com/english/REACH.htm.
Class 1 Laser Product,Complies with FDA Radiation Performance
standards, 21 CFR, Subchapter J.

8
English
Complies with 21 CFR 1040.10 and 1040.11 except for deviations pursuant to Laser
Notice No.50,dated June 24, 2007.
󰄛󰄑󰎲
󰇐
󰚫󰎲󰖭

󰇐󰁎󰄛

󰇐
 

󰓨

󰂧󰁺

󰏭

󱸡


      
󰌹
󰅿      
 󰇐󰇐
󰄛
 󰇐󰇐
󰄛󰄥

󰄛󰎲
Safety Certifications
• C-Tick Mark
• BSMI Certification

English
9
Check your ASUS GX810 ROG Gaming Mouse package for the following items:
• ASUS GX810 ROG Gaming Mouse
• Nano USB 2.4 GHz receiver
• 3 x AAA batteries
• Quick Start Guide
• Support CD
If any of the above items is damaged or missing, contact your retailer immediately.
Package Contents
Specifications Summary
Product Name
GX810
Color
Black
Wireless Technology
RF 2.4GHz
OS Support
Windows® XP / Windows® Vista / Windows® 7
Dimensions (mm)
Mouse: 105(L) x 66(W) x 37(H)
Weight
Mouse: 82g (without battery)
Buttons / Switches
1 x Left button / Right button / Scroll wheel
1 x Left/Right tilt wheel
2 x Side buttons
1 x DPI switch (Gaming Mode only) / Application switch
(Standard Mode only)
1 x Dual Mode switch
Resolution
800 / 1600 / 2000 / 3200 dpi (adjustable in Gaming Mode only)*
* The resolution is fixed at 1200dpi in Standard Mode.The
default resolution for Gaming Mode is 3200dpi.
Input Voltage
1.5V
Battery Requirement
1 to 3 AAA batteries
Specifications are subject to change without prior notice.

10
English
Knowing your ASUS GX810 ROG Gaming Mouse
Your ASUS GX810 ROG Gaming Mouse comes with a left button, a right button, a scroll
wheel, two side buttons, a DPI switch, and a specially designed Dual Mode switch.
1
Left button
2
Right button
3
Scroll wheel / Tilt wheel / Resolution
indicator*
4
• DPI switch (Gaming Mode only)
• Application switch (Standard Mode
only)
5
Mouse cover
6
ROG logo
7Side buttons
8Slip-resistant rubber design
9Mouse feet
10 Laser sensor
11 Dual Mode switch**
12 USB dongle compartment
13 Nano USB 2.4 GHz receiver
Status Indications
Flash once 800 dpi
Flash twice 1600 dpi
Flash thrice 2000 dpi
Flash four times 3200 dpi
*Resolution indicator
Icons Indications
Powered off
Standard Mode
Gaming Mode
** Dual Mode switch
2
3
4
5
6
7
8
7
1
9
12
9
11 9
13
10

English
11
Installing the battery
• The bundled batteries are not chargeable.
• If you do not use the mouse for a long time,remove the batteries.
• Use new or similar-type batteries.
• Since your GX810 mouse can work with only one battery,you can adjust your
mouse weight through adding or removing one or two batteries.
• When the mouse power is turned on with low batteries, the orange LED (scroll
wheel) will flash for one minute and turn off immediately when you move your
mouse or click a button.
123
1. Locate the notch near the top end of the cover. Place your thumb over the notch,
and then lift the cover upward to remove it.
2. Insert up to three batteries into the slots,taking note of the correct polarity.
3. Press the cover in the direction of the arrows to replace it.

12
English
Customizing your ASUS GX810 ROG Gaming Mouse
The bundled support CD includes a specially designed program which allows you to
customize your GX810 to avail all its features.Place the support CD into the optical
drive and follow the onscreen instructions to install the program.
• If Autorun is NOT enabled in your computer, browse the contents of the support
CD to locate the setup.exe file. Double-click it to install the program.
• Refer to the user manual in the support CD for detailed instructions on how to
customize your mouse.
Connecting to PC
2
• You can store the USB receiver inside the mouse.
• To save power,turn off the power when you are not using the mouse.
1. Take out the USB receiver from the USB
compartment and then turn the power
switch to Standard Mode for normal use
or to Gaming Mode for better gaming
performance.
2. Insert the USB receiver into an
available USB port.
1
USB dongle compartment
Off
Standard
Mode
Gaming Mode

English
13
Click Start >All Programs >ASUS Gaming Mouse GX810 >ASUS ROG Gaming
Mouse GX810 to launch the program.
If the screen below appears,plug your ASUS GX810 Gaming Mouse into your
computer’s USB port and then click OK to relaunch the program.
Launching the program
Main menu
3
6
7
8
11
17
18
4
5
10 9
12
1516 14 1213
19
23
24
22
21
20

14
English
Items Descriptions
1. Displays the current mouse mode you are using.
2. Displays the current battery level.
3. Select a function for each button / action from the dropdown list.
* Refer to the table on the next page for more details.
4. Select a resolution from the dropdown list.
* This item becomes configurable in Gaming Mode only.
5. Drag the slider to adjust the scroll speed.
6. Drag the slider to adjust the double-click speed.
7. Double-click this icon to test the current double-click speed.
8. Click to save the changes you have made to the selected profile.
9. Click to apply the selected profile.
10. Click to discard the changes you have made and close the screen.
11. Click to save the changes you have made and close the screen.
12. Click to restore the last settings you have made.
13. Click to adjust the mouse sensitivity.
14. Tick to enable or disable changing the mouse sensitivity through adjusting the X-axis
and/or Y-axis values.
15. Click to bring up the Macro Settings window. See page 16 for details.
16. Click to bring up the Preferences window.See page 17 for details.
17. Click to create a new profile.
18. Click to import a profile from your computer.
19. Click to export a profile to your computer.
20. Displays the polling rate.
21. Double-click on the profile name to change it.
22. The blue dot next to the item indicates the active profile.
23. Click to duplicate the selected profile.
24. Click to delete the selected profile.
* The active profile cannot be deleted.

English
15
Items Descriptions
Left Button Mimics the behavior of the standard left mouse button.
Right Button Mimics the behavior of the standard right mouse button.
Scroll Button When selected, press the button to perform the standard scrolling
function.
DPI Switch When selected,press the button to select a mouse resolution.
* This option only appears in Gaming Mode.
Burst Fire When selected,press the button to do a burst fire in a click-to-attack
game,which is the same as triple-clicking the left mouse button. See page
18 for details.
Page Forward When selected,press the button to go to the next page you viewed,which
is the same as pressing <Alt + Right>.
Page Backward When selected,press the button to go to the previous page you viewed,
which is the same as pressing <Alt + Left>.
Macro When selected,press the button to run a command or a series of
commands which you can edit though the Macro Profile Management
menu.See page 19 for more details.
Launch Program When selected,press the button to launch the program that you specified.
See page 20 for details.
One Touch Setting When selected,press the button to launch this program.
My Computer When selected,press the button to open My Computer window.
Web Browser When selected,press the button to launch your default web browser.
E-mail Client When selected,press the button to launch your default email application.
Scroll Left / Right When selected,press the button to scroll leftward / rightward as a tilt
wheel does.
* This function only works in the Microsoft® Office applications under
Windows® 7 / Vista.
Mute When selected,press the button to turn the volume’s mute mode on/off.
Media Player/
PlayPause
When selected,press the button to launch your default media player or
play / pause the playback in an active media player.
Application Switch When selected,press the button to switch among the running
applications,which is the same as you press <Alt + Tab>.
Flip-3D When selected,press the button to switch windows using Flip 3D.
* This function only works under Windows® 7.

16
English
Macro Settings menu
Items Descriptions
1. Click to start recording the keystrokes and click again to stop.
* You can record maximum 40 keystrokes for each profile.
2. Tick to ignore all time delays between keystrokes.
3. Displays the recorded keystrokes and the time delays during recording.
4. Click to move up/down the selected keystrokes or time delays.
5. Click to insert the time delay.
6. Click to select the delay time you want to insert.
7. Click to select the repeat mode.
• Once per click: Select to perform the macro profile once when clicking the mouse
button.
• Click to repeat,next click to stop:Select to repeat performing the macro profile
when clicking the mouse button and clicking the button again to stop.
• Click to repeat:Select how many times you want to repeat performing the macro
profile when clicking the mouse button. Select the repeated times from the dropdown
list.
• Pressed to repeat:Select to repeat performing the macro profile when holding down
your mouse button and release the button to stop.
8. Click to save the changes you have made to the selected profile.
5
7
8
11 10 9
12
12
13
14
3
4
6
continued on the next page
15

English
17
Items Descriptions
1. Tick to show the ROG icon in Windows Notification Area.
2. Tick to enable the onscreen display function.
3. Click to save the changes you have made and close the screen.
4. Click to disregard the changes you have made and close the screen.
Preferences menu
34
2
1
Items Descriptions
9. Click to disregard the changes you have made and close the screen.
10. Click to save the changes you have made and close the screen.
11. Click to assign the selected profile to a mouse button.
12. Click to create a new macro profile.
13. Click to deleted the selected macro profile.
14. Click to duplicate the selected macro profile.
15. Double-click on the profile name to change it.

18
English
Burst Fire menu
2
4
3
1
Items Descriptions
1. Click to launch the Burst Fire menu.
2. Click to select the burst fire mode.
• 3 Rounds Mode: Select to fire three rounds when click the mouse button.
• 5 Rounds Mode: Select to fire five rounds when click the mouse button.
• Full Automatic Mode: Select to fully fire automatically when clicking the mouse button
and clicking again to stop.
3. Click to save the changes you have made and close the screen.
4. Click to discard the changes you have made and close the screen.

English
19
Macro Settings menu
3
2
1
Items Descriptions
1. Click to launch the Macro Settings menu.
2. Click to assign the selected profile to a mouse button.
3. The blue dot next to the item indicates the active macro profile.

20
English
Program Selection menu
Items Descriptions
1. Click to launch the Program Selection menu.
2. Key in the shortcut name of the program you want to run when clicking the mouse
button.
3. Select a program you want to run when clicking the mouse button.
4. Click to disregard the changes you have made and close the screen.
5. Click to save the changes you have made and close the screen.
2
3
1
54
