Asus NX1001 User manual

Quick Installation Guide
Copyright © 2006 ASUSTeK COMPUTER INC.
All Rights Reserved.
NX1001
PCI Fast Ethernet Adapter
E2573
English

2
English
Introduction
Thank you for purchasing ASUS NX1001 PCI Fast Ethernet
Adapter! It is a 10/100Mbps 32bit PCI adapter which boasts
high performance and low processor utilization.
Features
• Supports 32-bit PCI Bus Master
• Complies to PCI 2.1 and PCI 2.2 specification
• Standard: IEEE 802.3 10BaseT IEEE 802.3u 100BaseTX
• Transmission Rate: 10Mbps or 100Mbps
• Supports Half/Full duplex capability
• Supports Auto-negotiation function
• Built-in FIFO buffers
• Provides diagnostic software
Supported OS
Windows 98/SE, ME, 2000, XP, NT4.0, Linux, Mac 10.X,
Novell, SCO 5, Solaris 8, and Unixware 7.
Package Contents
1. ASUS NX1001 PCI Fast Ethernet Adapter
2. Support CD
3. Quick Installation Guide

3
English
Hardware Installation:
1. Shut down the computer, cut off the power source, then
open the chassis.
2. Remove a PCI shield and insert the network card into the
PCI slot. Secure the card to the chassis. Close the chassis.
3. Connect the Ethernet cable to the RJ-45 port of the card.
Install ASUS NX1001 Driver
Windows 98 SE, ME, 2000, and XP
After the installation is complete, restart your system.
Window automatically detects the new hardware. Insert
the support CD into your optical drive to autorun the driver
installation program.
Windows 98, NT4.0, Linux, Mac10.X, Novel, SCO5,
Solaris 8, Unixware 7
After installing the network adapter, insert the support CD
into your optical drive and follow the instructions in the
“Readme.txt” to install the driver.
Status Indicator and Port
LED Indicator:
ON: Link established
Blinking: Link established. Transmitting data.
OFF: No link established.
Port:
RJ-45: For connecting the Ethernet cable.

4
English
Technical Specification
Communication Standards
IEEE 802.3 10Base-T
IEEE 802.3u 100Base-TX
IEEE 802.3x Full Control
Data Transfer Rate
10Mbps and 100Mbps
Connector
RJ-45 Ethernet cable
System interface
PCI specification 2.2 compliant
Power Consumption
1.5W
Environmental:
Operating Temperature: 0°C~55°C
Humidity: 5%~95% (non-condensing)
Storage temperature: -20°C~80°C
