Asus ESC500 User manual

ESC500
Conguration Guide
CompactFlashI/II/MD
Smart Card
MS/MSPRO/SD/MMC

II
Copyright © 2011 ASUSTeK COMPUTER INC. All Rights Reserved.
No part of this manual, including the products and software described in it, may be reproduced, transmitted,
transcribed, stored in a retrieval system, or translated into any language in any form or by any means,
except documentation kept by the purchaser for backup purposes, without the express written permission
of ASUSTeK COMPUTER INC. (“ASUS”).
ASUS provides this manual “as is” without warranty of any kind, either express or implied, including but not
limited to the implied warranties or conditions of merchantability or tness for a particular purpose. In no
event shall ASUS, its directors, ofcers, employees, or agents be liable for any indirect, special, incidental,
or consequential damages (including damages for loss of prots, loss of business, loss of use or data,
interruption of business and the like), even if ASUS has been advised of the possibility of such damages
arising from any defect or error in this manual or product.
Specications and information contained in this manual ae furnished for informational use only, and are
subject to change at any time without notice, and should not be construed as a commitment by ASUS.
ASUS assumes no responsibility or liability for any errors or inaccuracies that may appear in this manual,
including the products and software described in it.
Product warranty or service will not be extended if: (1) the product is repaired, modied or altered, unless
such repair, modication of alteration is authorized in writing by ASUS; or (2) the serial number of the
product is defaced or missing.
Products and corporate names appearing in this manual may or may not be registered trademarks or
copyrights of their respective companies, and are used only for identication or explanation and to the
owners’ benet, without intent to infringe.
E6546
First Edition
June 2011

III
Contents
Revision history
Revision Revision history Date
V1 First release of ESC500 conguration guide June 2011
Revision history.......................................................................................... III
Safety information ...................................................................................... IV
Chapter 1: Product introduction
1.1 Key features.................................................................................. 1-2
1.2 System overview.......................................................................... 1-4
1.3 Front panel features..................................................................... 1-5
1.4 Rear panel features...................................................................... 1-6
1.5 Systemspecications ................................................................. 1-7
Chapter 2: Components
2.1 Upgrading CPU and CPU heatsink............................................. 2-2
2.2 Upgrading system memory......................................................... 2-3
2.3 Upgrading hard disk drives......................................................... 2-4
2.4 Upgrading 5.25-in drives ............................................................. 2-5
2.5 Upgrading the smart card reader ............................................... 2-5
2.6 Upgrading expansion card.......................................................... 2-6
2.7 OS support list ............................................................................. 2-6

IV
Safety information
Electrical Safety
• Before installing or removing signal cables, ensure that the power cables for
the system unit and all attached devices are unplugged.
• To prevent electrical shock hazard, disconnect the power cable from the
electrical outlet before relocating the system.
• When adding or removing any additional devices to or from the system, contact
a qualied service technician or your dealer. Ensure that the power cables for
the devices are unplugged before the signal cables are connected. If possible,
disconnect all power cables from the existing system before you service.
• If the power supply is broken, do not try to x it by yourself. Contact a qualied
service technician or your dealer.
Operation Safety
• Servicing of this product or units is to be performed by trained service
personnel only.
• Before operating the server, carefully read all the manuals included with the
server package.
• Before using the server, make sure all cables are correctly connected and the
power cables are not damaged. If any damage is detected, contact your dealer
as soon as possible.
• To avoid short circuits, keep paper clips, screws, and staples away from
connectors, slots, sockets and circuitry.
• Avoid dust, humidity, and temperature extremes. Place the server on a stable
surface.
Lithium-Ion Battery Warning
CAUTION! Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type recommended by the
manufacturer. Dispose of used batteries according to the manufacturer’s
instructions.
CD-ROM Drive Safety Warning
CLASS 1 LASER PRODUCT
Heavy System
CAUTION! This server system is heavy. Ask for assistance when moving or
carrying the system.
This product is equipped with a three-wire power cable and plug for the user’s
safety. Use the power cable with a properly grounded electrical outlet to avoid
electrical shock.

1-
This chapter describes the key features
of ESC500. It includes the product
overview and general specications.
Chapter 1
Product introduction

Chapter 1: Product introduction1-2
1.1 Key features
The ESC500 supports up-to-date Intel®Xeon® E3-1200 and Core™ i3-2100 series
processors, Genuine Windows® 7 Professional, up to 32GB DDR3 ECC/non-ECC
memory and state-of-the-art I/O solutions. It is the best choice for a new generation
workstation system that performs unprecedented I/O throughput, high reliability
and super quietness working level for SOHO & SMB users.
Designed with Optimized Workstation Architecture
The ESC500 features Intel®Xeon® E3-1200 workstation processors and the
workstation-specic Intel® C206 chipset to boost extreme-output HD3000 integrated
graphics. It provides ultimate visualization and 3D modeling capabilities, with
dedicated support for professional applications like Adobe®Photoshop®, Autodesk
®AutoCAD®, Autodesk®Inventor®, UGS®Solid Edge®and more to experience
extreme graphics performance.
Ultimate Graphics Performance with NVIDIA®Quadro®GPUs
The ESC500 is specially designed to accommodate optimized professional
OpenGL performance. Benchmarking in SPECviewperf® 11 indicates the ESC500
design results in outstanding performance, so users in computer-aided design
(CAD), computer-aided engineering (CAE), digital content creation (DCC) and
geographic information systems (GIS) can make good use of the ample graphics
power the ESC500 supports.
Diverse CPU and Memory Types
The ESC500 supports 2nd generation Intel® Core™ i3 series desktop processors
and Intel®Xeon® E3-1200 series server/workstation CPUs. System builders can
also choose between robust server-grade DDR3 ECC unbuffered memory modules
and more mainstream and readily available DDR3 non-ECC unbuffered memory.
By supporting different processors and memory types, the ESC500 allows for a
wide range of workstation builds for every budget and need.
Built in Dual Intel®Server-class Gigabit LAN
For more reliable networking, the ESC500 features built-in dual Intel®server-class
Gigabit LAN connections. It uses lower CPU utilization, increasing throughput to
achieve outstanding performance as well as better support for diverse operating
systems. It also features teaming and fault tolerance functions provide doubled
bandwidth/network redundancy compared to standard Gigabit LANs. Intel® 82574L
chipsets are certied by VMware for native virtualization support. IPv6 readiness
resolves upcoming IPv4 address shortages even before they occur, hassle-free.
True USB 3.0 Support
Experience ultra-fast data transfers up to 4.8Gbps with USB 3.0—the latest
connectivity standard. Built to connect easily with next generation components
and peripherals, USB 3.0 transfers data up to 10X faster and is also backward
compatible with USB 2.0 components.

ASUS ESC500 1-3
True SATA 6Gb/s Support
Supporting next-generation Serial ATA (SATA) storage interface, this motherboard
delivers up to 6.0Gb/s data transfer rates. Additionally, get enhanced scalability
and faster data retrieval, double the bandwidth of current bus systems.
SAS Upgrade Kit for Multiple Storage Solution
The ESC500 supports four SATA3G and two native SATA6G HDDs to meet the
data storage demands of professionals. In addition, to make hardware upgrades
simpler and more convenient, the optional ASUS upgrade kits SASsaby 1064E
(supports LSI® Integrated RAID 0, 1, 1E) and SASsaby M (supports H/W RAID 0, 1,
10, 5) provide direct support for SAS storage and ensure reliable data protection.
Ultra-Quiet Working Environment
With ASUS unique fan control technology, the ESC500 is able to adjust fan speeds
intelligently and run Quad-core CPU systems at a very low acoustic level (24.5dBA
at idle mode), providing a super quiet working environment for customers, which
will facilitate SOHO & SMB users.
ExtremeSystemEnergyEfciency
Tap into the EPU, the world’s rst real-time PC power saving chip through a simple
onboard switch or the AI Suite II utility. Get total system-wide energy optimization
by automatically detecting current PC loadings and intelligently moderating power
consumption. This also reduces fan noise and extends component longevity!
High Quality Components for Great System Reliability
The ASUS 8-Phase CPU power and 2-Phase memory power design provides
support to 95W CPUs, reduces input ripple current and output ripple voltage, which
keeps CPUs and power modules from suffering the risk of high power stress.
Furthermore, high quality power components effectively lower system temperatures
to ensure longer component lifespan. The ESC500 utilizes all Japan-made 5000hr
ultra long life conductive polymer capacitors, which is sustainable up to 57 years.
80+ Bronze PSU for Energy Saving
With current trends leaning towards power efciency, the ESC500 is equipped
with 80+ Bronze PSU to reduce the power loss and power consumption, and save
power bills for users.
• All specications are subject to change without notice. Please check with
your supplier for exact offers. Products may not be available in all markets.
• PCB color and bundled software versions are subject to change without
notice.
• Brand and product names mentioned are trademarks of their respective
companies.

Chapter 1: Product introduction1-4
1.2 System overview
3
4
5
6
7
8
9
1
2
Items
1. Central processing unit (CPU)
2. CPU heatsink and fan
3. System memory
4. Hard disk drives
5. Graphics card
6. Single power supply
7. System fan
8. Optical drive (optional)
9. Smart card reader

ASUS ESC500 1-5
1.3 Front panel features
CompactFlash I/II/MD
Smart Card
MS/MS PRO/SD/MMC
1394
1394b 1394b
USB
CTR
BASS
LINE
KY
MIC IN
IN
REAR
FRONT
SPK
SIDE
SPK
SPDIF OUT
DVI
3.0
Optical Drive
Empty 5.25-inch bay
Smart Card Reader
Power LED (blue)
HDD access LED (orange)
Reset button
USB 2.0 / Microphone /
Headphone ports
Power button

Chapter 1: Product introduction1-6
1.4 Rear panel features
The PS/2 keyboard / mouse combo port, USB ports, DVI-I ports, Audio ports,
S/PDIF Out ports, and Gigabit LAN ports do not appear on the rear panel if
motherboard is not present.
1394
USB
CTR
BASS
LINE
K
MIC IN
IN
REAR
FRONT
SPK
SIDE
SPK
SPDIF OUT
DVI
3.0
Power supply module
Expansion slots
Power supply switch
Power cord connector
PS/2 keyboard / mouse
combo port
USB 2.0 ports
8-channel audio ports
USB 3.0 ports
LAN (RJ-45) port 2
DVI port
Coaxial SPDIF Out port
Optical SPDIF Out port
IEEE 1394a port
System fan
LAN (RJ-45) port 1

ASUS ESC500 1-7
1.5 Systemspecications
(continued on the next page)
Model Name ESC500
Operating System Genuine Windows®7 Professional
Processor / System Bus
supported
1 x Socket LGA1155
Intel®Xeon® E3-1200 Processor Family
Intel® Core™ i3-2100 Processor Family
Intel® Core™ G8X0 Processor Family
Intel® Core™ G6X0 Processor Family
Core Logic Intel® C206 Chipset
Memory
Total Slots 4 (Dual-Channel)
Capacity Maximum up to 32GB (UDIMM)
Memory Type
DDR3 1333 / 1066 MHz, non-ECC/ECC UDIMM
* Refer to www.asus.com for detail memory AVL &
non-ECC UDIMM vs CPU support list
Memory Size 1GB, 2GB, 4GB, 8GB (UDIMM)
Expansion Slots
Total PCI/PCI-
X/PCI-E Slots 6
Slot Type
1 x PCIe 2.0 x16 (at x16 or x8 mode)
1 x PCIe 2.0 x16 (at x8 mode)
2 x PCIe 2.0 x16 (at x4 mode)
1 x PCIe x1 (at x1 mode)
1 x PCI
Storage SATA Controller
Intel® C206 Chipset
- 2 x SATA 6.0Gb/s ports (gray)2 x SATA 6.0Gb/s ports (gray)
- 4 x SATA 3.0Gb/s ports (blue)4 x SATA 3.0Gb/s ports (blue)
- IntelIntel®Rapid Storage Technology supporting
RAID 0, 1, 10, and 5 (for Windows®only)
HDD Bays
I = internal
A or S will be
hot-swappable
3 x Internal 3.5” SATA HDD Cages
Networking LAN 2 x Intel® 82574L Dual GbE LAN
Graphic VGA
DVI-I s/ RGB ports (only enabled with Intel®
Core™ i3 / Xeon E3-12x5, E3-1260L
Processors)
Supports DVI with max. resolution 1920 x 1200
at 60Hz
Supports RGB with max. resolution 2048 x 1536
at 75 Hz
Maximum shared memory of 1748 MB

Chapter 1: Product introduction1-8
*Specicationsaresubjecttochangewithoutnotice.
Auxiliary Storage FDD / CD /
DVD
3 x 5.25” media bays
(Options: No ODD / DVD-RW)
Back Panel I/O
1 x PS/2 KB/MS port
1 x S/PDIF Out (Optical & Coaxial)
6 x USB 2.0/1.1 ports
2 x USB 3.0/2.0 ports
1 x IEEE1394a
2 x LAN ports
1 x DVI-I port
1 x 8-channel Audio I/O
Front Panel I/O
2 x USB 2.0 ports
1 x Line In
1 x Line Out
Anti-virus Software Optional Anti-Virus CD Pack
Dimension (HH x WW x DD) 190mm x 423mm x 435mm (W x H x D)
Net Weight Kg (CPU, DRAM &
HDD excluded) 10.8 Kg
Power Supply 500W 80Plus Single Power Supply, Bronze
700W 80Plus Single Power Supply, Silver
Power Rating Input: 100–240Vac, 10–5A, 50/60Hz Class 1
Environment
Operation temperature: 10°C–35°C
Non operation temperature: -40°C–70°C
Non operation humidity: 20%–90% (Non-
condensing)

1-
This chapter lists the key components
and optional accessories for the server
system.
Chapter 2
Components

Chapter 2: Components2-2
2.1 Upgrading CPU and CPU heatsink
ESC500 supports Intel®LGA1155 Xeon® E3-1200 / Core™i3-2100 series
processors.
1
4
5
2
3
Order P/N Description
90-S000U09Y1T Quad Core Intel Xeon E3-1220, 3.10GHz, 8MB L2
(Single pack, w/o cooler)
90-S000U09Z1T Dual Core Intel Xeon E3-1220L, 2.20GHz, 3MB L2
(Single pack, w/o cooler)
90-S000U0A11T Quad Core Intel Xeon E3-1225, 3.10GHz, 6MB L2
(Single pack, w/o cooler)
90-S000U0A21T Quad Core Intel Xeon E3-1230, 3.20GHz, 8MB L2
(Single pack, w/o cooler)
90-S000U0A31T Quad Core Intel Xeon E3-1235, 3.20GHz, 8MB L2
(Single pack, w/o cooler)
90-S000U0A41T Quad Core Intel Xeon E3-1240, 3.30GHz, 8MB L2
(Single pack, w/o cooler)
90-S000U0A51T Quad Core Intel Xeon E3-1245, 3.30GHz, 8MB L2
(Single pack, w/o cooler)
90-S000U0A61T Quad Core Intel Xeon E3-1260L, 2.40GHz, 8MB L2
(Single pack, w/o cooler)
90-S000U0A71T Quad Core Intel Xeon E3-1270, 3.40GHz, 8MB L2
(Single pack, w/o cooler)
90-S000U0A81T Quad Core Intel Xeon E3-1275, 3.40GHz, 8MB L2
(Single pack, w/o cooler)
90-S000U0A91T Quad Core Intel Xeon E3-1280, 3.10GHz, 12MB L2
(Single pack, w/o cooler)
90-S000U0BR0T Quad Core Intel Xeon E3-1290, 3.10GHz, 12MB L2
(Single pack, w/o cooler)

ASUS ESC500 2-3
2.2 Upgrading system memory
The motherboard comes with four Double Data Rate 3 (DDR3) Dual Inline Memory
Modules (DIMM) sockets.
Memorypopulationconguration
Order P/N Description
90-S000I05M0T DDR3 1333 ECC UNB 2G 240P SINGLE PACK
90-S000I0570T DDR3 1333 ECC UNB 4G 240P SINGLE PACK

Chapter 2: Components2-4
2.3 Upgrading hard disk drives
The system supports three SATAII hard disk drives.
We recommend that you install identical drives of the same model and capacity
for RAID conguration.
Order P/N Description
90-S000H65B0T 3.5” SATA3 Pharaoh 1T 7200rpm / 6Gb single pack
90-S000H65C0T 3.5” SATA3 Pharaoh 750G 7200rpm / 6Gb single pack
90-S000H65D0T 3.5” SATA3 Pharaoh 500G 7200rpm / 6Gb single pack

ASUS ESC500 2-5
2.4 Upgrading 5.25-in drives
1
22
2.5 Upgrading the smart card reader

Chapter 2: Components2-6
2.6 Upgrading expansion card
1
2
3
4
2.7 OS support list
OS support list
Windows®7 Professional x86
Windows®7 Professional x64
