Asus AP1710-I5 User manual

Intel®Xeon Tower/5U Rackmount Server
®
AP1710-I5
User’s Manual
with 533MHz FSB support

ii ASUS AP1710-I5
Disclaimer/Copyrights
No part of this manual, including the products and software described in it, may be
reproduced, transmitted, transcribed, stored in a retrieval system, or translated into
anylanguageinanyformorbyanymeans,exceptdocumentationkeptbythepurchaser
forbackuppurposes, without theexpresswritten permission ofASUSTeK COMPUTER
INC. (“ASUS”).
ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND,
EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOTLIMITEDTO THE IMPLIED
WARRANTIES OR CONDITIONS OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS DIRECTORS,
OFFICERS, EMPLOYEES ORAGENTS BE LIABLE FORANY INDIRECT, SPECIAL,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR
LOSS OF PROFITS, LOSS OF BUSINESS, LOSS OF USE OR DATA,
INTERRUPTION OF BUSINESS AND THE LIKE), EVEN IF ASUS HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY
DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.
Productwarranty or servicewill not be extended if:(1) the product is repaired,modified
or altered, unless such repair, modification of alteration is authorized in writing by
ASUS; or (2) the serial number of the product is defaced or missing.
Productsand corporatenames appearing in this manual may or may not be registered
trademarks or copyrights of their respective companies, and are used only for
identification or explanation and to the owners’ benefit, without intent to infringe.
The product name and revision number are both printed on the product itself. Manual
revisions are released for each product design represented by the digit before and
after the period of the manual revision number. Manual updates are represented by
the third digit in the manual revision number.
Forpreviousorupdatedmanuals,BIOS,drivers,or product release information, contact
ASUSathttp://www.asus.com.tw or through anyofthemeansindicatedonthefollowing
page.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE
FURNISHED FOR INFORMATIONALUSE ONLY,ANDARE SUBJECTTO CHANGE
AT ANY TIME WITHOUT NOTICE, AND SHOULD NOT BE CONSTRUED AS A
COMMITMENT BY ASUS. ASUS ASSUMES NO RESPONSIBILITY OR LIABILITY
FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS MANUAL,
INCLUDING THE PRODUCTSAND SOFTWARE DESCRIBED IN IT.
Copyright © 2003 ASUSTeK COMPUTER INC. All Rights Reserved.
Product Name: AP1710-I5
Manual Revision: First Edition E1304
Release Date: June 2003

User’s Manual iii
ASUS Contact Information
ASUSTeK COMPUTER INC. (Asia-Pacific)
Address: 150 Li-Te Road, Peitou, Taipei, Taiwan 112
General Tel: [phone]
General Fax: [phone]
General Email: [email protected]
Technical Support
MB/Others (Tel): [phone] (English)
Notebook (Tel): [phone] (English)
Desktop/Server (Tel): [phone] (English)
Support Fax: [phone]
Web Site: www.asus.com.tw
ASUS COMPUTER INTERNATIONAL (America)
Address: 44370 Nobel Drive, Fremont, CA 94538, USA
General Fax: [phone]
General Email: [email protected]
Technical Support
Support Fax: [phone]
General Support: [phone]
Web Site: www.asus.com
Support Email: [email protected]
ASUS COMPUTER GmbH (Germany & Austria)
Address: Harkortstr. 25, 40880 Ratingen, BRD, Germany
General Fax: [phone]
General Email: [email protected] (for marketing requests only)
Technical Support
Support Hotline: MB/Others: [phone]
Support Fax: [phone]
Support (Email): www.asuscom.de/kontakt (for online support)
Web Site: www.asuscom.de

iv ASUS AP1710-I5
FCC/CDC Statements
Federal Communications Commission
This device complies with FCC Rules Part 15. Operation is subject to the
following two conditions:
• This device may not cause harmful interference, and
• This device must accept any interference received including
interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with
manufacturer’s instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
WARNING! The use of shielded cables for connection of the monitor
to the graphics card is required to assure compliance with FCC
regulations. Changes or modifications to this unit not expressly
approvedbythepartyresponsible for compliancecould void theuser’s
authority to operate this equipment.
Canadian Department of Communications
This digital apparatus does not exceed the Class B limits for radio noise
emissionsfromdigitalapparatus set outin theRadio InterferenceRegulations
of the Canadian Department of Communications.
This class B digital apparatus complies with Canadian ICES-003.

User’s Manual v
Contents
Disclaimer/Copyrights ....................................................................... ii
ASUS Contact Information ............................................................... iii
FCC/CDC Statements........................................................................ iv
Safety Precautions........................................................................... vii
Electrical Safety ............................................................................... vii
Operation Safety .............................................................................. vii
Introduction
About this guide............................................................ I-1
Audience ........................................................................................... I-2
Contents............................................................................................ I-2
Conventions ..................................................................................... I-3
References........................................................................................ I-3
System Package Contents .............................................................. I-4
Chapter 1: System Overview
System Overview ......................................................... 1-1
1.1 System Features.................................................................... 1-2
1.2 Front Panel Features............................................................. 1-3
1.3 Rear Panel Features .............................................................. 1-4
1.4 Internal Features.................................................................... 1-5
1.5 LED Table ............................................................................... 1-6
Chapter 2: Hardware Reference
Hardware Reference .................................................... 2-1
2.1 Removing and installing chassis cover .............................. 2-2
2.2 Motherboard installation....................................................... 2-4
2.3 Central Processing Unit........................................................ 2-5
2.4 System Memory ..................................................................... 2-9
2.5 Fixed Device Bays ............................................................... 2-12
2.6 Installing a Hard Disk Drive ................................................ 2-18

vi ASUS AP1710-I5
2.7 Screwless Expansion Card Slot......................................... 2-23
2.8 Long Card Support Guide................................................... 2-24
2.9 RAID Card............................................................................. 2-25
2.10 Hard Drive Blower ............................................................... 2-26
2.11 Chassis Fan ......................................................................... 2-27
2.12 Connecting Cables .............................................................. 2-28
2.13 SCSI Backplane ................................................................... 2-29
Appendix A: Optional chassis roller-wheel
Chassis Roller-wheel Installation ..................................................A-2
Appendix B: Power Modules
Redundant Power Modules ............................................................A-4
Appendix C: Troubleshooting
Troubleshooting ..............................................................................A-9

User’s Manual vii
Safety Precautions
Electrical Safety
Operation Safety
This product is equipped with a three-wire power cable and plug
forthe user’ssafety. Use thepower cablewith aproperly grounded
electrical outlet to avoid electrical shock.
CAUTION
• Any mechanical operation on this server must be conducted by
certified or experienced engineers.
• Before operating the server, carefully read all the manuals
included with the server package.
• Before using the server, make sure all cables are correctly
connected and the power cables are not damaged. If any damage
is detected, contact your dealer as soon as possible.
• To avoid short circuits, keep paper clips, screws, and staples
away from connectors, slots, sockets and circuitry.
• Avoid dust, humidity, and temperature extremes. Place the server
on a stable surface.
IMPORTANT
IMPORTANT
• Before installing or removing signal cables, ensure that the power
cables for the system unit and all attached devices are unplugged.
• To prevent electrical shock hazard, disconnect the power cable from
the electrical outlet before relocating the system.
• When adding or removing any additional devices to or from the
system, ensure that the power cables for the devices are unplugged
before the signal cables are connected. If possible, disconnect all
power cables from the existing system before you add a device.
• If the power supply is broken, do not try to fix it by yourself. Contact
an authorized dealer.

viii ASUS AP1710-I5
CAUTION:Dangerofexplosionifbatteryisincorrectlyreplaced.
Replacedonlywith the same orequivalenttyperecommended
by the manufacturer. Dispose of used batteries according to
the manufacturer’s instructions.
Lithium-Ion Battery Warning
CLASS 1 LASER PRODUCT
CD-ROM Drive Safety Warning
• Electrical hazard, do not remove
chassis cover.
• This equipment is to be serviced
by a trained personnel only.

User’s Manual I-1
Introduction
About this guide
“About This Guide” introduces the contents
of this document. This part includes the
target audience, chapter description, and
conventions used. It also lists other sources
of information that are not contained in this
manual.

I-2 ASUS AP1710-I5
Audience
Contents
This guide contains the following parts:
1. Introduction: About this guide
This part introduces the contents of this document. It includes the target
audience, chapter description, and conventions used. It also lists other
sources of information that are not contained in this manual.
2. Chapter 1: System overview
This chapter describes the general features of the AP1710-I5 system
server. It includes sections on front panel and rear panel specifications.
3. Chapter 2: Hardware setup
This chapter lists the hardware setup procedures that you have to
perform when installing system components.
4. Appendix A: Optional Chassis Roller-wheels
This appendix contains the installation procedure for the optional
chassis roller-wheel units for the AP1710-I5 server system.
5. Appendix B: Redundant Power Modules
This appendix contains detailed hardware operation and specifications
of the AP1710-I5 redundant power modules.
6. Appendix C: Troubleshooting
This appendix lists the common problems that you may encounter while
using the AP1710-I5 server. It lists the possible causes of the
problems and offers solutions. You may refer to this part and try to
solve simple problems before calling customer support.
This user guide is intended for system integrators, and experienced users
with at least basic knowledge of configuring an entry-level server.

User’s Manual I-3
Conventions
Symbols
To make sure that you perform certain tasks properly, take note of the
following symbols used throughout this manual.
WARNING: Information to prevent injury to yourself when
trying to complete a task.
CAUTION:Information to preventdamagetothecomponents
when trying to complete a task.
IMPORTANT: Information that you MUSTfollow to complete
a task.
NOTE: Tips and information to aid in completing a task.
References
Refer to the following sources for additional information and for product
and software updates.
1. ASUS PRL-DL Motherboard User’s Manual
This manual contains detailed information about the PRL-DL
motherboard.
2. ASUS Websites
The ASUS websites worldwide provide updated information on ASUS
hardware and softare products. The ASUS websites are listed in the
ASUS Contact Information on page v.
3. Optional Documentation
Your product package may include optional documentation such
as a CD-ROM manual, warranty flyers, and others that may have
beenadded by yourdealer.NOTE:These documentsarenot part
of the standard server package.

I-4 ASUS AP1710-I5
System Package Contents
The following checklist enumerates the components included in the
standard system package.
1) ASUS AS-35 Tower/5U Rackmount chassis
2) ASUS PRL-DL motherboard
3) 500W redundant power supply with single power module
4) Backplane board (BP6LS-AS35)
5) CD-ROM drive (1 piece)
6) floppy disk drive (1 piece)
7) special heatsink with fan assembly (2 sets)
8) hot swap IDE hard disk drive tray (6 units)
9) ASUS BBATA2U3, ATA133 IDE to Ultra160 SCSI HDD Bridge
board x 1
10) AC power cord
11) Support CD that includes drivers, utilities, ASUS System
Monitoring Agent (ASMA) with the ASUS Server Web-based
Management (ASWM)
12) Trend Micro ServerProtect Anti-virus software CD for enterprises
13) Motherboard user guide
14) System user guide
15) ASUS PCI-SCU3 Ultra160 Dual Channel SCSI Card in Standard
packing
16) ASMS (ASMA + ASWM) user guide
17) chassis roller wheels (4 sets)
18) Keys x 2
19) screws and labels
Optional:
1) ATA133 IDE to Ultra160 SCSI HDD bridge board (max. 6 pieces)
2) ASUS AS-35 5U rackmount rail kit
3) ASUS PXL-S30 U320 LSI 1030 SCSI Card
4) ASUS PXI-G45 Gb LAN Card
5) LSI MegaRAID 320-I single channel RAID card
If any of the above items is missing, contact your dealer.

User’s Manual 1-1
Chapter 1
System Overview
This chapter describes the general features of
the AP1710-I5 system server. It includes
sections on front panel, rear panel and internal
specifications.

1-2 ASUS AP1710-I5
1.1 System Features
The ASUS AP1710-I5 server is a stylish server system featuring the
ASUS PRL-DL motherboard. The server supports the Intel®Xeon™
processor in a 604-pin socket, and includes the latest I/O, LAN, and
video technologies through the chipsets embedded on the
motherboard.
The following are highlights of the server’s many features:
•Chassis: Pedestal or rackmount 5U with removable front door
bezel and chassis foot stand or roller-wheels.
•Motherboard: ASUS PRL-DL
•Chipset: RCC Grand Champion SL Server 3.1 (GCSL), RCC
Champion South Bridge 6.0 (CSB6)
•Memory: Supports four 184-pin DDR DIMM sockets, PC2100/
PC1600 registered ECC DDR DIMMs, 128MB to 4GB system
memory.
•Processor: Support for two Intel® XeonTM processor up to 3.06
GHz frequency with 35º ambient 85% CPU utilization.
•Network Controller: Intel® 82540 Gigabit Ethernet controller
•Drive Controller: LSI 53C1010R/32-bit/33MHz Dual Ultra-160
channels. Two UltraDMA100 IDE channels and oneATA66 IDE
channel.
•Graphics: ATI RAGE-XL PCI with 8MB PC-100 SDRAM video
memory
•Onboard IO: 1 X PS/2 mouse port, 1 X PS/2 keyboard slot, 1 X
serial ports, 1 X 15-pin VGA port, 1 X floppy drive slot, 3 X IDE
ports, 4 X USB ports, 1 X RJ-45 LAN port, 2 X 68-pin SCSI
connectors
•Special IO: IPMB connector, SM-Bus
•Expansion: 4 X 64-bit/33Mhz 3V PCI slots, 1 X 32-bit/33Mhz
5V PCI slot
•Device Bays: 6 X hot-swap trays for ATA 133 hard drives, 3 X
5.25 inch bay, 1 X floppy disk drive bay.
•Power Supply: 500Wredundantpowersupplywithsinglepower
module.
•Hardware Monitors: Voltage, temperature, Automatic System
Restart (ASR), fan speed.

User’s Manual 1-3
1.2 Front Panel Features
Thefrontpanelallowseasy access to the hard diskdrives.The power
and reset buttons, LED indicators, optical drive, floppy drive and two
USB connectors are also located on the front panel. For future
installation of 5.25 devices, there are two drive bays available. The
front panel of the server is protected by a door and lock for added
security.
6 ATA 133 Hard
Drive Swap Trays
CD-ROM Drive
Drive Activity LED
3.5” Floppy Drive
Reset Button
Power Button
2 USB PortsFront Door Lock
2 empty 5.25” bays
Power LED
HDD Access LED
Message LED
Status LED
For more detailed information of each LED display, refer to
“1.5 LED Table” on page 1-6.

1-4 ASUS AP1710-I5
1.3 Rear Panel Features
The server rear panel includes the connectors, the system devices,
a chassis lock and six full-length expansion cards slot. The following
shows the features on the rear side of the server.
AC Power IN Connector
AC Power Status LED
12 cm chassis fan
6 Full-Length PCI Slots
Chassis Lock
PS/2 mouse port
PS/2 keyboard port
2 x USB ports
Serial port
Parallel port
VGA port
Gigabit LAN
port
You may secure the chassis lock with an additional padlock
or other security device for added server system security.
Optional Gigabit
LAN card
Optional SCSI card

User’s Manual 1-5
1.4 Internal Features
Thestandardcomponentsinside the server include themotherboard,
power supply, floppy and CD-ROM drives, and cables. The picture
below shows the standard components of the server.
1. Redundant power
supply cage
2. 4 x DDR DIMM sockets
3. 2 x IDE cable
4. 51/4” CD-ROM drive
5. HDD hot swap modules
6. 4 x 64 bit 3V PCI slots
1 4
75
10
9
3
8
7. CPU sockets
8. Internal 68-pin SCSI cable
9. PCI Long Card support guide
10. 12 cm hot swap
module blower
11. PRL-DL motherboard
12. Chassis intrusion sensor
11
2
6
12

1-6 ASUS AP1710-I5
1.5 LED Table
ThefollowingtabledescribestheLEDdisplayfoundonthefrontpanel
and rear panel of the AP1710-I5 server system.
LED Display Description
Green
Bridgeboardconnectedto
SCSI backplane
Drive Status
LED Red
Bridge board failure
Blinking
HDD Read/Write data
Drive Activity
LED
ON System power ON
Power LED Blinking
Suspend Mode
OFF No activity
HDD Access
LED Blinking
Read/Write data in HDD
OFF Normal/Noincomingevent
Message
LED Blinking
ASMS indicate HW
monitor event
Icon
1
1
2
3
4
1
2
3
4

User’s Manual 2-1
Chapter 2
Hardware Setup
This chapter lists the hardware setup
procedures that you have to perform when
installing system components.

2-2 ASUS AP1710-I5
2.1 Removing and installing chassis cover
The chassis is designed for easy assembly and disassembly, making the
installation of internal components very convenient.
2.1.1 Removing the chassis cover
1. The side chassis cover is held by two large thumb screws. Loosen the
screws.
2. Slide the chassis cover for about half an inch.
3. Release the cover from the chassis.
