Asus Asus Nexus 7 User manual

Quick Start Guide
For online help and support, visit
support.google.com/nexus

Copyright
Copyright © 2012 ASUSTek COMPUTER INC.
All rights reserved.
No part of this guide, including the products and software
described in it, may be reproduced, transmitted, transcribed,
stored in a retrieval system, or translated into any language in
any form or by any means, except documentation kept by the
purchaser for backup purposes, without the express written
permission of ASUSTek COMPUTER INC. ("ASUS"). This clause
does not apply to such software which is licensed under the
General Public License ("GPL" ) or other Free Open Source
Licenses. Copies of the respective license terms, and where
required an offer to provide the respective source code, are
included in the product.
Google, Android, Gmail, Google Maps, Nexus 7, Google Play,
YouTube, Google+, and other trademarks are property of Google
Inc. ASUS and the ASUS logo are trademarks of ASUSTek
Computer Inc. All other marks and trademarks are properties of
their respective owners.
The content of this guide may differ in some details from the
product or its software. All information in this document is
subject to change without notice.

ASUS Pad ME370TG.
For online help and support, visit
support.google.com/nexus

Nexus 7 3
 
 
your point of purchase for assistance
 
country or region.
What’s in the box




Warranty

Nexus 7
4
Your Nexus 7
Touch screen
Front-facing
camera

3.5m headset jack
4-pin connector
Microphone
SIM card tray

Nexus 7 5
Microphone
Power/lock key
3.5mm headset jack
Volume key

Speaker
Microphone
Volume key
Power/lock key
NFC area
Microphone
4-pin connector
SIM card tray

Nexus 7
6
Charge the battery
a

unpack your Nexus 7. It’s a good idea to fully charge the
battery as soon as you get a chance.

charging unit, as shown in the illustration. Then connect
the charging unit to a power outlet.
DO NOT throw the battery in municipal waste.
The symbol of the crossed out wheeled bin
indicates that the battery should not be placed in
municipal waste.

Nexus 7 7
•The USB charging unit varies by country or
region.
•Use only the USB charging unit that comes with
your Nexus 7. Using a different charging unit
may damage your tablet.
•To avoid risk of injury or damaging your device,
unit and USB cable before charging the battery.
•The input voltage range between the wall outlet
and this charging unit is AC 100V–240V, and
the charging unit’s output voltage is DC 5V, 2A.
•Your Nexus 7 can be charged via the USB port
•The socket-outlet shall be installed near the
equipment(Pad) and shall be easily accessible.
on a computer only when Nexus 7 is in sleep
mode (screen off) or turned off. Charging
through the USB port will take longer than
charging with the USB charging unit.
DO NOT throw Nexus 7 in municipal waste. This
product has been designed to enable proper
reuse of parts and recycling. The symbol of
the crossed out wheeled bin indicates that the
product (electrical, electronic equipment and
mercury-containing button cell battery) should
not be placed in municipal waste. Check local
regulations for disposal of electronic products.

Nexus 7
8
Insert SIM card

insert a micro SIM card provided by your carrier. If no
card is installed, the message “No SIM card” appears
on the tablet’s lock screen.
When the tablet is face down, the SIM card tray is
located on the right side.The eject button is a small
round aperture on the left side of the tray door.

Nexus 7 9
To install a new SIM card:
1. Turn your tablet off and place it on a flat surface
with the screen facing down.
2. Locate the SIM card tray on the right side of your

tray door.
3. Insert the SIM ejection tool that comes with
the tablet (or a paperclip) into the eject button

pops out.
4. Remove the tray and place the micro SIM card
inside it, with the contacts facing up and the
angled corner to the left. There is only one

5. Carefully reposition the tray in the slot and push it
gently back into the tablet.
To activate a new SIM card, turn off Wi-Fi after setting


instructions. Once you’re done, you can turn Wi-Fi
back on.

Nexus 7
10
Turn on and off
To turn on your Nexus 7:
 
edge near the top for four seconds.
When Nexus 7 is on, press the Power button again to
put it into sleep mode or wake it up.
To turn off your Nexus 7:
 
OK
to complete the shut down.
To restart your Nexus 7 if it becomes unresponsive:
 
seconds.
SAFE TEMPERATURE: This Nexus 7 should
only be used in environments with ambient
temperatures between 0°C (32°F) and 35°C (95°F).

Nexus 7 11
Set up your Nexus 7

Welcome screen. To choose a different language, touch
the menu. Then touch Start and follow the on-screen
instructions.
A series of screens takes you through the setup
process. If you already have Gmail, use your Gmail
address and password when asked. If you don’t have
Gmail or any other Google Account, go ahead and
create one.
A Google Account lets you access your personal
information from any computer or mobile device:
 Access from anywhere. Play music, view
movies, or read books from your Google Play
libraries no matter where you are or what
computer or mobile device you’re using – as
long as you have a Wi-Fi or 3G data network
connection. The same goes for your email, text
messages, or social stream.
 Buy stuff from Google Play. You can connect
your Google Account to Google Wallet, which
makes it easy to purchase music, books, apps,
movies, and more from Google Play and other
online stores.

Nexus 7
12
 Never lose your contacts again. When you sign
into your tablet with a Google Account, all the
contacts you associate with that account in
the People app are automatically backed up.
They’re always accessible through your Google
Account from any computer or mobile device.
 Keep your stuff secure and available. Google
works around the clock to protect your personal
data from unauthorized access and to ensure
that you get it when you need it, wherever you
need it.
 Synchronize and back up all your data. Whether
you draft an email, add a contact, add an event
to your calendar, or take a photo, your work
gets backed up continuously by Google and
synchronized with any computer where you use
the same Google Account.
 Use other Google services. Your Google
Account also lets you take full advantage of
any other Google apps and services that you
may want to use, such as Gmail, Google Maps
Navigation, Google Play, YouTube, Google+, and
many more.

Nexus 7 13
If you skipped some of the steps in the Setup Wizard,

adjust many other settings at any time. Touch the All
Apps icon from any Home screen, then Settings.
Airplane precautions
Check with airline personnel if you want to use your
Nexus 7 on board an aircraft. Most airlines have
restrictions for using electronic devices. Most airlines
allow electronic use only between and not during
takeoffs and landings.
There are three main types of airport security
devices: X-ray machines (used on items placed
on conveyor belts), magnetic detectors (used on
people walking through security checks), and
magnetic wands (hand-held devices used on
people or individual items). You can send your

not send your Nexus 7 through airport magnetic
detectors or expose it to magnetic wands.

Nexus 7
14
Appendix
FCC RF Exposure Requirements
Nexus7 ME370TG
GSM 850: 0.916 W/kg
GSM 1900: 1.3 W/kg
WCDMA Band II: 1.39 W/kg
WCDMA Band IV: 1.12 W/kg
WCDMA Band V : 1.12 W/kg
The highest SAR value for the device as reported to
the FCC is 1.39W/kg when placed next to the body.

Nexus 7 15
ME370TG CE SAR (maximum is band I @ SAR 10g,
0.788 W/Kg )
Federal Communication Commission
Interference Statement
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired
operation.
WLAN 2.4GHz
Bluetooth
Mode / Band
GSM900
GSM1800
WCDMA Band I
WCDMA Band VIII
Test Position
Body (1.5 cm Gap)
Body (1.5 cm Gap)
Body (1.5 cm Gap)
Body (1.5 cm Gap)
Body (1.5 cm Gap)
Body (1.5 cm Gap)
SAR-10g
(W/kg)
0.505
0.373
0.788
0.424
0.048
N/A

Nexus 7
16
This device has been tested and found to comply
with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful
interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy,
and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation If
this equipment does cause harmful interference to radio
or television reception, which can be determined by
to try to correct the interference by one or more of the
following measures:
* Reorient or relocate the receiving antenna.
* Increase the separation between the equipment and
receiver.
* Connect the equipment into an outlet on a circuit
* Consult the dealer or an experienced radio/TV
technician for help.

Nexus 7 17
FCC Caution:
Any Changes or modi cations not expressly approved
by the party responsible for compliance could void the
user‘s authority to operate the equipment.
The antenna(s) used for this transmitter must not be
co-located or operating in conjunction with any other
antenna or transmitter.
Note: The country code selection is for non-US model
only and is not available to all US model. Per FCC
US operation channels only.
RF Exposure Information (SAR)
This device meets the government’s requirements
for exposure to radio waves. This device is designed
and manufactured not to exceed the emission limits
for exposure to radio frequency (RF) energy set by
the Federal Communications Commission of the U.S.
Government.

Nexus 7
18
The exposure standard for wireless device employs a unit of
SAR limit set by the FCC is 1.6W/kg. *Tests for SAR are conducted
using standard operating positions accepted by the FCC with the
frequency bands. Although the SAR is determined at the highest
cert d power level, the actual SAR level of the device while
operating can be well below the maximum value. This is because
the device is designed to operate at multiple power levels so as to
use only the poser required to reach the network. In general, the
closer you are to a wireless base station antenna, the lower the
power output.
The highest SAR value for the model device as reported to the FCC
when worn on the body, as described in this user guide, is 1.39
W/kg (Body-worn measurements di er among device models,
depending upon available accessories and FCC requirements.)
devices and at various positions, they all meet the government
requirement.
The FCC has granted an Equipment Authorization for this model
device with all reported SAR levels evaluated as in compliance with
the FCC RF exposure guidelines. SAR information on this model
Grant section of www.fcc.gov/oet/ea/fccid after searching on
FCC ID: MSQME370TG.

Nexus 7 19
Limitation of Liability
Circumstances may arise where because of a default on ASUS’
part or other liability, you are entitled to recover damages
from ASUS. In each such instance, regardless of the basis on
which you are entitled to claim damages from ASUS, ASUS is
liable for no more than damages for bodily injury (including
death) and damage to real property and tangible personal
property; or any other actual and direct damages resulted
from omission or failure of performing legal duties under
this Warranty Statement, up to the listed contract price of
each product.
ASUS will only be responsible for or indemnify you for loss,
damages or claims based in contract, tort or infringement
under this Warranty Statement.
This limit also applies to ASUS’ suppliers and its reseller. It is
the maximum for which ASUS, its suppliers, and your reseller
are collectively responsible.
UNDER NO CIRCUMSTANCES IS ASUS LIABLE FOR ANY OF THE
FOLLOWING: (1) THIRD-PARTY CLAIMS AGAINST YOU FOR
DAMAGES; (2) LOSS OF, OR DAMAGE TO, YOUR RECORDS OR
DATA; OR (3) SPECIAL, INCIDENTAL, OR INDIRECT DAMAGES OR
FOR ANY ECONOMIC CONSEQUENTIAL DAMAGES (INCLUDING
LOST PROFITS OR SAVINGS), EVEN IF ASUS, ITS SUPPLIERS OR
YOUR RESELLER IS INFORMED OF THEIR POSSIBILITY.
