User Guide
E9969
ASUS Tablet
Revised Edition V3 / November 2014

Charging your device
Ensure to fully charge your ASUS Tablet before using it in
battery mode for extended periods. Remember that the power
adapter charges your ASUS Tablet as long as it is plugged into
an AC power source. Be aware that it takes much longer to
charge the ASUS Tablet when it is in use.
IMPORTANT! Do not leave the ASUS Tablet connected to
the power supply once it is fully charged. ASUS Tablet is not
designed to be left connected to the power supply for extended
periods of time.
Airplane precautions
Contact your airline provider to learn about related inight
services that can be used and restrictions that must be followed
when using your ASUS Tablet in-ight.
IMPORTANT! You can send your ASUS Tablet through x-ray
machines (used on items placed on conveyor belts), but do not
expose them from magnetic detectors and wands.
Safety precautions
This ASUS Tablet should only be used in enviroments with
ambient temperatures between 0°C to 35°C (32°F to 95°F).
Long time exposure to extremely high or low temperature
may quickly deplete and shorten the battery life. To ensure the
battery’s optimal performance, ensure that it is exposed within
the recommended environment temperature.

ASUS Tablet
3
Package contents
NOTES:
• Ifanyoftheitemsisdamagedormissing,contactyour
retailer.
• Thebundledpoweradaptervarieswithcountryorregion.
Micro USB cable
ASUS Tablet Power adapter
ASUS Tablet
USER GUIDE
User guide Warranty card

ASUS Tablet
4
Your ASUS Tablet
Front view
Front camera
Touch screen panel

ASUS Tablet
5
Rear view
Microphone
Audio speaker
Rear camera Power button
Volume button
MicroSD card slot*
Micro USB
2.0 port
Speaker/
Headset port
Dock port
Hinge hole Hinge hole
* The microSD card slot supports microSD, microSDHC, and microSDXC card formats.
** The model with NFC tag may vary by country or region.
Audio speaker
NFC tag**

ASUS Tablet
6
Charging your ASUS Tablet
To charge your ASUS Tablet:
Charge your ASUS Tablet for eight (8) hours before
using it in battery mode for the rst time.
Connect the micro USB cable to the power adapter.
Plug the micro USB connector into your ASUS Tablet.
Plug the power adapter into a grounded power outlet.

ASUS Tablet
7
IMPORTANT!
• UseonlythebundledpoweradapterandthemicroUSBcable
to charge your ASUS Tablet. Using a dierent power adapter
may damage your ASUS Tablet.
• Peeltheprotectivelmofromthepoweradapterandmicro
USB cable before charging the ASUS Tablet to prevent risk or
injury.
• Ensurethatyouplugthepoweradaptertothecorrectpower
outlet with the correct input rating. The output voltage of this
adapter is DC 5.2 V, 1.35 A.
• WhenusingyourASUSTabletwhileplugged-intoapower
outlet, the grounded power outlet must be near the unit and
easily accessible.
• DonotplaceobjectsontopofyourASUSTablet.
NOTES:
• YourASUSTabletcanbechargedviatheUSBportona
computer only when it is in sleep mode (screen o) or turned
o.
• ChargingthroughaUSBportofacomputermaytakelonger
time to complete.
• Ifyourcomputerdoesnotprovideenoughpowerfor
charging your ASUS Tablet, charge your ASUS Tablet via the
grounded power outlet instead.

ASUS Tablet
8
Appendices
Federal Communications Commission
Statement
This device complies with FCC Rules Part 15. Operation is
subject to the following two conditions:
• Thisdevicemaynotcauseharmfulinterference.
• Thisdevicemustacceptanyinterferencereceived,including
interference that may cause undesired operation.
This equipment has been tested and found to comply with
the limits for a class B digital device, pursuant to Part 15 of the
Federal Communications Commission (FCC) rules. These limits
are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy and,
if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur
inaparticularinstallation.Ifthisequipmentcausesharmful
interference to radio or television reception, which can be
determined by turning the equipment o and on, the user is
encouraged to try to correct the interference by doing one or
more of the following measures:
• Reorientorrelocatethereceivingantenna.
• Increasetheseparationbetweentheequipmentand
receiver.
• Connecttheequipmentintoanoutletonacircuitdierent
from that to which the receiver is connected.

ASUS Tablet
9
• Consultthedealeroranexperiencedradio/TVtechnicianfor
help.
Changes or modications not expressly approved by the party
responsible for compliance could void the user‘s authority to
operate the equipment.
The antenna(s) used for this transmitter must not be co-
located or operating in conjunction with any other antenna or
transmitter.
Operation on the 5.15-5.25 GHz frequency band is restricted
for indoor use only. The FCC requires indoor use for the 5.15-
5.25 GHz band to reduce the potential for harmful interference
toco-channelMobileSatelliteSystems.Itwillonlytransmit
on 5.25-5.35 GHz, 5.47-5.725 GHz and 5.725-5.850 GHz bands
when associated with an access point (AP).
RF Exposure Information (SAR)
This device meets the government’s requirements for exposure
to radio waves. This device is designed and manufactured not
to exceed the emission limits for exposure to radio frequency
(RF) energy set by the Federal Communications Commission of
the U.S. Government.
The exposure standard employs a unit of measurement
known as the Specic Absorption Rate, or SAR. The SAR limit
set by the FCC is 1.6 W/kg. Tests for SAR are conducted using
standard operating positions accepted by the FCC with the EUT
transmitting at the specied power level in dierent channels.
The highest SAR value for the device as reported to the FCC is
1.14 W/kg when placed next to the body.

ASUS Tablet
10
The FCC has granted an Equipment Authorization for this device
with all reported SAR levels evaluated as in compliance with the
FCC RF exposure guidelines. SAR information on this device is
on le with the FCC and can be found under the Display Grant
section of www.fcc.gov/oet/ea/fccidaftersearchingonFCCID:
MSQK0101.
Canada, Industry Canada (IC) Notices
ThisClassBdigitalapparatuscomplieswithCanadianICES-003,
RSS-210,andCANICES-3(B)/NMB-3(B).
Operation is subject to the following two conditions: (1) this
device may not cause interference, and (2) this device must
accept any interference, including interference that may cause
undesiredoperationofthedevice.TheICIDforthisdeviceis
3568A-K010.
Radio Frequency (RF) Exposure Information
The radiated output power of the Wireless Device is below
theIndustryCanada(IC)radiofrequencyexposurelimits.The
Wireless Device should be used in such a manner such that
the potential for human contact during normal operation is
minimized.
This device has been evaluated for and shown compliant with
theICSpecicAbsorptionRate(“SAR”)limitswheninstalled
in specic host products operated in portable exposure
conditions.
