Asus T103HAF User manual

E13440
Revised Edition V2 / August 2017
User Guide
E13440_T103HAF_2-in-1_UM_V2_20pages.indd 1
2017/8/22 �� 01:58:26

2
ASUS Tablet User Manual
Hardware Setup
Front View
Camera indicator
Front camera
Back View
MicroSD card slot (hidden)
Kickstand
Touch screen panel
E13440_T103HAF_2-in-1_UM_V2_20pages.indd 2
2017/8/22 �� 01:58:26

ASUS Tablet User Manual
3
Top and bottom sides
Left and right sides
ASUS Pen (on selected models)
Hinge hole
Dock port
Hinge hole
Power button
Power indicator
Array microphones
Micro USB 2.0 port
Audio speakers Headphone/Headset jackUSB 3.0 port
Volume button Audio speakers
Micro HDMI port
Right-click button Eraser button
NOTE: Certain USB 3.0 devices may cause interference with wireless transmission.
E13440_T103HAF_2-in-1_UM_V2_20pages.indd 3
2017/8/22 �� 01:58:26

4
ASUS Tablet User Manual
ASUS Mobile Dock (optional)
NOTE:
• Thekeyboard’slayoutmayvarypermodel,region,orcountry.
• TheASUSMobileDockmaybesoldseparately.
Touchpad
Keyboard
Latch hook Latch hook
Dock connector
Hinge
Top View
E13440_T103HAF_2-in-1_UM_V2_20pages.indd 4
2017/8/22 �� 01:58:27

ASUS Tablet User Manual
5
WARNING! Keep the magnetic attachment away from external storage drives and
cards with magnetic strips to prevent demagnetization. Refer to E-Manual for details.
E13440_T103HAF_2-in-1_UM_V2_20pages.indd 5
2017/8/22 �� 01:58:27

6
ASUS Tablet User Manual
2. Powering on your ASUS Tablet
NOTE: Thepoweradaptermayvaryinappearance,dependingonmodelsandyour
region. Use only the bundled power adapter for charging.
Charge the ASUS Tablet before using it in battery mode for the rst time.
Getting started
1. Charge your ASUS Tablet
A. Connect the micro USB cable to the power adapter.
B. Plug the micro USB connector into your ASUS Tablet.
C. Plug the power adapter into a grounded power outlet.
E13440_T103HAF_2-in-1_UM_V2_20pages.indd 6
2017/8/22 �� 01:58:28

ASUS Tablet User Manual
7
CAUTION!
• ThisASUSTabletshouldonlybeusedinenvironmentswithambienttemperaturesbetween
5°C (41°F) and 35°C (95°F).
• RefertotheratinglabelonthebottomofyourASUSTabletandensurethatyourpower
adapter complies with this rating.
• Thepoweradaptermaybecomewarmtohotwhileinuse.Donotcovertheadapterandkeep
it away from your body while it is connected to a power source.
• DonotleaveyourASUSTabletonyourlapornearanypartofyourbodytoprevent
discomfort or injury from heat exposure.
• Donotusedamagedpowercords,accessories,andotherperipheralswithyourASUSTablet.
IMPORTANT!
• Locatetheinput/outputratinglabelonyourASUSTabletandensurethatitmatchesthe
input/output rating information on your power adapter. Some ASUS Tablet models may have
multiple rating output currents based on the available SKU.
• EnsurethatyourASUSTabletisconnectedtothepoweradapterbeforeturningitonforthe
rst time. We strongly recommend that you use a grounded wall socket while using your
ASUS Tablet on power adapter mode.
• ThesocketoutletmustbeeasilyaccessibleandnearyourASUSTablet.
• TodisconnectyourASUSTabletfromitsmainpowersupply,unplugyourASUSTabletfrom
the power socket.
• Thepoweradaptervarieswithmodeltype.Useonlythebundledpoweradapter.
• Poweradapterinformation:
 -Inputvoltage:100-240Vac
 -Inputfrequency:50-60Hz
 -Ratingoutputcurrent:2A(18W)
 -Ratingoutputvoltage:9V
Safety notices for your ASUS Tablet
E13440_T103HAF_2-in-1_UM_V2_20pages.indd 7
2017/8/22 �� 01:58:28

8
ASUS Tablet User Manual
WARNING!
ReadthefollowingprecautionsforyourASUSTablet’sbattery.
• OnlyASUS-authorizedtechniciansshould
remove the battery inside the device
(for non-removable battery only).
• Thebatteryusedinthisdevicemaypresent
a risk of re or chemical burn if removed or
disassembled.
• Followthewarninglabelsforyourpersonal
safety.
• Riskofexplosionifbatteryisreplacedbyan
incorrect type.
• Donotdisposeofinre.
• Neverattempttoshort-circuityourASUS
Tablet’sbattery.
• Neverattempttodisassembleand
reassemble the battery
(for non-removable battery only).
• Discontinueusageifleakageisfound.
• Thisbatteryanditscomponentsmustbe
recycled or disposed of properly.
• Keepthebatteryandothersmall
components away from children.
Nordic Lithium Cautions (for lithium-ion batteries)
ATTENTION!Ilyadangerd’explosions’ilyaremplacementincorrectdelabatterie.Remplacer
uniquementavecunebatteriedumêretypeoud’untypeéquivalentrecommandéparle
constructeur.Mettreaurebutlesbatteriesusagéesconformémentauxinstructionsdufabricant.
(French)
RF Exposure information (SAR) - CE
This device meets the EU requirements (1999/519/EC) on the limitation of exposure of the
general public to electromagnetic elds by way of health protection.
The limits are part of extensive recommendations for the protection of the general public. These
recommendations have been developed and checked by independent scientic organizations
through regular and thorough evaluations of scientic studies. The unit of measurement for the
EuropeanCouncil’srecommendedlimitformobiledevicesisthe“SpecicAbsorptionRate”(SAR),
and the SAR limit is 2.0 W/Kg averaged over 10 gram of body tissue. It meets the requirements
oftheInternationalCommissiononNon-IonizingRadiationProtection(ICNIRP).
Fornext-to-bodyoperation,thisdevicehasbeentestedandmeetstheICNRPexposure
guidelinesandtheEuropeanStandardEN50566andEN62209-2.SARismeasuredwiththe
device directly contacted to the body while transmitting at the highest certied output power
level in all frequency bands of the mobile device.
WARNING! A minimum separation distance of 1 cm must be maintained between
theuser’sbodyandthedevice,includingtheantennaduringbody-wornoperation
to comply with the RF exposure requirements in Europe.
