Asus ME370TG User manual

Eee Pad User Manual
ME370TG
EXXXX
ASUS is devoted to creating environment-
friendly products/packagings to safeguard
consumers’health while minimizing the
impact on the environment. The reduction
of the number of the manual pages complies
with the reduction of carbon emission.
For the detailed user manual and related
information, refer to the user manual
included in the device or visit the ASUS
Support Site at http://support.asus.com or
the Eee Pad website at http://eee.asus.com/
eeepad for updated information.

There are three main types of airport security devices:
X-ray machines (used on items placed on conveyor
belts), magnetic detectors (used on people walking
through security checks), and magnetic wands
(hand-held devices used on people or individual
items). You can send your Eee Pad through airport
X-ray machines. But do not send your Eee Pad
through airport magnetic detectors or expose it to
magnetic wands.
Charging Your Batteries
If you intend to use battery power, be sure to fully charge
your battery pack before going on long trips. Remember
that the power adapter charges the battery pack as long as
it is plugged into the computer and an AC power source. Be
aware that it takes much longer to charge the battery pack
when the Eee Pad is in use.
Remember to fully charge the battery (8 hours or more)
before rst use and whenever it is depleted to prolong
battery life. The battery reaches its maximum capacity after
a few full charging and discharging cycles.
Airplane Precautions
Ask an airline personnel if you want to use your Eee Pad
onboard an aircraft. Most airlines have restrictions for using
electronic devices. Most airlines allow electronic use only
between and not during takeos and landings.

ASUS Eee Pad
3
Eee Pad Micro USB Cable
USB Charging Unit Warranty Card
User Manual
Package contents
• Ifanyoftheitemsisdamagedormissing,contact
your retailer.
• Thebundledpowerplugvarieswithcountryor
region.

ASUS Eee Pad
4
Your Eee Pad
1
2
3
5
7
9
6
4
5
75
8
6
9
8
10

ASUS Eee Pad
5
1Touch screen panel
The touch screen panel allows you to operate your
Eee Pad using the stylus or touch gestures.
2Built-in front camera
Use the built-in camera for picture taking,
video recording, video conferencing, and other
interactive applications.
3Audio speaker system
Your Eee Pad is equipped with a built-in high
quality stereo speaker. Audio features are software
controlled.
4Audio jack
The stereo combo jack (3.5mm) connects the Eee
Pad’s audio out signal to amplied speakers or
headphones. Using this jack automatically disables
the built-in speaker.
5Built-in side microphone
The built-in mono microphone can be used for
video conferencing, voice narrations, or simple
audio recordings.

ASUS Eee Pad
6
6Power button
Press and hold the Power button for four seconds
to power on your Eee Pad.
When your Eee Pad is powered on, press the
Power button to put the Eee Pad into sleep mode
or wake it up from sleep mode.
If the system becomes unresponsive, press and
hold the power switch for at least eight seconds to
force the Eee Pad to shut down.
Press the Power button for four seconds and when
prompted, tap OK to shut down your Eee Pad.
Forcing the system to shut down may result in
data loss. Please ensure that you back up all your
important data regularly.
7Micro USB port (2.0)
The Micro USB (Universal Serial Bus) port allows
you to charge the battery of your Eee Pad using
the USB charger or transfer data from or to your
computer.
Charging via USB: If you connect your Eee Pad to
the USB port on your computer, your Eee Pad will
be charged only when it is in sleep mode (screen
o) or powered o.

ASUS Eee Pad
7
8Reset button
Using a paper clip, press this button to reset the
system to its factory default settings.
9Volume key
Press this button to increase or decrease the
system volume.
10 SIM Tray
Put Micro-SIM card to connect the internet.

ASUS Eee Pad
8
Connecting to the power adapter
Connect the power adapter into the Eee Pad and to a power
outlet.

ASUS Eee Pad
9
• Useonlythepoweradapterthatcomeswith
your device. Using a dierent power adapter may
damage your device.
• Pleasepeeltheprotectivelmofromtheplug,
USB charging unit, and USB cable before charging
the Eee Pad to prevent risk or injury.
• UsingthebundledpoweradapterandUSBcableto
connect your Eee Pad to a power outlet is the best
way to charge the Eee Pad.
• Theinputvoltagerangebetweenthewalloutlet
and this adapter is AC 100V–240V, and the output
voltage of this adapter is DC 5V, 2A.
• Toprolongbatterylife,fullychargethebatteryfor
up to eight (8) hours when using the Eee Pad for
the rst time and whenever the battery power is
fully depleted.
• YourEeePadcanbechargedviatheUSBporton
the computer only when it is in sleep mode (screen
o) or powered o.
• ChargingthroughtheUSBportmaytakelonger
time to complete.
• Ifyourcomputerdoesnotprovideenoughpower
for charging your Eee Pad, charge your Eee Pad via
the power outlet instead.

ASUS Eee Pad
10
Setting up your Google account
Use your Google account to fully enjoy your Eee Pad's
Android features such as GTalk, Gmail, Navigation, Android
Market, and Maps.
If you have not set up your Google account the rst time
you turned on your Eee Pad, follow these steps to set up
your Google account:
1. From the upper right corner of the Home screen, tap
Apps.
2. Tap Settings > Accounts & sync > Add account.
3. Tap Google accounts.
4. Key in your e-mail address and password, then tap Sign
in. Wait for a few minutes until your Eee Pad connects to the
Google server.
If you do not have an existing Google account, create
one on the Google website at http://mail.google.
com
