Asus ASUS TV TUNER CARD User manual

®
TV Tuner Card
The PCI-based
TV Tuner Card
USER’S MANUAL
Hardware & Video Drivers

ASUS TV Tuner Card User’s Manual
2
USER’S NOTICE
No part of this manual, including the products and software described in it, may be repro-
duced, transmitted, transcribed, stored in a retrieval system, or translated into any language
in any form or by any means, except documentation kept by the purchaser for backup pur-
poses, without the express written permission of ASUSTeK COMPUTER INC. (“ASUS”).
ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND,
EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOTLIMITED TO THE IMPLIED
WARRANTIES OR CONDITIONS OF MERCHANTABILITYOR FITNESS FORAPAR-
TICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS DIRECTORS, OFFICERS,
EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDEN-
TAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF
PROFITS, LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSI-
NESS AND THE LIKE), EVEN IF ASUS HAS BEENADVISED OF THE POSSIBILITY
OF SUCH DAMAGESARISING FROM ANY DEFECT OR ERROR IN THIS MANUAL
OR PRODUCT.
Product warranty or service will not be extended if: (1) the product is repaired, modified or
altered, unless such repair, modification of alteration is authorized in writing by ASUS; or
(2) the serial number of the product is defaced or missing.
Products and corporate names appearing in this manual may or may not be registered trade-
marks or copyrights of their respective companies, and are used only for identification or
explanation and to the owners’ benefit, without intent to infringe.
• Windows, MS-DOS, and DirectX are registered trademarks of Microsoft Corporation.
• Adobe and Acrobat are registered trademarks of Adobe Systems Incorporated.
The product name and revision number are both printed on the product itself. Manual revi-
sions are released for each product design represented by the digit before and after the period
of the manual revision number. Manual updates are represented by the third digit in the
manual revision number.
For previous or updated manuals, BIOS, drivers, or product release information, contactASUS
at http://www.asus.com.tw or through any of the means indicated on the following page.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUALARE FUR-
NISHED FOR INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT
ANY TIME WITHOUT NOTICE, AND SHOULD NOT BE CONSTRUED AS A COM-
MITMENT BY ASUS. ASUS ASSUMES NO RESPONSIBILITY OR LIABILITY FOR
ANYERRORS ORINACCURACIESTHATMAYAPPEARINTHIS MANUAL,INCLUD-
ING THE PRODUCTSAND SOFTWARE DESCRIBED IN IT.
Copyright © 2002 ASUSTeK COMPUTER INC.All Rights Reserved.
Product Name: ASUS TV Tuner Card
Manual Revision: 1.01 E1102
Release Date: Augest 2002

ASUS TV Tuner Card User’s Manual 3
ASUS CONTACT INFORMATION
ASUSTeK COMPUTER INC. (Asia-Pacific)
Address: 150 Li-Te Road, Peitou, Taipei, Taiwan 112
General Tel: [phone]
General Fax: [phone]
General Email: [email protected]
Technical Support
MB/Others (Tel): [phone] (English)
Notebook (Tel): [phone] (English)
Desktop/Server (Tel): [phone] (English)
Support Fax: [phone]
Support Email: [email protected]
Web Site: www.asus.com.tw
Newsgroup: cscnews.asus.com.tw
ASUS COMPUTER INTERNATIONAL (America)
Address: 6737 Mowry Avenue, Mowry Business Center,
Building 2, Newark, CA 94560, USA
General Fax: [phone]
General Email: [email protected]
Technical Support
Support Fax: [phone]
General Support: [phone]
Web Site: www.asus.com
Support Email: [email protected]
ASUS COMPUTER GmbH (Europe)
Address: Harkortstr. 25, 40880 Ratingen, BRD, Germany
General Fax: [phone]
General Email: [email protected] (for marketing requests only)
Technical Support
Support Hotline: MB/Others: [phone]
Notebook (Tel): [phone]
Support Fax: [phone]
Support (Email): www.asuscom.de/de/support (for online support)
Web Site: www.asuscom.de

ASUS TV Tuner Card User’s Manual
4
CONTENTS
I. Introduction .......................................................................... 7
Highlights.............................................................................................. 7
Models Available .................................................................................. 7
Getting started....................................................................................... 8
2. Hardware Setup .................................................................... 9
Operating System Requirements .....................................................9
ASUS TV Tuner Card Layout........................................................10
Installation Procedures...................................................................11
Connecting the Audio ....................................................................12
ASUS TV Tuner Card Connectors.................................................12
Using Your Tuner Card ..................................................................13
Connecting Your Tuner Card .........................................................15
Using the Remote Control .............................................................17
Installing Batteries .........................................................................17
ASUS Remote Controller Layout ..................................................18
ASUS Remote Controller Functions..............................................20
3. Software Setup .................................................................... 23
Device Driver Installation..............................................................23
Windows 98/ME ................................................................................. 23
Method 1: ASUS Quick Setup Program ....................................... 23
Method 2: Plug and Play .............................................................. 24
Windows 2000/XP .............................................................................. 26
Method 1: ASUS Quick Setup Program ....................................... 26
Method 2: Plug and Play .............................................................. 27
Install ASUS Remote Controller Driver ............................................. 29
Method : ASUS Quick Setup Program ......................................... 29
Install DirectX..................................................................................... 31
Uninstall the TV Tuner Card Drivers.................................................. 32
Windows 98 / ME ......................................................................... 32
Method : Usingt he Control Panel.......................................... 32
Windows 2000 / XP...................................................................... 33
Method : Using Control Panel................................................ 33
Install VideoSecurity........................................................................... 34
Install PowerVCR II ........................................................................... 35
Install PowerDirector Pro ................................................................... 36
Install Medi@Show ............................................................................ 37
Install ASUSDVD XP......................................................................... 38
4. Software Reference............................................................. 39
ASUS Remote Master....................................................................39
PowerVCR II .................................................................................41

ASUS TV Tuner Card User’s Manual 5
CONTENTS
Displaying Options ............................................................................. 43
Recording............................................................................................ 43
Instant TV Replay ............................................................................... 46
Programming with CyberEPG ............................................................ 47
PowerDirector 2.0 ..........................................................................48
Medi@Show ..................................................................................50
ASUS VideoSecurity .....................................................................52
5. Resolution Table.................................................................. 57
6. Troubleshooting .................................................................. 59

ASUS TV Tuner Card User’s Manual
6
FCC & DOC COMPLIANCE
FederalCommunicationsCommission Statement
This device complies with FCC Rules Part 15. Operation is subject to the following
two conditions:
• This device may not cause harmful interference, and
• This device must accept any interference received, including interference that
may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installa-
tion. This equipment generates, uses and can radiate radio frequency energy and, if
not installed and used in accordance with manufacturer’s instructions, may cause
harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the inter-
ference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
WARNING! The use of shielded cables for connection of the monitor to the
graphics card is required to assure compliance with FCC regulations. Changes
or modifications to this unit not expressly approved by the party responsible for
compliance could void the user’s authority to operate this equipment.
CanadianDepartmentof Communications Statement
This digital apparatus does not exceed the Class B limits for radio noise emissions
from digital apparatus set out in the Radio Interference Regulations of the Cana-
dian Department of Communications.
This Class B digital apparatus complies with Canadian ICES-003.
CetappareilnumériquedelaclasseBestconformeàlanormeNMB-003duCanada.
MacrovisionCorporationProduct Notice
This product incorporates copyright protection technology that is protected by
method claims of certain U.S. patents and other intellectual property rights owned
by Macrovision Corporation and other rights owners. Use of this copyright protec-
tion technology must be authorized by Macrovision Corporation, and is intended
for home and other limited viewing uses only unless otherwise authorized by
Macrovision Corporation. Reverse engineering or disassemby is prohibited.

7ASUS TV Tuner Card User’s Manual
I. Introduction
Highlights
Thank you for purchasing an ASUS TV tuner card. The first TV tuner card to attain
Microsoft
®
WHQL Certification, provides a total solution suitable for watching TV
programs, making scheduled recordings, capturing video from TVs or camcorders,
and making movies on your PC. The ASUS TV TUNER CARD introduces a new
dimension in video quality by incorporating the newest video/audio decoder for
enhanced performance, functionality and enjoyment. Combined with the ASUS
remote control and useful software bundle, theASUS TV TUNER CARD lets your
PC be a smart multimedia center!
• Use the advanced video/audio decoder - Conexant CX23880 that has
a 10-bit video ADCs for most excellent video quality
• Philips NTSC TV tuner module built-in
• Enjoy a total TV experience from the convenience of your computer
• Provide with special TV experience - viewing, TimeShift, scheduled
recording, capture still image with MPEG I, II compression
• Support STEREO and SAP modes while watching TV
• Come with a remotes control for the ultimate in convenience
• Video-in connector for external video stream
• Let you capture/edit/author/burn yourfavorite videos and images in
one software package
• Build your own video security and monitoring system
• WDM video capture driver for Windows 98/ME/2000/XP
• Microsoft® DirectShowTM compliant
• Microsoft® WHQL certifieddrivers inside
• PCI revision 2.2 compliant
• Videoconference over the Internet
1. Introudction
Highlights/Models
1. Introudction

ASUS TV Tuner Card User’s Manual8
Getting Started
The following steps will help you get your ASUS TV Tuner Card connected and
working quickly and assume that your computer is shut down and turned off.
1 Unpack your ASUS TV Tuner Card pagkage.
Shown here are the TV tuner card and accessories.
ASUS TV tuner card
Cables
(1) Video-in cable for connection to video camera or camcorder
(2) Audio cable for connection to sound card
Software
(1) ASUS installation driver CD
(2) ASUS VideoSecurity utility
(3) ASUSDVD XP
utility
(4) CyberLink
®
PowerVCR II bundled
(5) CyberLink
®
PowerDirector bundled
(6) CyberLink
®
Medi@Show bundled
Remote control with transmitter, receiver and batteries
ASUS TV Tuner Card user’s manual
2 Connect cables and other accessories.
• Details for connecting a cable TVsystem and home antenna to your tuner starts
on page 13.
• Details for connecting other devices to your tuner card are on page 15.
3 Install batteries in remote control.
• Details are on page 17.
4 Start your computer.
5 Install the Device drivers.
• Details for installing the software to run your tuner card are on page 23.
6 Install the DirectX.
• Details for installing the software to run your tuner card are on page 31.
7 Installing software.
• Details for installing the software to run your tuner card are on page 34.
8 Using software.
• Details for using the software to run your tuner card are on page 39.
I. Introduction
1. Introudction
Highlights/Models
1. Introudction

9ASUS TV Tuner Card User’s Manual
2. Hardware Setup
Operating System Requirements
• Intel®orAMD®chipset-based mainboard recommended
• One available PCI compliant slot
• Minimum 64 MB system memory
• VGA card with 16MB memory above
• CD-ROM drive (for driver installation)
• Sound card needed
• Microsoft Windows 9X®/ME®/2000®/XP®
• DirectX®8 or above needed
2.H/W Setup
NOTES
•To avoid damage to your tuner card, unplug your computer’s power sup-
ply before inserting your tuner card into the PCI slot.
•Videoconferencingrequiresthe addition of avideo camera or videocamcorder.

ASUS TV Tuner Card User’s Manual10
Item Checklist
ASUS TV Tuner Card (NTSC)
User’s Manual
ASUS Driver and Utility CD Disc
Notes
• Use the same TV standard for all devices.
•and cannot be connected at the same time.
• Drawings are for reference only; actual cards may vary.
ASUS TV Tuner Card
2. Hardware Setup
2.H/W Setup
R
PHILIPS
PHILIPS
CONEXANT
Broadcast Decoder
CX23880
Cable/
Antenna
Connector
AV Input
(8pin)
CATV
Antenna
ASUS AV Adapter
Sound Card
Audio Out
S

11ASUS TV Tuner Card User’s Manual
2. H/W Setup
Installation Procedures
New Tuner Card
1. Unplug all electrical cords on your computer.
2. Remove the system unit cover.
3. Locate the PCI bus expansion slot. Make sure this slot is unobstructed.
4. Remove the corresponding expansion slot cover from the computer chassis.
5. Ground yourself to an antistatic mat or other grounded source .
6. Pick up the board (still in its sleeve) by grasping the edge bracket with one hand
and then remove the plastic sleeve.
7. Position the card directly over the PCI slot and insert one end of the board in the
slot first. Firmly but gently press the bus connector on the bottom of the card
down into the slot. Be sure the metal contacts on the bottom of the host adapter
are securely seated in the slot.
8. Anchor the board’s mounting bracket to the computer chassis using the screw
from the slot cover that you set aside previously.
9. Replace the cover on the system unit.
10. Connect cables and devices, if available.
NOTE: This TV Tuner card can only be installed in motherboards with a PCI slot.
WARNING! Computer boards and components contain very delicate Integrated
Circuit (IC) chips. To protect the computer board and other components against
damage from static electricity, you must follow some precautions.
1. Make sure that you unplug your power supply when adding or removing
expansion cards or other system components. Failure to do so may cause
severe damage to both your motherboard and expansion cards.
2. Keep all components such as the host adapter in its antistatic bag until you
are ready to install it.
3. Use a grounded wrist strap before handling computer components. If you do
not have one, touch both of your hands to a safely grounded object or to a
metal object, such as the power supply case. Hold components by the edges
and try not to touch the IC chips, leads, or circuitry.
4. Place components ona grounded antistatic pador on the bagthat came withthe
component whenever the components are separated from the system.
2. Hardware Setup

ASUS TV Tuner Card User’s Manual12
Connecting the Audio
You may connect the audio portion either externally. Follow the procedure below to
connect the audio.
External Audio Connection
1. Looking at the back of your computer, locate the audio out connector on the
ASUS TV Tuner Card.
2. Locate the Line-In connector on your sound card. If necessary, refer to the
documentation supplied with your sound card.
3. Attach one end of the sound cable to the Audio Out the ASUS TV Tuner Card
and the other end to the Line-In on your sound card.
ASUS TV Tuner Card Connectors
The TV Tuner Card provides stereo audio output, and two video input connectors.
For input from cable TV or antenna.
RF-IN
AV-IN
AUDIO-OUT
LINE IN
MIC IN
SPK/LINE
JOYSTICK
For input from composite video source.
For stereo audio input from external sources.
RF-IN
AV-IN
AUDIO-OU
T
AV Input (8 pin)
Cable/Antenna
connector
Audio out
2. Hardware Setup
2.H/W Setup

13ASUS TV Tuner Card User’s Manual
Using Your TV Tuner Card
There are three general steps in using or setting-up your TV Tuner Card.
Step 1 Disconnect the CATV system or antenna from your TV system.
Step 2 Reconnect the CATV system or antenna to your TV Tuner Card.
Step 3 Connect the included and other accessories to your TV Tuner Card.
CATV/Home Antenna Connections
There are various types of cable TV (CATV) and antenna connections. Each type
requires a different method of connection.
NOTEConsult your dealer for the typeof adaptor, splitter,A/B switchor combiner
that may be required when setting up your TV Tuner Card.
Your TV Tuner Card is capable of receiving up to 100 channels. If you do not have
a CATV system, you may use an indoor or outdoor antenna that carries only VHF
(channels 2–13), only UHF (channels 14–69), or VHF and UHF channels to connect
to your TV Tuner Card.
Your CATV sytem or antenna may be connected in either of the following two ways:
direct to the TV or through a VCR system.
Connection Through a TV System
2. Hardware Setup
CATV
Connection Through a VCR System
To start using your TV Tuner Card, follow the steps and sketch on the following
pages to connect a CATV system or home antenna to your TV Tuner Card.
CATV
2. H/W Setup

ASUS TV Tuner Card User’s Manual14
Step 1
Disconnect the CATV system or antenna from your TV system.
Reconnect the CATV system or antenna to your TV Tuner Card.
2. Hardware Setup
Cable/
Antenna
Connector
TV Tuner Card
CATV
Disconnection from a TV System
Disconnection from a VCR System
Step 2
Cable/
Antenna
Connector
TV Tuner Card
CATV
CATV
CATV
Direct Connection
Connection Through either anAdaptor, Splitter, A/B Switch or Combiner
2.H/W Setup

15ASUS TV Tuner Card User’s Manual
Connecting Your TV Tuner Card
Step 3
Connect the audio system to your TV Tuner Card.
2. Hardware Setup
Audio Out
TV Tuner Card
Connect to speaker
2. H/W Setup
Connection through Stereo Audio System
Amplifier Audio Out
TV Tuner Card
NOTES: Audio out is unamplified. Connect to amplified speakers or to an
amplifier.

ASUS TV Tuner Card User’s Manual16
2. Hardware Setup
Audio In
Audio Out
Sound Card
Amplifier
Audio Out
Connection through sound card with Stereo Audio System
You are now ready to install the software.
2.H/W Setup
Audio Out
TV Tuner Card
Audio In
Audio Out
Sound Card
Connection through sound card with Audio System

17ASUS TV Tuner Card User’s Manual
Using the Remote Control
The Remote Control allows you to operate the VCR/ DVD at a distance. It has all
the major controls necessary for operating your tuner card, such as turning your TV
on/off, viewing theTV, and changing the channels and volume.Aim the front of the
Remote Control at the Remote Control Receiver and press the control buttons as
you would on the infrared rays receiver.
Installing Batteries
Open the back cover of Remote Controller and put in two pieces AAA betteries
(alkaline battery recommended).
If the Remote Control does not operate or fails to function normally, replace the batteries.
The Remote Control operates on two AAA (UM-4) 1.5 volt batteries, available at most
stores, such as electronics and camera stores.
The remote control receiver may be
placed anywhere, as long as it is not
blocked
2. Hardware Setup
2. H/W Setup
Installing receiver of ASUS remote control kit
Plugging receiver (with USB port on it) into the USB port of your computer and
have the receiver grip on the top of computer panel or your favorite location for easy
operation.

ASUS TV Tuner Card User’s Manual18
ASUS Remote Controller
2. Hardware Setup
2.H/W Setup
ASUS Remote Controller Layout

19ASUS TV Tuner Card User’s Manual
2. Hardware Setup
Features:
1. Innovation design of ASUS Remote Controller for controlling ASUSDVD XP/
PowerVCR II/EPG software with desktop PC.
2. Mouse mode can be used as mouse function while you aren’t in front of your
computer.
3. Receiver with USB Port, it’s easy to connect with your computer.
4. Provide default settings for four computer software (DVD button -ASUSDVD
VCRbutton-PowerVCR II, EPG Button-Titan.com/TVTV.com)and can bereset-
up depends on user demands.
5. Convenient to edit personalhot key for eachcomputer software with easyoperation
setting program.
Specifications:
• OperationVoltage : 3V; Battery :AAABattery x 2 (alkaline battery recommended)
• Receiver Inter face : USB Port
2. H/W Setup

ASUS TV Tuner Card User’s Manual20
2.H/W Setup
Functions
Mode 1 Mode2 Mode3
Power On/Off Power On/Off Power On/Off
Instant Replay Menu -
Playback Subtitles -
-
Snapshot Snapshot -
Mouse Mouse -
-
System settings Configuration -
-
Backward Backward -
Play/Pause Play/Pause -
Forward Forward -
VCR Mode
DVD Mode
Teletext Mode
(for PAL system only)
Button
2. Hardware Setup
EPG
(Electronic Program Guide)
Audio
(Switch available audio)
Mouse
Left button Mouse Left button
Mouse
Right button Mouse Right button
--
-
-
-
-
(1X /2X / 3X / 4X / 8X / 16X / 32X)
(1X /2X / 3X / 4X / 8X / 16X / 32X)
(1X)
