ATAGO PAL-HIKARi 5 User manual

Cat.No.5455
Instruction Manual
Introduction
Measurement Measurement tips and precautions
Replacing the Batteries
Error Meassages
Thank you for purchasing the instrument.
Read and follow all safety instructions before
operating the instrument.
Fairure to comply with the following instructions
may result in personal injury or property damages.
This instrument measures amount of light absorbed
by shining the near infared light to the fruit
then converts to Brix (sugar level) to display.
Brix (sugar level) can be measured with no need
to cut and squeeze the fruits.
Measurment variance may be seen depending on
the variety and harvest timing. This instrument is
equipped with offset function to match the value
in such cases.
Place a fruit, then
press the START button.
Press the
START button
Press the
side button
Press against a fruit,
then press the side button.
The measurements are displayed.
The temperature difference between the
surface and the inside of the fruit, and
temperature difference between this
instrument and the fruit may affect the
measurement values.
Especially when measuring refrigerated
fruits, be sure to let the fruits acclimate
to the ambient temperature.
The instrument may not measure correctly
when there is water droplets, dust or scar,
and bruising soft spots.
Measure an area larger than 70mm in
diameter with no dents.
Be sure to avoid any spacing between the
fruit and the outer cushion to avoid the
external light interference. If the cushion
is deteriorated, please replace it with a
brand new cushion. (Refer to “How to
change the cushion”)
Example for measurement value: Take few
measurements from the same fruit, then
compute and use the average.
●Acclimate the fruit and this instrument
to ambient temperature.
● Clean the surface of the fruits.
Do not measure the spoiled spots.
● Place the sample stage to the fruit.
● Sugar level varies depending on the
measured area.
When there is an operation error or malfunction, the below
error message will show with alarm sound for warning.
The battery is low.
Measurement was
taken for fruits with
Brix lower than the
measurement range.
Measurement was
taken when the unit’s
temperature was 5℃
or lower.
Measured when
the main unit’s
temperature is
exceeding 45℃.
Measurement was
taken when the fruit’s
temperature was 5℃
or lower.
Measured when the
fruit’s temperature
is exceeding 45℃.
Measurement was
taken for fruits with
Brix highter than the
measurement range.
The instrument is
faulty.
Replace the
batteries. Contact ATAGO if
this error persists.
When the history
of measured data
reaches 100. Turn
OFF the NFC
Function or Delete Data
History.
※Main unit’s temperature
error will preferentially display
when the main unit’s and
fruits’temperatures are both
out of range.
When it is outside of temperature
compensation range.
Digital Hand-held “Pocket” IR Brix Meter
PAL- HIKARi ５
or
1. Insert a coin in the groove on the battery
compartment cover. Turn the coin
counterclockwise to remove the cover.
2. Insert two batteries
3. Align the cover and push it down.
4. Close the battery compartment cover by
pushing the cover in with a coin in the groove
and turning it clockwise until it stops.
Observe the correct polarity.
Groove
When the
cover is
open
When the
cover is
closed
・About battery indicator
When the battery icon indicates the low power
level , replace both batteries with a brand new set
of AAA alkaline batteries (1.5V).
*Check the expiration dates on batteries before
purchase.
Touch the fruit and do not move.
5455-E09
QR code
The warranty period extension method 1 year 2 years
The warranty period will be extended from 1 year to 2 years when you register customer information.
ATAGO Logger NFC can also be downloaded at the same time.
Trouble scanning the code? Access this link https://www.atago.net/ur/index.php?l=en
Beep
Beep
11.7
12.2
12.4
＝
12.1
11.7+12.2+12.4
3
（Example）
Note
Beep
Depending on the variety, there may be a difference between the refractometer (sugar
meter) and the measured value. Please confirm the difference from the value measured
with your refractometer (PAL - 0 of the set when purchasing IR Brix Meter x Brix Meter)
and use the offset function as necessary. (Refer to “Offset Function” )
Measurement was
taken while the
sample stage was not
in contact with fruit.
When correct measurements
are not achievable due to
interference from external
light.
There is a
temperature
difference between
the fruit and the main unit.
Parts
Contents
・Main unit (with silicone cover) ・・・・・・・・・・・・・・・・・・・・ 1
・Instruction Manual(this book) ・・・・・・・・・・・・・・・・・・・・・ 1
・Inspection Report ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 1
・Cushion RS (for replacement)・・・・・・・・・・・・・・・・・・・・ 3
・AAA alkaline batteries ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 2
※AAA alkaline batteries are included.
Silicon cushion R
Light emitting part
Radiation
temperature
sensor
Cushion RS
Receiver
START button
Battery compartment
Side button
Sample stage
LCD
Menu button
Lanyard hole
Full
＜LCD Auto Shut-off＞
The instrument will turn itself off
after 30 seconds of inactivity.
To manually turn it off, hold down
the START button for more than
3 seconds.

Offset Function
Automatic Temperature Compensation
Cleaning
Storage
This function modifies the measurement value by a constant. Use this function to match the measurement value to the refractometer (Brix meter).
ATAGO instruments are rigorously inspected to ensure each
unit meets the highest standards of quality assurance.
How to set addition/subtraction number [Range:-9.9～9.9]
1. Hold down menu while
it is turned on. 2. Press menu to select either addition or
subtraction.
(Example) (Example)
No plus sign will be displayed.
Current addition/subtraction number is
displayed and
“-“ will flash.
4. Enter the addition/subtraction
number. 5.
Press START to confirm the
addition/subtraction number.
3. Press START
to confirm.
The first digit :
0 to9
The
second digit :
0 to9
The first digit:
Press menu to
changethe number.
Press START to
confirm and move
to the next digit.
The second digit:
Press menu to
change the number.
The entered
addition/subtraction
number will flash first
then remains lit once
confirmed.
Press the START
button or side button
to begin measuring.
・Screen image during
measurement when
offset is on.
The measurement values are temperature dependent. This unit
is equipped with automatic temperature compensation to correct
the readings that are within the range to display measurement
value at 20℃.
The unit displays temperature at the fruit surface.
Safety Precautions
Repair and Warranty
Specifications
The instrument is warranted for one year from the date of
purchase. This warranty is void if the instrument shows
evidence of the following. Send the included batteries as well if
they are still in use.
・Having been disassembled by unauthorized personnel
・Water damage or having been dropped
・Having been misused and/or operated outside the environmental
specifications
・Leakage from batteries other than those included with the unit
Repair services are available for a fee after the warranty expires.
Contact an ATAGO authorized service center for service and
support.
・Do not aim it at a face when measuring.
・Do not attempt to repair, modify, or disassemble the instrument.
Brix scale
Brix represents the weight of sucrose in 100 grams of sucrose
solution as percentage by weight. When other dissolved solids
are present in the solution, Brix conversion may be applied.
Brix is a measure of the total dissolved solids in a solution and
indicates the combined concentration of all soluble substances,
such as sugar, salt, protein, and acids.
When the measured values are off
①Are there any difference between the fruit, unit, and ambient
temperature?
②Are there any water droplets or soiled area in the measurement section?
Is the fruit spoiled?
③Does the fruit and inner cushion have a good contact?
Especially when using the side button, is it out of alignment?
④Are there any difference depending on measured section?
①～④ → Refer to “Measurement tips and precautions”
⑤Are there any damages or soil on the light emitting or
receiving section? → Refer to “Cleaning”
If light emitting or receiving section is damaged or soiled,
contact ATAGO.
⑥Is the cushion wet? → Refer to “Cleaning”
Replace cushion to a new one if there is any deterioration. →
Refer to “How to Change the Cushion”
⑦Check the offset feature → Refer to “Offset Function”
Measurement range
Resolution
Measurement accuracy
Repeatability
Automatic temperature
compensation range
Ambient temperature range
Measurement time
Backlight
Power supply
International Protection class
Dimensions and weight
＊Apple varieties and measurement environment may affect accuracy.
Brix 10.0 to 18.0% Temperature 5.0 to 45.0℃
Measurement fruits Apple
Brix 0.1% Temperature 0.1℃
Brix
± 1%
＊ Temperature
± 1℃
Brix
± 0.5%
5.0～35.0℃
5 to 35℃
Approx. 1 second
Two (2) AAA alkaline batteries
IP64
61(W) x 44 (D) x 115 (H)mm, 120g (main unit only)
2108K Printed in Japan
Gasoline
To clean the soiled sample stage, use a wetted tissue
or soft cloth to wipe the area.
Completely dry the cushion area.
Avoid using ethyl alcohol. It may compromise the
adhesion on the cushion.
Never splash
water on the
unit.
Do not use organic
solvents (paint
thinner, benzene,
gasoline, etc.) on
the plastic body
case.
Do not keep:
●
In a hot and humid place ● Close to a heater
●
In direct sun light ● Extreme low temperature
●
Inside a closed car
・Before use, carefully read this instruction manual and fully
understand the function and operation for each part of the
instrument. ・ATAGO is not liable for any or all damages as a
result of use of the instrument for those other than its intended
purposes (measurement of Brix, of fruits). ・Do not hit or
protrude the light emitting or receiving section with a sharp object.
・ATAGO is not liable for any loss and damage caused by the
measurement and use of this instrument. ・Do not expose the
instrument to a rapid change in ambient temperature. ・Do not
use the instrument where there is much dust. ・Do not subject
the instrument to strong vibration. ・Do not place the
instrument under anything heavy. ・If the instrument is dropped or
subjected to a strong impact, contact your supplier for
inspection. ・Loosen the battery compartment cover for air
transportation.
Headquarters: The Front Tower Shiba Koen, 23rd Floor
2-6-3 Shiba-koen, Minato-ku, Tokyo 105-0011, Japan
TEL: [phone] [e-mail] http://www.atago.net/
TEL: [phone] [email protected]
TEL: [phone] / 8076 [email protected]
TEL: [phone] [email protected]
TEL: [phone] customerser[email protected]
TEL: [phone] customerser[email protected]
TEL: [phone] [email protected]
TEL: [phone] [email protected]
TEL: [phone] [email protected]
menu menu
（While the measurement is
displayed.）
WARNING
CAUTION
The backlight stays on for 30 seconds then
turns off after 30 seconds. The backlight is
off when measurements are taken.
TEL: [phone] [email protected]
How to Change the Cushion
The Silicon cushion R, the Cushion RS and the Silicone Cover
can be replaced. Please contact ATAGO.
RE-39011 Silicon cushion R
１.Pull off the Silicon cushion R from the sample stage.
２.Fit the Silicon cushion R on to the sample stage.
RE-39012 Cushion RS（3sets)
１.Remove the old cushion from the sample stage.
２.Peel the paper backing off the sticker. Place the cushion on
the sample stage.
Do not block the radiation thermometer with the cushion.
RE-39415 JORDAN for PAL-HIKARi(Silicon Cover)
Note
1. Press and hold menu then press the side
button while it is turned on.
3. While pressing menu, use the side button
to select ON/OFF.
2. Release the side button while
continuing to press menu.
Press START or
side button to
begin measuring.
Do not press menu for 5 seconds or more before
pressing the side button. Holding menu will activate
the addition/subtraction number setting.
Note
4.Release finger from menu.
Confirm setting.
Pressing the side button will switch it between ON/OFF.
(Example)
(Example)
Side button
ON/OFF will flash first then remains lit
once confirmed.
* Keep menu
pressed until step
3 is completed.
How to Set Alarm Sound and Alarm Vibrationcan
Buzzer sound and Vibration can be set to alarm when measurement error is displayed or at the beginning and end of measurement.
Buzzer
sound
ON/OFF Buzzer
sound
Vibration
ON/OFF
Vibration
Snd Snd Snd Snd
vbr vbr vbr vbr
Switch it between Sound or Vibration
Press and hold menu then press the
start button.
Pressing the start button will switch it
between Buzzer Sound or Vibrationcan.
Maximum number of data history
Output
100
NFC Forum Type 4 Tag ISO/IEC 14443 Type A
Output category：Date Time, Brix [%], Temp [degC]
(e.g.) 2017/08/17 09:30:45, 12.3, 20.4
For default Press the side button while setting up the Off-Set feature.
