AT&T WPS1 User manual
Page 1
User’s Manual
WPS1
Waterproof Bluetooth Wireless Speaker
Page 2
Welcome |Thank you for purchasing the WPS1
Introduction
Features
- High powered Bluetooth®waterproof speaker
- Wireless streaming throughBluetooth enabled devices
- Built-in microphone
- Auxiliary input to play music from any device
- Automatically connects to any paired devices
- Hands-free speakerphone
Page 3
What’s included
Micro USB cable
WPS1
Unpack the speaker system and make sure all accessories are put aside
so they will not be lost.
Page 4
Content
Introduction
Features 2
What’s Included 3
Safety Information
Warning! 5
Important Safety Instructions 6
Getting Started
Location of Main Unit Controls 8
Charging the WPS1 9
LED Status Indicator 9
Powering ON/OFF 9
Operational Instructions
Bluetooth Operation 10
Setting up your WPS1 for pairing 10
Using the auxiliary input connection (3.5mm) 11
Function-M 11
Button controls 12
Call function 12
Troubleshooting 12
12
Compliance with FCC Regulations 13
Warranty Information
Limited Warranty 14
Page 5
Safety Information
Warning!
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE
THIS APPLIANCE TO DRIPPINGOR SPLASHING LIQUIDS.
NOTES: Caution symbolsare printed on rear of unit.
Please refer to user’s manual. This device complies with Part 15
of the FCC Rules. Operation is subject to the condition that this
device does not cause harmful interference.
and arrowhead
symbol within
the triangle is
a warning sign
alerting you
of “dangerous
voltage” inside the
product.
The exclamation
point within
the triangle is
a warning sign
alerting you
of important
instructions
accompanying
the product.
WARNING: To
reduce the risk
of electricshock,
do not remove
cover (or back). No
user-serviceable
parts inside. Refer
service personnel.
Page 6
When used in the directed manner, thisunit has been designed and
manufactured to ensure your personal safety. However, improper use
safety and operating instructions carefully before installation and use,
and keep these instructions handy for future reference. Take special
noteof all warnings listed in this user’s manual and onthe unit.
1. Cleaning - Unplug the unit from the wall outlet before cleaning. Clean the
unit using a damp cloth; do not use liquid or aerosol cleaners.
2. Attachments - Do not use attachments that are not recommended by the
manufacturer.
3. Placement - Do not place the unit on an unstabletable, stand, tripod, or
bracket. This may result in seriouspersonal injuries and damage to the unit.
4. Ventilation - The unit should be situated so that itslocation or position
does not interfere with its proper ventilation. For example, it should not be
situated on a bed, sofa, rug or similar surface that may block ventilation
openings. Also, it should not be placed in a built-in installation, such as
ventilation openings.
5. Periods of Non-use -
of time, such as amonth or longer, the power cable should be unplugged
from the unit to prevent damage or corrosion.
6. Power Source - The unit should be connected to a power supply only of the
type described in the operating instructions or as marked on the unit. If you
are not sure, please consult the dealer or local power company.
7. Power Cord protection - Power supply cord should be routed so that it is
not likely to be walked on or pinched by items placed uponor against them.
It isalways better to have aclear area from where the cable exits the unit to
where it is plugged into an AC outlet.
Safety Information
Important Safety Instructions
Page 7
8. Lightning - Unplug the unit from the wall outlet and disconnect theantenna
unused for long periods of time. This will prevent damage to the product due
to lightning and power-line surges.
9. Overloading - Do not overload wall outlets, extension cords, or integral
10. Heat - The unit should be situated away from heat sources such as radiators,
heat.
11. Damage Requiring Service -
personnelwhen:
A. the power supply cable or plug has been damaged.
B. objects have fallen into or liquid has been spilled onto the enclosure.
C. the unit has been exposed to rain.
D. the unit has been dropped or the enclosure damaged.
E. the unit exhibits amarked change in performance or does not operate
normally.
12. Servicing - The user should not attempt to service the unit beyond those
methods described in the user’s manual. Opening or removing covers will
personnel.
13. Safety Check - Upon completion of any service or repair to the unit, ask the
service technician to perform safety checks to determine that the product is
in proper working condition.
14. Built-in Battery Care - This device contains a rechargeableLithium ion
battery. The battery can be charged and discharged hundredsof times.
Unplug the charger from the electrical outlet and product when not in
use. Do not leave a fully charged battery connected to a charger, since
overcharging may shorten its lifetime. Leaving the product in hot or cold
places will reduce the capacity and lifetime of the battery.
Page 8
Getting Started
Location of Main Unit Controls
1. Decrease Volume - |
Skip to previous track
2. LED light - charging
3. Increase Volume + |
Skip to next track
4. Play/Pause Music
5. Mode
6. LED light - Bluetooth indicator
7.
Answer/End Call
8. 3.5mm Aux input
9. Micro USB charging port
Back View
Top View
1 3 4 5 72
89
AUX DC 5V
6
Page 9
Getting Started
Charging the WPS1
1. Connect a Micro USB charging cable to the charging port on
the WPS1.
2. Connect the USB end of the Micro USB cable to your computer’s
USB port or an AC USB adapter.
3. When the speaker is charging, the LED indicator light located on the
top panel of the speaker will turn red.
4.
LED Status Indicator
Bluetooth LED Indicator
-Blinking BlueLED: Bluetooth on with no connection. (Ready to pair)
- Solid Blue LED: Bluetooth paired and connected
Powering ON/OFF
1. To power the speaker on, press and hold thepower button until
you hear anascending audible toneand theBluetooth LED light
starts blinking.
2.
hear a descending audible tone. The Bluetooth LED light will
Page 10
Operational Instructions
Bluetooth Operation
The WPS1 connects with most Bluetooth devices inlcuding iPad®devices,
iPhone®devices, and iPod®touchdevices, and most smartphones,
laptops, and tablets.
Setting Up Your WPS1 for Pairing
1. Turn on the WPS1 wireless speaker
2.
ready to be paired with your Bluetooth device.
Pairing a Bluetooth Device for the First Time
1. Navigate to the Bluetooth manager on your Bluetooth device
2. Search Bluetooth devices and select ‘WPS1’ to start connecting.
3. Once paired, the WPS1 will beep and the Bluetooth LED light will
turn solid blue.
4. Your Bluetooth device is now paired, connected, and ready to
Mode Button
Press theMode (M) button, to toggle betweenBluetooth and Auxiliary
function.
Page 11
Operational Instructions
Using the Auxiliary Input Connection (3.5mm)
You can connect the audio output of an external device, such as a MP3
player or smartphone, to the WPS1 for listening to the audio of that
device through the speaker system.
1. Use a standard stereo headphone (3.5 mm) cable to connect the
“headphone-out” or “audio line-out” of the device to the aux-injack
of this speaker system.
2. Turn on the speaker system and the external device (eg. MP3-player
or smartphone).
3. Make sure the speaker system is not connected to any
Bluetooth devices.
4. Start playback of the external device and adjust the volume of the
docking station to the desired level.
5.
using the external device.
Button Controls
Lower volume
Press and hold |- | button to decrease the volume level
Increase volume
Press and hold | + |button to increase thevolume level
Skip backward
Press the | - | button to skip to the previous track
Skip forward
Press the | + | button to skip to the next track
Call Function
To answer any incoming calls, press the answer call button .
To end the call, press the same button again.
Troubleshooting
Symptom Solution
Music is not streaming over
Bluetooth
- Check if both devices are paired and
connected over Bluetooth.
- Make sure there isn’t a 3.5mm cable
connected to theaux input on the
backof the speaker.
- Restart the WPS1 to auto-connect
with your Bluetooth device.
No power - Recharge your speaker using
included cable. If the problem
cable.
Battery is not charging - Verify WPS1 isplugged in properly
and into a proper power source.
Remarks: If troubleshooting does not eliminate the problem, disconnect the DC IN
Power Output: 3W
Play time: Up to 4-5 hours
Impedance: 4
Rechargeable Battery: 3.7V/1200mAh (Built-In)
Battery charging time: 2-3 hours
Page 12
Compliance with FCC Regulations
Caution!
party responsible for compliance could void the user’s authority to operate the
measures:
-
-
-
-
and operated to provide a separation distance of at least 20 cm from all persons
THE SPECIFICATION AND EXTERNAL APPEARANCE OF THE SPEAKER SYSTEM
ARE SUBJECT TO CHANGE WITHOUT PRIOR NOTICE.
Page 13
Warranty Information
Limited Warranty
The AT&T brands are used under license. Any repair, replacement, or
warranty service, and all questions about this product should be directed
to Concept 101 LLC at www.att.com/electronics or call 1 (888) 920-8680
from the USA or Canada.
Exclusions:
REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS
THE EXCLUSIVE REMEDY OF THE CUSTOMER; Concept 101 LLC SHALL
NOT BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES
FOR BREACH OF ANY EXPRESS OR IMPLIED WARRANTY ON THIS
PRODUCT, EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE
LAW. ANY IMPLIED WARRANTY OF MERCHANTABILITY OF FITNESS
FOR A PARTICULAR PURPOSE ON THIS PRODUCT IS LIMITED TO THE
DURATION OFTHE WARRANTY.
Page 14
1-800-8-BATTERY.
Li-Ion
Some states do not allow the exclusion or limitations of incidental or
consequential damages, or limitations on how long the warranty lasts.
In these cases the above exclusions or limitations may not apply to you.
rights which vary from state to state.
Obtaining Service:
the date of purchase, model number and a brief description ofthe
Page 15
Page 17
www.att.com/electronics
FCCWarningStatement
Changesormodificationsnotexpresslyapprovedbythepartyresponsibleforcompliancecould
voidtheuser’sauthoritytooperatetheequipment.Thisequipmenthasbeentestedandfoundto
complywiththelimitsforaClassBdigitaldevice,pursuanttoPart15oftheFCCRules.These
limitsaredesignedtoprovidereasonableprotectionagainstharmfulinterferenceinaresidential
installation.Thisequipmentgeneratesusesandcanradiateradiofrequencyenergyand,ifnot
installedandusedinaccordancewiththeinstructions,maycauseharmfulinterferencetoradio
communications.However,thereisnoguaranteethatinterferencewillnotoccurinaparticular
installation.Ifthisequipmentdoescauseharmfulinterferencetoradioortelevisionreception,
whichcanbedeterminedbyturningtheequipmentoffandon,theuserisencouragedtotryto
correcttheinterferencebyoneormoreofthefollowingmeasures:
‐‐ Reorientorrelocatethereceivingantenna.
‐‐ Increasetheseparationbetweentheequipmentandreceiver.
‐‐Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthereceiveris
connected.
‐‐ Consultthedealeroranexperiencedradio/TVtechnicianforhelp.
Thisdevicecomplieswithpart15oftheFCCRules.Operationissubjecttothefollowing
twoconditions:(1)Thisdevicemaynotcauseharmfulinterference,and
(2) this device must accept any interference received, including interference that may
cause undesiredoperation.
The device has been evaluated to meet general RF exposure requirement. The device can be used
in portable exposure condition without restriction.
Table of contents
Other AT&T Speakers manuals
