Quick Start Guide
1-Port Modbus Gateway
MODEL：ATC-3002
1
1
1.Check Package Content
■ATC-3002 unit 1Pcs
■ATC-3002 Quick Start Guide 1Pcs
■DC9V Ext power adapter 1Pcs
2
2.Hardware Installation
■Connect an Ethernet cable to ATC-3002 unit if connecting to a
switch or cross-over direct to the PC as Figure 1.
Figure 1
■ATC-3002 10/100 Port t connect to Ethernet card use
coss-Through Cable as Figure 2.
Figure 2
RS-232 Pinout：（DB9 Male)
RS-422/485 Pinout：（Six Terminal from left）
■Connect the power adapter to ATC-3002 and
other apply power. Power from other
device.(+9--+48V).
3
3.LED indication
LINK ——Ethernet interface right light, indicating
Ethernet is established, the green light is
on behalf of the establishment, not bright
or bright yellow on the contrary;
ACT ——Ethernet interface left light, blinking
between the Ethernet port and RS232 /
422/485 data transmission;
TXD —— Blinks when data is sent by the Ethernet
port to the RS232 / 422/485 serial ports;
RXD —— Blinks when data is sent by the RS232 / 422/485 serial
port to the Ethernet port;
PWR—— Power indicator, red light when the power is turned on.
4
4.Software Installation
■None
5
5.Configure the ATC-3002
■Use this section to set up your computer to assign it a static IP
address in the 192.168.2.1 to 192.168.2.254 range with a subnet
mask of 255.0.0.0. The default IP address of ATC-3002 is
192.168.2.3, the computer IP user can not set this value,
otherwise it will cause IP address conflict.
This is necessary to ensure that your computer can communicate
with your ATC-3002. Your computer must have an Ethernet card
and TCP/IP installed. TCP/IP should already be installed on
computer using Windows 98/2000/XP and later operating
systems.
■Open your web browser and type http://192.168.2.3 in the browser’s
address box. This address is the factory set IP Address of your
ATC-3002. Press “Enter”.
Figure 3
Terminel
No.
1
2
3
4
5
6
RS-422
T+
T-
R+
R-
VCC
GND
RS-485
485+
485-
/
/
VCC
GND
（DB9 Male）
Signal
I/O
PIN2
RXD
IN
PIN3
TXD
OUT
PIN5
GND
-

The “Username and Password required” prompt box will appear. The
default user name and password is null, do not need to fill in, just click OK
to enter the page.(Figure 3)
■Set the serial communication parameters and Mosbus protocol
It supports three serial protocols: RS232, RS485, RS422;
Serial communication parameter defaults to 9600,8, N, 1;
Default Modbus protocol Modbus RTU, Modbus Ascii user can
change the protocol according to their needs;
Other parameters is recommended to use the default values;
Then Click OK, and then click Apply Settings, modify the previous
settings to take effect; when you need to modify the parameters
have to click OK and then click Apply Settings, wait a few seconds to
complete the modification ATC-3002 after modifying.(Figure 4)
Figure 4
■Setting Mosbus connection
Figure 5
Use ATC-3002 as a slave, Connect protocol in
the protocol option to select Default Modbus / TCP
Server attached to slave (s).(Figure 5)
Figure 6
ATC-3002 when used as a master, Connect protocol option to
select the protocol Modbus / TCP Client attached to master,
Modbus / TCP Port default 502, Uint ID to IP Address Mapping
set as the slave can enter the user's device IP address and ID
number. Then click OK, then Apply Settings wait a few seconds to
complete the setting changes.
■Setting RS485、RS422
If the user is using a serial interface RS485 or RS422, will be
needed in the Configurable Pins CP2 is set to RS485 Tx Enable,
Active level is set to High, and then click OK, Apply Settings wait
a few seconds to complete the setting changes.(Figure 7)
Figure 7
Note: After the success of the user to modify the parameters,
some browsers still display parameters did before the amendment,
refresh the page is still valid, it is recommended to re-login
ATC-3002 Web Configuration address 192.168.2.3 user closes
the browser (recommended IE browser or 360 browser).
