ATD Tools 5951 User manual

REV03‐13
ATD‐5951
400WATTINVERTER
•Forusewith12Vsystems
•InputDCvoltagerange:DC10V‐15V
•Overloadandshort‐circuitprotection
•Built‐incoolingfan
•(2)110VAC3‐pronggroundedreceptaclesandoverloadindicator
•Modifiedsinewave
•(1)replaceable40Ampfuse
•Cigarettelighterandbatteryhookupcablesincluded
•14AWG24"cigaretteplugcable(black/red)withbatteryclamp
•MaximumContinuousPower:400W
•PeakLoadPowerRate:Upto800W
•NoLoadCurrentDraw:Upto0.5Amps



REV03‐13
Welcome
ThisATDproducthasbeencarefullyengineeredandmanufacturedtogiveyoudependableoperation.Pleaseread
thismanualthoroughlybeforeoperatingyournewATDproduct,asitcontainstheinformationyouneedto
becomefamiliarwithitsfeaturesandobtaintheperformancethatwillbringyoucontinuedenjoymentformany
years.Pleasekeepthismanualonfileforfuturereference.
AboutATDInverters
ATD,aninnovatorinportableinverterdesign,hasdevelopedanewlineofsuper‐efficientpowerinverterswiththe
highestsurgecapabilityintheindustry.Theseextremelyadvanced,microprocessorcontrolledunitsruncoolerand
morereliablethananyintheirclass.Theirsuperiorsurgecapabilityallowsthemtostarteventhemostdifficult
loads,includingcolortelevisions,TV/VCRcombinations,microwaves,refrigerationunits,evensmallair
conditioners!Theyalsohavethehighestefficiencyavailable(upto90%)whichtranslatesintolongerrunningtime
andextendedbatterylife.
Invertersconvertlowvoltage,directcurrent(DC)to110‐voltalternatingcurrent(AC).Dependingonthemodel
anditsratedcapacity,theinvertersdrawpowereitherfromstandard12voltautomobileandmarinebatteriesor
fromportablehighpower12voltsources.

GeneralSafetyWarnings
WARNING:Theinstructionsandwarningscontainedinthismanualshouldbereadandunderstood
beforeusingoroperatingthisunit.Donotallowanyonetouseoroperatethisunituntiltheyhavereadthis
manualandhavedevelopedathoroughunderstandingofhowthisunitworks.Failuretoobserveanyofthe
followinginstructionscouldresultinseverepersonalinjurytounituserandbystanders,orcausedamagetothe
unitandproperty.Keepthismanualforfuturereference.
Note:Thewarningsandcautionsdiscussedinthisinstructionmanualcannotcoverallpossibleconditions
andsituationsthatmayoccur.Itmustbeunderstoodbytheoperatorthatcommonsenseandcautionarefactors
whichcannotbebuiltintothisproduct,butmustbesuppliedbytheoperator.
WARNING:Donotoperate,setuporpluginthistoolifyouaretiredorundertheinfluenceofalcohol,
drugs,ormedicationsthatcouldaffectyourabilitytousethetoolproperly.
WARNING:Dressproperly.Donotwearlooseclothingorjeweleryastheycanbecaughtinmovingparts.
Wearrestrictivehaircoveringtocontainlonghair.
WARNING:Donotreachoveroracrossrunningmachines.Keepproperfootingandbalanceatalltimes.
Non‐skidfootwearisrecommendedwhenworking.




REV03‐13
LeadAcidBatterySafetyWarnings
CAProp65WARNING:
BatteriescontainleadandotherchemicalsknowntotheStateofCaliforniatocausecancer,birthdefectsand
otherreproductiveharm.Washhandsafterhandling.

WARNING:WORKINGAROUNDLEAD‐ACIDBATTERIESMAYBEDANGEROUS.
•Lead‐acidbatteriesreleaseexplosivegasesduringnormaloperation,chargingandjumpstarting.
•Alllead‐acidbatteries(car,truckandboat)producehydrogengaswhichmayviolentlyexplodeinthe
presenceoffireorsparks.Donotsmoke,usematchesoracigarettelighterwhilenearbatteries.
•Onlyworkwithlead‐acidbatteriesinawell‐ventilatedarea.Donothandlethebatterywhilewearing
vinylclothingbecausestaticelectricitysparksaregeneratedwhenvinylclothingisrubbed.
•Toreduceriskofbatteryexplosion,followtheseinstructionsandthosepublishedbythebattery
manufacturerandmanufacturerofanyequipmentyouintendtouseinthevicinityofthebattery.Review
cautionarymarkingsontheseproductsandonengine.

EYEPROTECTION:
•Userandbystandersshouldalwaysweareyeprotection,appropriateprotectiveclothingandothersafety
equipmentwhenworkingnearlead‐acidbatteries.Donottoucheyeswhileworkingonoraroundlead‐
acidbatteries.
•IFSPLASHEDWITHBATTERYACID,IMMEDIATELYFLUSHAFFECTEDAREASUCHASFACEAND
PARTICULARLYTHEEYESWITHCLEANWATER.SEEKMEDICALATTENTIONANDCONTINUEFLUSHING
FACEANDEYESUNTILMEDICALHELPARRIVES.

WORKINGINENGINECOMPARTMENT:
•Useextremecautionwhileworkingwithintheenginecompartment,becausemovingpartsmaycause
severeinjury.Readandfollowallsafetyinstructionspublishedinthevehicle’sOwner’sManual.

GENERALPRECAUTIONS/PERSONALPRECAUTIONS:
•Neverworkalonewithlead‐acidbatteries.Makesurethatsomeoneisaroundtogiveassistanceifyou
needhelp.
•Wearcompleteeyeprotectionandclothingprotection.Avoidtouchingeyeswhileworkingnearbattery.
•Incaseofbatteryacidcontactwitheyes,skinorclothing,alwayshavesoapandwaternearyourwork
area.
•Removejewelerysuchasrings,bracelets,necklacesandwatcheswhenworkingaroundabattery.A
lead‐acidbatterycanproduceashortcircuitcurrent,whichcanmeltmetalsandresultinasevereburn.
•Donotdroptoolsorothermetalobjectsonornearthebatteryasasparkmayresult,ignitingexplosive
gases.
•Neverjumpstartorattempttorechargeafrozenbattery.




REV03‐13
ElectricalSafetyWarnings
WARNING:Readallsafetywarningsandinstructions.Failuretofollowallwarningsandinstructionsmay
resultinelectricshock,fireand/orseriousinjuryordeath.
WARNING:Beforeconnectingatooltoapowersupply,alwayschecktoensurethepowersupply
correspondstothevoltageonthenameplateofthetool.Apowersupplywithavoltagegreaterthanthat
specifiedforthetoolcanresultinseriousinjurytotheuser,aswellasdamagetothetool.Usingapowersupply
withavoltagelessthanthenameplateratingisharmfultothemotor.Ifindoubt,donotpluginthetool.
WARNING:Groundedtoolsmustbepluggedintoanoutletproperlyinstalledandgroundedin
accordancewithallcodesandordinances.Thistoolisequippedwitha3‐prongpluganda3‐wiregrounding
system.Neverremovethegroundingprongormodifythepluginanyway.Donotuseanyadapterplugs.Check
withaqualifiedelectricianifyouareindoubtastowhethertheoutletisproperlygrounded.
NOTE:Doubleinsulatedtoolsareequippedwithapolarizedplug(onebladeiswiderthantheother).This
plugwillfitinapolarizedoutletonlyoneway.Iftheplugdoesnotfitfullyintheoutlet,reversetheplug.Ifitstill
doesn’tfit,contactaqualifiedelectriciantoinstallapolarizedoutlet.Donotchangethepluginanyway.
WARNING:Toreducetheriskofelectricshock,DONOTuseindampconditions,onwetsurfaces,or
exposetorain.Donotpluginthistooloroperateitwithwethandsorwhilestandinginwater.
WARNING:Neverusethecordforcarrying,pullingorunpluggingthepowertool.Graspplugandpullto
disconnectfromoutlet.Keepcordawayfromheat,oil,sharpedgesormovingparts.Replacedamagedcords
immediately.
WARNING:Donotcarrythepowertoolwithyourfingerontheswitch.Ensuretheswitchisintheoff
positionbeforepluggingthetoolintothepoweroutlet.Intheeventofapowerfailurewhileatoolisbeingused,
turntheswitchofftopreventsurprisestartingwhenthepowerisrestored.
WARNING:Alwaysremovethepowercordfromtheelectricoutletwhenmakingadjustments,changing
parts,cleaningorworkingonthetool.
WARNING:Careshouldbetakentoarrangethecordsoitwillnotbesteppedon,trippedover,or
otherwisesubjectedtodamageorstress.
WARNING:Neverattempttopluginoroperateequipmentwithdefectiveordamagedwires,powercord
orpowercordplug.Haveanydefectiveordamagedpartsreplacedimmediatelybyqualifiedpersonnel.
WARNING:Avoidbodycontactwithelectricallygroundedsurfaces.Thereisanincreasedriskofelectric
shockifyourbodyisgrounded.




REV03‐13
ElectricalSafetyWarnings(Continued)
WARNING:IftheworkareaisnotequippedwithapermanentlyinstalledGroundFaultCircuitInterrupter
outlet(GFCI),useaplug‐inGFCIbetweenthepowertoolorextensioncordandthepowerreceptacle.

WARNING:Ifanextensioncordisnecessary,useonly‘Listed’extensioncords.Ifusedoutdoors,they
mustbemarked“ForOutdoorUse”.Thosecordshavinga3‐pronggroundingtypeplugsandmatingreceptacles
aretobeusedwithgroundedtools.
WARNING:Useofimpropersizeorgaugeofextensioncordmaycauseunsafeorinefficientoperationof
yourtool,orcausedamagetoyourtool.Besureyourextensioncordisratedtoallowsufficientcurrentflowto
themotor.Ifindoubt,alwaysusealargergaugecord.Besuretocheckthevoltagerequirementsofthetoolto
yourincomingpowersource.
NOTE:Thetablebelowshowsthecorrectsizetouseaccordingtocordlengthandtheamperagedrawof
thetool(specifiedonthenameplate).Whenindoubt,usethenextheaviergauge.Thesmallerthegauge
number,theheavierthecord.(AWG=AmericanWireGauge).

MinimumGaugeforExtensionCords(AWG)
(whenusing120voltsonly)
AmpereRatingTotalLengthofCordinFeet(meters)
MoreThanNotMoreThan25'(7.6m)50'(15m)100'(30.4m)150'(45.7m)
0618161614
61018161412
101216161412
12161412NotRecommended



InverterSafetyWarnings
WARNING:ReadalltheCautionsandWarningsbeforeinstallingandusingthepowerinverter.The
invertermustbeproperlyinstalled.Ifyouarenotfamiliarwith12volthighcurrentwiring,itisrecommendedthat
youhaveaprofessionalautomotiveinstallerinstalltheinverter.Failuretofollowallwarningsandinstructions
mayresultinelectricshock,fireand/orseriousinjuryordeath.
WARNING:Thepowerinvertergenerates115VACpowerfromyour12voltcarbattery.Treatthe115
VACoutputjustlikeyoutreatthe115VACinyourhouse.Keepchildrenawayfromtheunit.
WARNING:ATDTools,Inc.doesnotauthorizeorrecommendthisinverteroranyrelatedproductstobe
usedwithlifesupportdevicesorsystems.


REV03‐13
InverterSafetyWarnings(Continued)
WARNING:Handlingthecordonthisproductorcordsassociatedwithaccessoriessoldwiththisproduct,
mayexposeyoutolead,achemicalknowntotheStateofCaliforniatocausecancerandbirthdefectsorother
reproductiveharm.Washhandsafterhandling.
WARNING:Withuse,theinverterwillbecomewarmandpossiblyhot.Keepitawayfromanyheat
sensitivematerials.Makesuretheinverterisnotclosetoanypotentialsourceofflammablefumes,gasesor
clothing.Keeptheunitawayfromflammablematerialorinanylocationwhichmayaccumulateflammablefumes
orgases,suchasthebatterycompartmentofyourcar,boat,RVortruck.
WARNING:Donotoperatetheunitinanenclosedareathatcontainsautomotivetypelead‐acidbatteries.
Thistypeofbatteryemitsexplosivehydrogengasthatcanbeignitedbysparks.
WARNING:Donotusetheinverternearanopenenginecompartment.
WARNING:Keeptheinverterdry.DONOTallowtheinvertertocomeintocontactwithrainormoisture.
DONOToperatetheinverterifyou,theinverter,thedevicebeingoperatedoranyothersurfacesthatmaycome
incontactwithanypowersourcearewet.Waterandmanyotherliquidscanconductelectricity,whichmaylead
toseriousinjury.
WARNING:DonotconnecttheunittoACdistributionwiring.
WARNING:Onlyconnectthepowerinvertertoa12‐voltbatteryaccessoryoutletor12‐voltbattery.Make
suretheACplugconnectionistight.DonotmodifytheACreceptacleinanyway.
WARNING:Donotplacetheinverterindirectsunlight.Keeptheunitincoolenvironments.Theidealair
temperatureforoperationisbetween50°and80°F.Keepoutofdirectsunlightandawayfromheatingvents,
radiatorsorothersourcesofheat.Keeptheinverterwellventilatedinordertoproperlydisperseheatgenerated
whileitisinuse.Makesurethereareseveralinchesofclearancearoundthetopandsidesanddonotblockthe
slotsoftheinverter.
WARNING:Donotopentheunit.Highvoltagesarepresentinside.
WARNING:Usepropersizewiring.Highpowerinverterscandrawmanyampsfromthe12voltsourceand
canmeltwiresifnotfusedandsizedproperly.
WARNING:Somechargersforsmallnickel‐cadmiumbatteriescanbedamagedifconnectedtotheunit.
Donotusetheunitonsmallbattery‐operatedappliancessuchasflashlights,razorsandnightlightsthatcanbe
pluggeddirectlyintoanACoutlettorecharge.Alsodonotusetheunitoncertainbatterychargersforbattery
packsusedinhandpowertools.
Thesechargerswillhaveawarninglabelindicatingthatdangerousvoltagesarepresentatthebatteryterminals.
WARNING:ThisdevicedoesnotincludeaninternalGroundFaultCircuitInterrupter(GFCI).

REV03‐13
GettingStarted
Whenyouturnonanapplianceoratoolthatoperatesusingamotorortubes,itrequiresaninitialsurgeofpower
tostartup.Thissurgeofpowerisreferredtoasthe"startingload"or"peakload".Oncestarted,thetoolor
appliancerequireslesspowertocontinuetooperate.Thisisreferredtoas"continuousload"intermsofpower
requirements.Youwillneedtodeterminehowmuchpoweryourtoolorappliancerequirestostartup(starting
load)andit'scontinuedrunningpowerrequirements(continuousload).Powerconsumptionisratedeitherin
wattage(watts)orinamperes(amps)andthisinformationisusuallystampedorprintedonmostappliancesand
equipment.Ifthisinformationisnotindicatedontheapplianceorequipment,checktheowner'smanualor
contactthemanufacturertodetermineifthedeviceyouareusingiscompatiblewithamodifiedsinewavesource.

Multiply:AMPSX110(ACvoltage)=WATTS
ThisformulayieldsacloseapproximationofthecontinuousloadofyourAppliance

Multiply:WATTSX2=StartingLoad
Thisformulayieldsacloseapproximationofthestartingloadofyourappliance.Mostoftenthestartuploadof
theapplianceorpowertooldetermineswhetheryourinverterhasthecapabilitytopowerit.

Todeterminewhethertheinverterwilloperateaparticularpieceofequipmentorappliance,runatest.The
invertersaredesignedtoautomaticallyshutdownintheeventofapoweroverload.Thisprotectionfeature
preventsdamagetotheunitwhiletestingappliancesandequipmentwithratingsinthe200wattrange.

Ifanapplianceinthe200wattrangewillnotoperateproperlywhenfirstconnectedtotheinverter,turnthe
inverterrockerswitchON(I),OFF(O),andON(I)againinquicksuccession.Ifthisprocedureisnotsuccessful,itis
likelythattheinverterdoesnothavetherequiredcapacitytooperatetheapplianceinquestion.

Important
•Theinverterisdesignedtooperatefroma12‐voltpowersourceonly.Donotattempttoconnectthe
invertertoanyotherpowersource,includinganyACpowersource.
•Donotattempttoextendorotherwisemodifythe12‐voltpowercordattachedtoyourinverter.
•110voltsofcurrentcanbelethal.Improperuseofyourinvertermayresultinpropertydamage,personal
injuryorlossoflife.













REV03‐13













ConnectingYourInverter
1. MakesuretheON/OFFrockerswitchlocatedonthefrontpaneloftheinverterisintheOFF(0)position.
2. Removeyourcigarettelighterandpushthe12voltpowerplugfirmlyintothecigarettelighterreceptaclein
yourvehicle.
3. TurntheinverterrockerswitchtotheON(I)position.TheGREENLEDIndicatorlightshouldglow,confirming
thatthereispowerrunningtotheinverter.
4. ConfirmthattheappliancetobeoperatedisturnedOFF.TurntheinverterrockerswitchtotheOFF(0)
position.PlugtheapplianceintotheACreceptacleonthefrontpaneloftheinverter.
5. TurntheinverterrockerswitchtotheON(I)position.Turntheequipmentorapplianceon.
Note
•Useofanextensioncordfromtheinvertertotheapplianceorequipmentbeingoperatedwillnot
significantlydecreasethepowerbeinggeneratedbytheinverter.Forbestoperatingresults,theextension
cordshouldbenomorethan50feetlong.
•IfthegreenLEDblinkswhenyoufirstturntheinverterON,thisindicatesthatthereisashortcircuitwithin
thepowersupply.TurntheinverterOFF.Removethe12voltplugfromthecigarettelightersocket,firmly
•Reinserttheplug,andthenturntheinverterONagain.Ifthisdoesnotremedytheproblemtryusinga
different12voltpowersource.


REV03‐13
TelevisionandAudioSuggestions
Althoughtheseinvertersareshieldedandfilteredtominimizesignalinterference,someinterferencewithyour
televisionpicturemaybeunavoidable,especiallywithweaksignals.However,herearesomesuggestionsthatmay
improvereception.
1. First,makesurethattelevisionantennaproducesaclearsignalundernormaloperatingconditions(i.e.,at
homepluggedintoastandard110VACwalloutlet).Also,ensurethattheantennacableisproperlyshielded
andofgoodquality.
2. Changethepositionsoftheinverter,antennacablesandtelevisionpowercord.
3. Isolatethetelevision,itspowercordandantennacablesfromthe12‐voltpowersourcebyrunningan
extensioncordfromtheinvertertothetelevisionset.
4. Coilthetelevisionpowercordandtheinputcablesrunningfromthe12‐voltpowersourcetotheinverter.
5. Attacha"FerriteDataLineFilter"tothetelevisionpowercord.Morethanonefiltermayberequired.These
filtersareavailableatmostelectronicsupplystores.
Note
•Inexpensivesoundsystemsmayemita"buzzing"soundwhenoperatedwiththeinverter.Thisisdueto
inadequatefiltersinthesoundsystem.Thereisnosolutiontothisproblemshortofpurchasingasound
systemwithahigherqualitypowersupply.
BlownAutomotiveFuses
Dependingonthemakeandmodelofyourautomobile,runningthepowerinverternearfullcapacityfromyour
cigarettelighterportmayresultinablownautomotivecigarettelighterfuse.Thisfusewillneedtobereplaced
withthesamesizefuse.Pleasenote,ablownautomotivefusewillnotcausedamagetoyourcarwiring.Toavoid
blowinganautomotivefuseinthissituation,donotoperatethepowerinverterover200wattsforextended
periodsoftimefromyourcigarettelighteror12voltpowerport.
BlownPowerInverterFuses
Yourpowerinverterisequippedwitha20‐ampspadetypefuse.Withreasonablecareitshouldnotbenecessary
toreplacethesefuses.Mostblownfusesaretheresultofreversepolarityorashortcircuitwithintheapplianceor
equipmentbeingoperated.Ifthefusehappenstoblow,disconnecttheapplianceorequipmentimmediately,find
thesourceoftheproblem,repairit,andtheninstallanewfuse.
SourceofPower
Mostautomobileandmarinebatterieswillprovideanamplepowersupplytotheinverterfor30to60minutes
evenwhentheengineisoff.Actualtimemayvarydependingupontheageandconditionofthebattery,andthe
powerdemandbeingplacedonitbytheequipmentbeingoperatedwiththeinverter.
Ifyoudecidetousetheinverterwhiletheengineisoff,werecommendthatyoustarttheengineeveryhourand
letitrunforapproximately10minutestorechargethebattery.Wealsorecommendthatthedevicepluggedinto
theinverterbeturnedOFFbeforestartingthevehicleengine.
Althoughitisnotnecessarytodisconnecttheinverterwhenturningovertheengine,itmaymomentarilyceaseto
operateasthebatteryvoltagedecreases.
Whentheinverterisnotsupplyingpower,itdrawsverylowamperagefromthebatteryandmaybeleftconnected
tothebatteryforuptothreehours.
However,werecommendtheinverteralwaysbedisconnectedwhennotinuse.

REV03‐13
InverterProtectionFeatures
TheREDLEDIndicatorlightwillturnonandtheinverterwillturnitselfoffautomaticallywhen:
1. Thepowerinputfromthebatterydropsto9.5volts.(Whenthepowerinputdropsto10.5volts,analarmwill
soundforanextendedperiod).
2. Thepowerinputfromthebatteryexceeds15.5volts.
3. Thecontinuousdrawoftheequipmentorappliancebeingoperatedexceeds200watts.
4. Thesurgedrawoftheequipmentorappliancebeingoperatedexceeds400watts.
5. Thecircuittemperatureexceeds165°F.
Note
•Theinverterisequippedwithacoolingfanwhichisdesignedtoruncontinuouslywhiletheinverteris
operating.Automaticshutdowncausedbyhighcircuittemperatureswilloccurwhenthecoolingfanis
unabletomaintainacoolenoughtemperatureforsafeoperationoftheinverter.
•Intheeventofautomaticshutdownorcontinuousaudiblealarm,turntheinverterrockerswitchtothe
OFF(0)positionuntilthesourceoftheproblemhasbeendeterminedandresolved.
HowPowerInvertersWork
Therearetwostagesinwhichapowerinverterchangesthe12‐voltDC(orbattery)powerinto110VAC
(householdcurrent).

STAGE1:
TheinverterusesaDC‐to‐DCconvertertoincreasetheDCinputvoltagefromthepowersourceto145voltsDC.

STAGE2:
TheinverterthenconvertsthehighvoltageDCinto110VAC(householdcurrent),usingadvancedMOSFET(Metal‐
oxide‐SemiconductorFieldEffectTransistor)transistorsinafullbridgeconfiguration.Thisdesignprovidesallour
inverterswiththecapabilitytostartandrundifficultreactiveloads,whileprovidingexcellentoverloadcapability.
Thewaveformthatisgeneratedbythisconversionisa"modifiedsinewave"asshowninthediagrambelow.
 


Themodifiedsinewaveproducedbyourinvertershasarootmeansquare(RMS)voltageof110volts.The
majorityofACvoltmetersarecalibratedforRMSvoltageandassumethatthemeasuredwaveformwillbeapure
sinewave.Consequently,thesemeterswillnotreadtheRMSmodifiedsinewavevoltagecorrectlyand,when
measuringtheinverteroutput,themeterswillreadabout20to30voltstoolow.Toaccuratelymeasureofthe
outputvoltageoftheinverter,useatrueRMSreadingvoltmetersuchasaFluke87Fluke8060ABeckman4410,
Triplet4200oranymultimeteridentifiedas"TrueRMS"


REV03‐13
InReview
•Neverattempttooperatetheinverterfromanypowersourceotherthana12‐voltDCvoltbattery.
•Theinverterisdesignedtobeconnectedtothepowersourcewiththe12voltpowerplug.Donotattemptto
modifythepowercordorplug.
•Whileconnectingtheinvertertothepowersource,makecertainthattheinverterispositionedfarawayfrom
anypotentialsourceofflammablefumesorgases,
•Makecertainthepowerconsumptionoftheapplianceorequipmentyouwishtooperateiscompatiblewith
thecapacityoftheinverter.Donotexceed400watts.
•Whenattemptingtooperatebatterychargers,monitorthetemperatureofthebatterychargerfor
approximately10minutes.Ifthebatterychargerbecomesabnormallywarm,disconnectitfromtheinverter
immediately.
•Useonly40ampspadetypefuses.
•Whenoperatingtheinverterwithanautomobileormarinebattery,starttheengineevery30to60minutes
andletitrunforapproximately10minutestorechargethebattery.
•Intheeventofacontinuousaudiblealarmorautomaticshutdown,turntheinverterOFFimmediately.Donot
restarttheinverteruntilthesourceoftheproblemhasbeenidentifiedandcorrected.
•Toavoidbatterydrain,alwaysdisconnecttheinverterwhennotinuse.
•Donotexposetheinvertertorainormoisture.
•Avoidplacingtheinverternearsourcesofheatorindirectsunlight.
•Whileinuse,makesuretheinverterisproperlyventilated.
•Donotoperatetheinverternearflammablematerials,fumesorgases.


TROUBLESHOOTING:
PROBLEM:LoworNoOutputVoltage

?Reason:Poorcontactwithlightersocketorbatteryclamps 
9Solution:Unplugandreinsert12voltplugorreattachbatteryclamps.

?Reason:Usingincorrecttypeofvoltmetertotestoutputvoltage.
9Solution:UsetrueRMSreadingmeter.

PROBLEM:RedLEDIndicatorOn
_____
?Reason: Batteryvoltagebelow9.5volts.
9Solution:Rechargeorreplacebattery.
_____
?Reason: Equipmentbeingoperateddrawstoomuchpower.
9Solution:Useahighercapacityinverterordonotusethisequipment.

REV03‐13
PROBLEM:RedLEDIndicatorOn(Continued)
_____
?Reason: Inverteristoohot(thermalshutdownmode).
9Solution:Allowinvertertocool.Checkforadequateventilation.
Reducetheloadontheinvertertoratedcontinuouspoweroutput.
_____
?Reason: Unitmaybedefective.
9Solution:SeeWarrantyandcallcustomerservice.

PROBLEM:TVInterference

?Reason:Electricalinterferencefromtheinverter.
9Solution:AddaferritedatalinefilterontotheTVpowercord.
RefertoTV&Audiosectionofthismanual.

PROBLEM:LowBatteryAlarmOnAllTheTime

?Reason:Inputvoltagebelow10.5volts.
9Solution:Keepinputvoltageabove10.5voltstomaintainregulation.

?Reason:Poororweakbattery.
9Solution:RechargeorReplacebattery.

?Reason:Inadequatepowerbeingdeliveredtotheinverterorexcessivevoltagedrop
9Solution:Checkconditionofcigarettelightersocket.Cleanorreplaceifnecessary,orcheck
cableclampconnections.


PROBLEM:TVDoesNotWork

?Reason:TVdoesnotturnon.
9Solution:TryturningtheinverterON/OFF/ON.ContactTVmanufacturerforstartupsurgespecifications
and/ortoseeiftheTViscompatiblewithamodifiedsinewave.Alargerinvertermayberequired.






REV03‐13
SPECIFICATIONS
Max.ContinuousPower...............................................................400Watts
SurgeCapability(PeakPower).....................................................800Watts
NoLoadCurrentDraw.................................................................0.5A
Waveform...................................................................................ModifiedSineWave
InputVoltageRange....................................................................DC10‐15V
ACReceptacles...........................................................................110VAC3pronggrounded
Fuse...........................................................................................40amp(spadetype)
Dimensions…………………………………………………………………………………….6.42”x4.96”x2.05”(163mmx126mmx52mm)
Weight…………………………………………………….………...….……...................2Ibs(0.90kg)


PowerCordSpecification
1pc18AWGx2c(Black)withcigaretteplug
1pc14AWGx2c(Black)withBatteryClamp(Black,Red)


InverterCables
200W&400WInverterscomewithacigarettelighterplug/cable&clamponbatterycables.
800WORGREATERMUSTBEHARDWIREDTOBATTERY.

*USETHETHICKESTWIREAVAILABLEINTHESHORTESTLENGTHPRACTICAL
Wattage 0'-4' Length 5'-10' Length
800W #2 AWG #0 AWG
1000W #0 AWG #2/0 AWG
1500W #0 AWG #2/0 AWG
2000W #2/0 AWG #4/0 AWG
3000W #2/0 AWG #4/0 AWG
6000W #2/0 AWG #4/0 AWG

REV03‐13
WARRANTY
1YEARREPLACEMENTWARRANTY

THISWARRANTYANDCONFIRMEDRECEIPT(S)SHOULDBERETAINEDBYTHECUSTOMERATALLTIMES
Thewarrantyisonlymadeavailablebyreturningtheproducttothepointofsale.

PURCHASEDFROM:________________________________________________

DATEPURCHASED:________________________________________________

INVOICE/RECIEPTNUMBER:_________________________________________

YourATD‐5950iswarrantedforaperiodof12monthsfromtheoriginaldateof.Anyconsumableitems,suchascarbon
brushes,batteries,drillanddriverbitsandchucksarecoveredbya90daywarranty.Thiswarrantyisvalidfordefectsin
workmanshipormaterialsonly,andishandledatthepointofsale.

Thewarrantygivenonthistoolisagainstdefectsinworkmanshipandmaterialsonly.Anymisuse,abuseoraccidental
damageisnotcoveredbywarranty.Thefollowingactionswillalsoresultinthewarrantybeingvoid:

•Ifthetoolhasbeenoperatedonasupplyvoltageotherthanthatspecifiedonthetool.
•Ifthetoolshowssignsofdamageordefectscausedbyorresultingfromabuse,accidentsoralterations.
•Ifthetoolisdisassembledortamperedwithinanyway.

Note:Warrantyexcludesconsumablepartssuchascarbonbrushes,batteries,drillanddriverbitsandchucks.











[Affixreceiptorinvoicehereforsafekeeping]
