ATD‐3305
10PRADIATORPRESSURE
TESTERADAPTERUPDATE*KIT
*ForusewiththeATD‐3300set

SAFETYWARNINGANDPRECAUTIONS
GeneralSafetyWarnings:
WARNING:Theinstructionsandwarningscontainedinthismanualshouldbereadandunderstoodbeforeusing
oroperatingthistool.Donotallowanyonetouseoroperatethistooluntiltheyhavereadthismanualandhave
developedathoroughunderstandingofhowthistoolworks.Failuretoobserveanyofthefollowinginstructionscould
resultinseverepersonalinjurytotooluserandbystanders,orcausedamagetothetoolandproperty.Keepthismanual
forfuturereference.
Note:Thewarningsandcautionsdiscussedinthisinstructionmanualcannotcoverallpossibleconditionsand
situationsthatmayoccur.Itmustbeunderstoodbytheoperatorthatcommonsenseandcautionarefactorswhich
cannotbebuiltintothisproduct,butmustbesuppliedbytheoperator.
WARNING:Usesafetyequipment.Userandbystandersshouldusesafetygogglesorsafetyglasseswithsideshields
whichcomplywithcurrentnationalstandards,orwhenneeded,afaceshield.UseanANSIapproveddustmaskorrespirator
whenworkingaroundmetal,wood,andchemicaldustsandmists.Thisappliestoallpersonsintheworkarea.Alsouse
non‐skidsafetyshoes,hardhat,gloves,dustcollectionsystems,andhearingprotectionwhenappropriate.
WARNING:Keepbystandersandchildrenoutoftheworkareawhileoperatingthistool.
WARNING:Alwayskeepyourworkareaclean,uncluttered,andwelllit.Clutteredordarkareasinviteaccidentsand
injuries.DONOTworkonfloorsurfacesthatareslippery.
WARNING:Donotoperatethistoolifyouaretiredorundertheinfluenceofalcohol,drugs,ormedicationsthatcould
affectyourabilitytousethetoolproperly.
WARNING:Dressproperly.Donotwearlooseclothingorjeweleryastheycanbecaughtinmovingparts.Wear
restrictivehaircoveringtocontainlonghair.
WARNING:Donotreachoveroracrossrunningmachines.Keepproperfootingandbalanceatalltimes.Non‐skid
footwearisrecommendedwhenworking.
OPERATINGINSTRUCTIONS:
•Beforeperformingthetestonyourcoolingsystem,testthepump(SuppliedseparatelywiththeATD‐3300orATD3301
sets)firstbypumpingfewtimestoensurethepumpisworkingcorrectly.Whentesting,DONOTpumpover20PSI.
•Duringyourinspectionandduringthetestofyourcoolingsystem,whenpumpingthepumphandle,alwaysmakesure
thattheforceisappliedstraightintothepumpratherthanatanangle,orelseitmaythepumptoleak.(SeeFigure1)

TOTESTFORLEAKSINCOOLINGSYSTEM:
1. Refertothevehicle’sservicemanualforanyspecificradiatorpressuretestinginstructions.
2. Loosenthevehicle’sradiatorcapslowlytorelieveanyexcesspressurebeforeremovingthecapcompletely.NEVEROPEN
THESYSTEMWHILEHOT,asthismaycausepersonalinjury.
3. Selecttheproperadapterandconfigurationofthestationaryseataccessories.Securelyattachtheadaptertothefiller
neckoftheradiatororexpansiontank.
4. Attachthequickconnectorofthehandpumpontotheadapter.
5. Rapidlypumpthehandpumphandleusingstraightforceasshowninfigure1whilewatchingthepressuregauge.
Pressurizetheradiatoruptotheoptimalpressureonly‐DONOTOVERPRESSURIZETHERADIATOR.Idealreadings
shouldrangebetween15‐20PSI(1.03‐1.37BAR).
•Needleholdssteady–Ifgaugehandholdsatthesamepressurenumberfor2minutes,therearenoseriousleaksin
thesystem.
•Needledropsslowly–Indicatesthepresenceofthesmallleaksorseepage.
•Needledropsquickly–Indicatesseriousleakageispresent.
6. Oncethetestiscomplete,releasetheairpressurebydepressingthepressurereleasevalveonthehandpump.Then
disconnectthequickcouplerandadapterassembly.
7. Maintenances–AftertestingprocessinRadiatorTest:
•Keeptheadaptorconnectedtothepumpasyouhadsetupwhileperformingtheactualtest.Operatethepump
severaltimestodissipatemoistureand/orcoolantthatmayhaveremainedintheadaptorandpump.
•Oilthehandpumpinordertolubricatethepistonandpreventcorrosionandinternaldamage.
8. Storetheradiatorpressuretesterkitinitscarryingcaseandkeepthekitinaclean,dry,safelocationoutofreachof
childrenandotherunauthorizedpersons.
TOTESTFORLEAKSINORIGINALRADIATORCAP:
1. Choosethecorrectradiatorcapconnector(5Aor5B)andcorrectsteelradiatorcap(#02,#03,or#04)forthecorrect
vehiclebeingtestedfromthetestkit.Fastentheoriginalradiatorcaptotheradiatorcapconnector(5Aor5B)andthen
fastenthesteelradiatorcap(#02,#03,or#04)fromthetestkittotheotherendoftheradiatorcapconnector(5Aor5B).
2. Removethehandpumpassembly(#1)fromthetestkitandfastenthequickcouplerattheendofthehosetotheradiator
cap(#02,#03,or#04)securely.Operatethehandpumpuntilreachingthepressurerecommendedbythevehicle
manufacturer.‐DONOTOVERPRESSURIZE.Idealreadingsshouldrangebetween15‐20PSI(1.03‐1.37BAR).
3. Checkthepressurereadingonthegaugeimmediatelyafterreachingthevehiclemanufacturer’srecommendedpressure.
Ifthepressuredrops,thereisaleakintheradiatorcap.Afterpressuretestingiscompleted,pressthereleasebuttonon
thequickcoupleruntilthereadingonthegaugereads0.Removequickcouplerfromradiatorcapandthenremovethe
originalradiatorcapfromtheoriginalradiatorcapconnector.Discardoriginalradiatorcapandreplacewithnewcapif
leakingorifitdoesnotmeetvehiclemanufacturer’srecommendations.

ITEM # ORDERING PART# PART DESCRIPTION
5A PRT3301-5A RADIATOR CAP TEST CONNECTOR FOR #2 & #3-BLACK
5B PRT3301-5B RADIATOR CAP TEST CONNECTOR FOR #2 & #4-BLUE
14 PRT3301-14 #14 ALUMINUM ADAPTER
FORD: (MONDEO), (FOCUS), (C-MAX03)
15 PRT3301-15 #15 ALUMINUM ADAPTER
MAZDA: (M3: 2004-);
FORD: (FOCUS: 2011-2012)
16 PRT3301-16 #16 ALUMINUM ADAPTER
MERCEDES: (A-CLASS : W168)
17 PRT3301-17 #17 ALUMINUM ADAPTER
BMW: (E60, E63,E64, E65)
18 PRT3301-18 #18 ALUMINUM ADAPTER
VW SHARAN 1.8T 2.8
19 PRT3301-19 #19 ALUMINUM ADAPTER
TOYOTA: (RAV4), (PREVIA), (CELICA: 2000-), (MR2 SPYDER: 2000-)
20 PRT3301-20 #20 ALUMINUM ADAPTER
ALFA
CITROEN
FIAT
MINI: (COOPER S: 2002-)
PEUGEOT: (206: 1999-), (307: 2004-), (406: 1999-), (407: 2004-), (807: 2004-)
RENAULT: ( ALL : 1985-1987); (AVANTIME: 2002-), (ESPACE: 2002-)
SAAB : (900: 1978-1993), (9000: 1986-1998)
STERLING: (ALL: 1987-1991)
JEEP
VOLVO : (PASSENGER VEHICLES W/ THREADED NECK)
21 PRT3301-21
#21 ALUMINUM ADAPTER
CADILLAC: (SEVILLE: 1998-2003); (FLEETWOOD: 1994-1996); (ESCALADE: 1999&NEWER); (CTS: 2003)
CHEVROLET: (TAHOE: 1999-2009); (SILVERADO2500: 1999-2009); (SUBURBAN: 2000-2009); (SILVERADO1500:
1999-2009); (METRO: 1999); (PRIZM: 1999); (MALIBU: 1997-1999); (CORVETTE: 1999); (IMPALA SS:
1994-1996); (CORSICA: 1992-1996); (COBALT: 2005-2009); (CAVALIER: 1995-1999); (CAPRICE:
1995-1996); (CAMARO: 1999); ( BERETTA: 1992-1996); (TRACKER:1999); (TRAILBLAZER: 2001-2002);
FORD: (FIVE HUNDRED: 2005); (F-150: 2004-2005); (EXCURSION: 2002–2004) (EXPLORER: 2002-2005); (TAURUS:
1996-2006)
FREIGHTLINER: (DIESEL TRUCK: 2004)
GM: (ALL MODELS WITH PLASTIC THREADED NECK: 1992-2009)
GMC: (ENVOY: 2002); (SIERRA 1500: 1999-2003); (SIERRA2500: 1999-2003); (YUKON: 1999);
JAGUAR: (S TYPE: 2000-2003)
LAND ROVER: (FREELANDER: 2005) ;( LR3: 2005-2007)
OLDSMOBILE: (ACHIEVA: 1992-1998); (ALERO: 1999); (AURORA: 1995-1999); (CUTLASS: 1997-1998); (INTRIGUE:
1999-2000)
PONTIAC: (GRAND AM: 1992-1999); (SUNFIRE: 1995-1999); (G6: 2005)
SAAB: (9,3: 2003-2004)
SATURN: (ALL MODELS:1990-1999); (VUE: 2003) ;(ION: 2005)
32 PRT3305-32 BLOW MOLDED CASE
N/S PRT3301-14G GASKET FOR #14 ADAPTER
N/S PRT3301-15G GASKET FOR #15 ADAPTER

N/S PRT3301-16G GASKET FOR #16 ADAPTER
N/S PRT3301-17G GASKET FOR #17 ADAPTER
N/S PRT3301-18G GASKET FOR #18 ADAPTER
N/S PRT3301-19G GASKET FOR #19 ADAPTER
N/S PRT3301-20G GASKET FOR #20 ADAPTER
N/S PRT3301-21G GASKET FOR #21 ADAPTER
