Ateme Kyrion CM5000 User manual

CM5000 - Modular Contribution Encoder
User Manual

CM5000 User Manual UM-CM5000-FW3.5.2.0-REV0.0
2019-07-08
www.ateme.com Page ii
Table of Contents
1. Document Overview ...................................................................................................................... 9
1.1. Document identification ....................................................................................................... 9
1.2. Disclaimer ......................................................................................................................... 9
1.3. Copyrights ......................................................................................................................... 9
1.4. Precautions ....................................................................................................................... 10
1.5. Symbols ........................................................................................................................... 11
2. Product Overview ........................................................................................................................ 12
2.1. Package Contents .............................................................................................................. 12
2.2. Front View ....................................................................................................................... 13
2.3. Rear View ........................................................................................................................ 14
2.4. Power Switch ................................................................................................................... 15
2.5. I/O Base Interfaces ............................................................................................................ 16
2.5.1. I/O Alarm Connector ............................................................................................... 16
2.6. Extended Interfaces ........................................................................................................... 18
2.6.1. Extended L-Band Modulator Interfaces ....................................................................... 19
2.6.2. Extended IF Modulator Interfaces .............................................................................. 20
2.6.3. Extended ASI/SDI Interfaces .................................................................................... 21
2.6.4. Extended AES Audio Interfaces ................................................................................ 22
2.6.5. Extended Analog Audio Interfaces ............................................................................. 24
2.7. Serial Number .................................................................................................................. 26
2.8. Ventilation ....................................................................................................................... 27
3. Installation .................................................................................................................................. 28
3.1. Hardware setup ................................................................................................................. 28
3.2. Quick start ....................................................................................................................... 29
4. User's Interfaces .......................................................................................................................... 30
4.1. Configuration tools ............................................................................................................ 30
4.2. Front Panel ...................................................................................................................... 30
4.2.1. Status LED ............................................................................................................ 30
4.2.2. LCD ..................................................................................................................... 31
4.2.3. TFT ...................................................................................................................... 31
4.2.4. Keypad ................................................................................................................. 31
4.2.5. Menu .................................................................................................................... 31
4.3. Web GUI ......................................................................................................................... 37
4.3.1. Access setup .......................................................................................................... 37
4.3.2. Web GUI Overview ................................................................................................ 38
4.3.3. Status Tab ............................................................................................................. 39
4.3.4. Channel Tab .......................................................................................................... 39
4.3.5. Remuxer Tab ......................................................................................................... 40
4.3.6. System Tab ............................................................................................................ 42
5. Settings ...................................................................................................................................... 46
5.1. Channel Settings ............................................................................................................... 46
5.1.1. Global ................................................................................................................... 46
5.1.2. TS ........................................................................................................................ 46
5.1.3. Output ASI ............................................................................................................ 48
5.1.4. Output DVB-S/S2/S2X/DSNG .................................................................................. 48
5.1.5. Output IP .............................................................................................................. 50
5.1.6. Video .................................................................................................................... 51
5.1.7. Audio ................................................................................................................... 57
5.1.8. Data ..................................................................................................................... 61
5.2. Remuxer Settings .............................................................................................................. 64
5.2.1. Global ................................................................................................................... 64

CM5000 User Manual UM-CM5000-FW3.5.2.0-REV0.0
2019-07-08
www.ateme.com Page iii
5.2.2. Output ASI ............................................................................................................ 66
5.2.3. Output IP .............................................................................................................. 66
5.2.4. Input TS ................................................................................................................ 68
5.3. System Settings ................................................................................................................. 68
5.3.1. System - Overview .................................................................................................. 68
5.3.2. System - Time ........................................................................................................ 68
5.3.3. System - Network Interface ...................................................................................... 69
5.3.4. System - Network VLAN ......................................................................................... 69
5.3.5. System - Network Route .......................................................................................... 70
5.3.6. System - Network VPN ........................................................................................... 70
5.3.7. System - Automation ............................................................................................... 70
5.3.8. System - Assets ...................................................................................................... 71
5.3.9. System - Alarms ..................................................................................................... 73
5.3.10. System - Logs ...................................................................................................... 74
5.3.11. System - SNMP Service ......................................................................................... 75
5.3.12. System - SNMP Trap Target ................................................................................... 75
5.3.13. System - SNMP Password ...................................................................................... 75
5.3.14. System - Misc security ........................................................................................... 75
5.3.15. System - Misc statmux ........................................................................................... 75
5.3.16. System - Misc redundancy ...................................................................................... 76
5.3.17. System - Misc remote syslog ................................................................................... 76
5.3.18. System - Misc modulator ........................................................................................ 76
6. Specific Operations ...................................................................................................................... 77
6.1. Installing License .............................................................................................................. 77
6.2. Firmware management ....................................................................................................... 77
6.3. Recovery ......................................................................................................................... 78
A. MIB User Guide ......................................................................................................................... 80
A.1. SNMP overview ............................................................................................................... 80
A.2. MIB overview .................................................................................................................. 81
A.2.1. Main nodes ........................................................................................................... 82
A.2.2. Preset editing guidelines .......................................................................................... 85
A.3. MIB use cases ................................................................................................................. 86
A.3.1. System ................................................................................................................. 86
A.3.2. Channel Presets ..................................................................................................... 90
A.3.3. Remuxer Presets ................................................................................................... 101
B. Simple RPC Guide .................................................................................................................... 105
B.1. Overview ....................................................................................................................... 105
B.2. Command list ................................................................................................................. 105
B.2.1. System ................................................................................................................ 105
B.2.2. Channel .............................................................................................................. 107
B.2.3. Remuxer ............................................................................................................. 108
C. VPN Guide ............................................................................................................................... 110
C.1. Overview ....................................................................................................................... 110
C.2. Server configuration ........................................................................................................ 110
C.3. Client configuration ......................................................................................................... 111
C.4. Troubleshooting .............................................................................................................. 111
D. Redundancy .............................................................................................................................. 112
D.1. Overview ....................................................................................................................... 112
E. Zixi/ARQ ................................................................................................................................. 114
E.1. Overview ....................................................................................................................... 114
E.2. Bonding ......................................................................................................................... 114
F. BISS-CA .................................................................................................................................. 116
F.1. Overview ....................................................................................................................... 116
F.2. Key ............................................................................................................................... 117

CM5000 User Manual UM-CM5000-FW3.5.2.0-REV0.0
2019-07-08
www.ateme.com Page iv
F.3. Decoder configuration ...................................................................................................... 118
F.4. Encoder configuration ...................................................................................................... 119
G. Use Cases ................................................................................................................................ 122
G.1. 4k ................................................................................................................................ 122
G.1.1. Overview ............................................................................................................ 122
G.1.2. Configuration ....................................................................................................... 123
G.2. 4k and modulator ............................................................................................................ 125
G.2.1. Overview ............................................................................................................ 125
G.2.2. Configuration ....................................................................................................... 126
H. Colorimetry .............................................................................................................................. 129
H.1. Colorimetry .................................................................................................................... 129
I. Appendix .................................................................................................................................. 130
I.1. Product's specification ....................................................................................................... 130
I.1.1. Notes ................................................................................................................... 145
I.2. Warranty ......................................................................................................................... 146
I.3. Normative Reference ........................................................................................................ 147
I.4. Glossary ......................................................................................................................... 148
I.5. Support and Resources ...................................................................................................... 151

CM5000 User Manual UM-CM5000-FW3.5.2.0-REV0.0
2019-07-08
www.ateme.com Page v
List of Figures
1.1. Direct current symbol ................................................................................................................ 11
1.2. Alternating current symbol .......................................................................................................... 11
1.3. Ground symbol ......................................................................................................................... 11
1.4. Blocked trash ............................................................................................................................ 11
2.1. Front View Interface .................................................................................................................. 13
2.2. Rear View Interface ................................................................................................................... 14
2.3. Power Switch ........................................................................................................................... 15
2.4. I/O Base Interface ..................................................................................................................... 16
2.5. I/O Base Alarm Connector Pinout ................................................................................................ 17
2.6. Extended L-Band Modulator Interfaces ......................................................................................... 19
2.7. Extended IF Modulator Interfaces ................................................................................................ 20
2.8. Extended ASI/SDI Interfaces ....................................................................................................... 21
2.9. Extended AES Audio Interfaces ................................................................................................... 22
2.10. Extended AES Audio Connector Pinout ....................................................................................... 23
2.11. Extended Analog Audio Interfaces .............................................................................................. 24
2.12. Extended Analog Audio Connector Pinout ................................................................................... 25
2.13. Serial Number and Production Code Markings .............................................................................. 26
2.14. Cool air intakes on the front panel .............................................................................................. 27
2.15. Warm air outputs on the rear panel ............................................................................................. 27
4.1. Front Panel sub-elements' identification ......................................................................................... 30
4.2. Log into the web server .............................................................................................................. 38
4.3. Web Interface ........................................................................................................................... 38
4.4. Web Interface - Status Tab ......................................................................................................... 39
4.5. Web Interface - Channel Tab ...................................................................................................... 39
4.6. Web Interface - Remuxer Tab ..................................................................................................... 41
4.7. Web Interface - System Tab ........................................................................................................ 42
4.8. Settings package configuration ..................................................................................................... 43
4.9. Simple setting edition ................................................................................................................ 44
4.10. Table setting edition ................................................................................................................. 44
D.1. redundancy ............................................................................................................................ 112
E.1. Flow diagram ......................................................................................................................... 114
E.2. Route configuration sample ....................................................................................................... 115
E.3. Encoder configuration sample .................................................................................................... 115
F.1. Overview ............................................................................................................................... 116
F.2. System ................................................................................................................................... 118
F.3. Service .................................................................................................................................. 119
F.4. System ................................................................................................................................... 120
F.5. Channel ................................................................................................................................. 121
G.1. 4K schema ............................................................................................................................. 122
G.2. 4K schema ............................................................................................................................. 125

CM5000 User Manual UM-CM5000-FW3.5.2.0-REV0.0
2019-07-08
www.ateme.com Page vi
List of Tables
1.1. Document Identification ............................................................................................................... 9
2.1. Front View Interface .................................................................................................................. 13
2.2. Rear View Interface ................................................................................................................... 14
2.3. Power Switch ........................................................................................................................... 15
2.4. I/O Base Interface ..................................................................................................................... 16
2.5. I/O Base Alarm Connector Pinout description ................................................................................. 17
2.6. Extended L-Band Modulator Interfaces ......................................................................................... 19
2.7. Extended IF Modulator Interfaces ................................................................................................ 20
2.8. Extended ASI/SDI Interfaces ....................................................................................................... 21
2.9. Extended AES Audio Interfaces ................................................................................................... 22
2.10. Extended Analog Audio Interfaces .............................................................................................. 24
4.1. Status LED .............................................................................................................................. 31
4.2. Front Panel Menu - Main ........................................................................................................... 31
4.3. Front Panel Menu - Service Modulator .......................................................................................... 34
4.4. Front Panel Menu - Service Main ................................................................................................ 34
4.5. Front Panel Menu - Service Remuxer ........................................................................................... 36
4.6. Web Interface - Channel Tab Settings ........................................................................................... 40
4.7. Web Interface - Remuxer Tab Settings .......................................................................................... 41
4.8. Web Interface - System Tab Settings ............................................................................................ 42
5.1. Global ..................................................................................................................................... 46
5.2. TS .......................................................................................................................................... 46
5.3. DVB compliance ....................................................................................................................... 47
5.4. Carrier ID ................................................................................................................................ 47
5.5. ATSC ...................................................................................................................................... 48
5.6. Output ASI .............................................................................................................................. 48
5.7. Output DVB-S/S2/S2X/DSNG ..................................................................................................... 48
5.8. DVB Carrier ID (DVB-CID) ....................................................................................................... 50
5.9. Output IP ................................................................................................................................. 50
5.10. Video .................................................................................................................................... 51
5.11. MPEG-4 AVC ........................................................................................................................ 53
5.12. MPEG-4 AVC-I ...................................................................................................................... 54
5.13. MPEG-2 ................................................................................................................................. 55
5.14. HEVC ................................................................................................................................... 55
5.15. Colorimetry ............................................................................................................................ 56
5.16. Audio .................................................................................................................................... 57
5.17. MPEG Layer2 ......................................................................................................................... 58
5.18. AAC ..................................................................................................................................... 58
5.19. Dolby Digital .......................................................................................................................... 59
5.20. Data ...................................................................................................................................... 61
5.21. Teletext .................................................................................................................................. 61
5.22. Teletext descriptor ................................................................................................................... 62
5.23. Teletext filter .......................................................................................................................... 62
5.24. VBI ....................................................................................................................................... 62
5.25. DVB Subtitles ......................................................................................................................... 62
5.26. DVB Subtitles descriptor .......................................................................................................... 63
5.27. SMPTE-2028 .......................................................................................................................... 63
5.28. SCTE-35 source ...................................................................................................................... 63
5.29. SCTE-35 SDI source ................................................................................................................ 63
5.30. SCTE-35 GPI source ................................................................................................................ 64
5.31. STD-B24 ................................................................................................................................ 64
5.32. MPE ...................................................................................................................................... 64

CM5000 User Manual UM-CM5000-FW3.5.2.0-REV0.0
2019-07-08
www.ateme.com Page vii
5.33. Global ................................................................................................................................... 64
5.34. DVB compliance ..................................................................................................................... 65
5.35. Carrier ID .............................................................................................................................. 65
5.36. SBTVD FullSeg compliance ...................................................................................................... 65
5.37. Carrier ID .............................................................................................................................. 66
5.38. Output ASI ............................................................................................................................. 66
5.39. Output IP ............................................................................................................................... 66
5.40. Input TS ................................................................................................................................ 68
5.41. Overview ............................................................................................................................... 68
5.42. Time ..................................................................................................................................... 68
5.43. Interface ................................................................................................................................. 69
5.44. VLAN ................................................................................................................................... 69
5.45. Route ..................................................................................................................................... 70
5.46. Route ..................................................................................................................................... 70
5.47. Automation ............................................................................................................................. 70
5.48. Assets .................................................................................................................................... 71
5.49. Alarms names ......................................................................................................................... 73
5.50. Alarms actions ........................................................................................................................ 74
5.51. Logs names ............................................................................................................................ 74
5.52. Logs levels ............................................................................................................................. 74
5.53. Trap target .............................................................................................................................. 75
5.54. Trap target .............................................................................................................................. 75
5.55. Passwords ............................................................................................................................... 75
5.56. Misc security .......................................................................................................................... 75
5.57. Misc Statmux .......................................................................................................................... 75
5.58. Misc Redundancy .................................................................................................................... 76
5.59. Misc Remote syslog ................................................................................................................. 76
5.60. Misc Modulator ....................................................................................................................... 76
A.1. Quality/Latency mapping ........................................................................................................... 91
A.2. Carrier/Modulation state mapping ................................................................................................ 96
A.3. Supported PCM layouts ............................................................................................................. 99
A.4. Channel to index mapping .......................................................................................................... 99
A.5. SDI pair to index mapping ......................................................................................................... 99
B.1. Export settings keywords .......................................................................................................... 106
C.1. Client configuration ................................................................................................................. 111
H.1. SDR ..................................................................................................................................... 129
H.2. DVB ..................................................................................................................................... 129
H.3. ATSC ................................................................................................................................... 129
H.4. ARIB .................................................................................................................................... 129
I.1. Specification - Identification ...................................................................................................... 130
I.2. Specification - Video Input ........................................................................................................ 130
I.3. Specification - Audio Input ........................................................................................................ 131
I.4. Specification - Data Input .......................................................................................................... 132
I.5. Specification - Black Burst-3Level and ASI Synchronization ............................................................ 132
I.6. Specification - Filter ................................................................................................................. 132
I.7. Specification - Video Processing ................................................................................................. 133
I.8. Specification - PIP Processing .................................................................................................... 134
I.9. Specification - Audio Processing ................................................................................................. 135
I.10. Specification - Data Processing ................................................................................................. 135
I.11. Specification - Remuxer .......................................................................................................... 136
I.12. Specification - 1+1 Redundancy ................................................................................................ 136
I.13. Specification - Muxer .............................................................................................................. 136
I.14. Specification - Output ............................................................................................................. 137
I.15. Specification - L-Band or IF Modulator ...................................................................................... 138

CM5000 User Manual UM-CM5000-FW3.5.2.0-REV0.0
2019-07-08
www.ateme.com Page viii
I.16. Specification - Configuration and management interfaces ............................................................... 140
I.17. Specification - System ............................................................................................................. 141
I.18. Specification - Licenses ........................................................................................................... 142
I.19. Specification - Physical ........................................................................................................... 144
I.20. Specification - Environmental and Power .................................................................................... 144
I.21. Specification - Certifications ..................................................................................................... 144
I.22. Normative reference ................................................................................................................ 147
I.23. Glossary ................................................................................................................................ 148

CM5000 User Manual UM-CM5000-FW3.5.2.0-REV0.0
2019-07-08
www.ateme.com Page 9
1. Document Overview
1.1. Document identification
Table 1.1. Document Identification
Title CM5000 - Modular Contribution Encoder - User Manual
Revision Number 0.0
Description Document for firmware release 3.5.2.0 (build 31.3.3.0)
Date of Issue 2019-07-08
Document Reference UM-CM5000-FW3.5.2.0-REV0.0
1.2. Disclaimer
The material in this document is for information only and subject to change without notice. While reasonable efforts
have been made in the preparation of this document to assure its accuracy, ATEME assumes no liability resulting
from errors or omissions in this document, or from the use of the information contained herein. ATEME reserves
the right to make changes or revisions in the product design or the product manual without reservation and without
obligation to notify any person of such revisions and changes.
1.3. Copyrights
Notice
The CM5000 is not designed or intended to violate any other entity's copyright or other IP (Intellectual Property)
rights. Each CM5000 user may only use their CM5000 in conjunction with materials legally owned or licensed by
such user, and only to the extent that such ownership or license rights permit such use.
Copyright © 2011-2018 ATEME
These materials, ATEME products and all related documentation are protected by copyright and other laws, interna-
tional treaties and conventions. All rights, title and interest in the materials, ATEME products and related documen-
tation shall remain with ATEME and its licensors. All registered or unregistered trademarks in these materials are the
sole property of their respective owners. No part of this document or related ATEME products may be reproduced in
any form, or by any means without written authorization of ATEME Corporation.
These materials are provided "as-is." ATEME makes no warranties, stated or implied, as to, the information contained
herein. In addition, ATEME makes no stated or implied warranties of merchantability or working condition for a
particular purpose or use with respect the information contained in these materials.
In no event shall ATEME be liable for any indirect, special, consequential or incidental damages, including, but not
limited to, lost profits or loss or damage to data arising from the use of these materials, even if advised in advance
of the possibility of such damages.

CM5000 User Manual UM-CM5000-FW3.5.2.0-REV0.0
2019-07-08
www.ateme.com Page 10
The glossary of this document is partially extracted from the Wikipedia encyclopedia.
Trademarks
ATEME, the ATEME logo, Kyrion and the Kyrion logo are all trademarks or registered trademarks of ATEME
Corporation. The CM5000 clustering technology - as well as other technologies included in CM5000 - are protected
bypatentsorpendingpatentapplicationsintheU.S.andothercountries.Allothertrademarksorregisteredtrademarks
are property of their respective owners.
1.4. Precautions
Only qualified persons are authorized to carry out maintenance on this device.
Read the Users' Manual carefully, and follow the correct procedure when setting up the device.
Do not open your CM5000 or attempt to disassemble or modify it, unless instructed by an ATEME representative. To
avoid any risk of electrical shock, fire, short-circuiting or dangerous emissions, never insert any metallic object into
the enclosure. Your CM5000 contains no user-serviceable parts. If it appears to be malfunctioning, have it inspected
by a qualified ATEME Technical Support representative.
Never expose your device to rain, use it near water, or in damp or wet conditions. Never place objects containing
liquids on the CM5000, as they may spill into its openings; doing so increases the risk of electrical shock, short-
circuiting, fire or personal injury.
Basic electrical safety precautions should be followed to protect you from harm and the system from damage:
• Be aware of where the On/Off power switch is situated on the chassis; as well as the rack's emergency power off-
switch. Check also where the disconnection switch or electrical outlet is located.
• Do not work alone when working with high voltage components.
• Power should always be disconnected from the system before opening it. When disconnecting the power, you
should first power down the system and unplug the power cords of the power supply.
• Ground pin shall be connected to earth for safe operation.
For the 220VAC version:
• Only the provided power supply cord must be use to power the CM5000. This power supply cord includes a
grounding plug and it must be plugged into a grounded electrical outlet. If you should use a different power supply
cord, make sure it is compatible with your locale electrical power supply.
• The mains plug (or the mains plugs for dual plug version) is used as the disconnect device and shall be easily
accessible.
For the 48VDC version:
• TheinternalfuseoftheDC filter boardshallbe replaced bya5x20mm medium-acting 8A250Vfuse, like LittleFuse
234 series.
• The rear connector is used as the disconnect device and shall be easily accessible.

CM5000 User Manual UM-CM5000-FW3.5.2.0-REV0.0
2019-07-08
www.ateme.com Page 11
Warning
This product contains a lithium battery. The lithium battery may explode if it is incorrectly replaced.
This battery must be replaced only with the same or equivalent type recommended by the manufacturer.
Dispose of used batteries according to the manufacturer's instructions.
1.5. Symbols
Figure 1.1. Direct current symbol
Figure 1.2. Alternating current symbol
Figure 1.3. Ground symbol
Figure 1.4. Blocked trash
The blocked trash can indicate that the product must be collected by a particular sector and, as such, must not be
thrown in a classic trash can.

CM5000 User Manual UM-CM5000-FW3.5.2.0-REV0.0
2019-07-08
www.ateme.com Page 12
2. Product Overview
2.1. Package Contents
Before continuing, please check the contents of the product package. This product package should contain the fol-
lowing items:
• One (1) CM5000,
• One (1) Power Cord,
• One (1) CD ROM,
• This User's Manual.
If anything is missing, please contact your place of purchase.

CM5000 User Manual UM-CM5000-FW3.5.2.0-REV0.0
2019-07-08
www.ateme.com Page 13
2.2. Front View
This figure describes the front interface of the CM5000.
Figure 2.1. Front View Interface
Table 2.1. Front View Interface
FP Front Panel
A Air Intakes
Front Panel Interfaces FP are described in Section 4.2, “ Front Panel ”
Ventilation using Air Intakes A is described in Section 2.8, “ Ventilation ”

CM5000 User Manual UM-CM5000-FW3.5.2.0-REV0.0
2019-07-08
www.ateme.com Page 14
2.3. Rear View
This figure describes the generic rear interfaces of the CM5000.
Depending on your exact model and the options purchased, the extended slots may contain additional connectors
which will be described in the next paragraphs.
Figure 2.2. Rear View Interface
Table 2.2. Rear View Interface
B I/O Base Interfaces
X I/O Extended X Interfaces
VA I/O Extended A Interfaces
VB I/O Extended B Interfaces
SN Serial Number and Product Code

CM5000 User Manual UM-CM5000-FW3.5.2.0-REV0.0
2019-07-08
www.ateme.com Page 15
2.4. Power Switch
This figure describes the location of the Power switch of the CM5000.
Figure 2.3. Power Switch
Table 2.3. Power Switch
P1 Power Switch Use this switch to turn ON the unit. Switch it
back to the original position to turn OFF the unit.

CM5000 User Manual UM-CM5000-FW3.5.2.0-REV0.0
2019-07-08
www.ateme.com Page 16
2.5. I/O Base Interfaces
This figure describes the I/O Base interfaces of the CM5000.
Figure 2.4. I/O Base Interface
Table 2.4. I/O Base Interface
B1 AC Inlet (~AC) Connect the provided cable to this inlet. The unit auto detects AC voltage.
B2 MGT Ether-
net Connector This dedicated Ethernet connector allows administration of the unit via the web GUI or SNMP. This interface is a 1000Base-T Ethernet port (1Gbps).
B3 STREAM Ether-
net Connector 1 This Ethernet connector is dedicated for streaming encoded video over IP. This interface is a Gigabit Ethernet port (1Gbps).
B4 STREAM Ether-
net Connector 2 Same as [B3].
B5 SYNC In Connector This BNC Connector is dedicated to synchronize the unit with an external reference signal. The supported signal standards are
black burst and tri-level. It can also be used to input ASI stream.
B6 ASI In Connector This BNC Connector is dedicated to input ASI stream.
B7 ALARM Connector This DB9 connector is dedicated to input and output discrete signals.
2.5.1. I/O Alarm Connector
The CM5000 provides the user with 4 external GPIOs : 2x IN and 2x OUT.
GPO are dry-loops based on electro-mechanical relays, AC/DC 1A / 24V max.
GPI are opto-isolated DC inputs, 5V to 24V HIGH input threshold.

CM5000 User Manual UM-CM5000-FW3.5.2.0-REV0.0
2019-07-08
www.ateme.com Page 17
Both have a 2KV isolation with the platform mechanical and electrical ground.
GPO dry-loops default to OFF (opened) when the unit is powered-up.
Those GPIOs are available on a 9 points female Sub-D connector :
Figure 2.5. I/O Base Alarm Connector Pinout
Table 2.5. I/O Base Alarm Connector Pinout description
Pin Function
1 GPI 1 + (first GP positive input, to be used with GPI 1-)
2 GPI 2+ (second GP positive input, to be used with GPI 2-)
3 NC (not used and not connected)
4 GPO 2a (first connection of second GP dry loop, to be used with GPO 2b)
5 GPO 1a (first connection of first GP dry loop, to be used with GPO 1b)
6 GPI 1- (first GP negative input, to be used with GPI 1+)
7 GPI 2- (second GP negative input, to be used with GPI 2+)
8 GPO 2b (second connection of second GP dry loop, to be used with GPO 2a)
9 GPO 1b (second connection of first GP dry loop, to be used with GPO 1a)

CM5000 User Manual UM-CM5000-FW3.5.2.0-REV0.0
2019-07-08
www.ateme.com Page 18
2.6. Extended Interfaces
Depending of the hardware options that you've purchased, some of the interfaces may be accessible on I/O Extended
Interfaces ([X], [VA], [VB]).

CM5000 User Manual UM-CM5000-FW3.5.2.0-REV0.0
2019-07-08
www.ateme.com Page 19
2.6.1. Extended L-Band Modulator Interfaces
This figure describes the Extended L-Band Modulator interfaces of the CM5000.
Figure 2.6. Extended L-Band Modulator Interfaces
Table 2.6. Extended L-Band Modulator Interfaces
XLB1 Encoder SDI IN BNC
75Ω Use this BNC connector to input the SDI video signal into the CM5000.
ALB1 Encoder
ASI OUT BNC
75Ω Use this BNC connector to output the encoded bitstream. It
should be connected to the ASI input of the Modulator [LB3].
LB1 Modula-
tor REF IN BNC
50Ω
Use this connector to input the external 10MHz reference
frequency used by the Modulator. The modulator can ei-
ther use this external reference frequency or a 10MHz in-
ternal reference frequency (selection trough GUI interface)
LB2 Modulator
REF OUT BNC
50Ω This connector outputs the 10MHz ref-
erence frequency used by the Modulator.
LB3 Modula-
tor ASI IN BNC
75Ω Use this BNC connector to input the ASI stream to be modulated.
LB4 Modulator
ASI MON BNC
75Ω This connector outputs a monitoring
copy of the ASI stream to be modulated.
LB5 Modulator L-
Band MAIN SMA
50Ω This connector outputs the modulated signal to
be connected to the emitting system (0 dBm).
LB6 Modulator L-
Band MON SMA
50Ω This connector outputs the modulated signal to be con-
nected to an analyzing or monitoring system (-20 dBm).

CM5000 User Manual UM-CM5000-FW3.5.2.0-REV0.0
2019-07-08
www.ateme.com Page 20
2.6.2. Extended IF Modulator Interfaces
This figure describes the Extended IF Modulator interfaces of the CM5000.
Figure 2.7. Extended IF Modulator Interfaces
Table 2.7. Extended IF Modulator Interfaces
XIF1 Encoder
SDI IN BNC 75 ΩUse this BNC connector to input the SDI video signal into the CM5000.
AIF1 Encoder
ASI OUT BNC 75 ΩUse this BNC connector to output the encoded bitstream. It should be connected to the ASI input of the Modulator [IF3].
IF1 Modula-
tor REF IN BNC 50 Ω
Use this connector to input the external 10MHz reference
frequency used by the Modulator. The modulator can ei-
ther use this external reference frequency or a 10MHz in-
ternal reference frequency (selection trough GUI interface)
IF2 Modulator
REF OUT BNC 50 ΩThis connector outputs the 10MHz ref- erence frequency used by the Modulator.
IF3 Modula-
tor ASI IN BNC 75 ΩUse this BNC connector to input the ASI stream to be modulated.
IF4 Modulator
ASI MON BNC 75 ΩThis connector outputs a monitoring copy of the ASI stream to be modulated.
IF5 Modulator
IF MAIN BNC 75 ΩThis connector outputs the modulated signal to be connected to the emitting system (0 dBm).
IF6 Modulator
IF MON BNC 75 ΩThis connector outputs the modulated signal to be con- nected to an analyzing or monitoring system (-20 dBm).
