ATEN StreamLIVE PRO UC9040 User manual

www.aten.com
UC9040
StreamLIVE™ PRO
Mul -Channel AV Mixer
User Manual

StreamLIVE™ PRO User Manual
ii
Compliance Statements
FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE
STATEMENT
This equipment has been tested and found to comply with the limits for a Class
A digital device, pursuant to Part 15 of the FCC ules. These limits are
designed to provide reasonable protection against harmful interference when
the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a
residential area is likely to cause harmful interference in which case the user
will be required to correct the interference at his own expense.
The device complies with Part 15 of the FCC ules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference,
and (2) this device must accept any interference received, including
interference that may cause undesired operation.
FCC Caution
Any changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate this equipment.
Warning
Operation of this equipment in a residential environment could cause radio
interference.
Achtung
Der Gebrauch dieses Geräts in Wohnumgebung kann Funkstörungen
verursachen.
KCC Statement

StreamLIVE™ PRO User Manual
iii
HDMI Trademar Statement
The terms HDMI, HDMI High-Definition Multimedia Interface, and the
HDMI Logo are trademarks or registered trademarks of HDMI Licensing
Administrator, Inc.
PSE
This product is PSE compliant.
RoHS
This product is oHS compliant.

StreamLIVE™ PRO User Manual
iv
User Information
Online Registration
Be sure to register your product at our online support center:
Telephone Support
For telephone support, call this number:
User Notice
All information, documentation, and specifications contained in this manual
are subject to change without prior notification by the manufacturer. The
manufacturer makes no representations or warranties, either expressed or
implied, with respect to the contents hereof and specifically disclaims any
warranties as to merchantability or fitness for any particular purpose. Any of
the manufacturer's software described in this manual is sold or licensed as is.
Should the programs prove defective following their purchase, the buyer (and
not the manufacturer, its distributor, or its dealer), assumes the entire cost of all
necessary servicing, repair and any incidental or consequential damages
resulting from any defect in the software.
The manufacturer of this system is not responsible for any radio and/or TV
interference caused by unauthorized modifications to this device. It is the
responsibility of the user to correct such interference.
The manufacturer is not responsible for any damage incurred in the operation
of this system if the correct operational voltage setting was not selected prior
to operation. PLEASE VE IFY THAT THE VOLTAGE SETTING IS
CO ECT BEFO E USE.
International http://eservice.aten.com
International 6-2- 692-6959
China 6-400- 10-0- 10
Japan 1-3-5615-5 11
Korea 2-2-467-67 9
North America 1- -999-ATEN ext 49
1-949-42 -1111

StreamLIVE™ PRO User Manual
v
Product Information
For information about all ATEN products and how they can help you connect
without limits, visit ATEN on the Web or contact an ATEN Authorized
eseller. Visit ATEN on the Web for a list of locations and telephone numbers:
International http://www.aten.com
North America http://www.aten-usa.com

StreamLIVE™ PRO User Manual
vi
Package Contents
Check to make sure that all the components are in working order. If you
encounter any problem, please contact your dealer.
1 UC9040 StreamLIVE™ P O Multi-Channel AV Mixer
1 USB Type-C to USB Type-C cable
1 USB Type-C to USB Type-A cable
1 power adapter
1 user instructions

StreamLIVE™ PRO User Manual
vii
Table of Contents
Compliance Statements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ii
User Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iv
Online Registration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iv
Telephone Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iv
User Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iv
Product Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . v
Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vi
Table of Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii
About this Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . x
Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xi
1. Introduction
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Top View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Rear View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Side View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
. Hardware Setup
Connecting the StreamLIVE™ PRO Unit . . . . . . . . . . . . . . . . . . . . . . . . . 11
Connecting iPad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
iPad with Lightning Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
iPad with USB-C Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Pairing an Android Tablet or Chromebook via Network . . . . . . . . . . . 15
Connecting Chromebook. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Using the OnAir Cam App . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Supported Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Installing the ATEN OnAir Lite App . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Connecting the iOS Mobile Device . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
3. ATEN OnAir PRO App & Side Menu
ATEN OnAir PRO Application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Page Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Side Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Current Project . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Changing Project Name . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Create Project . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Copy as New Project . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Open Project . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Import Project . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Export Project . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

StreamLIVE™ PRO User Manual
viii
All Projects . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Tutorial . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
About . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Firmware Upgrade . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Self-Diagnostic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
4. ATEN OnAir PRO App & Video Mixer
Video Mixer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Transition Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Transition Control when the Quick Mode is Disabled . . . . . . . . . . 3
Transition Control when the Quick Mode is Enabled . . . . . . . . . . 3
Scene Editor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Resize/Crop Tool . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Resize . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Crop (Media Only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Add/Edit Text Overlay . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Re-order the Overlays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
5. ATEN OnAir PRO App & Audio Mixer
Audio Mixer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
6. ATEN OnAir PRO App & Settings
Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Stream . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Others . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Reset Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Example Live-stream URL and Stream Key (Facebook). . . . . . . 57
Example Live-stream URL and Stream Key (YouTube) . . . . . . . . 57
Recording Live-stream Video (External Storage) . . . . . . . . . . . . . . . . 5
External Storage Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Video Information for Live-stream Recording . . . . . . . . . . . . . . . . 62
7. Quick Live-Stream Setup
Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
During the Live-Stream / Live-Stream Recording . . . . . . . . . . . . . . . 66
8. Firmware Upgrade
Download Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Preparing the Firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Upgrading the Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Upgrade Assessment Fail. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Upgrade Fail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Appendix

StreamLIVE™ PRO User Manual
ix
Safety Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
International . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .75
North America . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Supported List of Android Tablets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Live-Streaming Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Create a Live Stream with YouTube . . . . . . . . . . . . . . . . . . . . . . . . . .
What is CDN Service?. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
RTMP/RTMPS and RTSP Protocols . . . . . . . . . . . . . . . . . . . . . . . . . .
Other ways to input image overlays . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

StreamLIVE™ PRO User Manual
x
About this Manual
This manual is provided to help you get the most from the UC9040 unit. It
covers all aspects of the device, including installation, configuration, and
operation. An overview of the information covered is provided below.
Chapter 1, Introduction introduces you to the Multi-Channel AV Mixer,
with its purpose, features, installation considerations, and panel components
presented and described.
Chapter , Hardware Setup describes the steps that are necessary to
quickly and safely set up your Multi-Channel AV Mixer.
Chapter 3, ATEN OnAir PRO App & Side Menu explains the functions
of the OnAir app and its side menu.
Chapter 4, ATEN OnAir PRO App & Video Mixer explains the functions
in the Video Mixer deck of the OnAir app, including scene editing, media
resizing/cropping, and text and image overlays.
Chapter 5, ATEN OnAir PRO App & Audio Mixer explains the functions
in the Audio Mixer deck of the OnAir app.
Chapter 6, ATEN OnAir PRO App & Settings explains the settings you
can configure for the interactions between the unit and the OnAir app.
Chapter 7, Quick Live-Stream Setup describes how to quickly set up
your system to help you start live-streaming.
Chapter 8, Firmware Upgrade describes the firmware upgrade procedures
and how the volume mixer LED behaves during the firmware upgrade.
Appendix provides a list of safety instructions and precautions, ATEN
technical support information, product specifications, and other technical
information.
Note:
ead this manual thoroughly and follow the installation and operation
procedures carefully to prevent any damage to the unit or connected
devices.
The product may be updated, with features and functions added, improved
or removed since the release of this manual. For an up-to-date user
manual, visit http://www.aten.com/global/en/

StreamLIVE™ PRO User Manual
xi
Conventions
This manual uses the following conventions:
Monospaced Indicates text that you should key in.
[ ] Indicates keys you should press. For example, [Enter] means to
press the Enter key. If keys need to be chorded, they appear
together in the same bracket with a plus sign between them:
[Ctrl+Alt].
1. Numbered lists represent procedures with sequential steps.
♦Bullet lists provide information, but do not involve sequential steps.
>Indicates selecting consecutive options (such as on a menu or
dialog box). For example, Start > Run means to open the Start
menu, and then select Run.
Indicates critical information.

StreamLIVE™ PRO User Manual
xii
This Page Intentionally Left Blank

1
Chapter 1
Introduction
Overview
The StreamLIVE™ P O is a portable, all-in-one, multi-channel audio / video
mixer device that integrates an 1080p video capture, video recorder, video
switch, stream broadcaster, video converter, 4K video splitter, and audio mixer
into one compact box to eliminate the hassle of working with different AV
equipment. The StreamLIVE™ P O makes HDMI video sources broadcast for
higher quality live stream to CDN platforms such as YouTube Live, Facebook,
and Twitch.
For added convenience, the StreamLIVE™ P O features an intuitive app
OnAir, which is designed for use with supported Android / Windows devices
or iPads, making it easy to monitor, edit image layouts, and DVE, PiP, or PbP
settings. There are eight stunning DVE transitions, including circle drop,
window slice, polka dot, circle open, fade, heart, cross hatch, and random
square.
The StreamLIVE™ P O is PC and software-free, and with its well-designed
control panel, it makes livestreaming operations smooth and effortless. Users
can even preview video and monitor audio levels before going live with their
web broadcast! To get started, simply connect audio / video sources with
Ethernet and an ATEN OnAir-installed Android / Windows device or iPad, and
you are ready to roll.
For enterprises in need of delivering remote presentations on Skype, Zoom,
MS Teams, OBS, or other platforms for meetings, online events, and webinars
alike, the StreamLIVE™ P O works with ATEN Stream to USB software,
which helps convert streams into USB webcam signals. Moreover, the
software enables operators to monitor the live production coming from all
StreamLIVE™ P O in a media pool and to broadcast each stream to the right
destination.
When it comes to outputting content from an iPhone / iPad, usually UI
elements appear on the video feed, which is not aesthetically pleasing. This is
where ATEN OnAir Cam app helps! The app helps capture camera feed from
an iPhone / iPad and turn it into an 1080p @ 60 Hz HDMI video source devoid
of on-screen icons or overlays. Such clean camera feed can be used on the
StreamLIVE™ P O for live stream rig or post production set-up enhancement,
achieving higher production value.

StreamLIVE™ PRO User Manual
2
Whether users are capturing, editing, or streaming, the StreamLIVE™ P O,
with its ergonomic and practical design, is flexible enough to fit all
independent live streaming broadcasting environments. With a rich feature set,
the StreamLIVE™ P O addresses the challenges that independent live
streaming broadcasters encounter and provides an easy-to-use solution.

Chapter 1. Introduction
3
Features
All-in-one design to simplify streaming workflow — integrates
capabilities of 1080p video capture, video recorder, video switch,
streaming encoder, video converter, video splitter, and audio mixer
Professional-quality live streaming everywhere — compatible with every
major platform and can livestream to two platforms at the same time from
virtually anywhere
1080p recording — features media recording that can be used to record a
program and save recordings directly to a connected external hard drive
via USB
Compact mixer control panel — switches and mixes multiple AV sources
with the easily identifiable luminous keys
Intuitive and powerful app OnAir — allows for preset up to 8 scenes with
custom video layout, preview and full screen program monitoring, real-
time editing, transitions in stunning DVE, PbP, or PiP visual effects, and
graphical and text overlays for a professional finish
DVE (Digital Video Effect) video transition — includes circle drop,
window slice, polka dot, circle open, fade, heart, cross hatch, and random
square
Storyboard-like management — quick and smooth transitions control for
professional programming during live events
Audio management — multi-channel audio mixing with faders, meters,
and balance for every input
Fanless and an optimized thermal air flow system for quiet operation
Multitask designed handle-stand to enhance portability and ergonomic
comfort angle
Supports Android / Windows devices or iPads
Works with ATEN Stream to USB software — converts streams from
multiple StreamLIVE™ P Os into USB webcam signals for delivering
remote presentations on Skype, Zoom, MS Teams, OBS, and more.
eceives clean HDMI camera feed via ATEN OnAir Cam app — the app
helps capture the iPhone / iPad camera feed and turn it into a clean 1080p
@ 60 Hz HDMI video source without on-screen icons or overlays for the
StreamLIVE™ P O’s usage

StreamLIVE™ PRO User Manual
4
Requirements
Ethernet connection
an iPad, Android tablet, or Chromebook with the following specs:
USB Storage Device (for live-stream video recording)
USB 3.x compatible mobile drive (HDD / SSD)
At least 32 GB of free space
Device Type OS other requirements
iPad iOS 11 or later iPad Pro (1st gen, 12.9”)
iPad Pro (1st gen, 9.7”)
iPad Pro (2nd gen, 12.9”)
iPad Pro (2nd gen, 10.5”)
iPad Pro (3rd gen, 12.9”, or above)
iPad Pro (3rd gen, 11”, or above)
iPad (5th gen or above)
iPad Air (3rd gen or above)
iPad mini (5th gen or above)
Android tablet Android 9 or later
 Octa-core ARM Cortex grade
CPU or above
 2.75 GB RAM or above
 StreamLIVE™ PRO must be of
firmware v1.1.109 or later
(see Firmware Upgrade,
page 67)
Note: Make sure to use a
compatible Android tablet. For a list
of compatible Android tablets,
see Supported List of Android
Tablets, page 76.
Chromebook Chromebook 1.1.105
or later
 StreamLIVE™ PRO must be of
firmware v1.3.121 or later
(see Firmware Upgrade,
page 67)
Windows 10 version 17763.0 or
later, 32 / 64-bit
 StreamLIVE™ PRO must be of
firmware v1.3.121 or later
(see Firmware Upgrade,
page 67)

Chapter 1. Introduction
5
Components
Top View
No. Component Description
Audio Section (Controls the audio settings of the system)
1 audio level control Controls the volume of the audio source selected.
2 volume meter The LED reflects the controlled volume.
During firmware upgrade, the LED behavior is changed.
Refer to Upgrading the Unit on page 69 for the LED
behavior during firmware upgrade.
3 MIC / Line-in
selector
Switches between the MIC / Line-in audio source.
The button is lit when switched to this source.
4 MIC / Line-in audio 1 Switches to the MIC / Line-in audio 1 source.
The button is lit when switched to this source.
5 MIC/Line-in audio 2 Switches to the MIC / Line-in audio 2 source.
The button is lit when switched to this source.
6 HDMI 1 audio
source
Switches to the HDMI 1 audio source.
The button is lit when switched to this source.
TUSFBNJOHUSBOTJUJPOTHP!MJWF4859BVUPDVUBVEJP2BVEJP3BVEJPTSDQHNTDFOFTIENJ2IENJ4BGWBGWBGWBGWIENJ3MJOFJOIENJ52637QHNNVUF11
12 13 14 15
16
17
1819
20
8
2
3
4
56 7
1
910

StreamLIVE™ PRO User Manual
6
7 HDMI 2 audio
source
Switches to the HDMI 2 audio source.
The button is lit when switched to this source.
HDMI 3 audio
source
Switches to the HDMI 3 audio source.
The button is lit when switched to this source.
9 HDMI 4 audio
source
Switches to the HDMI 4 audio source.
The button is lit when switched to this source.
10 AFV Audio-Follows-Video: Press to light the AFV button. the
source’s audio is played whenever its video is being
displayed.
11 mute Mutes / unmutes the audio of the audio source selected.
Muting HDMI source 1, 2, 3, or 4, will also turn off its AFV.
12 PGM Switches to the audio of PGM.
The button is lit when switched to this source.
Video Section (controls the video settings of the system)
13 scenes selector Selects the current stream (PGM) scene and the preview
(PRV) scene.
Greenly lit button indicates PRV Preview.
Redly lit button indicates PGM Preview.
Transition Control Section (switches the current stream (PGM) scene to the preview
(PRV) stream and vice versa)
14 auto (transition) Pressing the Auto button performs the transition at a set
interval (0.3 - 3 seconds).
Go to the Setting Deck and refer to page 54 on how to
modify this specified time.
Press and hold for 3 seconds to enter Quick Mode. Refer
to dit the video scenes in scene editor, tune audio
settings in the audio mixer deck, adjusting audio delays
in the settings deck, etc. Tap Apply to apply the changes.
on page 66 for more information.
15 cut (transition) The transition happens immediately when you press the
Cut button.
Press and hold for 3 seconds to enter Quick Mode. Refer
to dit the video scenes in scene editor, tune audio
settings in the audio mixer deck, adjusting audio delays
in the settings deck, etc. Tap Apply to apply the changes.
on page 66 for more information.
No. Component Description

Chapter 1. Introduction
7
16 T-Bar (transition) Slide the T-Bar to start the transition. The scene
transition speed depends on how fast you slide the bar.
Sliding the T-bar all the way to one end will complete the
transition.
You can create different effects by sliding it slowly, quickly
or even pausing it halfway.
17 iPad stand Holds the iPad for convenient viewing.
1 Go Live Press this button to start streaming and/or recording.
Press again to stop.
19 pause stream Press this button to enter a pause screen during
streaming.
20 SRC / PGM view
selector
Press to switch displaying between HDMI source 1,
HDMI source 2, HDMI source 3, HDMI source 4, and
PGM.
No. Component Description

StreamLIVE™ PRO User Manual
Rear View
No. Component Description
1 SRC / PGM output
port
Programmed (PGM) video output.
2 4K HDMI loop out
port/4K HDMI 1
input port
An 4K HDMI 1 input source and a 4K HDMI loop out.
3 FHD HDMI 2 input
port/HDMI 3 input
port/HDMI 4 input
port
HDMI 10 0P video input that can take HDMI 10 0P
video input 2, 3, or 4. To select input 2, 3, or 4, go to
Media on page 40.
4 Ethernet port For Internet connection.
5 USB 3.1 Gen1 Type-
A port (storage only)
For livestream recording.
6 USB 3.1 Gen1 Type-
A port
For firmware upgrade.
7 MIC in/Line in audio
ports
Connect MIC or audio sources for additional audio
effects.
power jack Powers the unit.
9 power switch Switch the power on the unit.
JOQVU!2JOQVU!3PVUQVUMPPQ!PVUIENJ2191QWJEFPIENJ5LWJEFPTSD0QHNBVEJP!2BVEJP!3JOQVU!4JOQVU!5QPXFSED23WVTCTUPSBHFNJD0MJOFJO124
39
678
5
