ATEN ALTUSEN KL1508A User manual

KL1508A / KL1516A
8 / 16-Port Multi-Interface Cat 5
Dual Rail LCD KVM Switch
User Manual

KL1508A / KL1516A User Manual
ii
Compliance Statements
FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE
STATEMENT
This equipment has been tested and found to comply with the limits for a Class
A digital device, pursuant to Part 15 of the FCC ules. These limits are
designed to provide reasonable protection against harmful interference when
the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a
residential area is likely to cause harmful interference in which case the user
will be required to correct the interference at his own expense.
The device complies with Part 15 of the FCC ules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference,
and (2) this device must accept any interference received, including
interference that may cause undesired operation.
FCC Caution
Any changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate this equipment.
Warning
Operation of this equipment in a residential environment could cause radio
interference.
Suggestion
Shielded twisted pair (STP) cables must be used with the unit to ensure
compliance with FCC & CE standards.
Achtung
Der Gebrauch dieses Geräts in Wohnumgebung kann Funkstörungen
verursachen.
KCC Statement

KL1508A / KL1516A User Manual
iii
Industr Canada Statement
This Class A digital apparatus complies with Canadian ICES-003.
RoHS
This product is oHS compliant.

KL1508A / KL1516A User Manual
iv
User Information
Online Registration
Be sure to register your product at our online support center:
Telephone Support
For telephone support, call this number:
User Notice
All information, documentation, and specifications contained in this manual
are subject to change without prior notification by the manufacturer. The
manufacturer makes no representations or warranties, either expressed or
implied, with respect to the contents hereof and specifically disclaims any
warranties as to merchantability or fitness for any particular purpose. Any of
the manufacturer's software described in this manual is sold or licensed as is.
Should the programs prove defective following their purchase, the buyer (and
not the manufacturer, its distributor, or its dealer), assumes the entire cost of all
necessary servicing, repair and any incidental or consequential damages
resulting from any defect in the software.
The manufacturer of this system is not responsible for any radio and/or TV
interference caused by unauthorized modifications to this device. It is the
responsibility of the user to correct such interference.
The manufacturer is not responsible for any damage incurred in the operation
of this system if the correct operational voltage setting was not selected prior
to operation. PLEASE VE IFY THAT THE VOLTAGE SETTING IS
CO ECT BEFO E USE.
International http://eservice.aten.com
International 886- -869 -6959
China 86-400-810-0-810
Japan 81-3-5615-5811
Korea 8 - -467-6789
North America 1-888-999-ATEN ext 4988
1-949-4 8-1111

KL1508A / KL1516A User Manual
v
Product Information
For information about all ATEN products and how they can help you connect
without limits, visit ATEN on the Web or contact an ATEN Authorized
eseller. Visit ATEN on the Web for a list of locations and telephone numbers:
International http://www.aten.com
North America http://www.aten-usa.com

KL1508A / KL1516A User Manual
vi
Package Contents
Check to make sure that all the components are in working order. If you
encounter any problem, please contact your dealer.
The KL1508A / KL1516A ’s standard package consists of:
1 KL1508A or KL1516A Multi-Interface Cat 5 Dual ail LCD KVM Switch
1 firmware upgrade cable
1 power cord
1 user instructions

KL1508A / KL1516A User Manual
vii
Contents
Compliance Statements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ii
User Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iv
Online Registration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iv
Telephone Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iv
User Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iv
Product Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . v
Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vi
Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii
About This Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . x
Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xi
Chapter 1. Introduction
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Features and Benefits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
External Console . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Computers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
KVM Adapter Cables. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Operating Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Front View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Keyboard Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
LCD Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Rear View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
KL1508A . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
KL1516A . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Chapter 2. Hardware Setup
Before you Begin. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Standard Rack Mount . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Front L-Bracket Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Optional Rack Mount Kits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Single-Station Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Daisy Chaining . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Chapter 3. Basic Operation
Opening the Console . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Opening Separately . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Opening Together . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Operating Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Closing the Console . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
LCD OSD Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
The LCD Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
The Adjustment Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Port Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

KL1508A / KL1516A User Manual
viii
Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
OSD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Hotkey . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Hot Plugging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Hot Plugging Stations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Hot Plugging KVM Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Hot Plugging Console Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Powering Off and Restarting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Port ID Numbering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Chapter 4. OS Operation
OSD Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
OSD Login . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
OSD Hotkey . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
OSD Main Screen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
OSD Navigation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
OSD Main Screen Headings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
OSD Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
F1: GOTO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
F : LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
F3: SET. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
F4: ADM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
F5: SKP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
F6: BRC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
F7: SCAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
F8: LOUT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Chapter 5. Hotkey Operation
Hotkey Port Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Invoking Hotkey Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Number Lock and Minus Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Control and F1 Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Hotkey Mode Environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Exiting Hotkey Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Selecting the Active Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Auto Scan Mode Switching . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Setting the Scan Interval . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Entering Auto Scan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Exiting Auto Scan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Skip Mode Switching . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Entering Skip Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Exiting Skip Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Computer Keyboard / Mouse Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Setting the Hotkey Beeper ON/OFF . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Setting the Hotkey key combination . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Setting the OSD Hotkey combination . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Setting the Port Operating System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

KL1508A / KL1516A User Manual
ix
Restore the Default Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Hotkey Summary Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Chapter 6. Keyboard Emulation
Mac Keyboard. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .59
Sun Keyboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Chapter 7. The Firmware Upgrade Utility
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Performing the Upgrade . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Starting the Upgrade . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Upgrade Succeeded . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Upgrade Failed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Recovering the Failed Main Board Firmware Upgrade . . . . . . . . . 67
Recovering the Failed Adapter Cable Firmware Upgrade . . . . . . . 67
Appendix
Safety Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .69
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Rack Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
International . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
North America . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .73
Connection Tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .75
KL1508A . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
KL1516A . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Compatible Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
OSD Factory Default Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Administrator Login Failure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
Dedicated Invocation Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
Sun Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

KL1508A / KL1516A User Manual
x
About This Manual
This manual is provided to help you get the most out of your KL1508A /
KL1516A. It covers all aspects of the device, including installation,
configuration, and operation.
The LCD KVM switch models covered in this manual include:
An overview of the information found in the manual is provided below.
Chapter 1, Introduction, introduces you to the KL1508A / KL1516A, its
purpose, features, and benefits, with its front and back panel components
described.
Chapter 2, Hardware Setup, describes how to set up the device, with the
necessary steps provided, from a basic single-stage hookup to a complete daisy
chained operation.
Chapter 3, Basic Operation, explains the fundamental concepts involved
in operating the KL1508A / KL1516A.
Chapter 4, OS Operation, provides a complete description of the
KL1508A / KL1516A's OSD (On Screen Display), and the various functions
contained.
Chapter 5, Hotkey Operation, details all of the concepts and procedures
involved in the hotkey operation of your KL1508A / KL1516A installation.
Chapter 6, Keyboard Emulation, provides tables that list the PC to Mac
and PC to Sun keyboard emulation mappings.
Chapter 7, The Firmware Upgrade Utility, explains how to upgrade the
KL1508A / KL1516A's firmware to the latest available version.
Appendix, provides the specifications and other technical information of the
KL1508A / KL1516A.
Note:
ead this manual thoroughly and follow the installation and operation
procedures carefully to prevent any damage to the unit or connected
devices.
Model Product Name
KL1508A 8-Port Multi-Interface Cat 5 Dual Rail LCD KVM Switch
KL1516A 16-Port Multi-Interface Cat 5Dual Rail LCD KVM Switch

KL1508A / KL1516A User Manual
xi
The product may be updated, with features and functions added, improved,
or removed since the release of this manual. For an up-to-date user
manual, visit http://www.aten.com/global/en/
Conventions
This manual uses the following conventions:
Monospaced Indicates text that you should key in.
[ ] Indicates keys you should press. For example, [Enter]
means to press the Enter key. If keys need to be chorded,
they appear together in the same bracket with a plus sign
between them: [Ctrl+Alt].
1. Numbered lists represent procedures with sequential steps.
♦Bullet lists provide information, but do not involve sequential
steps.
>Indicates selecting consecutive options (such as on a menu
or dialog box). For example, Start > Run means to open the
Start menu, and then select Run.
Indicates critical information.

KL1508A / KL1516A User Manual
xii
This Page Intentionally Left Blank

1
Chapter 1
Introduction
Overview
KL1508A / KL1516A KVM switch is a control unit that allows access and
control to multiple computers from a single KVM (keyboard, monitor, and
mouse) console. A single KL1508A / KL1516A can control up to 8 / 16
computers. They consist of an integrated LED-backlit LCD monitor, keyboard,
and touchpad in a 1U rack-mountable retractable sliding housing.
The similarities and differences among the models in the KL1508A / KL1516A
series are shown in the following table:
The LCD and keyboard/touchpad modules slide independently of each other.
To maximize space in your data center, the keyboard/touchpad module slides
back to “hide away” when not in use, while the thin profile LCD monitor
rotates back — flush against the rack — allowing administrators to monitor the
activities of connected computers.
By daisy chaining up to 31 additional switches, as many as 256 / 512 computers
can be controlled from the original KVM console. An auto-sensing function
recognizes the position of each station on the chain, eliminating the need to
manually set the position, and a seven-segment front panel LED displays each
Station's position for easy identification.
Compact, high-density, J-45 connectors and CAT 5e/6 cables make for
simple wiring configuration, with the flexibility to use PS/2 and USB KVM
adapter cables in any combination to link various types of computers,
including PCs, Macs, Sun computers, and serial devices.
Setup of the KL1508A / KL1516A is fast and easy — plugging cables into their
appropriate ports is all that is entailed. There is no software that needs to be
configured nor complex installation procedures.
Model LC Panel Ports
KL1508AM 17" 8
KL1508AN 19" 8
KL1516AM 17" 16
KL1516AN 19" 16

Access and switching to any computer on the installation is easily
accomplished — either by pressing front panel port selection pushbuttons,
entering hotkey combinations on the keyboard, or by means of a powerful OSD
(On Screen Display) menu system. A convenient Auto Scan function also
permits automated monitoring of all connected computers by switching views
from one to another at set intervals.
Your KL1508A / KL1516A investment is protected through firmware
upgrades. You can download the latest firmware update files from our website,
and upgrade the device with its Firmware Upgrade function.
There is no better way to save time and money than with a KL1508A /
KL1516A installation. By using the KL1508A / KL1516A with its sliding
LCD console to manage your installation, you: (1) eliminate the expense of
purchasing separate keyboards, monitors, and mice; (2) save all the space those
extra components would take up; (3) save on energy costs; and (4) eliminate
the inconvenience and wasted effort involved in constantly having to move
from one computer to another.

Chapter 1. Introduction
3
Features and Benefits
The features and benefits provided by the KL1508A / KL1516A are described
in the following table:
Features Benefits
Keyboard/Touchpad
module
KVM console with a built-in 17"/ 19" LED-backlit LCD monitor
in a sliding housing with top and bottom clearance for smooth
operation on a 1U rack.
Dual Rail operation — LCD monitor slides independently of
the keyboard/touchpad.
Console lock enables the sliding console to remain securely
locked away when not in use.
LCD module rotates up to 1 0 degrees for a more
comfortable viewing angle.
LED Light Exclusive LED illumination light — designed by ATEN to
illuminate the keyboard and touchpad to allow visibility in low-
light conditions.
Single Console Control Access and control up to 8 (KL1508A) or 16 (KL1516A)
computers from a single PS/ or USB KVM (keyboard, video,
and mouse) console.
Scalability By daisy chaining up to 31 additional KL1508A / KL1516A
switches, as many as 56 / 51 computers can be controlled
from the original KVM console — eliminating the expense of
purchasing separate peripherals for each server.
Easy Installation Setting up the KL1508A / KL1516A is fast and easy —
plugging cables into their appropriate ports is all that is
entailed. Because there is no software that needs to be
configured, incompatibility and configuration issues are non-
existent.
Easy Operation Three port selection methods: Manual (via front panel
pushbuttons), Hotkey, and multi-language OSD (On Screen
Display).
Keyboard Language support: English (US); English (UK);
German; German (Swiss); French; Spanish; Traditional
Chinese; Japanese; Korean; Swedish; Italian; Russian;
Hungarian and Greek
Hardware Independent
Cross-Platform
Support
The KL1508A / KL1516A supports Windows 000 / XP / Vista
/ 7, Linux, Unix, Novell, FreeBSD, Sun, and Mac.
Space-Saving RJ-45
Connectors and Cat
5e/6 Cabling
This space-saving innovation means that the KL1508A /
KL1516A can be conveniently installed in a 1U system rack,
and the installation can take advantage of the internal
network wiring built into most modern commercial buildings.
Reduces cable clutter for a neat and tidy data center
environment

KL1508A / KL1516A User Manual
4
KVM Adapter Cables
to Connect to Servers
and Devices
For convenience and flexibility, the KL1508A / KL1516A's
design utilizes KVM adapter cables that serve as the medium
between the KVM switch and the connected devices, for
convenient mixing and matching among various interfaces
and platforms.
KVM adapter cables are available in PS/ , USB, and serial
interfaces to support a wide variety of data center servers and
devices.
Two-Level Password
Security
Supports one administrator and ten user profiles. Strong
password protection prevents unauthorized accessing to the
installation — keeping your valuable data secure.
Upgradeable Firmware Stay up-to-date with the latest functionality improvements and
updates by downloading firmware upgrade files from our
website and installing them with the built-in firmware upgrade
utility.
Effortless Upgrades Simultaneous firmware upgrades to all daisy-chained KVM
switches and dongles through the daisy-chain cable.
Auto Scanning and
Broadcast Mode
Auto scanning provides hands-free, automated monitoring of
selected devices by switching among them at variable rates.
Broadcast Mode sends commands from the console to all
computers — allowing you to perform operations (such as
software installation, upgrades, shutdowns, etc.), on them
simultaneously
Superior Video Quality Supports video resolutions of up to 1 80 x 10 4 @ 75 Hz for
up to 50 meters with ATEN KVM Cable Adapter KA7000
series.
Multiple User Accounts Supports up to 10 user and 1 administrator accounts
Hot Pluggable Ability to add or remove components without having to power
off the KVM switch.
Adapter Cables with ID The KL1508A / KL1516A KVM series supports automatic ID
recognition of the ATEN KVM Cable Adapter KA7000 series
(KVM Adapter Cables). Using adapter cables with ID means it
is not required to change cable configuration settings when
moving cables from one port to another.
Device ID and attributes are stored in the adapter cables
allowing you to hot-swap port connections without having to
reconfigure them.
Optional rack mount
kits
Optional rack mount kits available, including easy installation
options.

Chapter 1. Introduction
5
Requirements
External Console
A VGA, SVGA, or multisync monitor capable of the highest resolution
that you will be using on any computer in the installation
A PS/2 or USB mouse
A PS/2 or USB keyboard
Computers
The following equipment must be installed or available on the computers that
connect to the KL1508A / KL1516A KVM ports:
A VGA, SVGA or multisync port
Note: The integrated LCD monitor's maximum resolution is
1280 x 1024 @ 75 Hz. If you want to use a higher setting for the
screen resolutions of the attached computers, see Troubleshooting,
page 80.
A Type A USB port and USB host controller (for USB KVM adapter cable
connection, see following section)
- or -
6-pin mini-DIN keyboard and mouse ports (for PS/2 KVM adapter cable
connection, see following section)
KVM Adapter Cables
Cat 5e/6 cable is required to connect the KL1508A / KL1516A to one of
the KVM adapter cables.
The following KVM adapter cables are required for use with the
KL1508A / KL1516A:
Function Module
Connect to devices with PS/ ports
KA79 0 / KA75 0 / KA71 0
KA95 0 / KA91 0
Connect to devices with USB ports
KA7166, KA7168, KA7169,
KA7970 / KA7570 / KA7170
KA9570 / KA9170
Connect to Sun Legacy systems (with 13W3 port) KA9130 / KA7130
Connect to Sun USB systems KA9170 / KA7170

KL1508A / KL1516A User Manual
6
Note: 1. KVM adapter cables are referred to as I/O Modules in some dialog
boxes.
2. The following cable models support the Adapter Cable ID function:
KA7920 / KA7970 / KA7520 / KA7570 / KA7120 / KA7130 /
KA7166 / KA7168 / KA7169 / KA7170.
Operating Systems
Supported operating systems are shown in the table, below:
Note: 1. Does not support USB.
2. Kernels below 2.6 do not support USB 2.0.
Connect to serial based devices KA9140
OS Version
Windows NT
1
, Server 003, Server 008, or later
Linux
2
RedHat 9.0, Fedora or later, RHEL AS 4, RHEL 5
SuSE 10 or later, OpenSUSE 10. ; SLES 10 SP1
Debian 3.1, 4.0
Ubuntu 7.04, 7.10
UNIX IBM AIX4.3, 5L (V5. ,V5.3), V6 (V6.1)
FreeBSD 5.5, 6.1, 6.
Novell Netware 5.0 or later
Sun Solaris 8, 9, 10
Mac 9.0, 9.1, 10.1, 10. , 10.3, 10.4 , 10.5
DOS 6. or later
1
Function Module

Chapter 1. Introduction
7
Components
Front View
No. Component escription
1 upper handle Pull to slide the LCD module out; push to slide the module in.
See Opening the Console, page 3, for details on sliding the
console in and out.
LCD module See LCD Module, page 9.
3 keyboard module See Keyboard Module, page 8.
4 lower handle Pull to slide the keyboard module out. See Opening the
Console, page 3, for more details on sliding the console in
and out.
5 power LED Lights (blue) to indicate that the unit is receiving power.
6 keyboard release
catch
These catches (one on each side) release the keyboard
module so you can slide it away.
7 LCD release
catch
These catches (one on each side) release the LCD module
so you can slide it away.
8 rack mount
brackets
The rack mount brackets located at each corner of the unit
secure the chassis to a system rack. See Standard Rack
Mount, page 1 , for details.
9 LED light Exclusive LED illumination light — illuminates the keyboard
and touchpad for operation under low-light conditions.
Turned on by default, click the exit / light button to turn it on /
off.

KL1508A / KL1516A User Manual
8
Keyboard Module
No. Component escription
1 keyboard Standard 105-key keyboard
touchpad Standard mouse touchpad
3 external mouse
port
This USB Type-A mouse port is provided for users who prefer
to use an external mouse.
4 station ID LED In a daisy chained installation, the station ID of the currently
selected station displays as a -digit figure in this panel.
See Port ID umbering, page 33 for further details.
5 station selection
area
 The LED displays the station number that the port with the
KVM focus is located on.
 The left button shifts the KVM focus down the chain
(Station → Station 1, etc.). After station 1, it cycles back
to the last station.
 The right button shifts the KVM focus up the chain. After
the last station, it cycles to station 1.
6 lock LEDs &
reset button
The Num Lock, Caps Lock, Scroll Lock LEDs are located
here.
A reset button is located just to the right of the Lock LEDs.
Press this button in with a thin object to perform a system
reset.
7 port selection
pushbuttons and
LEDs
To access a port on the currently selected station press its
corresponding port selection button. Indicator LEDs are built
into the switches:
 An On Line LED lights to indicate that the computer
attached to its corresponding port is up and running.
 A Selected LED lights to indicate which port has the KVM
focus.
