ATEN VS-881 User manual

user manual
VS-BS1_________
Read ftis guide thoroughiy and toflow thè installation and operaton proctì-
durescare(ully in order to prevent any damage to thè unte and/or any de-
vtees that connect to Ihem.
Thfs package contains:
1 8 Port Video Swttch
1 Infrand Remote Control Handset
1 WraredReceiver (with 1.8mattached cable)
) Video Cable (1.2m)
1 Power Adapter
1 User Manual
i Qutek Start Guide
O Copyright 2000 ATEN*lntemational Co., Ltì. C.
Marmai Pan No. PAPE-1213-100
Printed in Taiwan 12/2002
AK bnuid nameg and tradanuute ai» thè faglatered property o< tneir
respecttve owners.
NOTE: This equipment has been tested and found
to comply with thè limits for a Class B digitai devtoe
pursuant to Subpart J of Part 15 of FCC Rutes. These
limits are designed to provide reasonable protection
against harmfui interference in a residential
installation. This equipment generates, uses and can
radiate radio frequency energy and, if not instalied
and used in accordance with thè instrucUons, may
cause harmfui interference to radio communications.
However, there is no guarantee that interference will
not occur in a particular installation. If this equipment
does cause harmfui interference to radio ortelevision
reception, which can be determined by tuming thè
equipment off and on, thè user is encouraged to try
to correct thè interference by one or more of thè
following measures:
* Reorientor relocate thè receiving antenna.

* Increase thè separation between thè equipment
and reciever.
* Connect thè equipment into an outiet on a circuii
different from that to which thè receiver is
connected.
* Consult thè dealer or an experienced
radioAelevision technician for help.
'EM requirements
VOAtSVQA, XGA, or Multisync compatible
''fiiìSiog .niónitor, with a standard PC high density cable
a 15 p»n HDB type male connector
||a/qa, SVGA, XGA,or Multisyrw anatog video card
jawjng a standard PC 15 pin HDB type temale
Noto: One (1) video cable is supplicò with this unit.
FRONT view
1. IR Reciever Port
Thè external IR Receiver has an attached cable that
alfows it to be placed anywhere up to 1.8m from thè
switch, Thè cable from thè extemal IR Receiver plugs
in nere.
2. Monitor Port
Thè cable from thè monitor or digitai projector plugs in
here.
3. Power Jack
Thè AC Power Adapter cable plugs in here.

OVERVIEW
Thè VS-881 Video Switeh is a modern control unit that
allows you to conveniently display thè video output of
eight separate computer systems on a single monitor, or.
via a multimedia projector - thereby eliminating thè
unnecessary expense of purchasing a separate monitor
for each computer. Thè VS-881 is perfect tor corporate
presentations, company briefings and institutional
learning centers.
Thè VS-881 improves on previous video switch modeis
with enhanced features that include a freely accessible
concentric-hub design; easy computer selection via push
buttons; intelligent infrared (IR) remote control; and
electronic switching technology, rather than medianica!
switching, for reliability and durability.
Thè VS-881 also saves on thè space that additional
monitors take up, as well as thè extra power costs, and
eliminates thè inconvenience and wasted effort ìnvolved
in constantly moving around from one computer to
another.
FEATURE S
* Displays thè video output of elght separate computerà
on a single monitor or projector
* New modern concentric design with logicai connector
layout for quick and easy access
* Fast and convenient computer selection via push
buttons or infrared (IR) remote contro!
* External IR Receiver (1.8m) for maximum efficiency
and convenlence
* Extra-thin IR handset allows easy Storage in thè
mother unit
* Electronic Switching for greater reliability and durability
* High resolution video-upto 2048 x 1536; DDC;
DDC2; DDC2B
* Supports, VQA, SVGA, XGA and multisync monitore
* Easy installation - no software required - no
configuration necessary
REAR VIEW

1. Video Porta
Thè cables that connect to thè computer video ports
plug in here.
There are eight video ports distributed around thè
VS-881 's circumference.
1. Port LEDS
* A LED lights GRANGE to indicate thè computer
connected to to its corresponding port is Onilne.
* Thè LED changes to QREEN to indicate thè computer
connected to to its corresponding port is thè one that Is
currently selected.
* Thè LED goes out when thè computar connected to to Its
corresponding port is in Stanctoy mode.
2. Port Down Switch
Press this button to switch thè video focus to thè
computer previous to thè current one.
3. VGA Display On / Off
Powers thè unit's VGA display ON and OFF.
4. Port Up Switch
Press this button to switch thè video focus to thè
computer subsequent to thè current one.

Projectop Monitor
PQRT SELECTION
MANUAL PdRT up / PORT ddwn
Use thè Port Up and Port Down buttons, located on thè
top of thè VS-881 unit, to cycle thè video focus to thè
port you want.
A Port LED changes from GRANGE to GREEN to
indicate that thè computer connected to its corresponding
port has thè video focus.
NoteBook PC
NotfcBook
PC NoteBook
Mac NoteBook Mac
IR port UP / PORT DaWN
Thè video focus can also be cycled among thè
computers using thè Port Up and Port Down buttons of
thè IR Remote Control Unit (see p. 7).
Note: Thè IR Remote Control Unit is used in conjunction
with thè external IR Receiver (see thè diagram onp.9).
limited warranty
IN NO EVENT SHALL THÈ DIRECT VENDOR'S
LIABILITY FOR DIRECT, INDIRECT, SPECIAL,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES
RESULTING FROM THÈ USE OF THÈ PRODUCT,
DISK, OR ITS DOCUMENTATION EXCEED THÈ
PRICE PAID FOR THÈ PRODUCT.
Thè direct vendor makes no warranty or representation,
expressed, implied, or statutory with respect to thè
contents or use of this documentation, and especially
disclaims its quality, performance, merchantability, or
fitness for any particular purpose.
Thè direct vendor also reserves thè right to revise or
update thè device or documentation without obligation to
notify any individuai or entity of such revisions, or update.
For further inquiries, please contact your direct vendor.

IR remoteCONTROLLI NIT
1. VGA Display ON/OFF
Powers thè unit's VGA display ON and OFF.
2. Port Up / Port Down
These buttons function in a similar manner to thè Port
Up / Port Down buttons on thè main unii. Press these
buttons to switeh thè video focus to thè NEXTor
PREVIOUS computer on thè Installation.
3. Port Selection
Thè numbers correspond to thè video portson thè
main unit. Press a button (1 to 8) to switeh thè video
focus to thè computer connected to to its
correspondingport.
Note: Thè VS-881's remote control handset comes
packaged in protective plastic film. Please
remove this film before operating it with thè
VS-881 main unit.
installation
Installation is simply a matter of plugging in cables.
1. Make sure that power to ali thè devices you will be
connecting up have been turned off.
2. Plug thè monitor or digitai projector cable into thè
unit's Monitor port.
3. Plug one end of a video cable (see thè System
Requirements section on p. 3), into any available
video port on thè unit; plug thè other end into thè
computer's video output port.
Note: One video cable is supplied with this unit.
Additional cables require an extra purchase.
4. Plug thè power adapter (supplied with this package)
into an AC source; plug thè power adapter cable into
thè unit's Power Jack.
5. Plug thè IR Receiver cable into thè IR Receiver port at
thè front of thè main unit.
6. Power On ali equipment.specificati a
IR Dl»ECT port selection
Instead of cycling among thè Individuai computers
one-by-one, a computer can be directiy selected by
pusnirig thè button on thè Remote Control Unit that
corresponds to its port number (1-8) on thè main unit.
Thè selected porfs LED changes from ORANGE to
GREEN to Indicate that thè computer connected to its
corresponding port has thè video focus.
Note: Thè VS-881's Remote Control Unit has a
ma^mum fnfrared-signal range of up to10 meters.
Por opttnum performance make sure that there is
a clear line-of-site between thè handset and thè
receivèr.
Funetlon Speciflcatlon
Connecto Video 8HDB-15 Male

rs In
Video
dui 1
HDB-15
Female
Power
In
1 Power Adapter Jack
IR 1 Earphone Jack
LEDs 8 Onilne / Selected (Orange /
Green)
1 VGA Display ON/OFF (Blue)
Fon Selection Push Button Switehes / IR Remote
Control
Video Resolution 2048x1536
Power
Consumptfon
AC 9V, 4.5W
Operating
Temperature 0-
50°C
Storage
Temperature
-20 - 60''C
Humidity 0 - 80% RH Non condensing
Housing Plastic
Weight 0.45 Kg
DImensions (L x W
x H) 17x19x4.5cm
