ATEN Slideaway CL1008 User manual

CL1008 / CL1016
LCD KVM Switch
User Manual

CL1008 / CL1016 User Manual
ii
Compliance Statements
FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE
STATEMENT
This equipment has been tested and found to comply with the limits for a Class
A digital device, pursuant to Part 15 of the FCC ules. These limits are
designed to provide reasonable protection against harmful interference when
the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a
residential area is likely to cause harmful interference in which case the user
will be required to correct the interference at his own expense.
The device complies with Part 15 of the FCC ules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference,
and (2) this device must accept any interference received, including
interference that may cause undesired operation.
FCC Caution
Any changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate this equipment.
Warning
Operation of this equipment in a residential environment could cause radio
interference.
Achtung
Der Gebrauch dieses Geräts in Wohnumgebung kann Funkstörungen
verursachen.
KCC Statement

CL1008 / CL1016 User Manual
iii
Industr Canada Statement
This Class A digital apparatus complies with Canadian ICES-003.
RoHS
This product is oHS compliant.

CL1008 / CL1016 User Manual
iv
User Information
Online Registration
Be sure to register your product at our online support center:
Telephone Support
For telephone support, call this number:
User Notice
All information, documentation, and specifications contained in this manual
are subject to change without prior notification by the manufacturer. The
manufacturer makes no representations or warranties, either expressed or
implied, with respect to the contents hereof and specifically disclaims any
warranties as to merchantability or fitness for any particular purpose. Any of
the manufacturer's software described in this manual is sold or licensed as is.
Should the programs prove defective following their purchase, the buyer (and
not the manufacturer, its distributor, or its dealer), assumes the entire cost of all
necessary servicing, repair and any incidental or consequential damages
resulting from any defect in the software.
The manufacturer of this system is not responsible for any radio and/or TV
interference caused by unauthorized modifications to this device. It is the
responsibility of the user to correct such interference.
The manufacturer is not responsible for any damage incurred in the operation
of this system if the correct operational voltage setting was not selected prior
to operation. PLEASE VE IFY THAT THE VOLTAGE SETTING IS
CO ECT BEFO E USE.
International http://eservice.aten.com
International 886-2-8692-69 9
China 86-400-810-0-810
Japan 81-3- 61 - 811
Korea 82-2-467-6789
North America 1-888-999-ATEN ext 4988
1-949-428-1111

CL1008 / CL1016 User Manual
v
Product Information
For information about all ATEN products and how they can help you connect
without limits, visit ATEN on the Web or contact an ATEN Authorized
eseller. Visit ATEN on the Web for a list of locations and telephone numbers:
International http://www.aten.com
North America http://www.aten-usa.com

CL1008 / CL1016 User Manual
vi
Package Contents
Check to make sure that all the components are in working order. If you
encounter any problem, please contact your dealer.
Basic Package
The basic CL1008 or CL1016 package consists of:
1 CL1008 or CL1016 with Standard ack Mount Kit
2 custom KVM cable sets
1 power cord
1 firmware upgrade cable
1 user instructions

CL1008 / CL1016 User Manual
vii
Contents
Compliance Statements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ii
User Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iv
Online Registration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iv
Telephone Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iv
User Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iv
Product Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . v
Package Contents. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vi
Basic Package. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vi
Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii
About this Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . x
Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xi
1. Introduction
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Computers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
OS Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Front View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Rear View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
. Hardware Setup
Before you Begin. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Standard Rack Mounting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Optional Rack Mount Kits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Single Stage Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Daisy Chain Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
3. Basic Operation
Opening the Console . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Closing the Console . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Operating Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Powering Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Powering Off and Restarting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
LCD OSD Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
The LCD Buttons. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
LCD Adjustment Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Port ID Numbering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Port Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Manual Port Switching. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Hot Plugging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
4. OSD Operation

CL1008 / CL1016 User Manual
viii
OSD Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Logging In. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
OSD Main Screen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
OSD Main Screen Headings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
OSD Navigation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
OSD Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
F1: GOTO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
F2: LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
F3: SET. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
F4: ADM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
F : SKP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
F6: BRC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
F7: SCAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
F8: LOUT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
5. Hotkey Operation
Hotkey Port Access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Invoking Hotkey Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Exiting Hotkey Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Hotkey Mode Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Hotkey Mode Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Selecting the Active Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Auto Scan Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Setting the Scan Interval . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Invoking Auto Scan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Pausing Auto Scan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Exiting AutoScan Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Skip Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Hotkey Beeper Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Hotkey Summary Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
6. The Firmware Upgrade Utility
Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Starting the Upgrade. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Upgrade Succeeded . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Upgrade Failed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Appendix
Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Rack Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Consignes de sécurité . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Général . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Montage sur bâti . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Technical Support. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
International . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
North America . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

CL1008 / CL1016 User Manual
ix
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
CL1008 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
CL1016 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Connection Tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .60
CL1008 – ACS1208A . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .60
CL1008 – ACS1216A . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .60
CL1016 – ACS1208A . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .61
CL1016 – ACS1216A . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .61
Clear Login Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
OSD Factory Default Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Dedicated Invocation Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
About SPHD Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

CL1008 / CL1016 User Manual
x
About this Manual
This User Manual is provided to help you get the most from your CL1008 /
CL1016 system. It covers all aspects of installation, configuration and
operation. An overview of the information found in the manual is provided
below.
Introduction, introduces you to the CL1008 / CL1016 system. Its purpose,
features and benefits are presented, and its front and back panel components
are described.
Hardware Setup, describes how to set up your installation. The necessary
step – from a basic single stage hookup to a complete 16 switch daisy chained
operation are provided.
Basic Operation, explains the fundamental concepts involved in operating
the CL1008 / CL1016.
OSD Operation, provides a complete description of the CL1008 / CL1016’s
OSD (on-screen display), and how to work with it.
Hotkey Operation, details all of the concepts and procedures involved in the
Hotkey operation of your CL1008 / CL1016 installation.
The Firmware Upgrade Utility, explains how to use this utility to upgrade
the CL1008 / CL1016's firmware with the latest available versions.
Appendix, provides specifications and other technical information regarding
the CL1008 / CL1016.
Note:
ead this manual thoroughly and follow the installation and operation
procedures carefully to prevent any damage to the unit or connected
devices.
The product may be updated, with features and functions added, improved,
or removed since the release of this manual. For an up-to-date user
manual, visit http://www.aten.com/global/en/

CL1008 / CL1016 User Manual
xi
Conventions
This manual uses the following conventions:
Monospaced Indicates text that you should key in.
[ ] Indicates keys you should press. For example, [Enter] means to
press the Enter key. If keys need to be chorded, they appear
together in the same bracket with a plus sign between them:
[Ctrl+Alt].
1. Numbered lists represent procedures with sequential steps.
♦Bullet lists provide information, but do not involve sequential steps.
>Indicates selecting the option (on a menu or dialog box, for
example), that comes next. For example, Start > Run means to
open the Start menu, and then select Run.
Indicates critical information.

CL1008 / CL1016 User Manual
xii
This Page Intentionally Left Blank

1
Chapter 1
Introduction
Overview
The CL1008 / CL1016 Slideaway
TM
LCD KVM Switch series are control units
that allow access to multiple computers from a single keyboard, video, and
mouse (KVM) console. A single CL1008 or CL1016 can control up to 8 or 16
computers. As many as 15 additional KVM switches can be daisy chained to
the CL1008 / CL1016, so that up to 256 computers can all be controlled from
a single KVM console.
The CL1008 / CL1016 offers a space-saving, streamlined approach to KVM
switch technology by integrating a keyboard, LCD monitor, and touchpad in a
1U rack-mountable sliding housing. The LCD display is built into the cover;
the keyboard and touchpad are built into the base. Slide the KVM module
section out; flip the cover up; and you are ready to work. When finished, flip
the cover down and slide the KVM module away.
The CL1008 / CL1016 is built on a modular design. The KVM section can be
detached from the switch section for convenient maintenance and repair.
Your CL1008 / CL1016 investment is protected by an included Firmware
Upgrade Utility. You can stay current with the latest improvements to the
switch by downloading firmware update files from our website as they become
available, and using the utility to quickly and conveniently perform the
upgrade.
Setup is fast and easy; plugging cables into their appropriate ports is all that is
entailed. Because the CL1008 / CL1016 intercepts keyboard input directly,
there is no software to configure; no need to get involved in complex
installation routines; nor any need to be concerned with incompatibility
problems.
Access to any computer connected to the installation is easily accomplished
either by entering hotkey combinations from the keyboard, or by means of a
powerful, mouse driven, on-screen display (OSD) menu system. A convenient
Auto Scan feature also permits automatic scanning and monitoring of the
activities of all computers running on the installation one by one.

CL1008 / CL1016 User Manual
2
Features
Exclusive LED illumination light - designed by ATEN to illuminate the
keyboard and touchpad to allow visibility in low-light conditions
KVM console with 17" LED-backlit LCD monitor in a sliding housing –
top and bottom clearance for smooth operation in a 1U high system rack
LCD module rotates up to 120 degrees for a more comfortable viewing
angle
Standard rack mount kit included – optional Easy Rack Mounting (single
person installation) rack mount kit available (requires separate purchase)
Daisy chain up to 15 additional units – control up to 128 (CL1008) or 256
(CL1016) computers
No software required – convenient computer selection via hotkeys and
mouse driven intuitive on-screen display (OSD) menus
Auto Scan feature for monitoring user-selected computers
Broadcast support – commands from the keyboard can be broadcast to all
available computers on the installation
Hot pluggable – add or remove computers without having to power down
the switch
Two level password security – only authorized users view and control the
computers – up to four users plus an administrator with separate profiles
for each
Video settings of attached computers are automatically adjusted for
optimal output to the LCD monitor
Upgradable firmware
Keyboard language support: English (US), English (UK), French,
German, German (Swiss), Hungarian, Italian, Japanese, Korean, ussian,
Spanish, Swedish and Traditional Chinese

1. Introduction
3
Requirements
Computers
The following equipment must be installed on each computer:
A VGA, SVGA or multisync card
Note: The integrated LCD monitor's maximum resolution is
1280 x 1024 @ 75 Hz. Make sure that none of the computer
resolution settings exceed the LCD monitor's maximum resolution.
6-pin Mini-DIN (PS/2 style) keyboard and mouse ports
Cables
Substandard cables may damage the connected devices or degrade overall
performance. For optimum signal integrity and to simplify the layout, we
strongly recommend that you use the high quality CS Custom Cable sets
described below:
Function Part Number Length
Daisy-chain Cables 2L-1700 0.6 m
2L-1701 1.8 m
2L-1703 3.0 m
2L-170 .0 m
2L-171 1 .0 m
KVM Switch to Computer 2L- 201P 1.2 m
2L- 202P 1.8 m
2L- 702P 1.8 m
2L- 203P 3.0 m
2L- 206P 6.0 m
2L- 202UP 1.8 m
2L- 203UP 3.0 m
2L- 20 UP .0 m
2L- 206UP 6.0 m

CL1008 / CL1016 User Manual
4
OS Support
Components
Front View
OS Version
Windows 2000 or later
Linux RedHat 7.1–7.3, 8.0, 9.0, Fedora Core 2–4
SuSE 8.2, 9.3, 10
Mandriva (Mandrake) 9, 200 Limited Edition, 2006
UNIX IBM AIX: 4.3, L
FreeBSD 4.2, 4.
Novell Netware: .0, 6.0
Press the Exit/Light pushbutton for
two seconds to turn the LED light
ON or O. (Default: On)
EXI T ILIGHT
4
1
2
2
3
5
12
13
8
6
7
9
10
11

1. Introduction
No. Component Description
1 handle Pull to slide the KVM module out; push to slide the module in
(see item 2 in this table).
2 slide release In order to slide the console out, you must first release it by
sliding these tabs to the inside. See page 1 for details on
sliding the console in and out.
3 LCD display After sliding the KVM module out, flip up the cover to access
the LCD monitor.
4 LCD controls The LCD On / Off switch is located here, as well as buttons to
control the position and picture settings of the LCD display.
See page 19 for details.
port selection
pushbutton /
LEDs (8 for
CL1008, 16 for
CL1016)
Press the port selection pushbuttons to bring the KVM focus
to the computer attached to its corresponding port. See
page 21 for details.
Two Port LEDs are built into the port switches. The one on
the left is the On Line LED; the one on the right is the
Selected Port LED:
 An On Line LED lights orange to indicate that the computer
attached to its corresponding port is up and running.
 A Selected LED lights green to indicate that the computer
attached to its corresponding port has the KVM focus. The
LED is steady under normal conditions, but flashes when
its port is accessed under Auto Scan Mode (see F7: SCAN,
page 3 ).
6 keyboard Standard 10 -key keyboard
7 touchpad Standard touchpad
8 LED
illumination light
Press the Exit / Light pushbutton for two seconds to turn the
LED light on or off. (Default: On)
9 power LED Lights dark green to indicate that the unit is receiving power.
10 rack mount
brackets
The rack mount brackets located at each corner of the unit
secure the chassis to a system rack.
11 lock LEDs The Num Lock, Caps Lock, Scroll Lock LEDs are located
here.
12 reset button Located to the right of the Lock LEDs. Press this button in
with a small object to perform a system reset.
13 firmware
upgrade
section
 Firmware upgrade port: The firmware upgrade cable that
transfers the firmware upgrade data from the
administrator's computer to the CL1008 / CL1016 plugs
into this RJ-11 connector.
 Firmware upgrade switch: During normal operation this
switch should be in the NORMAL position. (See p. 43 for
firmware upgrading details.)

CL1008 / CL1016 User Manual
6
Rear View
Note: The CL1016 is pictured above. The CL1008 rear panel is the same as
that of the CL1016, except that it has 8 KVM ports instead of 16.
No. Component Description
1 daisy chain port When daisy chaining units, the cable plugs in here.
2 KVM port section The cables that link to the computers plug in here.
Note: The shape of these SPHD connectors has been
specifically modified so that only KVM cables designed to
work with this switch can plug in (see the Cables section on
page 3, for details). Do NOT attempt to use ordinary 1 pin
VGA connector cables to link these ports to the computers.
3 power socket This is a standard 3-prong AC power socket. The power cord
from an AC source plugs in here.
4 power switch This standard rocker switch powers the unit on and off.
1
2
34

7
Chapter
Hardware Setup
Before you Begin
Standard Rack Mounting
A standard rack mount kit is provided with your CL1008 / CL1016. The kit
enables the switch to be mounted in rack with a depth of 42.0–82.0 cm.
Note: It takes two people to mount the console.
The standard rack mount kit does not include screws or cage nuts.
If you need additional screws or cage nuts, contact your rack
dealer.
1. Important safety information regarding the placement of this
device is provided on page 49. Please review it before proceeding.
2. Make sure that power to all the devices you will be connecting up
have been turned off. You must unplug the power cords of any
computers that have the Keyboard Power On function.
left & right L-shaped brackets
side mount
brackets

CL1008 / CL1016 User Manual
8
To rack mount the switch, do the following:
1. Have one person position the unit in the rack and hold it steady. Have the
second person screw the front brackets to the rack.
2. While the first person still holds the unit in place, the second person slides
the left & right L-shaped brackets into the unit’s side mounting brackets
from the rear, installing four screws in the brackets to secure them in place.
3. After the L-shaped brackets are secured, tighten all the screws.
Allow at least 5.1 cm on each side for proper ventilation, and at least 12.7
cm at the back for the power cord and cable clearance.
