Ativa 272-210 User manual

version 0816

What's in the box / Qué contiene la caja :
2.
Quick start guide/
Guía de inicio rápida
3.
User manual/
Manual del usuario
1.
Shredder/
Trituradora de papel
Table of Contents / Tabla de contenidos
English
Warning ..................................................... .
Know your Ativa shredder ............................. .
Operation .................................................... ..
Maintenance ................................................ ..
Troubleshooting ............................................ ..
FAQ ............................................................
Limited Warranty ..........................................
Español
Advertencia .................................................
Conozca su trituradora Ativa .........................
Operación ...................................................
Mantenimiento .............................................
Solución De Problemas ................................
FAQ ............................................................
Garantía Limitada .........................................
4
5
6-7
8-9
10-12
12
13
14
15
16-17
18-19
20-22
22
23
Overheat:
Redlight – Shredder has shred
runningtime and overheating. If this
happens,switch the shredder off for
60minutes or longer before resuming
normaloperation.
PowerOn:
Greenlight – Power light will only
activatewhen paper/media is inserted
toshred.
What’s in the box!
4
QUICK START GUIDE
Plugin 120V power
outlet
Slideswitch to Auto to
powerON shredder
Readinstructions
Makesure you do not
exceedsheet count per
pass(8 sheets max).
Insertpaper as straight
aspossible into feed
slotand release.
Insertone credit card
ata time into the middle
ofthe feed slot.
Slideswitch to OFF to
powerOFF shredder
Shredding Operation
Control Switch
LED Status Indicators
071216
1
Shredder
2
Usermanual
Forproduct support please call:
1-866-397-9075
1 2 3
5 6
272-210 / 25433923
A08MC17
®
PowerOn:
Slidethis switch to
controlpower
ON/OFF.
Reverse:
Theshredder runs in
reversewhen the switch
isin this position.
PowerOff:
Theshredder will shut off
powerwhen the switch
isin this position.
ENGLISH
version0816
version0816
version 0816

4ENGLISH
WARNING :Read all instructions prior to operation.
MAGAZINE
M
Large paper clips,
binder clips & CDs
Continuous computer
paper
Window or insulated
envelopes
Cardboard
Checkbook or
notepad
Adhesive materials
Newspaper
Laminated document
and magazines
DO NOT SHRED:
Read instructions before use.
Avoid touching the document
feed opening with hands.
Product is not intended for use by
children (product is not a toy).
Shredder oil only.
Do not spray or keep any
aerosol products in or around
shredder.
Avoid loose clothing or jewelry
touching the document feed
opening.
Avoid getting hair near the
document feed opening.
tAlways turn the shredder off and unplug the power cord when: not in use, before
cleaning it, moving it, or emptying the waste basket.
tRISK OF FIRE. Never use any petroleum based or flammable oils or lubricants in or
around the machine and do notdispose of flammable chemicals or materials in the shredder basket.
tA socket-outlet should be near the equipment and be easily accessible.
tDo not place the shredder near water or any heat source. Do not use the shredder if the power cord
is damaged in any way.
tDo not attempt to service this product yourself as doing so may expose you to sharp cutting blades
and/or electricity and will void the manufacturer's warranty.
tNever try to clean or clear the shredder blade.

5ENGLISH
KNOW YOUR ATIVA SHREDDER
Shredder
head
Shredder
body
Product Specifications:
NOTE:
* ONE FOLDED SHEET OF PAPER EQUATES TO 2 SHEETS OF PAPER
Heavier paper (above 20 lb.), humidity may reduce shredding capacity below 8 sheets per pass.
** Voltage: Use in other country outside of the USA, is not recommended.
8
sheets
Credit Card
8.7”/220mm
Min
5
Sheet Capacity *
8 Sheets of 20 lb.
bond paper
Credit Card Capacity
1 at a time
Paper Shred Size
0.16 in. x 0.39 in. pieces
4 mm x 10 mm pieces
Security level: P-4
Duty Cycle
Shred time: 5 min.
Cool down time: 60 min.
Paper Entry Width
8.7 in / 220 mm
Voltage**
120V~60Hz / 3.2 A
LED Status Indicators
Control Switch
(Reverse/Off/Auto)
Paper Entry
Credit Card Entry
Window
Handle

6ENGLISH
OPERATION
nPlug into grounded standard US
household power outlet (120 Volt).
pMake sure you do not exceed
sheet count per pass (8 sheets
max). Insert paper as
straight as possible into
feed slot and release.
oSlide switch to AUTO to Power
ON shredder.
qInsert one credit card at a time
into the middle of the feed slot.
CONTINUED NEXT PAGE
Shredding operation:
Control Switch:
Power On:
Slide this switch to control
power ON/OFF.
Reverse:
The shredder runs in reverse when
the switch is in this position.
Power Off:
The shredder will shut off power
when the switch is in this position.
rSlide switch to OFF to
power OFF shredder

Overheat:
Red light – Shredder has reached maximum running time and is overheating.
If this happens, switch the shredder off for 60 minutes or longer before resuming
normal operation.
7ENGLISH
OPERATION
Power On:
Green light – Power light will activate when switched to Auto mode.
LED Status Indicators:

8ENGLISH
MAINTENANCE
!
Warning: Failure to properly maintain your shredder will void the warranty.
Keep your shredder running with ultimate reliability with the following Ativa shredder supplies: Oil
the shredder blades every month with Ativa brand lubricant sheets or Office Depot brand oil.
To maintain with shredder oil: Simply apply a bead of lubricant across a sheet of paper and
feed into the shredder, or apply lubricant directly into the paper feed entrance.
To maintain with a shredder sheet: Simply insert the shredder sheet into the feed slot the
same way you would a piece of paper.
Lubricant Procedure:
oApply shredder oil across paper entry. Or insert
a shredder sheet into the feed slot.
nTurn off shredder. pTurn shredder in reverse
mode for 3-5 seconds.
CONTINUED NEXT PAGE

9ENGLISH
MAINTENANCE
To dust/clean the shredder:
nAlways UNPLUG the
shredder first.
oTake a soft dry cloth and
wipe the shredder body.
pDo not clean the shredder with spray
or liquid cleaners or water. Do not im-
merse the shredder in water.
tDo not spray or keep any aerosol products
in or around shredder.
tDO NOT USE CANNED AIR ON SHREDDER.
Don't/Caution:
DO NOT USE
AEROSOL PRODUCTS!

10 ENGLISH
TROUBLESHOOTING
1)t4MJEFUIFQPXFSTXJUDIUPSFWFSTF
t1VMMUIFQBQFSBUBBOHMFUPSFNPWF
KBNNFEQBQFSBTNVDIBTQPTTJCMF
2)tTVSOPGGTISFEEFS
t"QQMZ shredder oilUPUIFGFFETMPU
t-FUPJMTPBLJOUPQBQFSBOENBDIJOFGPS
NJOVUFT
Note: Repeat 1 & 2 steps if needed
3)t4MJEFUIFQPXFSTXJUDIUP"VUP0O
t6TFUIJDLQBQFSTUPDLPSBHSFFUJOHDBSE
UPQVTIUIFKBNUISPVHI
4)t3FEVDFUIFOVNCFSPGTIFFUTCFJOHGFE
DPVOUQBHFTUPCFTVSFOPUUPFYDFFE
UIFNBYJNVNTIFFUDPVOU
t3FGFFEUIFQBQFS
Warning: DO NOT USE ANY SPRAY
CANS OR AEROSOLS.
!
WARNING: DO NOT ATTEMPT TO REPAIR BY OPENING THE SHREDDER HEAD. THIS
WILL VOID THE PRODUCT WARRANTY. *GZPVDPOUJOVFUPIBWFQSPCMFNT, QMFBTFDPOUBDU
DVTUPNFS TVQQPSUBUPVS 4FSWJDF CFOUFSBU1-866-397-9075.
Shredder is Jammed
No-power to the shredder
n3FWFSTFUP SFNPWF QBQFS
oTVSOPGGTISFEEFS
pTVSOPOTISFEEFS
q3FEVDFTIFFUTUP
SFTVNFTISFEEJOH
"QQMZTISFEEFSPJM
BOEXBJUGPSNJO
6TFUIJDLQBQFSUP
QVTIKBNUISPVHI
Min
30
1VMMVQ
1).BLFTVSFQPXFSDPSEJTQMVHHFEJOUPB
GVODUJPOJOH7TUBOEBSEIPVTFIPME
QPXFSPVUMFU
0SUSZVTJOHBEJGGFSFOUXPSLJOHPVUMFU
2)(SFFO1PXFS0OJDPOMJHIUXJMMBDUJWBUF
XIFOTXJUDIFEUP"VUPNPEF
n$IFDLQPXFSPVUMFU o$IFDL1PXFSMJHIU
CONTINUED NEXT PAGE
!
