Atlantic Technology Atlantic FS-4000 Operating manual

3 high-performance
speakers in one for today’s
fl at screen technologies
Home Theater could be the most enjoyable,
signifi cant development in at-home
entertainment to come along in a generation.
Being able to literally “go to the movies”
in one’s own living room has completely
transformed the experience of watching
television.
Great sound is an integral, essential
component to the theater experience at home.
The downside for most people comes from
having to mount and wire speakers all over
their room. It’s inconvenient, confusing, and
unsightly.
Enter Atlantic’s innovative FS-4000 Front
Stage Loudspeaker. This sleek, 40”-long unit
contains all three front speakers—left, center,
and right—in a single enclosure. It’s perfect for
the growing number of customers who just
want a simple, attractive, one-piece speaker
solution under their fl at-screen television, without all the visual clutter of separate left,
center, and right speakers surrounding their stylish, thin TV. The cabinet is internally
separated into three chambers, each with a 1” tweeter, a 4½” magnetically-shielded
woofer and a 4½” Bass Pressure Driver. Bass response extends down to 75Hz, for full-
bodied sound even without a subwoofer.
All three speakers in the FS-4000 have two rear-panel
controls—a 3-position HF Energy switch and a 2-position
Boundary Compensation switch—to optimize the speakers’
performance regardless of room acoustics or placement.
These controls allow the FS-4000 to always sound its best.
The FS-4000 uses the same drivers and crossover
technology as our highly-acclaimed 2200 and FS-3200
systems, so there is absolutely no compromise in
sound quality or tonal accuracy by having the three front channels in a
single enclosure. With the FS-4000, it’s now possible to enjoy the
legendary Atlantic sound from speakers that blend right into
the room.
The decorative side panels are fi nished in a
choice of automotive-grade Metallic Silver
or a rich-looking Gloss Black paint.
3
high-performance
speakers in one for today’s
fl at screen technologies
Home Theater could be the most enjoyable,
signifi cant development in at-home
entertainment to come along in a generation.
Being able to literally “go to the movies”
The FS-4000 uses the same drivers and crossover
technology as our highly-acclaimed 2200 and FS-3200
systems, so there is absolutely no compromise in
sound quality or tonal accuracy by having the three front channels in a
single enclosure. With the FS-4000, it’s now possible to enjoy the
legendary Atlantic sound from speakers that blend right into
the room.
Product Information Sheet
FS-4000 Flat Screen Speaker System

©2005 Atlantic Technology • 343 Vanderbilt Ave.
Norwood, MA 02062 • 781.762.6300
www.atlantictechnology.com 7.05
Atlantic Technology is a registered trademark of Atlantic Technology
International. Specifi cations subject to change without notice.
Mounting Options
Five mounting options, included with speakers:
Notice that the FS-4000’s tweeters
are offset above the centerline of the
woofers. This is a perfect example
of the way that Atlantic pays close
attention to acoustic details. By moving
the tweeters up, we signifi cantly
reduce the audibly-intrusive
interference patterns that result from
woofers and tweeters being mounted
side-by-side.
1. “Straight Ahead”
wall bracket holds
the speaker ½” off
the wall pointing
straight ahead.
Specifi cations
Type 2-way with Bass Pressure Drivers
Drivers Woofer (3) 4½” (115mm) GLH§
(3) 4½” (115mm) Bass Pressure Drivers
Tweeter (3) 1” (25mm) soft dome
Frequency Response 75Hz – 20kHz ±3dB
Nominal Impedance 8 Ohms
Crossover Frequency 3.75kHz, 3rd order
2. “Angled” wall bracket—
angles the speaker up
or down, depending on
whether it’s mounted
above or below the
video display.
3. Keyhole mount (on the rear
of the speaker), for simple
fl ush wall mounting.
5. Using Atlantic’s exclusive center channel rocker base, the FS-4000 can
be used as a freestanding speaker on a TV or on a shelf in addition to
wall mounting.
The decorative side panels are fi nished
in a choice of automotive-grade
metallic silver or a rich-looking Gloss
Black paint.
4. Atlantic’s stud bracket can be used to anchor the FS-4000 from the wall studs to
either the regular keyhole mount (as shown in option 3) or to the straight or angled
brackets (as shown in options 1 and 2).
Sensitivity 89dB
Recommended Power 10 – 125 Watts RMS per channel
Magnetic Shielding Yes
Dimensions w/grille 40 x 6.5 x 5”*
(W x H x D) 1021 x 165 x 127mm
Weight 27lbs; 12.3kg
§Graphite Loaded Homopolymer
*Height without base. Add 1” height for base.
Mounting Options
Five mounting options, included with speakers:
1. “Straight Ahead”
wall bracket holds
the speaker ½” off
the wall pointing
straight ahead.
2. “Angled” wall bracket—
angles the speaker up
or down, depending on
whether it’s mounted
above or below the
FS-4000 Flat Screen Speaker System
