Atlantic Technology FS-3200 User manual

A high-performance
speaker for today’s
fl at screen televisions
The FS-3200 LR and FS-3200 C speakers
form the heart of a home theater loudspeaker
system to compliment today’s latest Flat Screen
televisions. Their overall size, thin depth and
beautiful fi nish options assure that they will fi t
appropriately in virtually every installation.
However, these speakers have several
performance and mounting innovations that make
them far more capable than ordinary “on-wall”
speakers.
Unlike conventional fl at-panel speakers, the FS-
3200’s do not require a subwoofer to deliver
full-bodied, exciting musical performance. All by
themselves, these speakers add great sound to
installations where space or décor precludes
using a subwoofer. By utilizing two high-power
4½” drivers and two 4½” Pressure Drivers in a
tuned enclosure, the bass response extends to
within an octave of the very lowest musical notes
while maximizing power handling and minimizing
distortion.
The tweeter of the FS-3200 LR is oriented at
one end of the speaker, instead of in the middle. This clever design feature means the
LR speakers can be “fl ipped” upside down—tweeter up or down—for optimum acoustic
alignment with the FS-3200 C tweeter, resulting in the best sound. Therefore, whether
the center channel is mounted above or below the television, the 3200 LR and C will
always be in the correct acoustic alignment with each other.
The FS-3200 LR and C speakers have two rear-panel controls—a 3-position HF Energy
switch and a 2-position Boundary Compensation switch—to optimize the speakers’
performance regardless of their location or placement. These controls allow the FS-
3200 LR and C to always sound their best, regardless of room acoustics or
position.
With the FS-3200 series, Atlantic Technology has raised the
standards for fl at-screen speakers in terms of acoustic
performance, mounting fl exibility, listening room
sound adjustment, and intelligent,
consumer-friendly design.
The decorative side panels are fi nished in a
choice of automotive-grade Metallic Silver
or a rich-looking Satin Black paint.
A high-performance
speaker for today’s
fl at screen televisions
The FS-3200 LR and FS-3200 C speakers
form the heart of a home theater loudspeaker
system to compliment today’s latest Flat Screen
televisions. Their overall size, thin depth and
The FS-3200 LR and C speakers have two rear-panel controls—a 3-position HF Energy
switch and a 2-position Boundary Compensation switch—to optimize the speakers’
performance regardless of their location or placement. These controls allow the FS-
3200 LR and C to always sound their best, regardless of room acoustics or
position.
With the FS-3200 series, Atlantic Technology has raised the
standards for fl at-screen speakers in terms of acoustic
performance, mounting fl exibility, listening room
sound adjustment, and intelligent,
consumer-friendly design.
Product Information Sheet
FS-3200 Flat Screen Speaker System

©2005 Atlantic Technology • 343 Vanderbilt Ave.
Norwood, MA 02062 • 781.762.6300
www.atlantictechnology.com 1.05
Atlantic Technology is a registered trademark of Atlantic Technology
International. Specifi cations subject to change without notice.
Mounting Options
Four mounting options, included with speakers:
Wall mount option
1. “Straight Ahead” wall bracket holds the speaker
½” off the wall pointing straight ahead.
Specifi cations
FS-3200 LR FS-3200 C
Type 2-way M-T-M array 2-way M-T-M array
with Bass Pressure Drivers with Bass Pressure Drivers
Drivers Woofer (2) 4 ½” (115mm) GLH§ (2) 4 ½” (115mm) GLH§
Pressure Drivers (2) 4 ½” (115mm) GLH§ (2) 4 ½” (115mm) GLH§
Tweeter (1) 1" (25mm) soft dome (1) 1" (25mm) soft dome
Frequency Response 75Hz – 20kHz ±3dB 75Hz – 20kHz ±3dB
Nominal Impedance 8 Ohms 8 Ohms
Crossover Frequency 3.75kHz, 3rd order 3.5kHz, 3rd order
Sensitivity 89dB 89dB
Recommended Power 10 – 140 Watts RMS 10 – 140 Watts RMS
Magnetic Shielding Yes Yes
Dimensions w/ grilles 6.5 x 25 x 5" 25 x 6.5 x 5"*
(W x H x D) 165 x 635 x 127mm 635 x 165 x 127mm
Net Weight 16lbs; 7.3kg each 16.5lbs; 7.5kg w/base
§Graphite Loaded Homopolymer
*Height without base.
2. “Angled” wall bracket—toes the LR
speaker in towards the listening area OR
angles the Center speaker up or down,
depending on whether it’s mounted
above or below the video display.
4. Two-way keyhole mount
(on the rear of the
speaker), so the LR speaker
can be mounted “tweeter
up” or “tweeter down,”
to align with the Center’s
tweeter.
3. Atlantic’s exclusive center
channel rocker base, so FS-
3200C can also be used as
freestanding speaker on TV
or on a shelf in addition to
wall mounting.
Boundary Compensation and High
Frequency Energy switches
An optional sand-fi llable fl oorstand
transforms FS-3200 LR into sleek
freestanding column speaker,
perfectly complimenting table-
mounted video displays.
Mounting Options
Four mounting options, included with speakers:
1. “Straight Ahead” wall bracket holds the speaker
½” off the wall pointing straight ahead.
2. “Angled” wall bracket—toes the LR
speaker in towards the listening area OR
angles the Center speaker up or down,
FS-3200 Flat Screen Speaker System
