Atlantic Loria 6000 Series User manual

User manual
for professionals
and users
to be kept by the user
for future reference
Loria 6010
Loria 6004
Loria 6006
Loria 6008
FR NL DE EN PL
ES PT IT PT PT
Air/water heat pump
single service split system
Loria 6000
atlantic-comfort.com
Subject to modications without notice.
Document not binding.
Document No. 1634-4 ~ 26/04/2016

- 2 -
Contents
Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Overall view of the installation . . . . . . . . . . . . . . . . . . . . . . . . .4
Precautions and warnings regarding your installation. 4
The outdoor unit . . . . . . . . . . . . . . . .4
The hydraulic unit. . . . . . . . . . . . . . . . 4
The controller . . . . . . . . . . . . . . . . . . 4
The radiators . . . . . . . . . . . . . . . . . . 4
User interface and description of the display . . . . .6
Commissioning the appliance . . . . . . . . . . . . . 8
Commissioning . . . . . . . . . . . . . . . . . . . .
WITHOUT room thermostat . . . . . . . . . . . . . . 8
Basic display . . . . . . . . . . . . . . . . . . 8
Time setting. . . . . . . . . . . . . . . . . . . 9
Floor heating systems . . . . . . . . . . . . .4
Fan-coil heaters with integrated control system 4
Domestic hot water (DHW) . . . . . . . . . . . 4
End of life of the device . . . . . . . . . . . . . . . . 5
Overall view of the installation. . . . . . . . . . . . . 5
Operation of the installation. . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Selecting the MODE and setting the TIME
PROGRAMME depending on the USE . . . . 10
Setting the temperature setpoints . . . . . . 12
Selecting the DHW* MODE and setting the DHW TIME
PROGRAMME . . . . . . . . . . . . . . . . . . . 14
Regulation parameters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Overview. . . . . . . . . . . . . . . . . . . . . . . 16
Setting parameters on the user interface . . . . . . 16
List of "End User" parameters . . . . . . . . . . . . 16
Information and troubleshooting . . . . . . . . . . . . . . . . . . . . . . . 18
Displaying information . . . . . . . . . . . . . . . . 18
Hydraulic unit errors . . . . . . . . . . . . . . . . . 18
Outdoor unit errors . . . . . . . . . . . . . . . . . 20
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Regular checks . . . . . . . . . . . . . . . . . . . 20
Outdoor unit check . . . . . . . . . . . . . . . . . 20
Holiday mode . . . . . . . . . . . . . . . . . 25
Standby mode . . . . . . . . . . . . . . . . 26
Exemption function – "Boost" button . . . . . 26
Information screen – Knob button . . . . . . 26
Stopping heating . . . . . . . . . . . . . . . 26
Stopping the DHW* . . . . . . . . . . . . . . 27
* Optional
Room thermostat UA55 (optional) . . . . . . . . . . . . . . . . . . . . . . 21
Room thermostat* and description of the display . . 22
Commissioning WITH room thermostat . . . . . . . 22
Setting the time and day . . . . . . . . . . . 23
Mode selection . . . . . . . . . . . . . . . . 23
Automatic mode: setting the TIME PROGRAMME
and the temperature setpoint . . . . . . . . . 24
Constant mode: setting the temperature setpoint 25
ERP performance values . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
ERP denition . . . . . . . . . . . . . . . . . . . . 28
ERP Specications . . . . . . . . . . . . . . . . . 28
Package sheet. . . . . . . . . . . . . . . . . . . . 30
User manual 1634 - EN
Loria 6000 heat pump

- 3 -
1 Safety instructions
"Please comply with the following instructions in order to avoid any risk of injury or inappropriate
use of the appliance.
• Commissioning
"Do not switch the appliance on until all lling operations are complete.
"Do not try to install this appliance yourself. This heat pump must be installed by qualied personnel
with a certicate of capacity.
"The installation must always be connected to the Earth and tted with a protective circuit breaker.
"Do not modify the electricity supply.
"The appliances are not reproof and should therefore not be installed in a potentially explosive
atmosphere.
• Use
"This appliance may be used by children aged 8 years or more and by people with physical, sensual
or metal decits and lacking experience or knowledge of the device provided that they are correctly
supervised or have been provided with instructions regarding the safe use of the appliance and
provided that the risks present have been fully understood. Children are not permitted to play with
the appliance. This appliance must not be cleaned or maintained by children without supervision.
"Do not let children insert foreign bodies into the fan protection grill or climb on top of the outdoor
unit. The blades in the air exchanger are extremely thin and may cause cutting injuries.
"Nothing should obstruct the air from circulating through the evaporator and out of the fan.
"The outdoor unit must only be installed outdoors. If a shelter is required, it must have broad
openings on all 4 walls and comply with the installation clearances (check with your installer).
"Do not climb on the top of the outdoor unit.
"The room in which the appliance is operating must be correctly ventilated in order to prevent any
loss of oxygen in the event of a refrigerant gas leak.
"For safety reasons, consult your installer before making any changes or modications to the
premises where the appliance is installed.
"Do not place a heat source under the room thermostat.
• Maintenance
"Do not try to repair this appliance yourself.
"This appliance does not contain any components capable of being repaired by the user. Removing
either of the covers can expose you to dangerous electrical voltages.
"In any case, switching off the current is not sufcient to protect you from any external electrical
shocks (capacitors)
"Do not open the heat pump while it is in operation.
"Switch off the power supply if there are any abnormal noises, smells or smoke coming from the
appliance and contact your installer.
"Switch off the power to the appliance before cleaning.
"Do not use aggressive cleaning liquids or solvents to clean the body work.
"Do not use a pressure washer to clean the heat pump. This may damage the air exchanger and
cause water to penetrate the electrical circuits.
User manual "1634 - EN"
Loria 6000 heat pump

- 4 -
2.1.5 Floor heating systems
New oor heating systems must be initially heated
slowly to avoid cracking. Check with your installer that
this initial heating procedure has been performed before
using your heating system as you see t.
The high inertia of oor heating systems prevent
sudden differences in room temperature. However, this
stability involves a reaction time of about several hours,
(approximately 6 hours).
Any changes to the settings must be made slowly,
allowing the installation time to react. Adjusting the
system to exaggerated settings or in an untimely manner
always results in signicant temperature uctuations
during the course of the day.
Similarly if your residence has a oor heating system,
do not reduce the heating or switch it off if you will be
absent for a short period. The reheating period is always
quite long (approx 6 hours).
2.1.6 Fan-coil heaters with integrated control sys-
tem
Do not use a room thermostat in the zone concerned.
2.1.7 Domestic hot water (DHW)
This function is designed as an optional extra with the
use of a DHW tank (with an electrical back-up heater).
When DHW is in demand, the heat pump prioritises this
demand.
No space heating takes place while domestic hot water
is being produced.
Domestic hot water (DHW) is produced by the heat
pump and then topped up, if necessary, by the electrical
back-up system.
In the event of extreme outdoor temperatures, the
electrical back-up system of the DHW tank must be left
in operation to guarantee a DHW setpoint greater than
45°C.
The electrical back-up heating enables Legionella
cycles to be conducted efciently.
2.1 Precautions and warnings
regarding your installation
2.1.1 The outdoor unit
The outdoor unit contains the equipment for capturing
energy from the ambient air.
Your installer has placed this unit in a location that
enables it to operate in an optimum manner.
Nothing should obstruct the air from circulating through
the evaporator and out of the fan.
The water contained in the ambient air may condense
and drain from the outdoor unit.
In cold periods, this water freezes in contact with the
exchanger and must be removed by regular defrosting
cycles. The control system automatically controls
the defrosting cycle, whose operation can lead to the
emission of steam, which is perfectly normal.
2.1.2 The hydraulic unit
The hydraulic unit contains the entire heat pump control
system, in charge of controlling the heating comfort
level and the production of domestic hot water (if the
installation is equipped with a DHW tank and electrical
back-up).
The hydraulic unit is equipped with an electrical back-
up system, which is designed to provide additional heat
during the coldest periods.
2.1.3 The controller
Your installer has carefully adjusted your installation. Do
not modify setting parameters without their agreement.
If in doubt, do not hesitate to contact them.
Your heating system is controlled according to the
outdoor temperature (weather-dependent system).
A room thermostat (optional) can be installed for
improved control (the inuence of the room temperature
is taken into account).
2.1.4 The radiators
To guarantee control, the room in which the room
thermostat is installed must not have a thermostatic
valve. If this is the case, the valves must be open fully.
2 Overall view of the installation
User manual 1634 - EN
Loria 6000 heat pump

- 5 -
2.3 Overall view of the installation
Your heat pump has been congured by your installer. It
is composed of the following main elements:
- The outdoor unit is positioned, as its name indicates,
outside of your residence and extracts energy from the
outdoor air.
- The hydraulic unit positioned in your boiler room,
cellar, garage or even in your kitchen, transfers the
energy to the heating circuit.
- The outdoor sensor detects the outdoor temperature.
- The room thermostat(s).
The heat pumps are systems that can be connected
to any form of low-temperature distribution: the heat
captured by the heat pump can therefore be used in
different ways:
- Radiators.
- Heating (or cooling) oor systems.
- Dynamic radiators or fan-coil heaters.
- Domestic hot water (DHW).
gure 1 - Overall view of the conguration of a complete installation
2.2 End of life of the device
The apparatus must be dismantled and recycled by a
specialised service provider.
The apparatus must never be disposed of with
household waste, large objects or in a landll.
When the apparatus reaches its end of life, please
contact you installer or the local representative in order
to proceed with the dismantling and recycling of this
apparatus.
User manual "1634 - EN"
Loria 6000 heat pump
+
-
°C
mode auto
reset prog man
or
Options depending
on the hydraulic
system congurations
The room
thermostat(s)
The outdoor
sensor
Optional controller
The cooling kit
The DHW kit
The 2-area kit
The outdoor unit The hydraulic unit
The domestic hot water
tank with electrical back-up
The heating circuit:
oor heating
(cooling) system
Dynamic radiators or
fan-coil heaters
Radiators

- 6 -
3.1 User interface and description of the display
OK
gure 2 - User interface
3
4
6
1
5
7
2
Ref. Functions - Denition of the functions
1 • SELECT - Browse and select the available uses.
2 • MODE - Browse and select the mode for the pre-selected use.
3 • Settings
• Scrolling
- Congure the setpoints of the selected function using the and keys.
- Scroll through the information and parameter lines.
- Congure the modiable values (after pressing OK to conrm).
4 • Information
• "ESC" output
- Access the "information" menu (the icon appears).
-Exit the menu currently displayed
-Cancel a modication being made
5 • Conguration - Access the user level (press and release: the icon appears).
List of parameters : see 4.3, page 16.
- Access the installer level (press and hold (for more than 5s): the icon appears).
6 • OK - Conrm (Conguration, Setpoint for the pre-selected mode)
7 • Digital display - Display: see table
- View the settings.
3 Operation of the installation
User manual 1634 - EN
Loria 6000 heat pump

- 7 -
• Description of the display (user interface).
Icons Denitions
Access the User settings
Use for heating
(reference to the circuit concerned Z1 or Z2)
Use for DHW
Use for cooling
(reference to the circuit concerned Z1 or Z2)
Stand-by (1)
Compressor operation
Electrical back-up operation
(heating or DHW)
PROG mode:
Controlled operation (2) according to the:
- programme set in the User interface
or
- programme set on the room thermostat
Constant mode
(with reduced temperature setpoint)
or
Constant mode
for heating or cooling
(with comfort temperature setpoint)
Holiday mode (heating only)
The use concerned is in Off mode
(area 1 / 2 - DHW)
Read information
Access the Installer settings
(1) Frost protection provided that the electric power supply to the HP
is not switched off.
(2) If the installation is equipped with a room thermostat, the
programme is exclusively managed on the room thermostat.
User manual "1634 - EN"
Loria 6000 heat pump

- 8 -
3.2 Commissioning the appliance
• The installation and rst commissioning of the heat
pump must be performed by a qualied installer. This
person will also instruct you on how to start and run
the heat pump.
• Ensure that the installation is correctly lled with water
and properly drained and that the pressure measured
by the pressure gauge is sufcient (1 to 1.5 bar).
• Close the installation's main circuit breakers.
In winter, or after long shutdown periods, close the
installation's main circuit breakers (power supply
to the outdoor unit) a few hours before activating
the heating demand to allow the compressor to
pre-heat.
3.3 Commissioning
WITHOUT room thermostat
Once your installer has commissioned your installation:
• Set the current date and time (see § 3.3.2).
• Select the programming mode for heating (and for
cooling if your installation is equipped with the cooling
kit) (see § 3.3.3, page 10).
• Set the temperature setpoints where necessary (see §
3.3.4, page 12).
• Select the DHW programming mode (if the installation
is equipped with a domestic hot water tank and
electrical back-up) (see § 3.4, page 14).
3.3.1 Basic display
The basic display on the user interface informs the user
of the main activity of the HP in progress.
gure 3 - Loria 6000
1. User interface (Operator section)
2. Pressure gauge (installation hydraulic pressure)
2
1
OK
gure 4 - User interface (example of basic display)
MODE programming
activated
Compressor on
Temperature setpoint for
comfort phase
Comfort phase of PROG
mode
View information for the
icon displayed (heating
Area 1)
User manual 1634 - EN
Loria 6000 heat pump

- 9 -
OK
OK
OK
OK
OK
Basic display.
1- Press
- The "key" icon appears,
- Alternation between the "time settings" parameter
(line No. 1) and the time (e.g. 18:30)
(No. 1 / 18:30):
2- Press
OK
to change the time.
- The hour display ashes.
3- Press the or button to set the hour.
4- Press
OK
to conrm.
The minutes display ashes.
5- Press the or button to set the minutes.
6- Press
OK
to conrm.
- The settings are saved.
7- Press the or button to change other
settings.
or the
8- Press to return to the basic display.
3
5
7
8
1
2
4
6
3.3.2 Time setting
User manual "1634 - EN"
Loria 6000 heat pump

- 10 -
3.3.3 Selecting the MODE and setting the TIME PROGRAMME depending on the USE
• Selecting the USE
To select the use: press the SELECT button several times.
OK
Select the use to be congured. The icon ashes.
Example:
Heating of area 1.
Description of the other uses*:
Heating of area 2.
Cooling of area 1.
Cooling of area 2.
DHW heating (see page 14).
• Selecting the MODE
To select the mode: press the MODE button several times.
OK
Selecting the desired mode (for the use displayed)
"PROG" mode: Automatic switching
comfort <-> reduced heating depending on the time
programme.
Description of the other modes*:
or constant comfort mode (heating or cooling*).
Constant reduced mode.
Holiday mode.
Off mode (for the use concerned).
OK
Conrming the adjustment
Press
OK
Note: When browsing, the temperature setpoints can be modied at any time using the or buttons. Press
OK
to conrm. Before exiting, check that you have conrmed the desired mode.
* Optional
User manual 1634 - EN
Loria 6000 heat pump

- 11 -
* Optional
• Changing the heating (or cooling*) TIME PROGRAMME
The default heating time programme is set for the whole week:
from 6 a.m. to 10 p.m. in comfort mode (from 10 p.m. to 6 a.m. in reduced mode).
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24
Reduced T°
start of comfort heating Reduced
T°
Comfort T°
1st phase end of comfort heating
For your comfort you can set up to 3 heating phases and apply these over different time periods (week, day etc.).
- Example: Monday to Friday [set parameter 11 to 8] (see table)
   3 phases [6 a.m.-8 a.m. / 11:30 a.m.-1:30 p.m. and 5 p.m.-10:30 p.m.] (set parameters 12 to
17, see table),
Saturday [set parameter 11 to 6] (see table)
 2 phases [6 a.m.-8 a.m. / 11:30 a.m.-10:30 p.m.] (set parameters 12 to 15),
Sunday
 1 phase identical to the default setting [6 a.m.-10 p.m.] (no modications required).
- On the user interface:
Press the button to enter the "user" level: the icon is displayed.
Selecting the parameter Settings
No.
11 OK
Select the day(s):
1: Monday, 2: Tuesday, 3: Wednesday, 4: Thursday, 5: Friday, 6: Saturday, 7: Sunday
10: Mon-Sun, 8: Mon-Fri, 9: Sat-Sun,
E.g.: 8 (Monday to Friday)
OK
No.
12
OK
start of comfort heating:
Start-up time for the 1st heating phase.
E.g.: 06:00
OK
No.
13
OK
end of comfort heating:
Shutdown time for the 1st heating phase.
E.g.: 08:00
OK
No.
14
OK
start of comfort heating:
Start-up time for the 2nd heating phase.
E.g.: 11:30
OK
No.
15
OK
end of comfort heating:
Shutdown time for the 2nd heating phase.
E.g.: 13:30
OK
No.
16
OK
start of comfort heating:
Start-up time for the 3rd heating phase.
E.g.: 17:00
OK
No.
17
OK
end of comfort heating:
Shutdown time for the 3rd heating phase.
E.g.: 22:30
OK
- Continue programming for another day (No. 11)...
or
- Press to return to the basic display.
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24
start
Reduced T° Reduced T° Reduced T° Reduced
T°
Comfort T° Comfort T° Comfort T°
1st phase 2nd phase 3rd phase
end end endstart start
• Use the same procedure to programme the time:
- for area 2* (Circuit 2 time programme) No. 18 to 24,
- for domestic hot water* (DHW time programme) No. 25 to 29 see page 14),
User manual "1634 - EN"
Loria 6000 heat pump

- 12 -
3.3.4 Setting the temperature setpoints
- A- Change the mode setpoint.
OK
Example: changing the ECO setpoint.
Current use (heating of area 1).
Current mode (PROG / comfort phase).
OK
If necessary, press the SELECT button
to display the use to be changed.
* * * *
[E.g.: Change the setpoint for the area 2 heating use]
OK
Press the MODE button to display the setpoint to be changed.
*
[E.g.: The ECO setpoint is set to 18 °C]
OK
Set the temperature setpoint using the following buttons:
to increase the setpoint.
to decrease the setpoint.
[E.g.: 17 °C]
Press
OK
to conrm.
Press to return to the basic display.
- B - Specic case: direct access to the current mode and use setpoints.
OK
E.g.:
Current use (heating of area 1).
Current mode (PROG / comfort phase).
[The current setpoint (comfort) is 20 °C]
OK
Set the temperature setpoint using the following buttons:
to increase the setpoint.
to decrease the setpoint.
[E.g.: 21 °C]
Press
OK
to conrm.
* Optional
User manual 1634 - EN
Loria 6000 heat pump

- 13 -

User manual "1634 - EN"
Loria 6000 heat pump

- 14 -
3.4 Selecting the DHW* MODE and setting the DHW TIME PROGRAMME
• Selecting DHW USE
To select the use: press the SELECT button several times.
OK
The icon ashes.
• Selecting the MODE
To select the mode: press the MODE button several times.
OK
The icon ashes.
"PROG" mode: Automatic switching
comfort <-> reduced heating depending on the time
programme.
Description of the other modes:
Constant comfort mode.
Constant reduced mode.
Off mode (for DHW).
OK
Conrming the adjustment
Press
OK
Notes:
- When browsing, the temperature setpoints can be modied at any time using the or buttons.Press
OK
to
conrm. Before exiting, check that you have conrmed the desired mode.
- In the event of extreme outdoor temperatures, the electrical back-up system of the DHW tank must be left in
operation to guarantee a DHW setpoint greater than 45°C.
* Optional
User manual 1634 - EN
Loria 6000 heat pump

- 15 -
• Changing the DHW timer programme
The default DHW timer programme is set for the whole week (Monday to Sunday: 10):
from 12 a.m. to 5 a.m. (1st DHW heating phase) and from 2:30 p.m. to 5 p.m. (2nd DHW heating phase).
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24
start of
comfort heating Comfort T° Comfort T°Reduced T° Reduced T°
1st phase 2nd phase
end of comfort
heating endstart
For your comfort you can set up to 2 DHW heating phases and apply these over different time periods (week, day
etc.).
- Example : Monday to Sunday [parameter 25 set to 10] (see table)
 2 phases [12 a.m.-7 a.m. / 1:30 p.m.-5 p.m. and 5 p.m.-10:30 p.m.] (set parameters 26 to 29,
see table),
Press the button to enter the "user" menu: the icon is displayed.
Selecting the line No. Settings
No. 25 OK
Select the day(s):
10: Mon-Sun, 8: Mon-Fri, 9: Sat-Sun,
1: Monday, 2: Tuesday, 3: Wednesday, 4: Thursday, 5: Friday, 6: Saturday, 7: Sunday
E.g.: 10 (Monday to Sunday)
OK
No. 26
OK
start of comfort heating:
Start-up time for the 1st heating phase.
E.g.: 00:00
OK
No. 27 OK
end of comfort heating:
Shutdown time for the 1st heating phase.
E.g.: 07:00
OK
No. 28 OK
start of comfort heating:
Start-up time for the 2nd heating phase.
E.g.: 13:30
OK
No. 29 OK
end of comfort heating:
Shutdown time for the 2nd heating phase.
E.g.: 17:00
OK
- Continue programming for another day (line 25).
or
- Press to return to the basic display.
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24
start Comfort T° Reduced T° Reduced T°Comfort T°
1st phase 2nd phase
end endstart
• DHW boost (without room thermostat).
A DHW boost function is available (on the user interface:
, parameter 55 - see page 16). This DHW
boost enables the DHW to be heated to the comfort
temperature at any time during the day. The boost
function is cancelled automatically when the demand
for hot water has been met.
• DHW boost (with room thermostat).
see § 7.2.7, page 26.
User manual "1634 - EN"
Loria 6000 heat pump

- 16 -
from these professional specialists.
4.2 Setting parameters on the user interface
Display user level Select parameter Conrm Select value Conrm
Back to
basic
display
Basic
display Press
OK
OK
If no setting is made for 15 minutes,
the screen automatically returns to the basic display.
4.3 List of "End User" parameters
No. Function Conguration
or display range
Basic
setting
Time / Date setting
1Hours / minutes 00:00... 23:59 01:00
2Day of Week 1... 7 (1 = Monday; 2 = Tuesday…; ... 7 = Sun-
day) -
Heating time programme (2), circuit 1
11 Pre-selection (day / week) 1 ... 10 -
1= Monday; 2= Tuesday… 7= Sunday; 8= Monday to Friday; 9= Saturday and Sunday
10 = Monday to Sunday (modications are applied to the whole week)
12 1st phase of the selected day (start of comfort) 00:00... 23:45 06:00
13 1st phase of the selected day (end of comfort) 00:15... 24:00 22:00
14 2nd phase of the selected day (start of comfort) 00:00... 23:45 - -:- -
15 2nd phase of the selected day (end of comfort) 00:15... 24:00 - -:- -
16 3rd phase of the selected day (start of comfort) 00:00... 23:45 - -:- -
17 3rd phase of the selected day (end of comfort) 00:15... 24:00 - -:- -
(1) These parameters (or menus) may not appear. They depend on the appliance's conguration (on the options selected).
(2) With a room thermostat, these menus are not shown on the user interface. The time programme is only managed using the room thermostat in the
area considered.
4.1 Overview
• Only the parameters accessible to the following level:
- User.
are described in this document.
• The parameters accessible to the following level:
- Installer.
… are described in the document reserved for
these professional specialists. Do not make any
modications to these parameters without advice
4 Regulation parameters
User manual 1634 - EN
Loria 6000 heat pump

- 17 -
No. Function Conguration
or display range
Basic
setting
Heating time programme (1) (2), circuit 2
18 Pre-selection (day / week) 1 ... 10 -
1= Monday; 2= Tuesday… 7= Sunday; 8= Monday to Friday; 9= Saturday and Sunday
10 = Monday to Sunday (modications are applied to the whole week)
19 1st phase of the selected day (start of comfort) 00:00... 23:45 06:00
20 1st phase of the selected day (end of comfort) 00:15... 24:00 22:00
21 2nd phase of the selected day (start of comfort) 00:00... 23:45 - -:- -
22 2nd phase of the selected day (end of comfort) 00:15... 24:00 - -:- -
23 3rd phase of the selected day (start of comfort) 00:00... 23:45 - -:- -
24 3rd phase of the selected day (end of comfort) 00:15... 24:00 - -:- -
DHW timer programme (1)
25 Pre-selection (day / week) 1 ... 10 -
1= Monday; 2= Tuesday… 7= Sunday; 8= Monday to Friday; 9= Saturday and Sunday
10 = Monday to Sunday (modications are applied to the whole week)
26 1st phase of the selected day (start of comfort) 00:00... 23:45 00:00
27 1st phase of the selected day (end of comfort) 00:15... 24:00 05:00
28 2nd phase of the selected day (start of comfort) 00:00... 23:45 14:30
29 2nd phase of the selected day (end of comfort) 00:15... 24:00 17:00
Heat pump
45 Switch from summer/winter (according to the
outdoor temperature) 15... 30 °C 18 °C
When the average of the outdoor temperatures reaches 18°C, the regulator switches off the heating (as an economy
measure).
46 Legionella function (1) 0 (off)... 1 (on) 0
47 Correction of outdoor temperature sensor - 5... 5 °C -
49 Assist mode 0 (Assist mode off)...
1 (Assist mode on) 0
55 DHW boost (1) 0 (off)... 1 (on) 0
(1) These parameters (or menus) may not appear. They depend on the appliance's conguration (on the options selected).
(2) With a room thermostat, these menus are not shown on the user interface. The time programme is only managed using the room thermostat in the
area considered.
User manual "1634 - EN"
Loria 6000 heat pump

- 18 -
5.1 Displaying information
The button calls up various information.
Depending on the appliance type, the conguration and
the state of operation, certain information lines may not
be available.
The information number is displayed and alternates
with its value.
No... Name Value...
1 Time. hh:mm
2 Outdoor temperature. ... °C
3 Circuit 1: Initial temperature. ... °C
4 Circuit 1: Initial setpoint. ... °C
5 Return temperature. ... °C
6 Flow measurement. ... l/min
7Compressor modulation level
(%). ... %
8 Heating back-up status. 0 = off
1 = on
9 Circuit 2: Initial temperature. ... °C
10 Circuit 2: Initial setpoint. ... °C
11 DHW temperature. ... °C
12 DHW setpoint. ... °C
13 HP status.
see details
§ "Status
list"
14 Heating circuit 1 status.
15 Heating circuit 2 status.
16 DHW circuit status.
17 DHW back-up status. 0 = off
1 = on
18 Outdoor unit error code
(see details in table page 20).
"Status list
The parameter number is displayed and alternates with
its value (example No. 13 / 1 = HP heating status).
No. Value... HP status
13
0 Pending.
1 Heating.
2 Cooling.
3 Error.
4 Assist mode.
5 Locked.
6 Defrost activated.
7Test mode.
No. Value... Heating circuit 1 and 2 status
14
&
15
0 Pending.
1 Comfort heating mode.
2 Reduced heating mode.
3 Comfort cooling mode.
4 Reduced cooling mode.
5 Holiday mode.
6 Controlled by the room thermostat.
7 Frost protection activated.
8 Floor drying mode.
9 Rate input activated.
No. Value... DHW status
16
0 Pending.
1 Comfort mode, charge activated.
2 Reduced mode, charge activated
3 Legionella charge.
4 Frost protection activated.
5 Forced operation.
5.2 Hydraulic unit errors
The faults or breakdowns of the hydraulic unit are reported on the display unit of the user interface. The display
shows the "Erxxx" error code. A minor error does not result in switching the appliance to safety mode (if in doubt on
the reasons for the malfunction or if the problem persists, contact your installer). A major error results in switching
the appliance to safety mode. Note the code and contact your installer.
Error codes
Description Switched to safety mode Probable causes
Minor
error
Major
error
3 -
Hydraulic ow rate too low.
-Circulation pump speed settings too
low.
Clogged ltering component.
- 131
(Appliance shutdown if the
error 3occurs 3 times in 1
hour)
5 - Initial temperature (T5) or return
temperature (T6) < 2 °C -Frost protection function defective. Back-up disconnected.
6 -
Communication error between
the interface board and the HP
regulator board.
- Check the wiring.
19 - Test mode activated. - -
"Always check that the electric power supply is switched off before maintaining the boiler.
5 Information and troubleshooting
User manual 1634 - EN
Loria 6000 heat pump

- 19 -
Error codes
Description Switched to safety mode Probable causes
Minor
error
Major
error
35 - HP outgoing ow sensor error
(T5). -
Short circuit, sensor disconnected
or cut off. Defective sensor. Other
error.
36 HP return ow sensor error (T6). -
Short circuit, sensor disconnected
or cut off. Defective sensor. Other
error.
- 132 Initial temperature > 70 °C (T5) -
46 - Circuit 2 sensor error (T12) -
Short circuit, sensor disconnected
or cut off. Defective sensor. Other
error.
48 - Outdoor temperature sensor error
(T7) -
Short circuit, sensor disconnected
or cut off. Defective sensor. Other
error.
47 - DHW tank sensor error (T8) -
Short circuit, sensor disconnected
or cut off. Defective sensor. Other
error.
- 148 Legionella cycle error This error appears if 3
consecutive tests fail. DHW back-up disconnected.
52 - Frost detected on the return
circuit when defrosting the
outdoor unit (temperature < 2 °C).
-
Circulating water volume too low
(contact installer).
- 180 Appliance shutdown if the error
52 occurs 3 times in 1 hour.
53 - Frost detected on the outgoing
circuit when defrosting the
outdoor unit (temperature < 3 °C).
-
- 181 Appliance shutdown if the error
53 occurs 3 times in 1 hour.
55 - Frost protection of the HP circuit
activated (with electrical back-up) - -
56 - Frost protection of the DHW tank
activated (with electrical back-up) - -
62 - Load shedding - peak shaving or
rate input activated - -
66 - Outdoor unit error (external
cause) -See § "5.3 Outdoor unit errors", page 20.
67 -
DHW cycle too long (> 6 hours).
-Too much draw-off during the same
cycle.
DHW back-up disconnected.
- 195
Appliance shutdown if
the error 67 occurs 3
consecutive times.
68 -
Room temperature in area 1
missing when the "room T°
inuence" function (No. 33) is
activated.
-
Parameter 33 used without room
unit.
Room unit disconnected or absent.
69 -
Room temperature in area 2
missing when the "room T°
inuence" function (No. 41) is
activated.
-
Parameter 41 used without room
unit.
Room unit disconnected or absent.
70 - Assist mode activated. - -
71 - Circuit temperature 2 > 55 °C - Defective mixing valve.
73 -External error linked to input EX3.
Parameter 56
set to ...
1 -> HP locked
Outdoor component error.2 -> Area 1 shut down
3 -> Area 2 shut down
76 -Low hydraulic ow rate. -Circulation pump speed settings too low.
Clogged ltering component.
User manual "1634 - EN"
Loria 6000 heat pump

- 20 -
6 Maintenance
To ensure that your device works properly for many years, the following maintenance operations should be performed
at the start of each heating season. Generally, these are performed as part of a service contract.
5.3 Outdoor unit errors
In the event of an outdoor unit error:
- The user interface displays the error code "Er 66".
- View the information menu ,
- Information " No. 18" species the error code for the outdoor unit " xx" (list provided below).
Outdoor
unit error
code
Interface board Outdoor unit
board Error contents
LED 2
(green) LED 1 (red) LED
0
1 Flash 1 Flash
Off Communication error between the interface board and the
outdoor unit: transfer error (Serial reverse).
1 1 Flash Communication error between the interface board and the
outdoor unit: transfer error (Serial forward).
2 4 Flashes 2 Flashes 22 Flashes Hydraulic unit exchanger temperature sensor error.
3 6 Flashes 3 Flashes 18 Flashes Inverter error.
4 6 Flashes 4 Flashes 19 Flashes Active lter error / PFC error
5 7 Flashes 1 Flash 2 Flashes Discharge temperature sensor error.
6 7 Flashes 2 Flashes 8 Flashes Compressor temperature sensor error.
77 Flashes 3 Flashes 5 Flashes Exchanger temperature sensor (centre) error.
8 4 Flashes Exchanger temperature sensor (output) error.
9 7 Flashes 4 Flashes 7 Flashes Outdoor temperature sensor error.
10 7 Flashes 7 Flashes 9 Flashes Radiator temperature sensor (inverter) error.
11 10 Flashes Radiator temperature sensor (P.F.C.) error.
12 7 Flashes 8 Flashes 6 Flashes Pressure regulator temperature sensor error.
13 8 Flashes 4 Flashes - Current current error.
14 8 Flashes 6 Flashes 3 Flashes Pressure sensor error / pressure switch error.
15 9 Flashes 4 Flashes 13 Flashes Current sensor error (permanent shutdown).
16 9 Flashes 5 Flashes 14 Flashes Detection error for the position of the compressor rotor
(permanent shutdown).
15 Flashes Compressor start-up error (permanent shutdown).
17 9 Flashes 7 Flashes 16 Flashes Outdoor unit fan motor 1 error.
17 Flashes Outdoor unit fan motor 2 error.
18 10 Flashes 1 Flash 11 Flashes Discharge temperature protection (permanent shutdown).
19 10 Flashes 3 Flashes 12 Flashes Compressor temperature protection (permanent shutdown).
20 10 Flashes 5 Flashes 20 Flashes Abnormal low pressure.
21 Depending on the outdoor unit error Error originating from the outdoor unit.
22 3 Flashes 2 Flashes - Communication error between the interface board and the HP
regulator board.
6.1 Regular checks
- Periodically check the water pressure in the heating
circuit (refer to the pressure level recommended by the
installer - between 1 and 2 bar).
- If you need to ll up and reset the pressure, check the
type of uid originally used (if in doubt, contact your
installer).
"If frequent rells are required it is essential that
you look for any leaks.
"The frequent supply of water risks causing
scale to build up within the heat exchanger and
degrade its performance and life.
- If error Er 76 is displayed: Call your installer.
6.2 Outdoor unit check
Remove any dust from the exchanger making sure you
do not damage the blades.
Check that there is nothing hindering the air ow.
"Always check that the electric power supply is switched off before maintaining the boiler.
User manual 1634 - EN
Loria 6000 heat pump
