L3 Fast Ethernet Switch
• L2, L3 and L4 functions
• SNMP, RMON and Web management
• IGMP Snooping
The Edge-Core A07-ES3628C is a L3 xedport desktop Ethernet standalone
switch that delivers not only thecomprehensive Layer-2 functions, but also the
most advanceLayer-3 and Layer-4 features. This advance switch bringsyou the
enhanced network performance, simplicity, andexibility required by today’s band-
width-sensitive application.Apart from the standard features like SNMP, RMON and
Webmanagement provided, the more completed networkmanagement functions
are provided such as Spanning TreeProtocol for standard bridging, GVRP for VLAN
management,and IGMP snooping for the multicast switching. Withthis Edge-Core
Switch, you can use VLAN groups to enhancenetwork performance, strengthen
security and simplifynetwork management.
A07-ES3628C

PRODUCT:
CODE:
EAN CODE:
Networking
Edge-Core
Subject to change without notice
A07-ES3628C_SE_065
AtlAntis lAnd S.p.A. - Viale De Gasperi 122
20017 Mazzo di Rho - Milano - ITALY
Phone: +39 - (0)2 - 93.90.60.85 Fax: +39 - (0)2 - 93.90.61.61
Web: www.atlantis-land.com
E-Mail: [e-mail]
L3 Fast Ethernet Switch
A07-ES3628C
8026974008455
L3 Fast Ethernet Switch
TECHNICAL FEATURES
L2 Features
IGMP Snooping
Link Aggregation IEEE 802.3ad with LACP (Dynamic):
- FE Ports: 2~8 Links per Trunk
- GE Ports: 2 Links per Trunk
- Up to 32 Trunks (FE & GE, including Cisco Compatible Fast EtherChannel)
Port Mirroring
Spanning Tree: IEEE 802.1D/w/s
VLAN
- IEEE 802.1Q
- Private VLAN
- GVRP
L3 Features
DHCP Relay
DHCP Server
IP Redundancy: VRRP
Multicast Routing:
- DVMRP
- PIM-DM
- PIM-SM
Unicast Routing:
- RIP
- OSPF
Management
Command Line Interface (CLI)
RMON: RMON I (1,2,3, & 9 groups)
SNMP: Agent
Web Interface
Performance
MAC Address Table Size: 16K
Stacking Feature: standalone
Physical Configuration
Dimension (HxWxD) cm.: 4.4 x 44 x 41.4
Fixed Ports:
- 24 x 10/100 Base-T ports
x 2 x 10/100/1000 Base-T ports
- 2 x SFP ports
Redundant Power Supply
QoS Features
CoS
- IEEE 802.1p
- IP Precedence
- DSCP
- TCP / UDP
Priority Queue Scheduling: WRR, Strict Priority
Rate Limiting
- FE Ports: (Ingress / Egress)
- Granularity (64Kbps)
- GE Ports: (Ingress / Egress)
- Granularity (1Mbps)
Security
ACL: L2 / L3 / L4
HTTPS / SSH
IEEE 802.1x: Port-based
RADIUS/ TACACS+
