Atlas Copco LSF19 S300-1 Instruction sheet

LSF19 S300-1
Printed Matter No. 9836 6287 01 Die grinder
Publication Date 2023-01-25
Valid from Serial No. A0440001 Product Instructions
LSF19 S300-1
(30000 rpm)
8423122481
WARNING
Read all safety warnings and instructions
Failure to follow the safety warnings and instructions may result in
electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference

2© Atlas Copco Industrial Technique AB - 9836 6287 01
Table of Contents
Product Information................................................................................................3
General Information ..........................................................................................3
Safety Signal Words ..............................................................................3
Warranty ................................................................................................3
Website..................................................................................................3
ServAid ..................................................................................................4
Safety Data Sheets MSDS/SDS............................................................4
Product Safety Video for Grinders.........................................................4
PTFE .....................................................................................................4
Country of Origin ...................................................................................4
Dimensional Drawings...........................................................................5
Overview...........................................................................................................5
Design and Function..............................................................................5
Technical Product Data .........................................................................5
Installation ...............................................................................................................6
Installation Requirements .................................................................................6
Air Quality ..............................................................................................6
Air Lubrication Guide .............................................................................6
Compressed Air Connection..................................................................6
Installation Instructions .....................................................................................6
Visual Inspection - Tools and Accessories ............................................6
Operation .................................................................................................................8
Ergonomic Guidelines.......................................................................................8
Operating Instructions.......................................................................................9
Tool operation overview ........................................................................9
Throttle Lever with Safety Trigger .......................................................10
Service ...................................................................................................................11
Maintenance Instructions................................................................................11
General Service and Maintenance Safety ...........................................11
Service Recommendations..................................................................11
Replacement of Vanes ........................................................................11
Lubrication Instructions...................................................................................11
Rust Protection and Cleaning..............................................................11
Lubrication ...........................................................................................11
Lubrication Guide ................................................................................12
Dismantling/Assembling Instructions ..............................................................12
Instructions for Vane Motors................................................................12
Recycling ...............................................................................................................15
Environmental Regulations.............................................................................15

LSF19 S300-1 EN Product Information
© Atlas Copco Industrial Technique AB - 9836 6287 01 3
Product Information
General Information
WARNING Risk of Property Damage or Severe Injury
Ensure that you read, understand and follow all instructions before operating the tool. Failure to follow
all the instructions may result in electric shock, fire, property damage and/or severe bodily injury.
►Read all Safety Information delivered together with the different parts of the system.
►Read all Product Instructions for installation, operation and maintenance of the different parts of
the system.
►Read all locally legislated safety regulations regarding the system and parts thereof.
►Save all Safety Information and instructions for future reference.
Safety Signal Words
The safety signal words Danger, Warning, Caution, and Notice have the following meanings:
DANGER DANGER indicates a hazardous situation which, if not avoided, will result in death or se-
rious injury.
WARNING WARNING indicates a hazardous situation which, if not avoided, could result in death or
serious injury.
CAUTION CAUTION, used with the safety alert symbol, indicates a hazardous situation which, if
not avoided, could result in minor or moderate injury.
NOTICE NOTICE is used to address practices not related to personal injury.
Warranty
■Product warranty will expire 12+1 months after dispatch from Atlas Copco's Distribution Center.
■Normal wear and tear on parts is not included within the warranty.
■Normal wear and tear is that which requires a part change or other adjustment/overhaul during
standard tools maintenance typical for that period (expressed in time, operation hours or other-
wise).
■The product warranty relies on the correct use, maintenance, and repair of the tool and its component
parts.
■Damage to parts that occurs as a result of inadequate maintenance or performed by parties other
than Atlas Copco or their Certified Service Partners during the warranty period is not covered by the
warranty.
■To avoid damage or destruction of tool parts, service the tool according to the recommended mainte-
nance schedules and follow the correct instructions.
■Warranty repairs are only performed in Atlas Copco workshops or by Certified Service Partners.
Atlas Copco offers extended warranty and state of the art preventive maintenance through its ToolCover
contracts. For further information contact your local Service representative.
For electrical motors:
■Warranty will only apply when the electric motor has not been opened.
Website
Information concerning our Products, Accessories, Spare Parts and Published Matters can be found on
the Atlas Copco website.
Please visit: www.atlascopco.com.

Product Information EN LSF19 S300-1
4© Atlas Copco Industrial Technique AB - 9836 6287 01
ServAid
ServAid is a portal that is continuously updated and contains Technical Information, such as:
■Regulatory and Safety Information
■Technical Data
■Installation, Operation and Service Instructions
■Spare Parts Lists
■Accessories
■Dimensional Drawings
Please visit: https://servaid.atlascopco.com.
For further Technical Information, please contact your local Atlas Copco representative.
Safety Data Sheets MSDS/SDS
The Safety Data Sheets describe the chemical products sold by Atlas Copco.
Please consult the Atlas Copco website for more information www.atlascopco.com/sds.
Product Safety Video for Grinders
Learn more about safety features on Atlas Copco grinders and what measures the operator has to take for
a safe operation. Click the link or scan the QR code below to view the video:
https://www.youtube.com/watch?v=XK_dHwli8-Q
PTFE
WARNING Polymer Hazard
The vanes in this product contain PTFE (a synthetic fluoropolymer). Due to wear, there might be
PTFE particles inside the product. Heated PTFE can produce fumes which may cause polymer fume
fever with flu-like symptoms, especially when smoking contaminated tobacco.
Health and Safety recommendations for PTFE must be followed when handling vanes and other com-
ponents:
►Do not smoke when servicing this product
►PTFE-particles must not come in contact with open fire, glow or heat
►Motor components must be washed with cleaning fluid and not blown clear with an air line
►Wash your hands before starting any other activity
Country of Origin
For the Country of Origin, please refer to the information on the product label.

LSF19 S300-1 EN Product Information
© Atlas Copco Industrial Technique AB - 9836 6287 01 5
Dimensional Drawings
Dimensional Drawings can be found either in the Dimensional Drawings Archive, or on ServAid.
Please visit: http://webbox.atlascopco.com/webbox/dimdrw or https://servaid.atlascopco.com.
Overview
Design and Function
This die grinder is intended for mounted wheels and rotary burrs only. This model is lubricated. The ma-
chine, its attachments and accessories must only be used for the purpose for which they were designated,
all other use is prohibited.
■Never use grinding wheels attached with an adapter as this machine is not fitted with a wheel guard
■Never attach circular saw blades or other cutters than the abrasive wheels or brushes specified for
the tool
Technical Product Data
Technical Product Data can be found on either ServAid, or the Atlas Copco website.
Please visit: https://servaid.atlascopco.com or www.atlascopco.com.

Installation EN LSF19 S300-1
6© Atlas Copco Industrial Technique AB - 9836 6287 01
Installation
Installation Requirements
Air Quality
■For optimum performance and maximum product life we recommend the use of compressed air with
a maximum dew point of +10°C (50°F). We also recommend to install an Atlas Copco refrigeration
type air dryer.
■Use a separate air filter which removes solid particles larger than 30 microns and more than 90% of
liquid water. Install the filter as close as possible to the product and prior to any other air preparation
units to avoid pressure drop.
For impulse/impact tools make sure to use lubricators adjusted for these tools. Regular lubricators will
add too much oil and therefore decrease the tool performance due to too much oil in the motor.
Make sure that the hose and couplings are clean and free from dust before connecting to the tool.
Both lubricated and lubrication free products will benefit from a small quantity of oil supplied from a lu-
bricator.
Air Lubrication Guide
Recommended air lubricators:
■Atlas Copco Optimizer (1 liter) 9090 0000 04
■Q8 Chopin 46
■Shell Air Tool Oil S2 A 320
Compressed Air Connection
WARNING Risk of severe injury
Air under pressure can cause injury.
►Always shut off the air supply when not in use or before any adjustments.
►Drain the hose of air pressure and disconnect the tool from air supply when not in use or before
any adjustments.
►Always use the correct hose size and air pressure for the tool.
WARNING Compressed Air
High air pressure can cause severe damage and bodily injury.
►Do not exceed maximum air pressure.
►Make sure that there are no damaged or loose hoses or fittings.
For correct air pressure and hose size, see the Technical Product Data on - https://
servaid.atlascopco.com or www.atlascopco.com.
Make sure that the hose and couplings are clean and free from dust before connecting to the tool.
Installation Instructions
Visual Inspection - Tools and Accessories
Inspect the tool and its parts visually before use.
■Collet holder.
■Throttle lever.

LSF19 S300-1 EN Installation
© Atlas Copco Industrial Technique AB - 9836 6287 01 7
■Lever catch.
Look for any damages or oil leakage that can compromise the safety of the tool.

Operation EN LSF19 S300-1
8© Atlas Copco Industrial Technique AB - 9836 6287 01
Operation
Ergonomic Guidelines
Consider your workstation as you read through this list of general ergonomic guidelines to identify areas
for improvement in posture, component placement, or work environment.
■Take frequent breaks and change work positions frequently.
■Adapt the workstation area to your needs and the work task.
■Adjust for a convenient reach range by determining where parts and tools need to be located to
avoid static load.
■Use workstation equipment such as tables and chairs appropriate for the work task.
■Avoid work positions above shoulder level or with static holding during assembly operations.
■When working above shoulder level, reduce the load on the static muscles by lowering the weight
of the tool, using for example torque arms, hose reels or weight balancers. You can also reduce
the load on the static muscles by holding the tool close to the body.
■Take frequent breaks.
■Avoid extreme arm or wrist postures, particularly during operations requiring a degree of force.
■Adjust for a convenient field of vision that requires minimal eye and head movements.
■Use appropriate lighting for the work task.
■Select the appropriate tool for the work task.
■In noisy environments, use ear protection equipment.
■Use high-quality inserted tools and consumables to minimize exposure to excessive levels of vibra-
tion.
■Minimize exposure to reaction forces.
■When cutting:
A cut-off wheel can get stuck if the cut-off wheel is bent or not guided properly. Use the correct
flange for the cut-off wheel and avoid bending the cut-off wheel during operation.
■When drilling:
The drill might stall when the drill bit breaks through. Use support handles if the stall torque is high.
The safety standard ISO11148 part 3 recommends using a device to absorb a reaction torque
above 10 Nm for pistol grip tools and 4 Nm for straight tools.
■When using direct-driven screwdrivers or nutrunners:
Reaction forces depend on the tool settings and joint characteristics. Strength and posture deter-
mine the amount of reaction force that an operator can tolerate. Adapt the torque setting to the op-
erator's strength and posture and use a torque arm or reaction bar if the torque is too high.
■In dusty environments, use a dust extraction system or wear a mouth protection mask.

LSF19 S300-1 EN Operation
© Atlas Copco Industrial Technique AB - 9836 6287 01 9
Operating Instructions
Tool operation overview
A Free speed check
B Maximum speed at 6.3 bar 90 psig
30000 r/m rpm
C Operation instructions
D Attach collet (1) and shank (2)
E Press safety catch forward (1) and press trigger to
start (2)
F Air hose size: 13 mm (1/2 ")
G Maximum air pressure: - 6.3 bar (- 90 psig)
Setting-up instructions
WARNING Risk of Serious Injury or Death
Overspeed can cause serious injury or death!
►Do not manipulate the speed of the tool.
►Do not override the maximum speed marked on the tool.
Testing of the die grinder should only be done by professional technicians. The technicians must be au-
thorized to test this type of tool and to operate a pneumatic system in accordance with national directives.
■Do a free speed check of the tool every day and whenever the tool has been serviced. Do the free
speed check with the grinding equipment removed.
■Use a pressure regulator to prevent a too high air pressure which can cause overspeed.

Operation EN LSF19 S300-1
10 © Atlas Copco Industrial Technique AB - 9836 6287 01
■Make sure that connections and the air hose are in good condition.
Throttle Lever with Safety Trigger
The purpose of a throttle lever with safety trigger is to avoid unintentional start of the tool.
Flip the safety trigger to lock/unlock the safety function. Always put the throttle lever in locked position
before putting away the tool.
■Make sure that the safety trigger works correctly.
■Replace the throttle lever if it does not work correctly.
■Never remove the safety trigger or lock it with tape.

LSF19 S300-1 EN Service
© Atlas Copco Industrial Technique AB - 9836 6287 01 11
Service
Maintenance Instructions
General Service and Maintenance Safety
Do not dismantle the tool.
The service must only be done by authorized workshops or qualified service technicians.
WARNING Risk of severe injury
Air under pressure can cause injury.
►Always shut off the air supply when not in use or before any adjustments.
►Drain the hose of air pressure and disconnect the tool from air supply when not in use or before
any adjustments.
►Always use the correct hose size and air pressure for the tool.
Service Recommendations
Preventive maintenance is recommended at regular intervals. See the detailed information on preventive
maintenance. If the product is not working properly, take it out of service and inspect it.
If no detailed information about preventive maintenance is included, follow these general guide-
lines:
■Clean appropriate parts accurately
■Replace any defective or worn parts
Replacement of Vanes
Replace the vanes in the motor when a power drop of the tool is experienced. If the vanes are not re-
placed in time other motor parts may be damaged. For increased life length of the vanes use an oil lubri-
cator to dose oil into the air inlet.
Lubrication Instructions
Rust Protection and Cleaning
Water in the compressed air can cause rust. To prevent rust we strongly recommend to install an air dryer.
Water and particles can cause sticking of vanes and valves. This can be prevented by installing an air fil-
ter close to the product to avoid pressure drop.
Before longer standstills always protect your tool by adding a few drops of oil into the air inlet. Run the tool
for 5–10 seconds and absorb any access oil at the air outlet in a cloth.
NOTICE Do not try to clear the air path using sharp tools.
The air inlet is equipped with a strainer. If this is punctured, foreign objects may harm the valves, resulting
in overspeed.
Lubrication
For flexible spindle extension – When fitting the extended spindle – apply 0.5 cm3 (0.03 cu in) of grease
type “Lubricating Engineers LE3752” (or EP grease) at the bottom of the hole in the collet holder.

Service EN LSF19 S300-1
12 © Atlas Copco Industrial Technique AB - 9836 6287 01
Lubrication Guide
Use lubricants of good quality. The oils and greases listed in the lubrication table are examples of lubri-
cants that can be recommended.
Brand
General purpose
Bearings
BP Energrease LS-EP2
Castrol Spheerol EP L2
Esso Beacon EP2
Q8 Rembrandt EP2
Mobil Mobilegrease XHP 222
Shell Alvania EP2
Texaco Multifak EP2
Molycote BR2 Plus
Dismantling/Assembling Instructions
Instructions for Vane Motors
WARNING Polymer Hazard
The vanes in this product contain PTFE (a synthetic fluoropolymer). Due to wear, there might be
PTFE particles inside the product. Heated PTFE can produce fumes which may cause polymer fume
fever with flu-like symptoms, especially when smoking contaminated tobacco.
Health and Safety recommendations for PTFE must be followed when handling vanes and other com-
ponents:
►Do not smoke when servicing this product
►PTFE-particles must not come in contact with open fire, glow or heat
►Motor components must be washed with cleaning fluid and not blown clear with an air line
►Wash your hands before starting any other activity
Dismantling
Service tools are also included in the Basic Service Tools set. For further information see ordering No.
9835 5485 00

LSF19 S300-1 EN Service
© Atlas Copco Industrial Technique AB - 9836 6287 01 13
Dismantling tool Mandrel A
Ordering No. Ø D Ø C
4080 0182 01 7 3.5
4080 0182 02 8 4.5
4080 0182 03 9 5.5
4080 0182 04 10 6.5
4080 0182 05 13 8.5
4080 0182 06 16 10.5
4080 0182 07 19 12.5
4080 0182 08 22 15.5
4080 0182 09 24 17.5
4080 0182 10 26 20.5
4080 0182 11 30 25.5
4080 0182 12 35 30.5
4080 0182 13 40 35.5
4080 0182 14 47 40.5
Inspection of motor parts
Assembling
E: Ball bearing

Service EN LSF19 S300-1
14 © Atlas Copco Industrial Technique AB - 9836 6287 01
Service tools are also included in the Basic Service Tools set. For further information see ordering No.
9835 5485 00
Dismantling tool Mandrel B
Ordering No. Ø D Ø C
4080 0567 04 12.5 5.2
4080 0567 11 14.5 6.5
4080 0567 01 15.5 5.2
4080 0567 05 18.5 6.2
4080 0567 02 18.5 8.2
4080 0567 06 21.5 7.5
4080 0567 03 21.5 8.2
4080 0567 07 25.5 10.5
4080 0567 08 27.5 12.5
4080 0567 09 31.5 15.5
4080 0567 10 34.5 18.5

LSF19 S300-1 EN Recycling
© Atlas Copco Industrial Technique AB - 9836 6287 01 15
Recycling
Environmental Regulations
When a product has served its purpose it has to be recycled properly. Dismantle the product and recycle
the components in accordance with local legislation.
Batteries shall be taken care of by your national battery recovery organization.

Original instructions
Atlas Copco Industrial
Technique AB
SE-10523 STOCKHOLM
Sweden
Telephone: [phone]
www.atlascopco.com
© Copyright 2023, Atlas Copco Industrial Technique AB. All rights reserved.
Any unauthorized use or copying of the contents or part thereof is prohibited.
This applies in particular to trademarks, model denominations, part numbers
and drawings. Use only authorized parts. Any damage or malfunction caused
by the use of unauthorized parts is not covered by Warranty or Product
Liability.
Out of respect to wildlife and nature, our technical literature is printed on
environmentally friendly paper.
