Atlas IED ASP-MG2240 Operating and maintenance instructions

1/11
AtlasIED.com
TELEPHONE: [phone]
FAX [phone]
1601 JACK MCKAY BLVD.
ENNIS, TEXAS 75119 U.S.A.
©2017 Atlas Sound LP. The Atlas “Circle A”, Soundolier, and Atlas Sound are trademarks of Atlas Sound L.P. IED is a Registered Trademark of Innovative Electronic Designs LLC. All rights reserved. All other trademarks are property of their respective owners. No endorsement is implied. Due to continual product development, specifications are subject to change without notice. ATS005619 RevC 10/17
ASP-MG2240
Amplified Sound Masking System
Features
• Amplified Masking Controller
• 2 Masking Zones
• 2 x 20-Watt Outputs
• Analog White & Pink Noise Generators
• Balanced Line Output for 3rd Zone
• Speech Enhanced Privacy Mode (Adjustable +/- 12dB)
• Mic / Line Input for Paging with EQ & Limiter
• Auxiliary Input for BGM with EQ & Limiter
• Push Here Diagnostic (PHD) System Test Circuitry
• Assignable Balanced Line Output
• DSP Parameters EQ, HI & Lo Pass Filters, Limiter
• PC Software Control
• 24 / 7 Schedule for Each Output
• System Commissioning Ramp On Each Output
• Meets Low Voltage Class 2 Wiring Codes
Applications
The ASP-MG2240 is suited for applications requiring a secured speech
environment, paging or background music (BGM) audio. The
ASP-MG2240 is designed to provide detailed masking privacy for a wide
range of acoustical environments including open office areas, conference
rooms, huddle/meeting rooms, as well as delivering non-masking
content to areas where needed.
General Description
The AtlasIED ASP-MG2240 is a two zone masking controller with
integrated amplification. The compact design incorporates features
including two-channels of amplification, separate analog masking
generators with EQ, 24/7 scheduler, System Commissioning Ramp,
balanced Mic/line input, auxiliary input for background audio, and a
line output. The PC control software allows the user to customize the
system to meet the installation requirements. Settings can be stored in
the unit or in the PC for file back up or recall. The ASP-MG2240 offers
industry leading preconfigured presets that are specific to common and
advanced masking applications. These settings are based on AtlasIED
proprietary Chanaud Masking Filters.
Precise sound masking is now quick to implement. The compact
ASP-MG2240 can deliver quality audio in a single masking zone up to
7000 sq. ft. or can be spilt into two 3500 sq. ft. zones. This compact
integrated solution features two internal 20-watt amplifier channels along
with internal DSP with intuitive control software. This software makes
setup fast because of the practical real life preset configurations that can
be selected and modified for customization.
Speech Privacy Enhancement for conference rooms or medical offices
is an economical solution to meet federal HIPAA law requirements. The
ASP-MG2240 features a customizable speech privacy solution for any
environment. When in a private meeting that requires speech privacy,
a switch can be pressed to activate the "Speech Privacy Enhancement"
mode. The masking signal level will increase to a pre-set level to
enhance privacy one the button is pressed. A variety of optional Speech
Privacy Enhancement signs are available to connect to the ASP-MG2240
that provide visual indication that a room is being used and that the
speech privacy system is in use.
The ASP-MG2240 is an all-in-one solution for most environments. The
ASP-MG2240 not only supplies speech privacy but also delivers paging
and background music audio. Mic / line and AUX inputs each have a
selectable five band EQ and Hi & Lo pass filters. For paging applications,
the ASP-MG2240 incorporates a unique hi Q feedback filter specifically
tailored to the vocal frequency range. Adjustable output limiters are in
the audio chain to protect against system overdrive.
Many installations are incorrectly installed for a variety of reasons and
are a leading cause of equipment failure. The ASP-MG2240 includes a
patent pending automatic diagnostic system test, called the Push Here
Diagnostic (PHD). The PHD button is designed to check the connected
speaker lines for wiring and amplifier loading errors. This test can be
activated once all speakers are connected and the circuit automatically
verifies that the attached speakers' tap settings do not exceed the
amplifier's rated power and the speaker wire is free from shorts.
Most traditional sound masking systems require the speaker wire to
be placed in electrical conduit because of the high voltage output of
the amplifier. This method is effective but is expensive to implement.
The ASP-MG2240 meets low voltage Class 2 wiring electrical code
requirements, eliminating the need to run the speaker wire in expensive
conduit. This is a huge cost savings for any installation. The ASP-MG2240
utilizes advance technology to meet the Class 2 electrical codes but still
delivers quality speech privacy, paging, and background music audio.
The integrated amplifiers are more than 90% efficient and when
combined with a 24 / 7 masking scheduler, the system has the perfect
balance between audio performance and energy conservation. When
the scheduler is set to minimum use, the ASP-MG2240 only draws
4.4-watts, during everyday use the average power consumption is only
19-watts, and under maximum use power consumption is 67-watts. The
ASP-MG2240 is one the most energy efficient sound masking systems
available today.
ASP-MG2240 Front
ASP-MG2240 Back
ASP-MG2240
Sound Masking Controller / Amplifier
Data
Privacy
Engaged
Amp A
Peak
Amp B
Peak
Masking
CH A
Masking
CH B
AUX
Lim/Sig
Mic/Line
Lim/Sig
PHD
CH A
PHD
CH B
PHD
CH A Test
PHD
CH B Test Power
Power
DC 24V
2500mA
AUX
Input
L+R
Sum
AUX
Level
Mic / Line
Input
Mic / Line
Level
Line
Output
Amp B
Output
Amp A
Output
Connect to 70V Speaker System
Class 2 Wire
Micro USB
Software Control
G++ – G COM COM
+ + +–
+
–+ –
–
1601 Jack McKay Blvd. • Ennis, TX 75119
800.876.3333 • AtlasIED.com
Firmware
Update
Privacy
Enhancement
G To LEDEngage
ASP-MG2240
Sound Masking Controller / Amplifier
Data
Privacy
Engaged
Amp A
Peak
Amp B
Peak
Masking
CH A
Masking
CH B
AUX
Lim/Sig
Mic/Line
Lim/Sig
PHD
CH A
PHD
CH B
PHD
CH A Test
PHD
CH B Test Power
Power
DC 24V
2500mA
AUX
Input
L+R
Sum
AUX
Level
Mic / Line
Input
Mic / Line
Level
Line
Output
Amp B
Output
Amp A
Output
Connect to 70V Speaker System
Class 2 Wire
Micro USB
Software Control
G++ – G COM COM
+ + +–
+
–+ –
–
1601 Jack McKay Blvd. • Ennis, TX 75119
800.876.3333 • AtlasIED.com
Firmware
Update
Privacy
Enhancement
G To LEDEngage

2/11
AtlasIED.com
TELEPHONE: [phone]
FAX [phone]
1601 JACK MCKAY BLVD.
ENNIS, TEXAS 75119 U.S.A.
©2017 Atlas Sound LP. The Atlas “Circle A”, Soundolier, and Atlas Sound are trademarks of Atlas Sound L.P. IED is a Registered Trademark of Innovative Electronic Designs LLC. All rights reserved. All other trademarks are property of their respective owners. No endorsement is implied. Due to continual product development, specifications are subject to change without notice. ATS005619 RevC 10/17
System
Type Sound Masking Controller & Amplifier
Power Supply Type External Inline 24V 2500mA Global
Amp Topology Class D
Number of Fixed Inputs 2
Accessory Inputs 0
DSP Internal Ye s
Network USB Interface
Optional Accessory Card Slot NA
Output Power (Note 1)
2 CH 20W x 2 into 115ΩLoad (Note: A Lower Impedance Will Cause the Amp to Go Into Protect)
Factory Default Settings (As Shipped)
Amplifier Configuration 2 CH
Level Controls Assignment Masking Fixed via Factory Preset, Mic & AUX Adjustable Rear Panel
I/O Matrix Masking Generator 1 = Amp Output 1, Masking Generator 2 = Amp Output 2
Mic & AUX Routed to Output 1 & 2
Level Position DSP Set to -10dBU, Rear Panel Level Control Set to 50%
EQ & Filters Masking EQ - Customer filters for Above Ceiling Preset
Mic = 120Hz HPF, AUX = 100Hz HPF
Limiter 0dB (Max Power)
GPIO Control Ports (Rear Panel) Speech Privacy Engage, Privacy Sign Output
Auto Power Down (APD) NA
24Hr / 7-Day Scheduler Off
System Commissioning Ramp Off
Inputs
Input Quantity 2
Input Type (Line Balanced or Unbalanced) Mic / Line Balanced & AUX L & R Summed Unbalanced
Input Impedance 40kΩ
Input Sensitivity Mic 5mV, Line 500mV, AUX Variable 1V - 316mV
Maximum Input Level dBu & Vrms Mic 50mV, Line 2V, AUX 2V
Input Connectors Type Mic / Line 3.5mm Euro Block, AUX 3.5mm
Accessory Slot NA
Level Control
Rear Panel Manual Mic / Line & AUX
GUI Control Mic / Line, AUX, Masking
Status Indicators - Front Panel and GUI
Power Blue Indicator
Standby (Remote Turn ON) NA
Output Signal Green, CH 1/2
Output Peak Fault CH A Red
Output Peak Fault CH B Red
PHD Fault CH A Red
PHD Fault CH B Red
AUX Signal / Limit Green
Mic / Line Signal / Limit Green
Masking A Green
Masking B Green
Privacy Engage Red

3/11
AtlasIED.com
TELEPHONE: [phone]
FAX [phone]
1601 JACK MCKAY BLVD.
ENNIS, TEXAS 75119 U.S.A.
©2017 Atlas Sound LP. The Atlas “Circle A”, Soundolier, and Atlas Sound are trademarks of Atlas Sound L.P. IED is a Registered Trademark of Innovative Electronic Designs LLC. All rights reserved. All other trademarks are property of their respective owners. No endorsement is implied. Due to continual product development, specifications are subject to change without notice. ATS005619 RevC 10/17
Front Panel Features
Power Switch Push, Latching
Push Here Diagnostics (PHD) Switch Push, Momentary
USB Micro USB
Rear Panel Features
Power Input 24V DC, 2500mA, 2 Position, 3.5mm Euro Block, (Phoenix)
AUX Input 3.5mm Jack
Mic / Line 3 Position, 3.5mm Euro Block, (Phoenix)
AUX Level Rotary Potentiometer
Mic / Line Level Rotary Potentiometer
Privacy Engage 3 Position, 3.5mm Euro Block, (Phoenix)
Line Output 3 Position, 3.5mm Euro Block, (Phoenix)
CH A Amplifier Output 2 Position, 5.08mm Euro Block, (Phoenix)
CH B Amplifier Output 2 Position, 5.08mm Euro Block, (Phoenix)
Firmware Update Switch Push, Momentary
DSP Features & Elements
Scheduler Separate 24Hr / 7-Day Scheduler for Masking A & B Outputs, 7 Day Battery Clock Back Up
Level Control Level & Mic / Line, AUX, Masking A & B, Line Out
System Commissioning Ramp Separate Commissioning Ramps for Masking A & B Outputs, 7 Day Battery Clock Back Up
Masking Noise Pink and White Noise Analog Generators
Presets 10 Total
Factory Presets - Open Ceiling, Above Ceiling, Below Floor, Factory
6 Available For Customer
Hi & Low Pass Filters Mic / Line, AUX, Masking A & B
EQ AUX & Line - 5 Parametric Filters, Masking 1/3 Octave
Delay NA
Limiter Mic / Line 0db - 15dB of Assignable Limiting
DSP Frequency Type 24bit
Interface Control Ports
USB Micro USB, ASP-MG2240 Software Required
Ethernet No
WiFi No
Bluetooth No
GPIO Ports
Location Rear
GPIO Ports Qty 1
Connection Euro Block PHX Type 3.5mm, 3 Pins, Ground, +10VDC (Output After Engaged), C1
Functions Speech Privacy Engage, Privacy Sign Output
Line Output
Output Quantity 1
Input Type (Line Balanced or Unbalanced) Balanced
Output Impedance 150Ω
Maximum Output Level dBu &Vrms 2V
Output Connector Type 3 Position, 3.5mm Euro Block, (Phoenix)

4/11
AtlasIED.com
TELEPHONE: [phone]
FAX [phone]
1601 JACK MCKAY BLVD.
ENNIS, TEXAS 75119 U.S.A.
©2017 Atlas Sound LP. The Atlas “Circle A”, Soundolier, and Atlas Sound are trademarks of Atlas Sound L.P. IED is a Registered Trademark of Innovative Electronic Designs LLC. All rights reserved. All other trademarks are property of their respective owners. No endorsement is implied. Due to continual product development, specifications are subject to change without notice. ATS005619 RevC 10/17
Output Terminals (Speaker)
Output Connectors Type 5.08mm Euro Block, (Phoenix)
Number of Terminals 2
Output Connectors Fixed or Removable Removable
Wire Size 14 AWG
Terminal Spacing 5.08mm
Current Rating 12A per Terminal
Wire Class Required Class 2
Cooling
Convection Ye s
Electrical Specifications (General)
Masking Generator Qty 2 Circuits Analog
Total Harmonic Distortion 1kHz and 1dB Below
Rated Power Typical, .2%
Frequency Response 50Hz - 15kHz (DSP Filters Set to Flat)
Signal to Noise Ratio >90dB Below Rated Output (A-weighted)
Damping Factor (20Hz to 400Hz) NA
Slew Rate NA
Crosstalk 69dB @ 1KHz
Protection Hi / Low Input Voltage, Thermal, Short, Over Current
Max Output Peak Voltage 48V (Meets Class 2 Low Voltage Wire Codes)
File Storage Recall or Save to Device, Recall or Save to Computer
AC Power Requirements
Operating Voltage External Supply 110V-230V, 50/60Hz
Mains Interface IEC C7 Receptacle to Inline Power Supply, To Amp - 24V DC Output 2 Position, 3.5mm Euro Block, (Phoenix)
Power Cord (Included) 2m, NEMA 1-15P Standard USA 2 Pin Plug to IEC C7 Receptacle with 18/2 SPT-2 Black
Rated up to 10A 100V to 240V
Minimum Power-Up Voltage 100V
Maximum Operating Voltage 240V
Recommended AC Mains Current Requirements 3A
Power Consumption and Current Draw (Note 4) Amps Watts BTU
Standby / APD Mode NA NA NA
Idle Active / On 72mA 4.4W 15 BTU
Average Power, All Channels Driven (Note 2) 275mA 19W 30 BTU
Max Power, All Channels Driven (Note 3) 908mA 67W 92 BTU
Dimensions and Weight
Rack Mount Requirements 1 RU, 19"
Dimensions - Unit W 10.5" x H 1.75" x D 11.25" (266mm x 44mm x 286mm)
Dimensions - Shipping W 11" x H 5.5" x D 13.5" (279mm x 140mm x 344mm)
Weight - Unit 5.75 lbs. (2.6kg)
Weight - Shipping 8.8 lbs (4kg)
Agency Approvals
North America Agency UL, TUV, GMA (Power Supply)
Testing Standard North America 60065
FCC Class A (Conducted & Radiated Emissions) Part 15 of the FCC Rules
RoHS / WEEE Compliant Ye s
CE Ye s

5/11
AtlasIED.com
Product
Description
TELEPHONE: [phone]
FAX [phone]
1601 JACK MCKAY BLVD.
ENNIS, TEXAS 75119 U.S.A.
©2017 Atlas Sound LP. The Atlas “Circle A”, Soundolier, and Atlas Sound are trademarks of Atlas Sound L.P. IED is a Registered Trademark of Innovative Electronic Designs LLC. All rights reserved. All other trademarks are property of their respective owners. No endorsement is implied. Due to continual product development, specifications are subject to change without notice. ATS005619 RevC 10/17
NOTES:
1. Power level measurement is define as follows: 1Hz sine AUX, line or mic inputs.
2. Average Power is defined as Pink Noise input signal applied to achieve 1/4 of the power rating.
3. Max Power is defined as 1 KHz input signal applied to achieve the maximum power output before clipping into a specified load.
4. BTU is calculated by the AC Mains Power consumed minus the total power output measured at the specified load and condition, multiplied by 3.412.
Example: 785 Watts from the AC Source - 600 Watts Total Output power = 185 x 3.412 = 631 BTU
Optional Accessories
ASP-MG2240S Wired Enhanced Privacy Sign

6/11
AtlasIED.com
TELEPHONE: [phone]
FAX [phone]
1601 JACK MCKAY BLVD.
ENNIS, TEXAS 75119 U.S.A.
©2017 Atlas Sound LP. The Atlas “Circle A”, Soundolier, and Atlas Sound are trademarks of Atlas Sound L.P. IED is a Registered Trademark of Innovative Electronic Designs LLC. All rights reserved. All other trademarks are property of their respective owners. No endorsement is implied. Due to continual product development, specifications are subject to change without notice. ATS005619 RevC 10/17
Common Applications
Example 1 – Shows a common open office environment requiring two zones due to the differences in architectural material designs. Zone A is an
open ceiling room and Zone B drop ceiling design. Both Zones require different masking tuning.

7/11
AtlasIED.com
TELEPHONE: [phone]
FAX [phone]
1601 JACK MCKAY BLVD.
ENNIS, TEXAS 75119 U.S.A.
©2017 Atlas Sound LP. The Atlas “Circle A”, Soundolier, and Atlas Sound are trademarks of Atlas Sound L.P. IED is a Registered Trademark of Innovative Electronic Designs LLC. All rights reserved. All other trademarks are property of their respective owners. No endorsement is implied. Due to continual product development, specifications are subject to change without notice. ATS005619 RevC 10/17
Common Applications
Example 2 – Shows a two-zone application with a lobby, Zone B, and an open office, Zone A, design. Sound Masking is applied to both zones that
require different tuning, paging to both zones, and background music to just Zone B.

8/11
AtlasIED.com
TELEPHONE: [phone]
FAX [phone]
1601 JACK MCKAY BLVD.
ENNIS, TEXAS 75119 U.S.A.
©2017 Atlas Sound LP. The Atlas “Circle A”, Soundolier, and Atlas Sound are trademarks of Atlas Sound L.P. IED is a Registered Trademark of Innovative Electronic Designs LLC. All rights reserved. All other trademarks are property of their respective owners. No endorsement is implied. Due to continual product development, specifications are subject to change without notice. ATS005619 RevC 10/17
Common Applications
Example 3 – Shows a conference room that requires speech privacy during certain meetings and a visual indicator to know the Speech Enhancement
is active.

9/11
AtlasIED.com
TELEPHONE: [phone]
FAX [phone]
1601 JACK MCKAY BLVD.
ENNIS, TEXAS 75119 U.S.A.
©2017 Atlas Sound LP. The Atlas “Circle A”, Soundolier, and Atlas Sound are trademarks of Atlas Sound L.P. IED is a Registered Trademark of Innovative Electronic Designs LLC. All rights reserved. All other trademarks are property of their respective owners. No endorsement is implied. Due to continual product development, specifications are subject to change without notice. ATS005619 RevC 10/17
Block Diagram
DC - DC
+10V
+9V
+3.3V
DC+24V/2.5A Input
DPI
HPF - LPF
DPI
HPF - LPF
5 Band Equalizer
AUX
Sensitivity
Control
Variable Limiter Variable Limiter
EQ Masking B
Level Control
Speech Privacy
Level
24 / 7
Scheduler
Mixer
AMP B
Mixer
AMP A
Mic / Line / AUX /
Masking AMP B
Mic / Line / AUX /
Masking AMP A
EQ Masking A
Level Control
Speech Privacy
Level
24 / 7
Scheduler
AMP A
Mic/Line
Level Control
AMP A
AUX Level Control
AMP B
Mic/Line
Level Control
AMP B
AUX Level Control
Pink Noise
Analog Masking Generator AMP A
Analog Masking Generator AMP B
White Noise
Pink Noise
White Noise
AMP A
Master Level
Control
AMP A
50Hz HPF POWER AMP A
PHD Detect
PHD Detect
AUDIO
Transformer
Masking AMP B
Masking AMP A
STM32F103RC Line Balance Output
Line Out
Level Control
Privacy Engage Orange
Speech Privacy Enhancement
Masking - A Signal Green Masking - B Signal Green AUX Limit/Signal Red/Green MIC Limit/Signal Red/Green
Power Switch
Power Blue
USB Server Control
1CH - 20W
AMP B
Master Level
Control
AMP B
50Hz HPF POWER AMP B AUDIO
Transformer 1CH - 20W
GND Privacy
+12VDC (To Sign)
– + GND
3V Battery
PHD Output A Yellow
PHD SWA
PHD Output B Yellow
Data - LED - Yellow PHD SWB
AMP A PEAK Red
AMP B PEAK Red
Firmware Update SW
+5V
Phantom 24V
Mic Notch Filter
5 Band Equalizer
AUX Level Dect
Mic/Line Level Dect
Mic/Line Input
AUX 3.5mm Jack Input
Unbalanced 1V=48V
AUX Input
Volume
Analog
Mic/Line
Input
Volume
Analog
Mic/Line
Switch
Analog
PEAK A
Detect
PEAK B
Detect
– +
– +
–
+
–
+
GND

10/11
AtlasIED.com
TELEPHONE: [phone]
FAX [phone]
1601 JACK MCKAY BLVD.
ENNIS, TEXAS 75119 U.S.A.
©2017 Atlas Sound LP. The Atlas “Circle A”, Soundolier, and Atlas Sound are trademarks of Atlas Sound L.P. IED is a Registered Trademark of Innovative Electronic Designs LLC. All rights reserved. All other trademarks are property of their respective owners. No endorsement is implied. Due to continual product development, specifications are subject to change without notice. ATS005619 RevC 10/17
Dimensional Drawings
266.00mm
216.00mm
282.00mm
3.50mm
44.00mm
ASP-MG2240
Sound Masking Controller / Amplifier
Data
Privacy
Engaged
Amp A
Peak
Amp B
Peak
Masking
CH A
Masking
CH B
AUX
Lim/Sig
Mic/Line
Lim/Sig
PHD
CH A
PHD
CH B
PHD
CH A Test
PHD
CH B Test Power
Power
Micro USB
Software Control

11/11
AtlasIED.com
TELEPHONE: [phone]
FAX [phone]
1601 JACK MCKAY BLVD.
ENNIS, TEXAS 75119 U.S.A.
©2017 Atlas Sound LP. The Atlas “Circle A”, Soundolier, and Atlas Sound are trademarks of Atlas Sound L.P. IED is a Registered Trademark of Innovative Electronic Designs LLC. All rights reserved. All other trademarks are property of their respective owners. No endorsement is implied. Due to continual product development, specifications are subject to change without notice. ATS005619 RevC 10/17
Architect and Engineer Specications
The AtlasIED ASP-MG2240 shall be a 1RU-half rack wide DSP Sound
Masking Controller processor with two zone integrated Amplifier and
one assignable Balanced Line output. The ASP-MG2240 shall provide one
Balanced Mic/Line and one AUX L & R Summed Unbalanced inputs. Two
independent analog pink or white noise generators for Masking A & B
shall be assignable sources. The Mic/Line inputs shall provide Mic 50mV,
Line 500mV, and AUX variable 316mV – 1V input sensitivity. Each of the
Mic/Line and AUX inputs shall have independent input level control on
rear panel. All inputs and outputs except the AUX input, shall be rear
panel plug-in Euro/Phoenix type connectors. The AUX input on rear panel
shall be a 3.5mm stereo (summed) jack. DSP Equalization shall be 1/3
octave for Masking A&B and 5 Band parametric filters with Limiter for
Mic/Line/AUX sources. The Masking A & B, Mic/Line and AUX shall have
Hi & Low Pass Filters.
The ASP-MG2240 shall have a USB PC interface with Windows®
programming software. The software shall provide an intuitive GUI
interface for mixing sources and easy setup of processor controls and
DSP settings. 6 User and 4 Factory proven presets shall be available
to recall/store processor settings. Factory Presets for applications shall
be Open Ceiling, Above Ceiling, Below Floor, and Factory. The GUI
interface shall provide a 24/7 scheduler to improve masking efficiency.
An “Enhanced Privacy” system shall be provided with contact closure
activation via 3-way Phoenix connector on the rear panel. The connector
shall include a 12VDC LED driver output for an Enhanced Privacy display
sign. Enhanced Privacy configuration Settings shall be available in the
software GUI. The ASP-MG2240 shall provide Push Here Diagnostic test
for confirming proper speaker loads. The ASP-MG2240 shall provide front
panel LED monitoring indication of Mic/Line/AUX Signal-Limit; Masking
Generator A & B Signal; Output Signal Peak-Fault Channel A & B; PHD
Fault Channel A & B; Privacy Engaged; and Power. Frequency Response
shall be 50Hz-15kHz (with DSP set to Flat). Dynamic Range shall be
greater than 90dB below rated output (A-Weighted). Power Consumption
shall be less than 20W average under normal use. Dimensions shall be
1.75" high, 10.5" wide, & 11.25" deep. Weight shall be 5.75 lbs. Warranty
coverage shall be 1-year. The unit shall be CE marked, RoHS/WEEE, TUV,
GMA (power Supply) compliant and UL certified. The ASP-MG2240 shall
meet low voltage wiring standards. The Sound Masking Controller &
Amplifier shall be an AtlasIED ASP-MG2240.
