Atlas IED 1544ZOP User manual

©2019 Atlas Sound LP. The Atlas “Circle A”, Soundolier, and Atlas Sound are trademarks of Atlas Sound L.P. IED is a Registered Trademark of Innovative Electronic Designs LLC. All rights reserved. All other Trademarks are property of their respective owners. No endorsement is implied. Due to continual product development, specifications are subject to change without notice. ATS005966 RevA 5/19 DOC1227B
AtlasIED.com
TELEPHONE: [phone]
[e-mail]
9701 TAYLORSVILLE ROAD
LOUISVILLE, KENTUCKY 40299 U.S.A.
4x4 Smart Zone Output Processor
1544ZOP
Installation Manual
Version: 0.3
Document: 1227B

©2019 Atlas Sound LP. The Atlas “Circle A”, Soundolier, and Atlas Sound are trademarks of Atlas Sound L.P. IED is a Registered Trademark of Innovative Electronic Designs LLC. All rights reserved. All other Trademarks are property of their respective owners. No endorsement is implied. Due to continual product development, specifications are subject to change without notice. ATS005966 RevA 5/19 DOC1227B
AtlasIED.com
TELEPHONE: [phone]
[e-mail]
9701 TAYLORSVILLE ROAD
LOUISVILLE, KENTUCKY 40299 U.S.A.
Table of Contents
Important Safety Instructions................................................................................................................................................................................. 3
Introduction ........................................................................................................................................................................................................... 8
Key Features.......................................................................................................................................................................................................... 8
Front Panel Description .......................................................................................................................................................................................... 9
Rear Panel Description ........................................................................................................................................................................................... 9
Installing the 1544ZOP..........................................................................................................................................................................................10
Connecting Supervised Logic Inputs.....................................................................................................................................................................11
Connecting Unbalanced Audio Inputs / Outputs ...................................................................................................................................................11
Connecting a Power Supply ..................................................................................................................................................................................11
Complete Unit Configuration ................................................................................................................................................................................11
Specifications ....................................................................................................................................................................................................... 12
FCC Notice ........................................................................................................................................................................................................... 13
Warranty ............................................................................................................................................................................................................... 16

©2019 Atlas Sound LP. The Atlas “Circle A”, Soundolier, and Atlas Sound are trademarks of Atlas Sound L.P. IED is a Registered Trademark of Innovative Electronic Designs LLC. All rights reserved. All other Trademarks are property of their respective owners. No endorsement is implied. Due to continual product development, specifications are subject to change without notice. ATS005966 RevA 5/19 DOC1227B
AtlasIED.com
TELEPHONE: [phone]
[e-mail]
9701 TAYLORSVILLE ROAD
LOUISVILLE, KENTUCKY 40299 U.S.A.
Important Safety Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this device near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other device that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A
grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided
plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the
device.
11. Only use attachments / accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the device. When a cart is used, use caution
when moving the cart / device combination to avoid injury from tip-over.
13. Unplug this device during lightning storms or when unused for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required when the device has been damaged in any way, such as power-supply cord
or plug is damaged, liquid has been spilled, or objects have fallen into the device, the device has been exposed to rain or moisture, does not
operate normally, or has been dropped.
15. This product is equipped with a three-wire grounding-type plug, a plug having a third (grounding) pin. This plug will only fit into a grounding-type
power outlet. This is a safety feature. If you are unable to insert the plug into the outlet, contact your electrician to replace your obsolete outlet. Do
not defeat the safety purpose of the grounding-type plug.
16. WARNING: To reduce the risk of fire or electric shock, this device should not be exposed to rain or moisture and objects filled with liquids, such as
a vase, should not be placed on this device.
17. To completely disconnect this equipment from the mains, disconnect the power supply cord plug from the receptacle.
18. The mains plug of the power supply cord shall remain readily operable.
19. Protective earthing terminal. The apparatus should be connected to a mains socket with a protective earthing connection.
The lightning flash with arrowhead symbol within an equilateral triangle,
is intended to alert the user to the presence of uninsulated “dangerous
voltage “ within the product’s enclosure that may be of sufficient
magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to
alert the user to the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the product.
WARNING: SHOCK HAZARD - DO NOT OPEN
AVIS: RISQUE DE CHOC ELÉCTRIQUE - NE PAS OUVRIR
WARNING:TO REDUCETHE RISK OF FIRE OR ELECTRIC SHOCK
DO NOT EXPOSETHIS EQUIPMENT TO RAIN OR MOISTURE
AVIS: NE PAS EXPOSER CE MATÉRIEL À LA PLUIE OU L’HUMIDITE
AFIN DE REDUIRE LE RISQUE D’INFLAMMATION OU DE CHOC ELÉCTRIQUE

©2019 Atlas Sound LP. The Atlas “Circle A”, Soundolier, and Atlas Sound are trademarks of Atlas Sound L.P. IED is a Registered Trademark of Innovative Electronic Designs LLC. All rights reserved. All other Trademarks are property of their respective owners. No endorsement is implied. Due to continual product development, specifications are subject to change without notice. ATS005966 RevA 5/19 DOC1227B
AtlasIED.com
TELEPHONE: [phone]
[e-mail]
9701 TAYLORSVILLE ROAD
LOUISVILLE, KENTUCKY 40299 U.S.A.
WARNING - When The Device Is In Use
• WARNING: For the terminals marked with symbol of may be of sufficient magnitude to constitute a risk of electric shock. The external wiring
connected to the terminals requires installation by an instructed person or the used of ready-made leads or cords.
• WARNING: The apparatus shall not be exposed to dripping or splashing and that objects filled with liquids, such as vases, shall not be placed on
apparatus.
• WARNING: The mains plug is used as disconnect device, the disconnect device shall remain readily operable.
• To prevent electric shock, do not remove the product cover as there are high voltage components inside. Refer all servicing to AtlasIED.
• Should any of the following irregularities occur during use, immediately switch off the power, disconnect the power cord from the AC outlet and
contact AtlasIED. Do not to attempt to continue operation with the product as this may cause fire or electric shock:
• Smoke or strange smell coming from the unit.
• If the product falls or the case is damaged.
• If water or any metallic objects falls into the product.
• If the power supply cord is damaged in any way.
• If the unit is malfunctioning.
• Do not insert or drop metallic objects or flammable materials into the ventilation holes of the product's cover, as this may result in electric shock or
fire.
• Do not place any containers with liquid or metallic objects on the top of the product. If any liquid spills into the unit, fire or electric shock may result.
• Never operate this product or touch the power supply cord during an electrical storm, electric shock may result.
• Never exceed the power rating on the product when connecting equipment. Fire and/or property damage may result.
• Operate the product only with the voltage specified on the unit. Fire and/or electric shock may result if a higher voltage is used.
• Do not modify, kink, or cut the power cord. Do not place the power cord in close proximity to heaters and do not place heavy objects on the power
cord, including the product itself, doing so may result in fire or electrical shock.
• Ensure that the safety ground terminal is connected to a proper ground. Never connect the ground to a gas pipe as a catastrophic disaster may
result.
• Be sure the installation of the product is stable, avoid slanted surfaces as the product may fall and cause injury or property damage.
CAUTION - When InstallingThe Product
• Plugging in or unplugging the power cord with wet hands may result in electric shock.
• Never move the unit with the power cord plugged into the wall, as damage to the power cord may result.
• When unplugging the cord from the wall, grasp the plug, NOT the cord.
• Never install this product in humid or dusty locations, nor in direct sunlight, near sources of heat, or in areas where sooty smoke or steam are
present. Fire and electric shock may result.
• Keep all sides of the unit at least 31/2" away from objects that may obstruct air flow to prevent the unit's internal temperature rise.
CAUTION - WhenThe Product Is In Use
• Never place heavy objects on the product, causing it to fall and/or break, resulting in personal injury and property damage. In addition, the product
itself may fall and cause injury and property damage.
• Contact AtlasIED for instructions on cleaning the inside of the unit. Large accumulations of dust inside the unit may result in heat buildup and fire.
• Ensure that the power supply plug is securely plugged into the wall outlet. Never allow dust to accumulate on the power plug or inside the wall
outlet.
• When cleaning the unit or the unit is not to be operated for an extended period, unplug the power cord from the wall.

©2019 Atlas Sound LP. The Atlas “Circle A”, Soundolier, and Atlas Sound are trademarks of Atlas Sound L.P. IED is a Registered Trademark of Innovative Electronic Designs LLC. All rights reserved. All other Trademarks are property of their respective owners. No endorsement is implied. Due to continual product development, specifications are subject to change without notice. ATS005966 RevA 5/19 DOC1227B
AtlasIED.com
TELEPHONE: [phone]
[e-mail]
9701 TAYLORSVILLE ROAD
LOUISVILLE, KENTUCKY 40299 U.S.A.
WARNING: To reduce the risk of fire or electric shock, do not expose this apparatus to rain, moisture, dripping, splashing, or place objects filled with
liquids on the equipment.
AVERTISSEMENT: Afin de réduire le risque d’incendie ou de choc électrique, n’exposez pas cet appareil à la pluie, à l’humidité, à l’égouttement, aux
éclaboussures, et ne posez pas des objets remplis de liquide sur l’appareil
WARNING: If apparatus is equipped with Class I grounding plugs for safety purposes, it must be connected to MAINS that employ a protective earth
ground connection.
AVERTISSEMENT: si l’appareil est équipé de prises de terre classe I, pour des raisons de sécurité, il doit être branché sur un réseau ayant une prise
de terre de protection.
WARNING: The MAINS plug on this device may be used as the DISCONNECT DEVICE for MAINS power and must remain readily operable.
AVERTISSEMENT: La prise principale de cet appareil peut être utilisé comme DISPOSITIF de DECONNEXION du courant principal et doit rester
facilement accessible.
WARNING: Installation and maintenance of AtlasIED equipment is to be made by trained / qualified personnel and must conform to all applicable local
codes.
AVERTISSEMENT: l’installation et la maintenance des équipements AtlasIED doit être faite par du personnel formé / qualifié et doivent être conformes
à toutes les réglementations locales en vigueur.
WARNING: If unit contains a lithium battery, there is a danger of explosion. Replace only with the same or equivalent type.
AVERTISSEMENT: Si l’unité contient une pile au lithium, il y a un danger d’explosion. Remplacez-la uniquement avec un modèle identique ou
équivalent.
Safety Considerations
Safety Precautions
Personnel properly qualified in the application and use of life safety equipment (“qualified personnel”) shall read this manual carefully before
performing any actions to specify, apply, install, maintain and perform operational tests of AtlasIED systems, and associated products in accordance
with the instructions in this manual. This manual shall be made available to all qualified personnel who operate, test, maintain, or service AtlasIED
systems, and associated products. It is strongly recommend that such personnel read and understand the entire manual.
WARNING: IF SAFETY PRECAUTIONS, INSTALLATION AND TESTING ARE NOT PERFORMED PROPERLY, CONDITIONS COULD EXIST IN
WHICH THE ATLASIED SYSTEM MAY NOT OPERATE, OR MAY OPERATE IMPROPERLY.THIS COULD RESULT IN PROPERTY DAMAGE AND
SERIOUS INJURY OR DEATH TO YOU AND/OR OTHERS.
AVERTISSEMENT: SI LES MESURES DE SECURITE, L’INSTALLATION ET LES ESSAIS NE SONT PAS EFFECTUES CORRECTEMENT, CELA
POURRAIT EMPECHER LE SYSTÈME ATLASIED DE FONCTIONNER, OU DE FONCTIONNER CORRECTEMENT. CELA POURRAIT PROVOQUER
DES DEGATS MATERIELS ET DES BLESSURES GRAVES, OU LA MORT POUR LES AUTRES ET/OU VOUS-MEMES.
It is very important that only responsible, trained personnel are allowed to operate and maintain these systems, and that they use only appropriate
equipment and tools. If a person is not trained, they shall contact the AtlasIED factory for direction on how to operate and maintain an AtlasIED
system.
Unauthorized personnel and equipment must be restricted from the areas of operation.
All operations should be performed carefully, methodically, and without hurrying. Greater effectiveness will be developed by increased familiarity of
personnel with their assignments. During any maintenance operation, if a malfunction occurs or an incorrect indication appears, stop the operation
and determine whether or not it is safe to proceed. Before performing any step in a procedure, be sure that the preceding step has been properly
executed and correct results obtained. Cleanliness and good housekeeping in all installation areas are major factors in effective accident prevention.
Tools and equipment should be maintained in good working order and should always be returned to their proper storage place after usage. Cleaning
agents and other cleaning aids should be removed from the equipment areas immediately upon completing the task at hand.

©2019 Atlas Sound LP. The Atlas “Circle A”, Soundolier, and Atlas Sound are trademarks of Atlas Sound L.P. IED is a Registered Trademark of Innovative Electronic Designs LLC. All rights reserved. All other Trademarks are property of their respective owners. No endorsement is implied. Due to continual product development, specifications are subject to change without notice. ATS005966 RevA 5/19 DOC1227B
AtlasIED.com
TELEPHONE: [phone]
[e-mail]
9701 TAYLORSVILLE ROAD
LOUISVILLE, KENTUCKY 40299 U.S.A.
General Precautions
Changes, modifications, or additions in connection with the AtlasIED system equipment shall not be made without explicit authorization of AtlasIED.
Safety devices found on mechanical, and electrical and electronic equipment are put there for the protection of personnel and equipment. These
devices must be maintained in good working order and operative at all times. Safety devices shall never be removed or bypassed unless specifically
authorized by the AtlasIED factory. Where safety devices have been rendered inoperable by proper and specific authorization, adequate notices shall be
posted to warn personnel of the potential hazard.
Avoid the use of flammable or toxic cleaning fluids, and the use of carbon tetrachloride is prohibited.
Maintenance of the equipment shall be at least what is specified in the AtlasIED manuals and literature, and performed only by qualified personnel.
Whenever operation and maintenance is ongoing, personnel in the equipment areas shall have an effective communication among these areas in order
to protect people if any accident occurs.
Preliminary Precautions
Precautions which are applicable to general electrical or electronic maintenance are as follows:
A. Check yourself. Wear no article that might catch on equipment or that might act as a conductor.
B. Check the working area. The equipment area shall be clean and dry. If possible, stand on a special insulator such as a rubber mat. There should be
ample working space and good lighting.
C. Check the tools. Always use proper tools and check them for their safe condition. Use screwdrivers with plastic handles. Check test equipment
periodically and examine test leads carefully as the slightest break in insulation is dangerous.
D. Check the procedures. Study the entire procedure before taking the first step. Consult the circuit diagram frequently to obtain an understanding of
what is accomplished at each step. Know what is in the equipment and how it differs from others on which you have worked.
E. Be aware that high voltages may be present across terminals that are normally low voltage, due to equipment breakdown. Be careful when
measuring low voltages in equipment containing high voltage circuits.
F. Do not make resistance measurements with power on.
G. Do not work within the equipment without the presence of a person who is capable of rendering aid, and who is familiar with the procedure for
emergency shutdown of the equipment.

©2019 Atlas Sound LP. The Atlas “Circle A”, Soundolier, and Atlas Sound are trademarks of Atlas Sound L.P. IED is a Registered Trademark of Innovative Electronic Designs LLC. All rights reserved. All other Trademarks are property of their respective owners. No endorsement is implied. Due to continual product development, specifications are subject to change without notice. ATS005966 RevA 5/19 DOC1227B
AtlasIED.com
TELEPHONE: [phone]
[e-mail]
9701 TAYLORSVILLE ROAD
LOUISVILLE, KENTUCKY 40299 U.S.A.
Precautions When Measuring High Voltage Potentials
Observe the following precautions when measurements must be performed on circuits with potentials over 48 volts.
A. Do not measure potentials over 48 volts without the presence or assistance of a person who is capable of rendering aid, and who is familiar with
the procedure for emergency shutdown of the equipment.
B. Be sure you are not grounded when you are adjusting equipment or using measuring equipment. Stand on a rubber mat or other insulator if
possible. Be sure the equipment area is clean and dry. In general, use only one hand when servicing live equipment.
C. If a test meter must be held or adjusted while voltage is applied, ground the case of the meter before starting a measurement. Do not touch the
live equipment or personnel working on live equipment while holding the meter. The “common” terminal on some A/C electronic voltmeters is at
ground potential; never connect the “common” terminal to any point above ground potential.
D. High-voltage, high-capacitance capacitors should be discharged before servicing is started.
WARNING! Discharging must be done carefully and judiciously. First ascertain whether there is a built-in bleeder network. If so, wait a
minute or two for the capacitor to discharge through the network. Otherwise, use an external discharge network. This is most important in
the case of high voltage or high capacitance capacitors. If one terminal is connected to ground, connect the discharge network between the other
terminal and ground. If neither terminal of the capacitor is grounded, connect the network across the capacitor terminals. Connecting a short circuit
across the terminals is not recommended. Doing so can produce extremely high currents and a flash which can injure the eyes, vaporize metals, and
cause burns.
AVERTISSEMENT: La décharge doit être faite soigneusement et judicieusement. Vérifier d’abord si il y a un réseau de purgeur incorporé. Si
c’est le cas, attendez une minute ou deux pour que le condensateur se décharge par le réseau. Sinon, utilisez un réseau de décharge externe.
Ceci est très important en cas de haute tension ou des condensateurs à haute capacité. Si un terminal est relié à la terre, connecter le réseau de
décharge entre l’autre terminal et la terre. Si aucun terminal de condensateur est fondé, relier le réseau au terminal du condensateur. La connexion
d’un court-circuit entre les terminaux n’est pas recommandée. Cela peut créé des courants très élevés où des étincelles pourrait blesser les yeux,
fondre les métaux et causer des brûlures.
Precautions When Working on Energized Equipment
When it is necessary to work on energized equipment, think ahead and anticipate every hazard. Never work alone on energized equipment.
Interlock switches are installed on some of the doors and panels to break the power circuits when the enclosure is entered. When it is necessary
to work within such an enclosure on energized equipment, the interlock may be bypassed. Extreme caution should then be exercised, as dangerous
voltages are present within the unit.
AC Power Circuits
Equipment obtaining power from a secondary distribution system should be grounded at all times by means of a third grounding wire on the power
lines. Equipment permanently wired to a secondary distribution system should also be grounded separately by connection to a grounding bus or
ground rod with a sufficiently large conductor to handle the current expected if the secondary source is accidentally shorted to the equipment.
The ground wire should be protected from mechanical damage and periodically inspected for good physical condition.
Personnel should never depend on a switch to remove power from equipment. If the equipment is connected to the secondary distribution system by
means of a power cable, detach the cable from the receptacle before attempting any repairs of removal of chassis.
If the equipment is permanently wired to the secondary distribution system, remove the main fuses or open the power switch. Attach a suitable
warning tag to the switch which will warn personnel not to operate the equipment; only the person who originally attaches the warning tag should be
authorized to remove it.
Resuscitation
Personnel working with or near high voltage should be familiar with modern methods of resuscitation. Such information and training is available from
the Red Cross or local emergency response personnel such as the police and fire department.

©2019 Atlas Sound LP. The Atlas “Circle A”, Soundolier, and Atlas Sound are trademarks of Atlas Sound L.P. IED is a Registered Trademark of Innovative Electronic Designs LLC. All rights reserved. All other Trademarks are property of their respective owners. No endorsement is implied. Due to continual product development, specifications are subject to change without notice. ATS005966 RevA 5/19 DOC1227B
AtlasIED.com
TELEPHONE: [phone]
[e-mail]
9701 TAYLORSVILLE ROAD
LOUISVILLE, KENTUCKY 40299 U.S.A.
Introduction
The 1544ZOP 4x4 Smart Zone Output Processor provides all the network audio routing and zone digital signal processing functions of a DNA2404D
integrated network amplifier unit. This includes Dante network audio input, equalization, level control, and IED’s patented AlwaysHEAR™ smart
ambient analysis automatic level adjustment. The 1544ZOP provides four line-level balanced analog audio outputs for driving external amplifiers or
powered line arrays. The 1544ZOP integrates with AtlasIED’s GLOBALCOM.IP announcement controller. Optionally, the processed zone output audio
may be routed back out over the network as Dante digital audio.
In addition to the four zone outputs, the 1544ZOP has four balanced line-level analog inputs that may be used as automated test inputs associated
with the four zone outputs. Alternately, the analog inputs may be routed out over the network as Dante digital audio for such uses as for background
music or auxiliary audio sources.
The 1544ZOP also provides eight (8) logic inputs. Four of the inputs are standard closure detection and four are supervision capable, which provides
the additional means to detect open or short conditions on the incoming links.
Inputs are provided for connecting up to eight (8) 540S ambient noise sensors (2 sensors for each output channel). This allows the output of each
channel to be automatically adjusted in real time based on the measured ambient noise level in the zone.
Key Features
• Four Balanced Line Level Audio Inputs
• Four Balanced Line Level Audio Outputs
• Four Standard Logic Inputs
• Four Supervised Logic Inputs
• Eight Ambient Sensor Inputs
• Supports Audinate’s Dante™ Digital Network Audio
• Compatible with AtlasIED GLOBALCOM®Systems and 3rd Party Dante™ Devices
• 7-band Parametric EQ and a High-Pass and Low-Pass Filter Per Channel
• Built-In Supervision of External Equipment or Speaker Lines May Be Configured
• Fault Reports and Amplifier Status Available Over Ethernet Using Standard SNMP Protocol
• LED Indicators for Power and Faults, Plus a Fault Relay (Form C)
• Two Inputs for Ambient Noise Sensors for Each Amplifier Output Channel

©2019 Atlas Sound LP. The Atlas “Circle A”, Soundolier, and Atlas Sound are trademarks of Atlas Sound L.P. IED is a Registered Trademark of Innovative Electronic Designs LLC. All rights reserved. All other Trademarks are property of their respective owners. No endorsement is implied. Due to continual product development, specifications are subject to change without notice. ATS005966 RevA 5/19 DOC1227B
AtlasIED.com
TELEPHONE: [phone]
[e-mail]
9701 TAYLORSVILLE ROAD
LOUISVILLE, KENTUCKY 40299 U.S.A.
Front Panel
1. Power Indicator - Illuminates green when unit is has power.
2. Status Indicator - Illuminates yellow when there is a fault in the system.
Rear Panel
1. Ambient Sensors - Up to two sensors (A and B) per channel may be connected. If only one sensor is used per channel, it can go into either the
A or B position for the channel.
2. Standard Logic Inputs - These four inputs only detect open or closed circuit connections, such as from dry contact closures. Wetting voltage for
inputs are supplied internally.
3. Supervisable Logic Inputs - These four inputs can be configured to detect shorts and opens in the connecting line as well as
activated / de-activated with proper external wiring.
4. Redundant Ethernet Connections - RJ-45 jacks for standard 100Base-T Ethernet connections.
5. Fault Relay Connection - Form-C relay connections of Normally-Open, Normally-Closed and Common.
6. Power Input - Input of 12V to 48V with current rating sufficient for 10 Watts of power.
7. Analog Audio Outputs - Balanced audio with level of +6 dBu maximum.
8. Analog Audio Inputs - Balanced audio with level of +6 dBu maximum.
1 2
4
1
5
2 3
6 7 8

©2019 Atlas Sound LP. The Atlas “Circle A”, Soundolier, and Atlas Sound are trademarks of Atlas Sound L.P. IED is a Registered Trademark of Innovative Electronic Designs LLC. All rights reserved. All other Trademarks are property of their respective owners. No endorsement is implied. Due to continual product development, specifications are subject to change without notice. ATS005966 RevA 5/19 DOC1227B
AtlasIED.com
TELEPHONE: [phone]
[e-mail]
9701 TAYLORSVILLE ROAD
LOUISVILLE, KENTUCKY 40299 U.S.A.
Installing the 1544ZOP
Unpacking and Preparing the Unit
Unpack the unit from its shipping carton and identify any accompanying components that may have been included. The unit comes with a PA702-RMK
kit of rack ears, blank spacer and joining clips for easy mounting into a 19" rack. The components of the rack mount kit are shown in the figure below.
The unit may be mounted either singly in a 19" rack using blank spacer and rack “ears”. The unit can also be combined with a second 1544ZOP or
compatible half-rack-unit device to mount two across in a 19" rack. See the instructions that are included with the PA702-RMK kit for specifics on how
to prepare units for rack mounting using the parts in the kit.
Installing the Unit into a Rack
The one rack unit assembly prepared above should be mounted into a 19" rack using the four mounting holes on the rack “ears”.
Blank Spacer
Rack Ears
Spacer / Ear
Screws and Nuts
Joining ClipsJoining Screws
