Atlas Metal WB SERIES User manual

Subsidiary of Mercury Aircraft, Inc.
1135 N.W. 159th DR., MIAMI, FL 33169
PHONE [phone], FAX [phone], E-mail: [e-mail]
PARTS LIST ICE CHEST & WATER STATIONS
WB & WSB SERIES
WB SERIES WSB SERIES
13
WB-19 SHOWN 4
12
7
12
11
9
8
WSB-15 SHOWN
6
5
12
14
13
14
ITEM NUMBE
R
PART NUMBE
R
DESCRIPTION
1 S81854-0 Lid Assembly
2 6043-0 Lid Handle
3 4043-1 Handle Screws (Not Shown)
4 7020-0 Nylon Spacer
5 3020-1 Faucet
6 S81806-0 Strainer
7 3018-0 1/2" Plastic Drain
8 47-102 1/2" Washer
9 2050-2 1/2" Nut
10 3019-0 1" Plastic Drain (Not Shown)
11 3100-0 1" Drain Washer
12 4200-0 1" Drain Nut
13 7002-0+Model # Vinyl Bead Gasket
14 S81809-0 Plastic Hinge
15 7030-0 Plastic Underlid (Not Shown)
16 3020-2 Picher and glass filler (Not Shown)

ICE CHEST & WATER STATIONS
WB & WSB SERIES
--------------------------------------------------------------------------------------------------------------------------------------------------------------------
INSTALLATION
Provide the correct counter cut-out opening (see chart below) and drop in. The vinyl gasket assures
complete seating. A non-toxic silicone seal may be used between the gasket and counter top (not
required).
MODEL NUMBER CUT-OUT SIZE
WB-15 13 1/2 X 17 1/4
WB-19 17 1/4 X 22 1/4
WSB-15 13 1/2 X 25 1/4
WSB-19 17 1/4 X 22 1/4
NOTE: Units are supplied with a 1” I.P.S. Drain to be connected for draining and cleaning purposes.
--------------------------------------------------------------------------------------------------------------------------------------------------------------------
OPERATION
The unit is ready to operate and should be level for draining purposes.
--------------------------------------------------------------------------------------------------------------------------------------------------------------------
MAINTENANCE
NEVER CLEAN PANS WITH A CHLORIDE BASED PRODUCT. CHLORIDES OR IMPROPER
CLEANING COULD SCAR, MARK AND/OR CORRODE PANS. DO NOT USE STEEL WOOL OR
ABRASIVE PRODUCTS. TO CLEAN USE SOAPY WARM WATER, RINSE THOROUGHLY TO
REMOVE ALL RESIDUES. FAILURE TO MEET THESE CONDITIONS WILL VOID
WARRANTY.
