Atlas HMA-7000-TC User manual

Commercial
Air Purifier
Model HMA-7000-TC
Air Purification Unit
User Guide
“Knock out
odors at their source”

CAUTION
RISK OF ELECTRICAL SHOCK
DO NOT OPEN
ATTENTION
Caution: TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT
REMOVE COVER. NO USER SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVCE PERSONNEL.
Please read all of the information provided in this user’s
guide before operating your new air unit.
WARNING
This air unit is not a medical device. Do not
stop or alter any medical therapy programs or
medications without the advice of your physician.
Excessive ozone concentrations may cause mucous
membrane or respiratory irritation.
This “bolt of lightning” indicates that uninsulated
material within your unit may cause an electrical
shock. For the safety of everyone, do not remove
product covering.
This “exclamation point” calls attention to a feature
for which you should read the enclosed literature
carefully to prevent operating and maintenance
problems.

CLEANING & MAINTENANCE
When the purifier no longer produces enough ozone to be effective, the ozone plates
should be cleaned. A good rule of thumb is every three months. Some environments
can cause ozone output to be reduced in shorter time but other environments may
take longer.
To clean a plate, first turn the unit off and unplug from outlet. Next remove the plates
from back of unit. Pull plates firmly to remove from slot. With plate firmly supported
in the hand or on a flat surface, wash with warm soapy water or a grease cutting
detergent and scrub with a stiff brush. A spray liquid detergent with chlorine may be
used if necessary. Be careful not to drop the plate. Clean the metal screen and the
ceramic tile. Rinse plate in hot water and dry completely before reinstalling. If avail-
able, you may use a hair dryer to dry the plate. Reinstall plate, making sure it is flush
with the back of the unit.
TIMER
The Commercial Purifier incorporates a timer for your convenience and safety. The timer
can be set for up to a total of 60 minutes. When you turn the dial to the right or clock-
wise you are activating the timer.
There is an override that can make the unit run indefinitely. To run the unit for a longer
period of time, turn the control knob counterclockwise to the “Hold” position. The
Industrial Cleaner is designed to operate in unoccupied areas only!
TROUBLESHOOTING
If you suspect a problem with your unit check the following:
· Unit is plugged in properly and turned on.
· Wall outlet is active.
· Ceramic plates are clean and dry.
· Plate alignment is correct, making sure plates are flush with back of unit.
· Fuse is installed properly and in good condition (to replace fuse, rotate fuse
holder counterclockwise to unscrew, remove old fuse, replace with spare). Fuse is
1 amp (1.25 inch).
· It’s important that the unit be properly grounded to avoid potential
shock.
If the fan is still not operating or no buzzing sound is detected when operating, call
the Service/Warranty Service number.
Caution: No attempt should be made to remove the top panel of the unit, as there
are no user serviceable parts. Opening the unit will void all warranties.

OPERATION
1, The power cord must be plugged into the three hole socket with a grounded on, and the machine into standby
mode, the backlight is not bright in the standby mode, LCD display in standby
2, ON/OFF button: standby mode, press the button ON, the machine is in running state, the LCD display
running state, backlight light; Running state, the button to turn it off
3, AUTO button: button switch on, machine intermittent
periodically according to system Settings "on - off - on - off -" cycle to run automatically, lit backlight, LCD
display to run automatically or automatically stop state, the time countdown, time is zero run or stop the
conversion
1．There are three time periods P1, P2 or P3 can choose, factory Settings for the P1
2．Press the AUTO key can select P1 or P2 or P3 cycle, and save
3．Press SET key can SET running time P1 or P2 or P3
4．factory settings：
P1 running time 10 minutes, stop time for 20 minutes
P2 running time20 minutes, stop time for 20 minutes
P3 running time40 minutes, stop time for 20 minutes
4，Press on the TIMER button: buttons, the machine according to the system setting into disposable timing
shutdown operation state, lit backlight, LCD display timing status, running time countdown, stop running time is
zero.
factory settings is one hour
Press SET button to SET the timing, time can be saved
5, SET key: according to national health enter the SET state, in order to safety, when SET, the ozone function is
shut down, stop is SET to 10 seconds after SET up, automatic machine back to AUTO or TIMER state, not
AUTO or the TIMER mode press SET key is invalid.
5.1 Under the condition AUTO
1) the first step: press SET button to enter operation cycle "running time" Settings, LCD display session P1, P2
and P3), "SET PRO. ON" the "time" flashing, press the UP or DOWN key can be SET UP "running time";
2) step 2: press the SET button to enter operation cycle "stop time" Settings, LCD display session P1, P2 and
P3), "SET PRO. OFF" "time" flashing, press the UP or DOWN key can be SET to "stop time";
3) repeat step 1, step 2, to get to the next session "running time", "stop time" Settings;
5.2 Under the condition TIMER
Time press SET button to enter the time setting, the LCD shows the TIMER OFF UNTIL 88:88 time flashing
when setting time, press the UP or DOWN to SET the time required to;
5.3 Don't press the UP or DOWN key to 10 seconds. Back in the running state
6，On the UP button: adjust the key, the SET mode, the time flashing, buttons can adjust timing time increased,
the step length for 5 minutes, long press the quick Settings;
7，The DOWN button: the regulating button, the SET mode, the time flashing,buttons can adjust timing time
reduced; Long press the quick setup;

Read ALL instructions carefully
before using this product.
FOR YOUR RECORDS
Please record the model and serial number below, for easy refer-
ence, in case of loss or theft. These numbers are located on the back
panel of your air purification unit. Space is also provided for other
relevant information.
Model Number ________________________________________
Serial Number _________________________________________
Date of Purchase _______________________________________
Purchased From________________________________________

Operating the Commercial Purifier
(Front View)
PART
Function Keys
LCD
Remote control
FUNCTION
Control the air purifier by hand
Display working status, time; with blue
backlight optional.
To control the working status of air purifier
This unit must be provided with an elec-
trical ground at all times!

(Back View)
Pre-filter
Fuse Holder
Power Cord
Stop the dust into the unit
Houses removable fuse.
(Spare fuse included, 1 amp, 1.25 inch)
120 Volt grounded cord (unless otherwise
Specified). DO NOT bypass ground.
1, Dustproof, set filter cotton into the tuyere, can be simple placed and replaced
2, Air duct: drum wind type air duct, ozone tablets placed inside, easy
installation and replacement, ozone corrosion prevention;
3, Directions for use: disinfection with ozone machine, used in unmanned space,
only, because of the large ozone generates required to be used family must
reduce ozone opens time,
1) Below 100 square meters of space, it is recommended to use P1 of the
AUTO operation mode;
2) 100-250 square meters space, it is recommended to use AUTO P2 operation3
) 250-400 square meters space, it is recommended to use the P3 AUTO run
mode;
4) More than 400 square meters space, it is recommended to use ON (HOLD
ON) operation mode;
5) Disinfection with ozone machine, only used in unmanned space, circulation
function, when using, because of the large ozone generates homes must
reduce ozone open time, suggest opening time for 1-2 minutes advisable.
PART FUNCTION
OTHER FUTURES
