INFORMACAST® IP COMPLIANT LOUDSPEAKER SYSTEM
POWERED BY CISCO®POE NETWORK SWITCHES I8S
FEATURES
• Use with Berbee InformaCast®software, Cisco®POE networks
& Cisco®IP Telephones to create extremely versatile paging and
messaging systems
• Highly efficient 10oz dual cone loudspeaker system provides 94dB
average SPL @ 1W/1M and is capable of 103dB @ 1 meter via the
rated power of the internal IP addressable amplifier
• 105˚ dispersion in the 2kHz octave band (-6dB)
• Wide frequency response of 86Hz to 8kHz (-3dB) is perfect for speech
and general messaging playback
APPLICATIONS
The perfect choice for education, military/government, and large scale
corporate applications, Berbee’s InformaCast IP Broadcasting Solution
revolutionizes communication, clock/bell and message playback
functionality. It provides the capability to simultaneously send a multicast
audio stream and text messages to any combination of Cisco IP phones,
Atlas Sound IP speakers, and PCs. With the push of a single button on
the phone or a single click from a PC, a user can send a live, recorded,
or scheduled broadcast to one or more paging groups. With InformaCast
compliant loudspeaker products from Atlas Sound, system designers
and integrators will have the ability to deploy extremely large scale and
complex paging systems over new or existing Cisco networks with the
convenience of centralized administration by IT personnel.
Extreme cost savings can also be realized from the elimination of
separate “stand alone” paging systems when InformaCast is utilized in
education applications in conjunction with the model I8S speaker baffle
system.
GENERAL DESCRIPTION
Model I8S from Atlas Sound consists of a factory assembled loudspeaker/
baffle with PCB amp/control board securely mounted to the rear of the
baffle via concealed weld studs. The amp/control board is capable of
producing 9 Watts RMS into the 8 Ohm loudspeaker with 9VDC minimum
power provided by Cisco IEEE 802.3AF compliant POE switches.
(local 12-18VDC PSUs may also be used instead of POE switches).
Interconnection is via a board mounted female RJ-45 connector. The
industry standard C10A loudspeaker used in the I8S is a dual cone 8”
(205mm) loudspeaker with a 10oz (260g) ceramic magnet. It includes a
curvelinear paper cone for lower harmonic distortion. The loudspeaker
is also equipped with a full 1” (25mm) diameter copper voice coil with
aluminum former for better heat dissipation. The 18 gauge construction
of the metal baffle provides security and durability in commercial
applications. The baffle is finished in neutral white electrostatic powder
coat and is packaged with all necessary mounting screws.
ENCLOSURE IS NOT INCLUDED. Available optional enclosures:
I8S
(Back View)
11.50
11.50
4.07
4.21
11.50
11.50
4.07
4.21
I8S
(3/4 View)
11.50
11.50
4.07
4.21
MODEL DESCRIPTION
SEA-I8S Surface mount, angled enclosure for I8S, neutral white finish
SEST-I8S Surface mount, straight enclosure for I8S, neutral white finish
FEST-I8S Flush mount straight enclosure for I8S, reclaimed powder coat
finish
I8S
(Side View)

Specifications subject to change without notice
1601 JACK MCKAY BLVD. / ENNIS, TEXAS 75119 U.S.A.
TELEPHONE: [phone] /FAX [phone] AtlasSound.com
ARCHITECT AND ENGINEER SPECIFICATIONS
Unit shall be Atlas Sound Model I8S. The loudspeaker system shall
include factory assembled loudspeaker, IP addressable PCB amplifier/
control and metal baffle.The loudspeaker shall have a 10oz (260g)
ceramic magnet and a seamless cone. Frequency response range
shall be 86Hz to 8kHz (-3dB). Sensitivity shall be 94dB average. Voice
coil former shall be black anodized aluminum to help dissipate heat,
have an impedance of 8 Ohms and a diameter of 1” (25mm). The IP
addressable PCB amplifier/control shall be mounted to the rear of the
loudspeaker baffle via concealed weld studs. The amplifier / control
PCB shall be capable of producing 9 Watts RMS with a minimum
of 9VDC power provided either locally or via Cisco IEEE 802.3AF
compliant POE switches. Interconnect shall be via female RJ-45
connector mounted to the PCB. All control functionality of the PCB
amplifier shall be determined via software. The metal loudspeaker baffle
overall dimensions shall be 11.5” (292mm) wide by 11.5” (292mm)
tall. Baffle construction shall be of 18 gauge cold rolled steel. Finish
shall be Atlas Sound neutral white electrostatic powder coat. Optional
enclosures shall include models SEA-I8S surface mount angled
enclosure for I8S - neutral white finish, SEST-I8S surface mount straight
enclosure for I8S - neutral white finish and FEST-I8S flush mount
straight enclosure for I8S - reclaimed powder coat finish.
© 2006 Atlas Sound LP Printed in U.S.A. 01106 ATS002380 RevB 11/06 SL1-2086
Loudspeaker Specifications
Speaker Size 8" (203mm)
Power Handling 15W
Sensitivity (SPL @ 1W/1M) 94dB
Frequencey Response186Hz to 8kHz
Dispersion252.5˚
Cone Material Treated Paper
Surround Material & Dampening Dampened self-storage
Flux Density 10,600 Gauss, 1.06 Tesla
Magnet Weight Nominal, 10oz (260g)
Basket Material Stamped, Plated 20 ga. CRS
Voice Coil Diameter 1" (25mm)
Voice Coil Material Cooper
Voice Coil Former Material Black Anodized Aluminum
Voice Coil Winding Width 0.225 (6mm)
Top Plate Thickness .239 (96mm)
Weight 32oz (908g)
Diameter &Depth 8.125 (206mm) Dia. & 2.875" (73mm) D
Mounting Dimensions 7.625" (194mm) Bolt Circle
1. Measured in reccomended enclosure 2. 3dB down point, 2 kHz octave band
Microphone Specification
Microphone Type Omni directional subminiature electret Condenser
Diameter 1/4" (6mm)
Baffle Specifications
Baffle material 18 gauge CRS
Overall Width x Height 11.5" (292mm) Square
Depth - Front of baffle to rear of speaker 4.21" (107mm)
Depth - Rear of baffle to rear of speaker 4.07" (103mm)
Color White
Amplifier/Controller Specifications
Power Rating 9W RMS into 8Ωload with 9VDC in
Inputs RJ-45 female on PCB accessable from rear of baffle
Outputs 2 wire main ± terminated to loudspeaker
Power Source Cisco IEEE 802.3AF compliant POE network switches
local 12-18VDC PSU
Dimensions 4.25" (108mm) by 7.25" (184mm)
Mounting 4 holes to weld studs on baffle (factory assembled)
Network Control Berbee Informacast on multicast enabled networks
