Atleisure 3PC Swivel Chat Set FRN-106180 Installation guide

3PC Swivel Chat Set
Assembly & Care Instructions
IMPORTANT : RETAIN FOR FUTURE REFERENCE
READ CAREFULLY
Item: FRN-106180
ATLeisure, LLC
Toll Free: 1-855-880-7205 (English is offered)
8am - 5pm, Monday through Friday, Eastern Standard Time
Email: customerser[email protected] or visit our website at www.atleisure.com
DO NOT RETURN TO STORE
For indoor/outdoor domestic use only. Not for commercial use.
Designed in USA
Made in China
For assistance with assembly, parts, or customer service, please contact:

2
Contents
Package Contents ...........................2-3
Assembly and Use...........................4-6
Care and Maintenance......................... 6
Warnings and Cautions ........................ 7
Warranty ................................... 7
Before assembling make sure all parts are present. If any part is missing or damaged,
do not attempt to assemble the product.
Package Contents
Table Parts
Item Letter/No. Sticker
Color
Quantity
Table Top
A
Red
1
Leg
B
Green
4
Leg Brace
C
Blue
1
Long Bolt
Short Bolt
Washer
Hex Key
(D) Long
Bolt
(E) Short
Bolt
(F) Washer
(G) Hex
Key
Black
1 Hardware
Package
Includes:
8 Long Bolts
(15mm)
4 Short Bolts
(10mm)
12 Washers
1 Hex Key

3
Package Contents (cont’d)
Chair Parts
Item Letter/No. Sticker
Color
Quantity
Seat & Back
A
Purple
Swivel Pole
B
Pink
Base
C
Tan
Seat Cushion
D Orange
Back Cushion
E
Teal
Bolt (M8x40mm)
Steel Plate
Thin Washer
Thick Washer
Screw Nut
Wrench
(F) Bolt
(G) Steel
Plate
(H) Thin
Washer
(I) Thick
Washer
(J) Screw
Nut
(K) Wrench
Gray
Hardware
Package
Includes:
4 Bolts (40mm)
2 Steel Plates
4 Thin Washers
4 Thick Washers
4 Screw Nuts
2 Wrenches
2 Hardware
Packages Total
2
2
2
2
2

4
Assembly and Use
Step 2: Turn the Seat & Back (A) right side up and insert it into the Base (C).
Step 3: Place the chair on a flat surface and put the Seat and Back cushions
(D&E) on. The chair is now ready for use.
C
E
D
Chair:
A
B
J
I
H
G
F
Step 1:Turn the Seat & Back (A) upside down. Align the main piece of the
Swivel Pole (B) with the hole on the bottom of the seat. Insert the Bolt (F)
through the Steel Plate (G) and the hole on the bar of seat. Place a Thin Washer
(H) over the holes of the steel piece of Swivel Pole (B). Then place the Thick
Washer (I) over the Thin Washer (H). Use the Wrench (K) to tighten the Screw
Nut (J) and Bolt (F) being careful not to over tighten.
K

5
Assembly and Use (cont’d)
Step 1: Align the Leg Brace (C) holes with corresponding table Leg (B) holes.
Place Washers (H) over holes and insert Short Bolts (E) to attach frame to the
table Legs (B). Use the Hex Key (G) to tighten bolts, being careful not to over
tighten.
E
F
C
B
Table:
D
A
F
Step 2: Place the Table Top (A) upside down on a soft, flat surface. Align the
table Leg (B) holes with corresponding Table Top (A) holes. Place the Washers
(F) over the Table Top holes and insert Long Bolts (D). Use the Hex Key (G) to
tighten the Long Bolts (D), being careful not to over tighten.
Step 3: Finally check that all bolts are tightened.

Step 4:
Step 5:
6
Care and Maintenance
• Use mild soap and warm water to clean. Rinse with clean water and dry
thoroughly.
• Be sure to drain any water accumulated inside the frames. To thoroughly drain,
remove leveling foot and tilt frames to remove all water. Water allowed to
accumulate inside the frames and then exposed to sub-freezing temperatures
can cause damage to frame tubing. Such damage is not covered under
warranty.
Assembly and Use (cont’d)
Turn the table right side up and place it on a at surface. Please adjust the
plastic leveling feet if the four legs are not level.The table is now ready for use.
Arrange all pieces and enjoy!

7
Warnings and Cautions
ATLeisure, LLC
1040 Boulevard SE, Suite B
Atlanta, Georgia 30312, USA
Customer Service Toll Free 1-855-880-7205
8am - 5pm Eastern Time, Monday through Friday
www.atleisure.com
Warranty
90 DAY WARRANTY
This product is covered under a manufacturer’s 90 day warranty from date of
purchase against defects in materials and workmanship. This warranty does
not cover damage due to neglect, abuse or weather related damage. For full
warranty disclosure, email us at customerser[email protected], call toll
free at 1-855-880-7205 or send mail to: 1040 Boulevard SE Ste. B, Atlanta GA
30312
NOT COVERED UNDER WARRANTY
This Warranty excludes the following: general frame rusting; glass breakage; acts of
nature (i.e. wind, fire, or freeze); damage caused by improper assembly, caused by
improper assembly, accident, disaster, misuse, abuse, negligence and commercial
use; discoloration or fading of the finish or fabric as a result of exposure to the
elements.
HOW TO FILE A CLAIM
If you are within your warranty you must have your receipt and pictures of your
information to send to ATLeisure at customerser[email protected], or send
by mail to 1040 Boulevard SE Ste. B, Atlanta GA 30312. This warranty gives
you specific legal rights, and you may also have other rights which vary from
state to state.
90 days.
