Atlona AT-UHD-EX-100CE-RX-PSE User manual

1
Installation Guide
AT-UHD-EX-100CE-RX-PSE
4K/UHD Power Sourcing over 100 M
HDBaseT Receiver with Ethernet, Control, and PoE
AT-UHD-EX-100CE-RX-PSE
The Atlona AT-UHD-EX-100CE-RX-PSE is a 4K/UHD HDMI over 100M HDBaseT receiver for
AV signals up to 330 feet (100 meters) over category cable with Ethernet pass-through, RS-
232, CEC, and Power over Ethernet. It receives video signals up to 4K/UHD @ 60 Hz with 4:2:0
chroma subsampling, plus embedded multi-channel audio. The AT-UHD-EX-100CE-RX-PSE is
HDCP 2.2 compliant and supports EDID communication. It is ideal for use with the AT-UHD-EX-
100CE-TX-PD HDBaseT transmitter, or an HDVS-200 Series HDBaseT switcher for extending
4K signals to a display. This receiver features a quarter rack width metal enclosure, with rear
panel I/O ports for uncluttered wire management. The AT-UHD-EX-100CE-RX-PSE is externally
powered by the included power supply, and provides Power over Ethernet for the AT-UHD-EX-
100CE-TX-PD, an HDVS-200 HDBaseT switcher, or other PoE-compatible HDBaseT transmitter.
IMPORTANT: Visit http://www.atlona.com/product/AT-UHD-EX-100CE-RX-PSE for the
latest rmware updates and Installation Guide.
Package Contents
1 x AT-UHD-EX-100CE-RX-PSE
1 x 3-pin captive screw connector
2 x Wall/table mount ears
4 x Screws for wall/mount ears
1 x 48V DC power supply
1 x Installation Guide

2
Installation Guide
AT-UHD-EX-100CE-RX-PSE
Panel Descriptions
1 LAN
Connect an Ethernet cable from this port,
to a display (sink) device for IP pass-
through control.
2 FW
Connect a mini-USB cable from this port
to update the rmware. Refer to Updating
the Firmware (page 7) for more
information.
3 POWER
This LED indicator glows solid green
when the unit is powered. Refer to
LED Indicators (page 6) for more
information.
4 LINK
This LED indicator glows solid amber
when a solid link is established between
the transmitter and receiver. Refer to
LED Indicators (page 6) for more
information.
5 DC 48V
Connect the included 48V DC power
supply to this power receptacle.
6 RS-232
Connect the included 3-pin captive screw
block to this receptacle. Refer to RS-232
(page 3) for more information.
7 HDBaseT IN
Connect a category cable from this
port to the HDBaseT OUT port on the
transmitter.
8 HDMI OUT
Connect an HDMI cable from this port to a
UHD/HD display.
1
7
2 3
65
4
8
Front
Rear

3
Installation Guide
AT-UHD-EX-100CE-RX-PSE
RS-232
The AT-UHD-EX-100CE-RX-PSE provides pass-through transport of RS-232 over HDBaseT,
which allows communication between a control system and an RS-232. This step is optional.
1. Use wire strippers to remove a portion of the cable jacket on the RS-232 cable.
2. Remove at least 3/16” (5 mm) from the insulation of the RX, TX, and GND wires for the RS-
232 connection.
3. Insert the TX, RX, and GND wires into correct terminal using one of the included 3-pin
captive screw connectors.
4. Tighten the captive screws to secure the wires in place. Do not over-tighten or use high-
torque devices to prevent damage to the connector block.
NOTE: Typical DE-9 connectors use pin 2 for TX, pin 3 for RX, and pin 5 for
ground. On some devices functions of pins 2 and 3 are reversed.
GND
AT-UHD-EX-100CE-RX-PSE RS-232 (DCE) Device
RX TX GND RX TX

4
Installation Guide
AT-UHD-EX-100CE-RX-PSE
The AT-UHD-EX-100CE-RX-PSE includes two mounting brackets and two mounting screws,
which can be used to attach the units to any at surface.
1. Remove the two top screws from each side of the enclosure.
2. Position one of the mounting brackets, as shown below, aligning the holes on the side of the
enclosure with one set of holes on the mounting bracket.
3. Use the enclosure screws to secure the mounting bracket to the enclosure.
4. Repeat the above steps to attach the second mounting bracket to the opposite side of the
unit.
Mounting Instructions
4. Mount the unit using the oval-shaped holes, on each mounting bracket. If using a drywall
surface, a #6 drywall screw is recommended.
NOTE: Mounting brackets can also be inverted to mount the unit under a table
or other at surface.

5
Installation Guide
AT-UHD-EX-100CE-RX-PSE
Installation
Refer to the tables below for recommended cabling when using Altona products with HDBaseT.
The green bars indicate the signal quality when using each type of cable. Higher-quality signals
are represented by more bars.
Cable Recommendation Guidelines
Core Shielding CAT5e CAT6 CAT6a CAT7
Solid UTP (unshielded) N/A
STP (shielded)
*Atlona recommends TIA/EIA 568-B termination for optimal performance.
Cable* Max. Distance @ 4K Max. Distance @ 1080p
CAT5e / CAT6 230 feet (70 meters) 330 feet (100 meters)
CAT6a / CAT7 330 feet (100 meters) 330 feet (100 meters)
IMPORTANT: Stranded or patch cables are not recommended due to
performance issues.
1. Connect a UHD/HD display to the HDMI OUT port.
2. Connect a category cable, from the HDBaseT IN port on the receiver, to the HDBaseT OUT
port on the transmitter.
3. OPTIONAL: Connect an Ethernet cable from the LAN port, on the receiver, to the display
(sink) device. This cable provides IP pass-through control from a control system to the
display (sink) device connected to the receiver.
4. OPTIONAL: Connect the RS-232 device to the RS-232 port on the receiver. Refer to RS-
232 (page 3) for more information.
5. Connect the included 48 V DC power supply to the DC 48V power receptacle.
6. Connect the power supply to an available AC outlet.

6
Installation Guide
AT-UHD-EX-100CE-RX-PSE
LINK Description
Solid amber The link integrity between the transmitter and the receiver is
good.
Blinking amber Poor signal integrity between the transmitter and the receiver.
• Make sure that the Ethernet connection between the
HDBaseT IN port on the transmitter and the HDBaseT
OUT port on the receiver is secure.
• The Ethernet cable may be compromised. Try using a
dierent Ethernet cable. Make sure that the cable is solid
core. Stranded or patch cables are not recommended.
O The link integrity between the transmitter and the receiver is
compromised.
• Check the Ethernet cable between the HDBaseT IN port
on the transmitter and the HDBaseT OUT port on the
receiver.
POWER Description
Solid green Unit is powered.
O Unit is not powered.
• Verify that the locking connector is securely fastened to the
power receptacle.
• Make sure that the power supply is connected to an active
AC outlet.
LED Indicators
The POWER and LINK LED indicator on the transmitter and receiver unit provides basic
information on the current status of the AT-UHD-EX-100CE-RX-PSE.

7
Installation Guide
AT-UHD-EX-100CE-RX-PSE
Updating the Firmware
Requirements:
• New rmware - Downloaded from atlona.com
• USB to mini-USB cable
• Computer running Microsoft Windows.
1. Connect a USB to mini-USB cable from the FW port on the unit to an available USB port on
the computer.
NOTE: The AT-UHD-EX Series can be powered over USB during the rmware
update procedure. Therefore, connection of an external power supply (or
HDBaseT) is not required.
2. Unzip the contents of the rmware .zip le to a location on the computer and locate the
UpdateVS100RX_[version].bat le.
3. Double-click the batch le to execute it.
4. After the update procedure is complete, the software will go through the verication process
and then display the following message:
Verication succeeded!!! :-)
IMPORTANT: Do not disconnect the USB cable during the update process.

8
Installation Guide
AT-UHD-EX-100CE-RX-PSE
Version 1
