Atlona AT-HAD-V31 User manual

AtlonA
3x1 HDMI Auto Switch with 6ft HDMI
Cable Pigtail
AT-HAD-V31
User Manual

TABLE OF CONTENTS
1. Introduction .................................................. 1
2. Specications .................................................. 1
3. Package Contents .................................................. 1
4. Panel Descriptions .................................................. 1
5. Connection and Operation .................................................. 1
6. Safety Information .................................................. 4
7. Warranty .................................................. 5

1 INTRODUCTION
1
Atlona’s AT-HAD-V13 is a high performance HDMI Switcher. It can easily switch between three
sources to one display up to 6ft. It not only has the key-press-switching function, but also has
an intelligent function. With one xed 6ft HDMI cable (pigtail) this converter not only reduces
cost but also saves time for consumers.
This kind of HDMI Switcher routes high denition video (in multiple resolutions up to 1080p)
and digital audio from any one of the three sources to display units. All inputs accommodate the
connections of the high denition video sources simultaneously; compatible with HD-DVD,SKY-
STB, PS3, Xbox36etc. The output sends the high denition audio/video signals to a high deni-
tion display.
1.1 INTELLIGENT FUNCTION
1) Once the source device is turned on or plugged in (should stay on “power-on” mode), the
switcher will automatically select this source.
2) Once the source device is turned off or unplugged, the switcher will select the next power-on
source automatically, depending on the sequence.
Note: When the source devises are on stand-by mode, power supply should be turned off,
otherwise this switcher will not meet intelligent function.
1.2 FEATURES
Atlona’s 3X1 HDMI Switcher has many features that enable it to perform in a superior manner.
Among those features:
• Support with HDMI1.3b
• Support 12-bit Deep Color.
• 24K gold plated connector
• 6ft Length HDMI Length
• High performance up to 2.5Gbps
• Multifunctional on switching : intelligent or mechanical
• Maintains high resolution video, beautifully sharp HDTV resolutions up to 1080p, 2k, and
computer resolutions up to 1920 x 1200 are easily achieved
• Support uncompressed audio such as LPCM
• Support compressed audio such as DTS Digital, Dolby Digital (including DTS-HD and Dolby
True HD)
• HDMI pass-through
• HDCP pass-through

2 SPECIFICATIONS
3 Package Contents
2
Signal Inputs/Output
Input Video Signal 0.5-1.0 volts p-p
Input DDC Signal 5 volts p-p (TTL)
Maximum Single Link Range 1920X1200, 1080P
Output Video HDMI 1.3b + HDCP 1.0/1.1
Video format supported
DTV/HDTV 480i/576i/480p/576p/720p/1080i/1080P
Digital Signal I/O
HDMI Compliance HDMI 1.3b
Operating Frequency
Video Amplier Bandwidth 2.5Gpbs/250MHz
Vertical Frequency Range 50/60Hz
Resolutions(HDTV)
Interlaced(50&60Hz) 480i,576i,1080i
Progressive(50&60Hz) 480p,576p,720p,1080p
Warranty
Limited Warranty 1 Year Parts and Labor
Environmental
Operating Temperature 0oC to +70oC
Operating Humidity 10% to 85 % RH (no condensation)
Storage Temperature -10oC to +80oC
Storage Humidity
Power Requirement 5% to 90 % RH (no condensation)
External Power Supply No power needed
Note: Specications are subject to change without notice.
Before attempting to use this unit, please check the packaging and make sure the following
items are contained in the shipping carton:
• Main unit
• User’s Manual

1) Connect the HDMI input sources into Atlona’s 3X1 switcher. (Input cables are optional)
*Please refer to connection diagram section.
2) Connect the xed HDMI cable (pigtail) to display.
3) Press the “select” button to select input sources.
Attention: Insert / Extract cable gently.
5.1 CONNECTION DIAGRAM
3
4 PANEL DESCRIPTIONS
5 CONNECTION AND OPERATION
2
Input 1Input 2Input 3
Select
1 2 3
BLU RAY
HD Camcorder
HDTV
PS3
3x1 HDMI Auto Switch
6Ft HDMI Cable

4
SAFETY INFORMATION
Safeguards
To reduce the risk of electric shock, do not
expose this product to rain or moisture.
If the wall plug does not t into your local
power socket, hire an electrician to replace
your obsolete socket.
Do not modify the wall plug.
Doing so will void the warranty and safety
features.
This equipment should be installed near
the socket outlet and the device should
be easily accessible in case it requires
disconnection.
Precautions
FCC Regulations state that any
unauthorized changes or modications to
this equipment not expressly approved by
the manufacturer could void the
user’s authority to operate this
equipment.
Operate this product using only the
included external power supply. Use of
other power supplies could impair
performance, damage the product or cause
res.
In the event of an electrostatic discharge,
this device may automatically turn off. If this
occurs, unplug the device, and plug it back
in.
Protect and route power cords so they will
not be stepped on or pinched by anything
placed on or against them. Be especially
careful of plug-ins, or cord exit points from
this product.
Avoid excessive humidity, sudden
temperature changes or temperature
extremes.
Keep this product away from wet locations
such as bathtubs, sinks, laundries, wet
basements and swimming pools.
Use only accessories recommended by
ATLONA to avoid re, shock or other
hazards.
Unplug the product before cleaning. Use
a damp cloth for cleaning. Do not use
cleaning uid or aerosols, which could
enter the unit and cause damage, re or
electrical shock. Some substances may
also mar the nish of the product.
Never open or remove unit panels or make
any adjustments not described in this
manual. Attempting to do so could expose
you to dangerous electrical shock or other
hazards. It may also cause damage to your
AT-HAD-V31. Opening the product will void
the warranty.
Do not attempt to service the unit. Instead
disconnect it and contact your Authorized
ATLONA reseller or contact ATLONA
directly.

4
WARRANTY
5
1. LIMITED WARRANTY
