Atlona AT-UHD-SW-5000ED User manual

4K/UHD 5 Input HDMI Switcher
with Two HDBaseT Inputs and
Mirrored HDMI/HDBaseT Outputs
atlona.com Toll free: 1-877-536-3976
Local: 1-408-962-0515
User Manual
AT-UHD-SW-5000ED
Please check http://www.atlona.
com/product/AT-UHD-SW-5000ED
for the most recent firmware
update or manual.

2
atlona.com Toll free: 1-877-536-3976
Local: 1-408-962-0515
Table of Contents
1. Introduction ................................................................................................... 3
2. Package Contents ................................................................................................... 3
3. Features ................................................................................................... 3
4. Category Cable ................................................................................................... 4
4. Panel Descriptions
a. Front ................................................................................................... 5
b. Back ................................................................................................... 5
5. Remote Control ................................................................................................... 5
6. Captive Screw ................................................................................................... 6
7. Audio ................................................................................................... 7
8. TCP/IP ................................................................................................... 8-16
9. RS-232 & TCP/IP
a. Terminal ................................................................................................... 17
b. Connection ................................................................................................... 17
c. Commands ................................................................................................... 18-19
d. IP Commands ................................................................................................... 19
e. Baud Rate ................................................................................................... 20
f. 3rd Party Control ................................................................................................... 20
10. Connection Diagram ................................................................................................... 20-21
11. Specifications ................................................................................................... 22
12. Safety ................................................................................................... 23
13. Warranty ................................................................................................... 24-25
14. Registration ................................................................................................... 25

3
atlona.com Toll free: 1-877-536-3976
Local: 1-408-962-0515
• 1 x UHD-SW-5000ED
• 1 x 48V DC power supply (AT-PW48V0.83A-CAPT)
• 4 x Female captive screw connector
(5pin: analog audio & IR, 3 pin: RS-232, and 2 pin: power)
• 1 x Short rack ear
• 1 x Long rack ear
• 2 x Mounting plates
• 1 x Remote control
• 4 x Rubber feet
• 1 x User Manual
• Mirrored HDMI and HDBaseT output
• Two HDBaseT Ethernet enabled PoE compatible input ports
• Automatic display control using TCP/IP/RS-232 commands, or CEC
• Auto input switching with video detection technology (activated through RS-232 or webGUI)
• Analog audio de-embedding through captive screw connector
• +4 dBu balanced analog audio output
• Control volume using webGUI, IR, TCP/IP, or RS-232
• Supports 4K @ 60Hz 4:2:0 or 4K @ 30Hz RGB with 8 bit color
• Supports Dolby®TrueHD and DTS-HD Master Audio™ when using an HDMI/HDBaseT for audio
input and output
• Digital audio de-embedding through the S/PDIF output for up to DTS™ 5.1 and Dolby® Digital
• Extended distance HDBaseT port w/PoE to power compatible receivers up to 100 meters (328 feet)
away
• Ability to switch HDCP reporting between compliant, noncompliant, and auto
• EDID management
• Easy to use webGUI through Ethernet connection
• Half-rack size
• Comes with rack mount ears and mounting plates
Introduction
Features
Package Content
The Atlona AT-UHD-SW-5000ED is a 5x1 switcher with two HDBaseT™ inputs, three HDMI inputs,
mirrored HDMI and HDBaseT outputs, balanced audio outputs, automatic input selection, and
advanced display control capability. The HDBaseT inputs match perfectly with the HDVS-200-TX
modules to enable VGA and HDMI sources to be easily integrated into a system. The switcher
supports 4K/UHD @ 60 Hz, 4:2:0; (10.2 Gbps). It transmits AV signals along with Ethernet, power,
and control over a single cable to displays up to 328 feet (100 meters) from the switcher. Control
options include automatic input selection, front-panel buttons, and compatibility with IR, RS-232,
or TCP/IP-based control systems. Displays are automatically turned on and off using CEC, IP, or RS-
232. Advanced features also include a web-based GUI for easy set-up and management of EDID,
HDCP, and display control. The switcher offers audio de-embedding of PCM audio over HDMI to
two-channel, balanced +4 dBu analog audio outputs. The switcher is a cost-effective product for
professional integration featuring a compact, 1U, half-rack width enclosure that is easily installed
with included 19” rack-mount brackets. Two units can be mounted side-by-side.

4
atlona.com Toll free: 1-877-536-3976
Local: 1-408-962-0515
Category Cable
For the category cables used in the installation of these products, please be sure to use a 568B
termination as pictured below:
Connector type and size is very important to ensure extenders work correctly. Please use the
matching cable type with the correct RJ45 connector.
CAT5e cables should use only CAT5e RJ45 connectors
CAT6 cables should use only CAT6 connectors
CAT6a cables should use only CAT6a connectors
CAT7 cables should use only CAT7 connectors
Using the wrong size connectors may result in interference causing loss of signal.
Important! “EZ RJ45 connectors” are not recommended with HDBaseT extenders. Doing so may result in interference
with audio and video transmission.
Use the table below to verify the best category cable for the installation.
Important! 4K (UHD) signals are sensitive to cable quality and installation technique. It is recommended to
use CAT6a/7 solid core cables for best results.
Note: For cable distances see the specifications on page 22
Performance Rating Type of LAN cable
Wiring Shielding CAT5e/6 CAT6a/7
Solid Shielded (STP/FTP) *** ****
Unshielded (UTP) ** N/A
Stranded - Patch
cable
(Not recommended)
Unshielded (UTP) * N/A
Shielded (STP/FTP) * N/A
Termination Please use EIA/TIA-568-B termination
1. White - Orange
2. Orange
3. White - Green
4. Blue
5. White - Blue
6. Green
7. White - Brown
8. Brown
Connector
Rack Ear x 1
Rack Ear x 1
Mounting Plate x 2
The UHD-SW-5000ED can be mounted in three ways: as a single unit in a rack, with a second unit
in a rack, or against a wall/table using the mounting plates.
Single unit mounting will use the long rack ear and short rack ear to affix the unit to the rack.
Two unit mounting will use two short rack ears (the second will be in the box with the second unit) and two
mountings plates to affix the two units together inside the rack.
Wall/table mounting will use both mounting plates to affix the unit to a table or wall.
Oval holes on the rack ears will
always be attached to the rack.
Circular holes will always
be attached to the unit.
Larger oval hole will be
attached to the wall/table.

5
atlona.com Toll free: 1-877-536-3976
Local: 1-408-962-0515
HDMI 1
HDMI 2
HDMI 3
HDMI 4
HDMI 5
VOLUME
AT-UHD-SW-5000ED
AUDIO
R
+ + -
-
L
FW
LAN
RS-232
RX TX
DC 48V
INPUT HDMI OUT HDBaseT OUT
1 2 3 4 5
POWER INPUT
-+
IN
IR
OUT
S S
HDMI 1
HDMI 2
HDMI 3
HDMI 4
HDMI 5
VOLUME
AT-UHD-SW-5000ED
AUDIO
R
+ + -
-
L
FW
LAN
RS-232
RX TX
DC 48V
INPUT HDMI OUT HDBaseT OUT
1 2 3 4 5
POWER INPUT
-+
IN
IR
OUT
S S
Back Panel
1. LAN port - Connect network switch or router to this port for Ethernet, TCP/IP, or webGUI control
2. IR port - Connect IR control system or compatible IR emitter/receiver to this port
3. RS-232 port - Connect control system to RS-232 port
4. Audio output - Connect to an amplifier, mixer, DSP, audio receiver, or other audio device
5. FW port: Firmware update port, connect a Mini USB to USB A cable to a computer
6. HDBaseT IN - Connect HDBaseT sources here (e.g. AT-HDVS-200-TX)
7. HDMI IN - Connect sources here
8. HDMI OUT - Connect to an HDMI display, extender, or switcher
9. HDBaseT OUT - Connect to an HDBaseT PoE receiver
10. DC 48V: Connect included captive screw, 48V DC power supply here
Remote Control
1
7
2
8
6
5
10
4321
3
5
4
9
1. Power On/Off: Turn switcher power on and off
2. Video On/Off: Turns video output off and on
3. Input selection: Selects source
4. Audio control: Adjust volume up/down
Mute: Mute output audio
Panel Descriptions
Front Panel
1. HDMI LEDs - Illuminates to indicate the selected source
2. Volume LEDs - Displays the volume level
3. Power Button - Turns switcher on, places the unit in standby mode, or control a connected
display through the HDBaseT output
4. Volume up/down - Adjusts output volume or display volume through the HDBaseT output
5. Input Button - Switches between HDMI inputs
SW-R1
Video 1
Video
Video 2
All On
Power
Vol +
Vol
-
Mute
1
3
2
4
5
Input Audio
On Off
On Off
On Off
1
2
34

6
atlona.com Toll free: 1-877-536-3976
Local: 1-408-962-0515
Captive Screw
The captive screw connectors allow you to cut cables to a suitable length, reducing cable clutter
while providing a more reliable connection.
Connecting
The captive screw connectors have
a contact bar that is adjusted to
compress the wire against the top
contact plate. Use the screws at the
top of the connector to compress
the wire against the contact plate.
When connecting the cables to the female captive screw connector it is important that the wires be
terminated correctly. The female captive screw connector has a contact plate at the top and must
have the wires touching it for signal to pass. When wired correctly (see picture A) the signal will pass,
incorrectly (see picture B) no signal will pass.
Female captive screw connectors are included: Power (see picture 1),
RS-232 (see picture 2), and IR (see picture 3).
The power cable
(picture 4) will have
exposed wires. Each
wire is encased in
a different colored
cover.
1
Power RS-232
Clockwise Counter
Clockwise
Turn the screws clockwise to
raise the contact bar to the
upper contact plate and hold
the wires in place.
Turn the screws counter
clockwise to lower the
contact bar to release the
wires.
AB
2
RS-232 pin out will be
determined by the RS-232
cable and will connect as
Rx (receiver), Tx (transmitter),
and (ground). (See picture 5)
Pin out color will differ
per RS-232 cable.
Black: - White: +
- +
45
Note: The IR receiver and IR transmitter is optional for the UHD-SW-5000ED. The compatible IR receiver (AT-IR-CS-RX)
and IR transmitter (AT-IR-CS-TX) can be purchased through atlona.com.
The wires of the emitter and receiver have been marked to differentiate the pin outs.
IR
3
Signal (S)
Ground ( )
S
S
The IR emitter (AT-IR-CS-TX sold separately) has two wires: signal and ground. Signal will have a solid
line and ground will be blank. The IR emitter will plug into the IR OUT ports.
There are two wires on the IR captive screw ready cable (AT-LC-CS-IR-2M sold separately): signal and
ground. The signal wire is red and ground wire is black. The IR cable will plug into the IR IN ports
and connect to third party control systems.
Signal (S)
Ground ( )

7
atlona.com Toll free: 1-877-536-3976
Local: 1-408-962-0515
Tip (+)
Analog Audio
A captive screw analog audio connector is provided to ensure a more reliable and secure
connection. The captive screw connector supports balanced and unbalanced audio output.
Balanced audio connections use two signal wires and a ground to minimize interference to audio
signals. Unbalanced audio connections use one signal wire and a ground and are used if other
system components don’t support balanced signals.
Important! With unbalanced connections a jumper is needed between ground and negative to reduce noise
Note: Pin outs may vary, please refer to the audio device’s manual to ensure a correct connection.
Important! When terminating cables, please ensure exposed adjacent wires do not touch. This may result in a short
that can damage connected devices.
XLR RCA
Sleeve ( Ground)
+
+
+
+
+
2 ( + )
3 ( - )
1 ( )
+
-
-
-
-
--
L / R
BALANCED UNBALANCED
L / R
+ +

8
atlona.com Toll free: 1-877-536-3976
Local: 1-408-962-0515
Ethernet
For convenience, the UHD-SW-5000ED comes with DHCP on. This enables the switcher to be
connected to a network without knowing available IP addresses. If your network does not allow
dynamic IP addresses or if you are using the switcher with a TCP/IP control system, this feature may
be turned off and the IP address set using RS-232 commands or the webGUI.
WebGUI
Atlona has created an easy to use webGUI for initial setup and later changes to the configuration
of the switcher.
To begin, plug a LAN cable into the LAN port of the UHD-SW-5000ED and the network switch,
then type the IP address of the unit into a web browser of a PC connected to the same network (as
seen below).
To find the switcher IP: use RS-232 command “IPCFG”.
Important: If any stability issues are experienced, disable any anti-virus or firewall that may interfere with
network communication to the switcher. Once set up is done and the switcher webGUI is no
longer used, the firewall and anti-virus can be re-enabled.
A login screen will appear (this is the same log in for admin and general users). For the first log in (and future
admin changes) the username is “root” and password is “Atlona”.
Note: Only the admin password can be changed (see page 9). The username will always remain “root”.
Note: IP addresses may also be found using common free IP scanner software such as “Advanced IP
Scanner”

9
atlona.com Toll free: 1-877-536-3976
Local: 1-408-962-0515
The home screen tab
will display the general
system information.
The Network Setup Page will allow the IP information to be changed. When a change is made the
screen will grey and the ability to save or cancel will display at the bottom.
Note: When DHCP is on, the IP address cannot be configured. Turn DHCP off to enable IP configuration.
Note: For a stable connection when using a control system, it is best to set up a static IP. As you select an IP address,
make certain no other devices on your network are using that IP address.
Login Mode has been added to provide a secure telnet login. Once Login Mode has been turned on
a username and password will be required on all IP connections to the switcher.
Note: Login mode should be in off position when the UHD-SW-5000ED is used with control systems that do not
support passwords. If your control system supports password protection, you can turn login mode on. The
webGUI always requires a password.
Note: The username and password used in IP Login Mode will be the same login information as the webGUI.

10
atlona.com Toll free: 1-877-536-3976
Local: 1-408-962-0515
System Settings
Auto Switch - Turn auto switching on/off. Default is off.
Factory Default - Resets all switcher settings to default
Video Settings
Source - Select one of the five inputs to be routed to the output.
Audio Settings
Volume - Adjust output volume up or down
HDMI Audio Mute - Toggle the HDMI output audio on/off
HDBT Audio Mute - Toggle the HDBT output audio on/off
L/R Audio Mute - Toggle the analog L/R audio output on/off

11
atlona.com Toll free: 1-877-536-3976
Local: 1-408-962-0515
The Config Page will allow the admin password to be changed, users to be added, and the RS-232
ports to be configured.
Note: User information will display for the admin only. Up to 3 users other than admin can be added.
Note: Only the admin password can be changed. The username will always remain “root”. If the admin password is
lost the system must be returned to factory settings and setup repeated.

12
atlona.com Toll free: 1-877-536-3976
Local: 1-408-962-0515
The EDID Page enables the input preferred timing to be selected and HDCP compliance reporting
to be set.
HDCP selection allows the HDCP reporting of the input to be changed between compliant and
non-compliant
Note: This function is controllable through RS-232 and TCP/IP.
Note: UHD-SW-5000ED protects HDCP encoded content and will not pass HDCP content to a non-HDCP compliant
device.
Note: Some devices flag all content as protected when connected to an HDCP compliant display. This prevents what
should be non-protected content from reaching devices (e.g. teleconference system) through the
UHD-SW-5000ED.
Note: When HDCP reports as non-compliant, only user created content is transmitted. Protected content from all
sources (e.g. Blu-ray, AppleTV, etc) is blocked.
Note: To ensure compatibility, it is best to set the EDID to match the native resolution of the connected display and the
audio format of the connected sound system
Note: To use the analog audio output, a 2Ch EDID will need to be selected
EDID Saved
Save the current output’s EDID to memory. There are eight total EDID memories to save to.
Note: Internal EDIDs include audio EDIDs as well. 2Ch is two channel audio, MCh is multi-channel audio (including up
to Dolby TrueHD or DTS-HD Master Audio), DD is Dolby Digital, and DVI does not include audio.
Internal EDIDs -
STD Sink (pass through) Int_1 1080P 2Ch Int_2 1080P MCh
Int_3 1080P DD Int_4 1080P 3D 2Ch Int_5 1080P 3D MCh
Int_6 1080P 3D DD Int_7 720P 2CH Int_8 720P DD
Int_9 1280x800 2Ch Int_10 1366x768 2Ch Int_11 1080P DVI
Int_12 1280x800 DVI Int_13 3840x2160 2Ch Int_14 3840x2160 MCh

13
atlona.com Toll free: 1-877-536-3976
Local: 1-408-962-0515
The Control Page includes settings which enable display controls by the switcher. It provides a
way to program button functions, turn auto switching on/off, and determine the type of control
commands (TCP/IP or RS-232) sent out.
Button Control Selection
Power - Set which device the power button controls
None: Power button will turn the UHD-SW-5000ED on and off
RS-232: Power button will send power on/off command over HDBaseT using RS-232 to
compatible receivers and displays
IP: Power button will send power on/off command over Ethernet using either the LAN
connection or the HDBaseT connection
Volume/Mute
Audio Out: Volume and mute buttons will control volume output of the switcher
RS-232: Volume/Mute buttons will send the commands over HDBaseT using RS-232 to
compatible receivers and displays
IP: Volume/Mute buttons will send the commands over Ethernet using either the LAN
connection or the HDBaseT connection
CEC Control
Power
On - Sends a command over HDBaseT to the HDMI output of the connected receiver to turn
the connected display on
Off - Sends a command over HDBaseT to the HDMI output of the connected receiver to turn
the connected display off
Note: CEC may not work with every display type

14
atlona.com Toll free: 1-877-536-3976
Local: 1-408-962-0515
System Settings
Display Auto Power On - When enabled, the unit will send a programmed command to the
display to turn on after detecting an A/V signal
Display Auto Power Off - When enabled, the unit will send a command to the display to turn off
after not detecting an A/V signal
Lamp Cool Down Timer (10-300) - Used with a projector whose lamp cannot be turned on for up
to 5 minutes after being shut off. Match settings with lamp delay on projector
Auto Power off timer (10-240) - Sets the period of time between the loss of A/V signal and when
the “Display Off” command is sent
Note: LED will blink red for the auto power off time period then go solid
Note: All functionality remains, only the HDBaseT output is turned off
Display Warm Up Timer (10-300) - Sets the period of time after the display is turned on, that the
power button will be locked
Note: LED will blink green for the warm up timer period and then stay solid
Note: When timers are set to 0 seconds, they will disable the timers’ functions
Control Type - Select whether the display on/off commands are sent using RS-232, TCP/IP, or
CEC
Feedback Verify
On: If receiving no feedback, the product will send the command up to 4 times
Off: The command will only be sent once, whether feedback is received or not

15
atlona.com Toll free: 1-877-536-3976
Local: 1-408-962-0515
TCP/IP Settings of Controlled Device
This option sets the IP for display control. The static IP set here should match the display’s static IP.
To set or view the display’s IP address, check the display’s user manual.
Note: The switcher and the display must be on the same network for these commands to work
Note: Be sure the static IP address set for the display does not match any other device on the network
IP Mode
Non-login: Does not require a username and password when using TCP/IP to control the
display
Login: Requires a username and password to control the display through TCP/IP
IP Address & Port - Set to match the display’s static IP
Username & Password - Required when in login mode
Save - Saves the IP settings for accessing the controlled device
RS-232/IP Commands
ASCII/Hex - Set which type of commands are sent to the display
On/Off/Volume+/Volume-/Mute - Enter the specific commands and feedback that will be sent/
received when using any of the control options
Note: Individual commands will be found in the display’s manual
End of line symbols - None, CR, LF, CR-LF, Space, STX, ETX, Null - Select the appropriate symbol
from the drop down list. Carriage return, line feed, and carriage return with line feed
are the most commonly used symbols.
Note: Be sure to check the display’s manual for the correct symbol

16
atlona.com Toll free: 1-877-536-3976
Local: 1-408-962-0515
For the best performance ensure the most current firmware is being used. Atlona frequently
updates firmware to add features, improve compatibility, and fix bugs. If any issues are experienced
with the switcher, check to make sure the most current firmware is installed.
Download the latest firmware from http://www.atlona.com/AT-UHD-SW-5000ED to a specific
place on the computer, unzip the firmware file, then update the unit using the browse and upload
buttons.
Click the browse button and select the firmware to be loaded from the PC. Once selected, press
the upload button. The progress bar displays the progress of the firmware update.
The Valens (HDBaseT) port has a separate firmware. This firmware can be found at http://www.
atlona.com/AT-UHD-SW-5000ED.
Click the browse button and select the Valens (HDBaseT) file that was downloaded. Once selected,
press the upload button, the progress bar displays the progress of the firmware update.

17
atlona.com Toll free: 1-877-536-3976
Local: 1-408-962-0515
RS-232 & TCP/IP
To set up the RS-232 terminal the first thing needed is to find the RS-232 communications port
under the computer’s device manager. Once there, right click the port and select “Properties”.
Under the properties menu select the port settings tab and set the menu to the switcher default:
Bits per second: 115200, Data bits: 8, Parity: None, Stop bits: 1 and Flow control: None.
Terminal
Connection
RS-232 is connected through a 9-pin female D connector. Three pins will have specific functions
associated with them, some are unassigned.
No. Pin Function
1 ---- Not used
2 Tx Transmit
3 Rx Receive
4 ---- Not used
5 Gnd Ground
6 ---- Not used
7 ---- Not used
8 ---- Not used
9 ---- Not used
54 3 2
9 8 7 6
1
B
A
C

18
atlona.com Toll free: 1-877-536-3976
Local: 1-408-962-0515
Commands (TCP/IP and RS-232)
The command codes are case sensitive, do not change capitalization, spacing, or lettering.
Command Feedback Description
PWON PWON Turns switcher on
PWOFF PWOFF Turns switcher off
PWSTA PWSTA Displays power status
VersionX
e.g. Version OSD
VersionX
e.g. Version x.x.xx
Displays the software versions: ex. VersionMCU
firmware [MCU]
OSD menu [OSD]
DSP [DSP]
FPGA [FPGA]
Type AT-UHD-SW-5000ED Displays the model information
Mreset Mreset Reset device to manufacture default
Lock Lock Locks the front panel buttons
Unlock Unlock Unlocks the front panel buttons
x3AVx1 x3AVx1 Switch inputs Ex. Switch output 1 to input 4= x4AVx1
Status x2AVx1, x3AVx2 Displays what input is connected to the what output
x1$ X x1$ on Turns on/off output channel (X= on, off, sta)
e.g. x2$ off - Turns output 2 off
AutoSW X AutoSW on Turns auto switching on/off (X= on, off, sta)
IRON IRON Turns on the IR receiver window
IROFF IROFF Turns off the IR receiver window
EDIDCopyX memY
e.g. EDIDCopy1 mem2
EDIDCopyX memY
e.g. EDIDCopy1 mem2
Save the EDID of output X (1 or 2) to memory Y (1-8)
e.g. Copy EDID of output 2 to memory 5 = EDIDCopy2 mem5
EDIDMSetX default EDIDMSetX default Set the EDID of the input to the default EDID
EDIDMSetX saveY EDIDMSetX saveY Set the EDID of an input to the previously saved EDID memory
e.g. EDIDMset3 save1 - sets input 3 to EDID memory 1
EDIDMSetX intY EDIDMSetX intY Sets the EDID of an input to one of the internal EDIDs
e.g. EDIDMSet2 int3 - Sets input 3 to internal EDID 3
HDCPSetX Y
e.g. HDCPSet1 on
HDCPSetX Y
e.g. HDCPSet1 on
Set HDCP reporting mode of the HDMI input (X= 1-5)(Y= on, off, sta)
e.g. Input 3 to report HDCP non-compliant = HDCPSet3 off
AudioOutX Y AudioOutX on Turns the HDMI audio of each output (X= 1, 2) on/off (Y= on, off, sta)
e.g. Turn Output 2 HDMI audio off = AudioOut2 off
VOUT1 + VOUT1 XX Increases volume output by 1
VOUT1 - VOUT1 XX Decreases volume output by 1
VOUT1 YY
e.g. VOUT1 -60
VOUT1 XX
e.g. VOUT1 -60
Set volume output to a specific value (XX= -80 to 6)
VOUT1 sta VOUT1 YY Displays current volume output
VOUTMute1 X VOUTMute1 X Mute or unmute the output volume (X= on, off, sta)
Each command or feedback is terminated with a carriage return.
Note: If the command fails or is incorrect the feedback is “Command FAILED”
Note: Preferred timings include audio EDIDs as well. 2Ch is two channel audio, MCh is multi-channel audio
(including up to Dolby TrueHD or DTS-HD Master Audio), DD is Dolby Digital, and DVI does not include audio.
[Y] preferred timing -
STD Sink (pass through) 11080P 2Ch 21080P MCh
31080P DD 41080P 3D 2Ch 51080P 3D MCh
61080P 3D DD 7720P 2CH 8720P DD
91280x800 2Ch 10 1366x768 2Ch 11 1080P DVI
12 1280x800 DVI 13 3840x2160 2Ch 14 3840x2160 MCh

19
atlona.com Toll free: 1-877-536-3976
Local: 1-408-962-0515
Command Feedback Description
IPCFG IP Addr : x.x.x.x
Netmask : x.x.x.x
Gateway : x.x.x.x
IP Port : x
Displays IP address configuration
IPQuit IPQuit Logs out of TCP/IP Connection
IPAddUser X Y
E.g. IPAddUser Atlona 1234
TCP/IP user was added Adds a user for TCP/IP control
X= user and Y= Password
IPAddUser username password
username password
username password
Displays a list of users and passwords
IPDelUser X TCP/IP user was deleted Delete a user from TCP/IP X= username
IPDHCP X IPDHCP X Turns DHCP on or off X= on, off, sta
IPStatic X Y Z
e.g. IPStatic 192.168.1.1
255.255.255.0
192.168.1.200
IPStatic X Y Z
e.g. IPStatic 192.168.1.1
255.255.255.0
192.168.1.200
Sets static IP address
IPStatic Address(X) Netmask(Y) Gateway(Z)
IPPort X IPPort X Set the TCP/IP Port
IPLogin X
e.g. IPLogin off
IPLogin X
e.g. IPLogin off
Enables IP Login
X= on, off, sta
Broadcast X
e.g. Broadcast on
Broadcast X
e.g. Broadcast on
Sets broadcast mode on or off
X= on, off, sta
IPTimeout XX
e.g. IPTimeout 300
IPTimeout XX
e.g. IPTimeout300
Determines amount of seconds of inactivity before TCP/IP
disconnects
Each command or feedback is terminated with a carriage return.
Note: If the command fails or is incorrect the feedback is “Command FAILED”
IP Commands
Command Feedback Description
SetCmd x[y]
e.g. SetCmd on[PWR ON]
SetCmd x[y]
e.g. SetCmd on[PWR ON]
Sets the RS-232 or IP command for the selected button or
function x = on, off, vol+, vol-, and mute y = command
e.g. Set the on command to send the command PWR ON
SetEnd x[y]
e.g. SetEnd off[CR-LF]
SetEnd x[y]
e.g. SetEnd off[CR-LF]
Sets the line termination for the chosen command
x = on, off, vol+, vol-, mute, fbkon, fbkoff, fbkmute
y = None, CR, LF, CR-LF, Space, STX, ETX, and null
e.g. Set the command off to have a carriage return and line feed
TrigCEC y
e.g. TrigCEC on
TrigCEC y
e.g. TrigCEC on
Triggers the stored CEC command to turn the display on
and off y = on, off
TrigRS y
e.g. TrigRS vol+
TrigRS y
e.g. TrigRS vol+
Triggers the RS-232 command from RS-232 or IP
y = on, off, vol+, vol-, and mute
TrigIP y
e.g. TrigIP vol-
TrigIP y
e.g. TrigIP vol-
Triggers the IP command from RS-232 or IP
y = on, off, vol+, vol-, and mute
CtlType x
e.g. CtlType rs-232
CtlType x
e.g. CtlType rs-232
Sets the control type x= ip, rs-232, cec
e.g. Set the control type to RS-232
CliMode x
e.g. CliMode non-login
CliMode x
e.g. CliMode non-login
Sets the control device’s IP mode x= sta, login, non-login
e.g. Sets the IP mode to non-login
CliUser x
e.g. CliUser
CliUser x
e.g. CliUser admin
Sets the IP username for login x= username, (blank)
e.g. Display the IP username by leaving x blank
CliPass x
e.g. CliPass AtlonA
CliPass x
e.g. CliPass AtlonA
Sets the IP password for login x= password, (blank)
e.g. Set the IP password to AtlonaA
CliIPAddr x
e.g. CliIPAddr sta
CliIPAddr x
e.g. CliIPAddr 192.168.0.23
Sets the IP address of the controlled device x= ip, sta
e.g. Display the IP address of the controlled device
CliPort x
e.g. CliPort 24
CliPort x
e.g. CliPort 24
Sets the IP port of the controlled device x= port, sta
e.g. Set the IP port to 24

20
atlona.com Toll free: 1-877-536-3976
Local: 1-408-962-0515
Connection Diagram
3rd Party Control
The UHD-SW-52ED is compatible with most 3rd party control systems. TCP/IP and RS-232
commands can be passed from 3rd party control systems to the UHD-SW-5000ED through the LAN
or RS-232 port.
Note: The switcher can also convert TCP/IP commands to RS-232 commands which are then sent to the compatible
HDBaseT devices.
The UHD-SW-52ED can take either TCP/IP or RS-232 command protocol and transmit it to a
connected device: saving labor, cable, and control system ports.
The RS232zone command re-transmits RS-232 commands to the display through the compatible
HDBaseT receiver. The command may be initiated using either RS-232 or TCP/IP commands.
The Display On/Off command may be used to transmit a TCP/IP command by either RS-232 or TCP/
IP to a display.
Zone output parameter commands (for display control)
RS232para1[baudrate,data-length,parity,stop-bit]
Example: To change the output baud rate to 19200 use RS232para1[19200,8,0,1]
RS232zone1[command]
Once the switcher and zone output have been set up for the best communication, commands can be sent
to control the display. The commands will come from the user manual of the display or projector. The
commands and any carriage returns/line feeds in the commands will need to be placed in the bracket.
Example: To turn the display or projector on if the command is PWRON carriage return, use the command:
RS232zone1[PWRON carriage return]
Note: Use this command if the connected display uses a different baud rate
Note: Use this command if the connected control system does not output 115200
Switcher parameter command
CSpara[baudrate,data-length,parity,stop-bit] (data-length, parity, and stop-bit for switcher must be 8,0,1)
Example: To change the baud rate to 38400 use CSpara[38400,8,0,1]
Baud Rate
Default baud rate to control the switcher is 115200 and default baud rate to control the display or projector
is 9600. Note: For the display’s actual baud rate, refer to the owner’s manual
To change the baud rate of the switcher (for switcher control) or the zone output (for display/projector
control), the commands below will be needed
Video
Audio
HDBaseT
HDMI 1
HDMI 2
HDMI 3
HDMI 4
HDMI 5
VOLUME
AT-UHD-SW-5000ED
AUDIO
R
+ + -
-
L
FW
LAN
RS-232
RX TX
DC 48V
INPUT HDMI OUT HDBaseT OUT
1 2 3 4 5
POWER INPUT
-+
IN
IR
OUT
S S
HDMI IN 1
1
2
HDMI IN 2
HDMI
AUDIO IN
PW
VGA IN
VGA
HDBaseT OUTLAN
DISPLAY ^
^
INPUT VOL
FW RS-232
AT-HDVS-200-TX
RX
TX
FW LINK
POWER
AT-UHD-EX-100CE-RX
RS-232
RXTX
IR IN
PS
IR OUT
S
HDBaseT IN
ETHERNET
HDMI OUT
L
1 2 3 4 5 6
1 2 3 4 5 6
FIXED
ZONE
1
ZONE
2
VAR TRIG
SUM
RS-232
IROUTPUTS
SOURCEINPUT CONNECTION SYSTEM
STATUS
NET LINK
LINEOUT
MUTE
R R R
L L
AT-HDVS-200-TX
AT-UHD-EX-100CE-RX
AT-UHD-SW-5000ED
