Atlona AT-MDP21 User manual

AtlonA
2x1 Mini DisplayPort KVM Switch
(Powerless)
AT-MDP21
User Manual

TABLE OF CONTENTS
1. Introduction .................................................. 1
2. Package Contents .................................................. 1
3. Features .................................................. 1
4. Specication .................................................. 1
5. Panel Descriptions .................................................. 2
5.1. Front Panel .................................................. 2
5.2. Rear Panel .................................................. 2
6. Connection Diagram .................................................. 3
7. Operation .................................................. 3
8. Safety Information .................................................. 4
9. Atlona Product Registration .................................................. 4
10. Warranty .................................................. 5

INTRODUCTION
1
Atlona Technologies’ AT-MDP21 is one of the most innovative Mini DisplayPort devices on the market
today. This mini display port switcher will allow users to connect up to two Mini DisplayPort computers
to a single display. The AT-MDP21 has 2 individual Mini DisplayPort and 4 USB inputs and an individual
Mini DisplayPort output as well as 2 USB outputs for keyboard and a mouse. This unit also boasts 4
USB inputs for the use of the 2 desired computer’s mouse and keyboard. Supporting digital video reso-
lutions up to 2560x1440, the AT-MDP21 is perfect for users looking to use a single Mini DisplayPort Monitor,
such as the Apple 24/27-inch and iMac 27-inch, Cinema Displayswith multiple Mini DisplayPort computers.
• 1 x AT-MDP21 2x1 Mini DisplayPort KVM Switch
• 1 x Instruction Manual
• 2 x 3ft Mini DisplayPort cables
• 4 x 3ft USB cables
• 2 mini display port inputs and 1mini display port output.
• 4 USB inputs and 2 USB outputs.
• 2 input select buttons on front panel to select the input sources.
• Supports digital video resolutions up to 2560x1440
• Supports high-speed uncompressed digital video.
Type of Switcher 2 inputs to 1 output, (Powerless) Mini DisplayPort KVM Switch
Video Resolutions Digital Video Resolutions 2560x1440
Controls Select buttons on the front panel
Support High-speed Uncompressed digital video and audio
Safety Approvals RoHS (2002/95/EC)
Dimensions (LWH) 6.25”x 5” x 1.23”(160mm x 134.8mm x 32mm)
Shipping Weight 0.3 Kgs / 0.65 lbs
FEATURES:
PACKAGE CONTENTS:
SPECIFICATIONS:

PANEL DESCRIPTION
1. Front Panel
• Input select buttons: Select between Inputs A and B on front panel to select the input sources
2. Rear Panel
• Mini DisplayPort Inputs: Inputs A and B for desired Mini DisplayPort sources
• Mini DisplayPort Output: Output to Desired Monitor
• USB Input A: For Input A, use USB inputs 1 and 2 for mouse and keyboard connection from computer
to switcher
• USB Input B: For Input B, use USB inputs 1 and 2 for mouse and keyboard connection from computer
to switcher
• USB Outputs: USB Outputs 1 and 2, use Outputs 1 and 2 for mouse and keyboard connection
2

2 3
1. Connect the AT-MDP21’s mini DP output to the desired monitor’s mini DisplayPort input via mini DP to
mini DP cable.
2. Connect the desired keyboard and mouse’s USB A to the AT-MDP21’s output USB jacks 1(keyboard)
and 2(mouse).
3. Connect the AT-MDP21’s mini DP A and B inputs to two different desired computer’s mini DisplayPort
outputs via mini DP to mini DP cable.
4. From the AT-MDP21, connect input A’s USB 1and 2 as well as input B’s USB 1 and 2 to two desired
computers’ mouse and keyboard USB jacks by using USB to USB cables.
CONNECTION DIAGRAM
OPERATION
AT-MDP21
Apple LED Cinema display
24/27-inch LED and iMac 27-inch
Apple laptop with mini
Displayport output
Apple laptop with mini
Displayport output
Keyboard
Mouse

4
SAFETY INFORMATION
Precautions
Avoid excessive humidity, sudden
temperature changes or temperature
extremes.
Keep this product away from wet locations
such as bathtubs, sinks, laundries, wet
basements and swimming pools.
Opening the product will void the warranty.
Do not attempt to service the unit. Instead
disconnect it and contact your Authorized
ATLONA reseller or contact ATLONA
directly.
ATLONA PRODUCT REGISTRATION
Thank you for purchasing this Atlona product — we hope you’ll enjoy it.
We also hope that you’ll take a few moments to register your new purchase. Registration creates an ownership
record if your product is lost or stolen and helps ensure you’ll receive notication of performance issues and rm-
ware updates.
At Atlona, we respect and protect your privacy and assure you that your registration information is completely
secure. Of course, Atlona product registration is totally voluntary and failure to register will not diminish your lim-
ited warranty rights.
To register go to www.atlona.com/registration

4
SAFETY INFORMATION
5
WARRANTY
1. LIMITED WARRANTY
Atlona Technologies warrants that (a) its products (the “Product”) will perform substantially in accordance with the
accompanying written materials for a period of 3 YEARS from the date of receipt and (b) that the Product will be
free from defects in materials and workmanship under normal use and service for a period of 3 years. In the event
applicable law imposes any implied warranties, the implied warranty period is limited to 3 years from the date of
receipt. Some jurisdictions do not allow such limitations on duration of an implied warranty, so the above limitation
may not apply to Customer.
2. CUSTOMER REMEDIES
Atlona Technologies and its suppliers’ entire liability and Customer’s exclusive remedy shall be, at Atlona Technolo-
gies’ option, either return of the price paid for the Product, or repair or replacement of the Product that does not meet
this Limited Warranty and which is returned to Atlona Technologies with a copy of Customer’s receipt. This Limited
Warranty is void if failure of the Product has resulted from accident, abuse, or misapplication. Any replacement Prod-
uct will be warranted for the remainder of the original warranty period or 3 year, whichever is longer.
3. NO OTHER WARRANTIES
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, ATLONA TECHNOLOGIES AND ITS SUPPLI-
ERS DISCLAIM ALL OTHER WARRANTIES, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED
TO IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, WITH
REGARD TO THE PRODUCT AND ANY RELATED WRITTEN MATERIALS. THIS LIMITED WARRANTY GIVES
CUSTOMER SPECIFIC LEGAL RIGHTS. CUSTOMER MAY HAVE OTHER RIGHTS DEPENDING ON THE JU-
RISDICTION.
4. NO LIABILITY FOR DAMAGES
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT SHALL ATLONA TECHNOLO-
GIES OR ITS SUPPLIERS BE LIABLE FOR ANY DAMAGES WHATSOEVER (INCLUDING WITHOUT LIMITA-
TION, SPECIAL, INCIDENTAL, CONSEQUENTIAL, OR INDIRECT DAMAGES FOR PERSONAL INJURY, LOSS
OF BUSINESS PROFITS, BUSINESS INTERRUPTION, LOSS OF BUSINESS INFORMATION, OR ANY OTHER
PECUNIARY LOSS) ARISING OUT OF THE USE OF OR INABILITY TO USE THIS PRODUCT, EVEN IF ATLONA
TECHNOLOGIES HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. IN ANY CASE, ATLONA
TECHNOLOGIES’ AND ITS SUPPLIERS’ ENTIRE LIABILITY UNDER ANY PROVISION OF THIS AGREEMENT
SHALL BE LIMITED TO THE AMOUNT ACTUALLY PAID BY YOU FOR THE PRODUCT. BECAUSE SOME JU-
RISDICTIONS DO NOT ALLOW THE EXCLUSION OR LIMITATION OF LIABILITY FOR CONSEQUENTIAL OR
INCIDENTAL DAMAGES, THE ABOVE LIMITATION MAY NOT APPLY TO YOU.
