ATMOX ACE 2.0 User manual

Moisture Control & Heat Reduction
INSTALLATION GUIDE

2
WELCOME
INSTALLER INFORMATION
SERIAL NUMBER: ___________________
INSTALL DATE: _____________________
INSTALLER CONTACT INFORMATION
NAME: _____________________________
PHONE: ____________________________
ACE 2.0 Control Set
APEX 2.0 Control Set
Power Booster 2.0
Thank you for purchasing an ATMOX Controller. This installation guide
covers the steps to install and set up the ATMOX ACE and APEX Controllers
and attached components. All information applies to both controllers unless
expressly noted by (ACE) or (APEX).
Please leave with homeowner for future reference. For instructions on fans,
lights, dehumidifiers, and other accessories, please refer to specification
sheets by product.
For assistance or questions, contact ATMOX:
PHONE: [phone]
EMAIL: [e-mail]
Issue: 2022-04 © Copyright 2022 ATMOX, INC.
All specifications and designs are subject to change without notice. This installation guide and its contents
are owned by ATMOX INC and are protected under the US Copyright Act and other intellectual property
laws. All trademarks, service marks, logos and the like (whether registered or unregistered) are owned and
controlled by ATMOX INC. Unauthorized use or duplication of ATMOX intellectual property is prohibited.
ITEM:

3
TABLE OF
CONTENTS
10
01
01
03
04
07
06
05
OPERATOR’S GUIDE LOW VOLTAGE
WIRING
OVERVIEW
PLANNING
COMPONENTS
CONTROLLER &
SENSORS
09
INSTALLATION
CHECKLIST
08
SETTINGS MENU
SETUP
TROUBLESHOOTING
OPERATING PRINCIPLE.......................... 4
INFORMATIONAL SCREENS .................. 4
NOTIFICATIONS........................................ 5
NAVIGATION & SETTINGS ...................... 7
MAINTENANCE......................................... 7
FREQUENTLY ASKED QUESTIONS....... 8
OVERVIEW............................................... 17
WIRING EXPLANATION.......................... 18
PRIMARY LOW VOLTAGE WIRE ........... 18
SUPPLEMENTAL LOW VOLTAGE
WIRE......................................................... 19
FASTENING WIRE & ATTACHING
CONNECTOR WIRES............................. 20
DISPLAY CONNECTION ........................ 22
DISPLAY SETUP...................................... 22
SETUP SCREENS................................... 23
POWER BOOSTER SYNC ..................... 24
DISPLAY INSTALLATION........................ 25
SETTINGS MENU ................................... 26
ACE SETTINGS....................................... 26
APEX SETTINGS..................................... 30
CHECKLIST ............................................. 32
SETUP ERROR MESSAGES................. 34
ALERTS .................................................... 35
SOFTWARE & HARDWARE
COMPATIBILITY ERRORS......................36
HARD RESET ..........................................37
CONTROLLER & SENSOR
ERRORS...................................................37
COMPONENT WIRING ERRORS..........40
TESTING ISSUES....................................42
SAFETY INSTRUCTIONS......................... 9
SPECIFICATIONS ................................... 10
BOX CONTENTS..................................... 10
PLACEMENT & CONFIGURATION
ACE........................................................... 11
PLACEMENT & CONFIGURATION
APEX......................................................... 12
LOW VOLTAGE WIRING PLANNING .... 13
FANS......................................................... 14
LIGHTS..................................................... 14
DEHUMIDIFIER ...................................... 14
CONTROLLER INSTALLATION ............. 15
OUTSIDE SENSOR................................. 15
INSIDE SENSOR..................................... 15
WOOD MOISTURE SENSOR ................ 16
WATER ALERT SENSOR ....................... 16
EXTENSION CABLES............................. 16
02

OPERATOR’S GUIDE
01
4
OPERATING PRINCIPLE
Unfinished spaces of your house need proper ventilation and/or dehumidification. The goal of
ATMOX is simple – reduce the moisture level in your crawl space and reduce both heat and
moisture levels in your attic.
The basic principle of how it works is also simple. Ventilate with “good” air from the outside only
when it will improve conditions in the space. The ATMOX controllers use sensors to measure
temperature and humidity and then calculate dew point both inside and outside. Based on the data,
the software will determine the best course of action to reduce moisture and/or heat. In a crawl space
environment, ATMOX can incorporate a dehumidifier in addition to fans that circulate internal air.
ATMOX systems are designed with a focus on energy efficiency and air quality of the home. Once
installed, the ATMOX system will operate automatically.
INFORMATIONAL SCREENS
The ATMOX display will automatically rotate through its standard informational screens about every
five seconds. To scroll more quickly, press the Information button.
WHAT EACH SCREEN DISPLAYS WHILE SCROLLING:
CONTROLLER
MODEL NAME
DEW POINT
OUTSIDE & INSIDE
RELATIVE HUMIDITY
OUTSIDE & INSIDE
Do not adjust settings on your system without talking to your
installer. Improper settings can negatively affect the operation of
the ATMOX system.
CAUTION
TEMPERATURE
OUTSIDE & INSIDE

OPERATOR’S GUIDE
01
5
The ATMOX system uses a series of calculations based on the data to determine the best action.
Temperature determines:
• If attic fans should operate for high heat. (APEX)
• If the outside temperature is within parameters to allow ventilation and to avoid air that is too cold
or too hot.
Dew point comparison determines:
• If outside ventilation will reduce moisture. Lower dew point means there is less moisture in the air.
Relative humidity determines:
• If internal fans or a dehumidifier should operate. (ACE)
• If outside ventilation should cease to optimize energy efficiency.
NOTIFICATIONS
When illuminated, the lights on the controller indicate which components on the system are currently
active. Flashing lights indicate that the system is in a time delay and may be
switching operations.
ACE DISPLAY LIGHTS
EXHAUST/INTAKE: Fans installed in exterior vent locations are in operation.
INTERNAL FANS: Fans installed inside a crawl space are in operation.
DEHUMIDIFIER: Dehumidifier is in operation.
IDLE: System has no current operation and no current alerts.
LIGHTS: Lights are in operation. Lights are turned on and off manually
by pressing the light bulb buttons. After two hours of operation, lights will
automatically turn off.
ALERT: The system is bringing an alert to your attention. Read message on
screen for more information.
WOOD MOISTURE
SNOW MODE
If installed, wood moisture measurement is a great tool to evaluate actual
moisture in the space. The readings will vary throughout the year. In
general, 10-16% wood moisture content is considered a healthy range for
an unfinished space.
(APEX) If activated, snow mode is a feature that can be turned on to
mitigate the potential for ice damming in climates where snow and ice
buildup create challenges for the attic. Snow mode is a tool used to fight
ice damming but needs to be viewed as part of an overall strategy as it
may not eliminate all issues in all attics on its own. Snow mode must be
activated during setup or in the settings menu. See SETTINGS MENU
section for instructions on how to turn on.

OPERATOR’S GUIDE
01
6
APEX DISPLAY LIGHTS
ATTIC FANS: Fans are in operation.
IDLE: System has no current operation and no current alerts.
LIGHTS: Lights are in operation. Lights are turned on and off manually
by pressing the light bulb buttons. After two hours of operation, lights will
automatically turn off.
ALERT: The system is bringing an alert to your attention. Read message
on screen for more information.
SCREEN ALERTS
When the Alert light is flashing red, the following alerts are notifications of a possible issue within the
space that should be watched or evaluated.
When the Alert light is solid red, the alerts are a notification of a hardware issue with the ATMOX
system. These errors will limit or cease operation and should be addressed immediately.
For any system alerts, contact your installer for assistance or view more
detailed information in TROUBLESHOOTING section.
CAUTION
WOOD MOISTURE
ALERT
HIGH WATER
ALERT
LOW TEMPERATURE
ALERT
ELEVATED RH
ALERT

OPERATOR’S GUIDE
01
7
NAVIGATION & SETTINGS
BUTTON FUNCTION
Information
Shown as: (i)
Used for scrolling through screens. When changing settings, this
button saves and updates any changes made.
Up Arrow
Shown as: (Y)
Used to turn lights on. Within a settings menu, this button indicates an
answer of Yes or increases numeric value.
Down Arrow
Shown as: (N)
Used to turn lights off. Within a settings menu, this button indicates an
answer of No or decreases numeric value.
Home
Shown as:
Home Button
Used to return to the main informational screens. To get to the menu
for settings and testing, press and hold this button for five seconds.
For more information on changing settings, see SETTINGS MENU
section.
MAINTENANCE
ATMOX suggests a periodic maintenance inspection of your ATMOX system and unfinished space
by your installer. Conditions in and around your home are always changing. Please be aware of the
following during other times of the year:
Power Connection
If the display screen is not showing any readings, it most likely has no electrical power and is not
operating. In this case, see if something is unplugged or make sure that the outlet being used by the
controller in the unfinished space has power. It is possible for controller to operate independently
of display for several days. If display and/or controller have no power, then contact your installer for
more information.
System Alerts
If the ATMOX system is showing an alert, then the system may not be operating or may be notifying
you of another potential issue. Please check periodically to make sure that the display has no alerts
needing attention.
Fan Operation
ATMOX fans (particularly in a crawl space environment) should periodically be brushed off lightly
to keep debris from blocking ventilation. The display may not give a notification if any single fan or
group of fans are not operating. Fans should periodically be checked for operation.
Dehumidifier Operation (ACE)
If a dehumidifier is installed, follow the guidelines from the dehumidifier manufacturer with regard to
filter replacement or cleaning. Many homes do not need a dehumidifier, but there are exceptions.
If you live in a very humid climate and have excessive ground moisture being released into the
crawl space during peak summer months, it may be necessary to incorporate a dehumidifier with
the ATMOX system. Contact your installer if you have questions about your situation or need more
information.

OPERATOR’S GUIDE
01
8
Water Management (ACE)
It is important to note that the ATMOX system is a moisture management system and not a water
management system. Dry air or a dehumidifier cannot get rid of standing water in a crawl space.
Every effort should be made to drain water away from the foundation. Gutters should be cleaned out,
and downspouts should drain away from the house. If you have water intrusion in your crawl space,
this needs to be addressed separately from or in addition to your moisture problem.
FREQUENTLY ASKED QUESTIONS
What happens if there is a blackout or power outage?
The ATMOX controller and components will not run without electrical power. When power is restored,
the ATMOX controller will automatically restart and continue normal operation. If controller has no
power, then check outlet for power interruption (i.e. a tripped GFCI). All settings are retained so there
is no need to do anything on display.
Will the fans running cause too much cold air to be brought in during the winter?
In the crawl space, the controller adjusts for seasonal ventilation modes. The fans will not bring
outside air into the crawl space below a set temperature. In the attic, the fans will not bring outside
air into the attic below a set temperature which can be adjusted.
The relative humidity inside my space is higher than outside, why aren’t my fans on?
Fans ventilating with air from the outside will compare conditions between the outside air and the
inside air. The fans will run based on a dew point comparison as this gives the best measurement of
actual moisture in the air. There are times of the year when the outside temperature is high, and the
dew point will not be lower outside even though the humidity appears lower. Humidity measurements
are greatly affected by temperature and can be misleading with regard to moisture in the air.
It is raining outside, and the fans are running. What is wrong?
The answer is probably nothing. You have to trust the system even when it doesn’t seem intuitive.
The fans will be activated by dew point and not humidity levels. If a cold front comes through (even
with rain), it is possible that the colder air will have a lower dew point than the dew point in the
space. The air with lower dew point will be beneficial to the space.
I have a system alert or a question, who should I contact?
Contact your local installer first as they will have more information about the specifics of your home
and system. For any additional information or questions, contact ATMOX by phone at 704-248-2858
or email [email protected].

OVERVIEW
02
9
SAFETY INSTRUCTIONS
• To reduce the risk of electric shock, the controller has a three-prong grounding plug
on the power cord. Do not cut, remove or bypass the grounding plug.
• Do not use with an extension cord.
• Do not operate with a damaged power cord. A damaged cord should be replaced by a
licensed electrician or an ATMOX representative.
• In the event of a malfunction, immediately stop operation and disconnect power cord.
• Do not install in standing water or location that could be directly splashed by water.
• Do not wire or attach components while controller is plugged in.
• Do not disassemble, repair or modify the product.
• Do not insert fingers or other items into any openings or ports other than designated
jacks.
• Only use approved ATMOX fans, lights and accessories with the ATMOX controller.
WARNING
WARNING
NOTICE
CAUTION
CAUTION
NOTICE
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy, and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there
is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment OFF and ON, the user is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
This device complies with Industry Canada license- exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not
cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
The ATMOX Controller 2.0 conforms to unified standard UL 60730-1 and UL 60730-2-9 and
CSA standard E60730-1 and CSA standard E60730-2-9.
WARNING: Cancer and Reproductive Harm – For more information, go to www.P65Warnings.ca.gov

OVERVIEW
02
10
SPECIFICATIONS
Input: 120VAC 60Hz 1.25A
Output: 12VDC 150WATTS MAX
Environmental Conditions: Pollution Degree 2
Data Input (ACE/APEX): 2 Temperature/Relative Humidity, 1 Wood Moisture,
1 Water Alert
Power Output (ACE): 4 Switched, 1 Constant
Power Output (APEX): 2 Switched, 1 Constant
Power Output (Booster): 4 Switched, 1 Constant
BOX CONTENTS (ACE/APEX)
1. Display
2. Controller
3. Outside Temperature and Humidity Sensor
4. Inside Temperature and Humidity Sensor
5. Mounting Plate for Display with Screws and Anchors
6. Extension Cables
7. Cable Couplers
8. Quick Splice Connectors
9. Installation Guide
General tools and supplies needed for installation are not included. Screws for mounting
controller, sensors or other ATMOX components should be selected based on the surface
to which you are mounting.
BOX CONTENTS (POWER BOOSTER)
1. Power Booster
2. Sync Cable
3. Quick Splice Connectors
4. Installation Guide

PLANNING
03
11
PLACEMENT & CONFIGURATION - ACE
Controller and Sensor
Placement
Display
1
Controller
2
Inside Sensor
3
Outside Sensor
4
1
234
Before beginning installation, take a moment to review components that you will be
installing. As you review steps, think about where components will be placed. A little
pre-planning will make things go very smoothly when installing.
CRAWL SPACE FUNCTION BY OUTPUT
Dehumidifier
runs when outside
air is not beneficial
and inside humidity
is elevated.
Fans run when
the outside air is
beneficial.
Constant Power
Fans run when
outside air is
beneficial or when
inside humidity
is elevated.
Lights turn on
when manually
activated.

PLANNING
03
12
PLACEMENT & CONFIGURATION - APEX
Controller and Sensor
Placement
Display
1
Controller
2
Inside Sensor
3
Outside Sensor
4
34
2
1
ATTIC FUNCTION BY OUTPUT
Constant Power
Fans run when
the outside air is
beneficial.
Lights turn on
when manually
activated.

PLANNING
03
13
LOW VOLTAGE WIRING PLANNING
Do not use a separate wire for each fan. The setup is a daisy chain.
Keep total length of low voltage wire on one run to a maximum of 150 feet.
Determine where components will be placed. The controller location will dictate the origin of your wiring.
It is important to understand the function of each component in the space. The function (not necessarily the
type of component) determines which output line the component will be wired to. These functions should
be determined prior to running low voltage wire to components. Each output line uses its own separate wire
running from the controller to the component locations.
Think about how to bring the low
voltage wire to all of the components on
the same output line starting from the
controller.
Begin at the controller and start taking
the primary wire to the components. At
the end of a run, cut off any wire.
If extra length is needed on the primary
wire, attach a supplemental wire to the
primary wire to keep going in the same
direction.
If your fans split off into different
directions, you can add a supplemental
wire to the primary wire in any location
and make a Y-type split.
For details on how to connect the wiring,
see LOW VOLTAGE WIRING section.
Wiring in an attic is the same as in a crawl
space.
1 2
3 4

COMPONENTS
04
14
FANS
Follow instructions supplied with each fan for proper mounting. The
controller will determine when fan operation is beneficial to the space.
CAUTION
LIGHTS
Follow instructions supplied with each light for proper mounting. Lights
can be turned on and off manually from the display box by pressing the
buttons with the light bulbs.
DEHUMIDIFIER (ACE)
Follow instructions supplied by dehumidifier manufacturer for proper
setup and water drainage. Follow instructions with ATMOX Relay Kit
or Adapter Kit to connect dehumidifier to ATMOX controller for proper
operation and setup.
The power supply in the controller is limited to 150 WATTS. Refer to the
specification sheet of each component used to determine total power usage.
If you exceed 150 watts of power with fans or lights, you must add a power
booster, which also has a limit of an additional 150 watts. Up to four power
boosters can be used with one controller. Each of the output lines on the power
booster will mirror those designated on the synced controller.
E
X
H
A
U
S
T
/
I
N
T
A
K
E
F
A
N
S
I
N
T
E
R
N
A
L
F
A
N
S
The ATMOX controller will power and/or control components. Once installed, components will
operate automatically or on command.
The use of fans or lights not manufactured by ATMOX may not be compatible with the ATMOX
controller and may cause an electrical surge or damage the controller. Damage caused by
noncompatible components or incorrect wiring is not covered under the ATMOX product
warranty.
Using components on the wrong output line may lead to improper operation of the ATMOX
controller and have a detrimental effect. As the installer, you should have a plan on effective
placement of components. Follow specific guidelines on wiring configuration by controller and
power booster, as described in PLANNING section.
CAUTION
Dehumidifier must have its own electrical outlet within distance of
dehumidifier electrical cord.
In a crawl space, intake fans should not be placed under a deck
or porch. Intake fans should not be placed within ten feet of a
gas meter or gas furnace exhaust.

CONTROLLER &
SENSORS
05
15
1
Use two screws to mount in outside location within a few feet of wire feed into attic/crawl space.
Plug jack into OUTSIDE TEMP/RH port.
OUTSIDE SENSOR
INSIDE SENSOR
Placing inside sensor in the middle of the attic/crawl space is preferable. If
you have a dehumidifier, do not place the inside sensor within ten feet of
the dehumidifier.
Pull sensor from mounting bracket.
Use two screws to mount on a joist or beam inside attic/crawl space.
Push sensor back into bracket.
Plug jack into INSIDE TEMP/RH port.
1
12 3 4
1
2
1
2
3
4
CONTROLLER INSTALLATION
Avoid locations adjacent to HVAC equipment or an exhaust fan. Avoid direct or
constant sun when possible as this may cause higher temperature readings.
Don’t place controller in an outside location. In attic, don’t place within two feet of
the roof rafters.
Mount using four screw holes by an
electrical outlet in or near the attic/
crawl space.
DO NOT PLUG CONTROLLER
INTO ELECTRICAL OUTLET AT THIS TIME.
TIP
TIP
1
CAUTION
2

CONTROLLER &
SENSORS 05
16
CAUTION
Place sensor in location that may have water issue.
Plug jack into WATER port.
WATER ALERT SENSOR
EXTENSION CABLES
Insert end of sensor cable into coupler.
Connect additional extension cables as needed.
Fasten cable to joists. Be careful not to staple through cable.
Create a drop loop at each coupler connection before securing to joist. Tension on jacks may cause
internal damage to cable.
12
1
2
1
2
3
4
12 3 4
Twenty-five foot extension cables and couplers are provided to extend sensor cables to the controller.
They can be used in any combination.
All coupler connections must be installed inside the attic/crawl space. If the jacks and
couplers are outside, they will get wet and corrode causing a sensor error.
It is not recommended to exceed two couplers in one cable run.
WOOD MOISTURE SENSOR
Use two screws to mount on a joist or beam inside attic/crawl space.
Plug jack into WOOD MOISTURE port.
It may take a few days for the wood sensor to acclimate and provide accurate
readings.
TIP
1
2
TIP
1 2

LOW VOLTAGE
WIRING
06
17
CAUTION Do not plug in the controller or booster until all wiring is complete.
ATMOX components such as fans and lights are designed for connection to controllers via
low voltage wiring.
Use 14/2 low voltage wire. This wire can have different grooves
or writing. Pick one side as positive and the other as negative. Be
consistent throughout installation. ATMOX suggests grooved side
as NEGATIVE and smooth side as POSITIVE.
Quick Splice Connectors
connect connector wire to the
low voltage wire.
Low voltage wiring connects to
controller in terminal blocks. The
colored block is POSITIVE. The
black block is NEGATIVE. Each
color is used for a different function.
Connector Wire connects
the ATMOX component to
low voltage wire with quick
splice connectors. Black wire
is POSITIVE. White wire is
NEGATIVE.
OVERVIEW
TIP
Before you begin any wiring, please follow these important steps:
• Determine function of each component being installed and determine which output line the
component needs to be wired to. Review page 11 and 12 in the PLANNING section.
• Refer to specification sheet of each component to determine watts used. The controller and
power booster each have the ability to power 150 watts.
• If your total usage exceeds 150 watts, then you need to split the components up between the
controller and a power booster. Output lines will function the same on both units once they have
been synced properly. Instructions on power booster setup are on page 24.
Note: The power booster will not work independently of the controller except for the use of the
constant power output.
Once you have finished wiring, proceed through the display setup and, if applicable, the booster
syncing process.

LOW VOLTAGE
WIRING 06
18
PRIMARY LOW VOLTAGE WIRE
Split wire about two inches from end.
Pull the ends apart.
Remove outer coating to expose internal copper
on each end of wire.
Twist exposed copper strands together.
Loosen screws in terminal blocks. Do not remove
screws completely.
Push exposed copper up and under one side
of each screw in terminal block. Be sure to put
your POSITIVE side of wire in colored block and
NEGATIVE side in black block.
Tighten each screw over exposed wire.
Tug slightly on wire to make sure that it is secure.
Repeat for each output line wired.
8
7
1
2
3
4
5
6
8
76
12 3 4 5
WIRING EXPLANATION FOR EACH OUTPUT
Black Terminal Block
Colored Terminal Block
Primary Low
Voltage Wire
Supplemental
Low Voltage Wire
Positive
(smooth side)
Negative
(grooved side)
Quick Splice
Connectors
Connector
Wire
Fan or
Accessory
9
CAUTION Screw connections must be tight. Do NOT put positive and negative wires under any
one screw.

LOW VOLTAGE
WIRING
06
19
On primary wire, select location where
supplemental wire will be attached. Split wire.
Pull apart the two sides to make a loop of about
three inches.
Cut end on supplemental wire to make sure it is
smooth and even.
Split wire about two inches from end.
Pull the ends apart.
Find the POSITIVE side of the primary wire in
the loop. Push the wire into the quick splice
connector.
Take the end of the POSITIVE side of the
supplemental wire. Insert the end of the wire into
the connector until it hits the plastic stop.
Use pliers on metal splice to make a connection
with both wires.
Push the cover of the quick splice connector
down to close.
Repeat Steps 6-9 with the NEGATIVE side of the
primary and supplemental wire.
When finished, both sides of wire will be
connected to each other.
10
11
9
8
71
2
3
4
5
6
8
76
12 3
910
45
11
910
SUPPLEMENTAL LOW VOLTAGE WIRE
11

LOW VOLTAGE
WIRING 06
20
FASTENING WIRE & ATTACHING CONNECTOR WIRES
8910
76
12 3 4 5
Secure wire to joists.
Create a drop loop location where you want to
attach the component.
In the drop loop, split wire.
Pull apart the two sides to make a loop of about
three inches.
Take the POSITIVE side of the low voltage wire in the
loop. Push the wire into the quick splice connector.
Take the end of the POSITIVE side of the
connector wire (black wire). Insert the end of the
connector wire into the connector until it hits the
plastic stop.
Use pliers on the metal splice to make a
connection with both wires.
Push the cover of the connector down to close.
Repeat steps 5-8 with the NEGATIVE side of the
low voltage wire and the NEGATIVE side of the
connector wire (white wire).
Plug the jack of the connector wire into the
component.
7
8
9
10
1
2
3
4
5
6
Avoid damage to wire tips. Do not use excessive force when pulling wires.
TIP
