ATN ODIN User manual

ATN ODIN
operator’s manual
Important Export Restrictions! Commodities, products,
technologies and services contained in this manual are
subject to one or more of the export control laws and
regulations of the U.S. Government and they fall under the
control jurisdiction of either the US Department of State
or the US BIS-Department of Commerce. It is unlawful
and strictly prohibited to export, or attempt to export or
otherwise transfer or sell any hardware or technical data or
furnish any service to any foreign person, whether abroad
or in the United States, for which a license or written
approval of the U.S. Government is required, without
first obtaining the required license or written approval
from the Department of the U.S. Government having
jurisdiction. Diversion contrary to U.S. law is prohibited.
OPERATOR’S MANUAL (ODIN) REVISION 1 – MARCH 2013
THERMAL MULTI-PURPOSE SYSTEM

Register your product warranty online at
www.atncorp.com/warranty
Manual (Odin) Revision 1 - MARCH, 2013
The information in this manual furnished for information use only, is subject to
change without notice, is not to be construed as a commitment by ATN Corp.
ATN Corp. assumes no responsibility or liability for any errors or inaccura-
cies that may appear in this book.
© 2013 ATN Corp. All right reserved.

a
SAFETY SUMMARY
STUDY CAREFULLY THIS MANUAL BEFORE TURNING ON
AND OPERATING THIS PRODUCT.
CAUTIONS
The ATN Odin thermal multi-purpose system are precision
optical-electronic instruments and requires careful handling.
To provide safe use of the systems the following instructions
should be observed:
• Do not dismantle the device.
• Keep the device clean; protect it from moisture, sharp tem-
perature drops and shocks.
• Be careful not to touch the glass surfaces. If you put finger-
prints on, or contaminate the glass surfaces, use only clean
and soft materials to clean it.
• Do not leave the device in on position during stops in operation.
• Remove the battery from the device for the period of storage.
THIS PRODUCT CONTAINS NATURAL RUBBER
LATEX WHICH MAY CAUSE ALLERGIC REACTIONS
CAUTION:

b
WARNING
Do not permanently attach the device to dynamic-mount applica-
tions that continuously transmit vibration (such as on vehicles or
heavy machinery).
WARNING
Do not point the monocular directly at any high-intensity objects
that you must not view with your eyes (such as the sun or a weld-
ing arc). If you do, you will damage the camera.
WARNING
Operating Odin outside of its specified operating temperature
range or voltage range can cause permanent damage and will
void the warranty.
WARNING
Use the power switch to turn the camera off before you remove
power (remove battery).
WARNING
Do not use any battery other than a CR-123A lithium battery. DO
NOT use any battery(ies) providing a (combined) voltage greater
than 3.0 volts.
WARNING
Do not replace battery in a possibly explosive environment, such
as a gas station (or any place where you must turn off your vehicle
engine). If you do, sparks can cause an explosion.
WARNING
Remove the battery before you store the camera for extended
periods (2 weeks or more).
WARNING
Do not carry battery in pockets containing metal objects such as
coins, keys, etc. Metal objects can cause the battery to short cir-
cuit and become very hot. In the case of lithium batteries, a short
circuit could cause them to explode.
WARNING
Observe battery manufacturer’s guidelines for safe handling and
proper disposal of batteries.

c
NOTE
Please be aware that the most common problem that first time
users of Thermal products encounter is improper utilization of
Calibrate/NUC function. The first step before using the product
should be to properly calibrate the device. To do this please turn
the unit on, close the objective lens with the lens cap and press
the Calibrate/NUC function either as described in 3.2.2.3 or by
holding down both the UP and DOWN buttons at the same time.
Please carefully read 3.2.2.3 as to additional information on Cali-
bration/NUC function.
EQUIPMENT LIMITATIONS
• The Odin detector spectral band (7 to 14 µm) provides a better
penetration through smoke, smog, dust, water vapor etc.
• Infrared radiation does not travel through glass and therefore
the monocular does not sense objects if they are behind a glass
window.

i
TABLE OF CONTENTS
pg.
CHAPTER 1. INTRODUCTION ........................1-1
1.1 General Information ...........................1-2
1.1.1. Scope ....................................1-2
1.1.2. Reports ...................................1-2
1.1.3. Storage ...................................1-2
1.1.4. Warranty Information ........................1-2
1.2. Equipment Description.........................1-5
1.2.1. Equipment characteristics, capabilities
and features ...............................1-5
1.2.2. Location and description of major components ....1-6
1.2.3. Specifications ..............................1-9
1.2.4. Mechanical Functions.......................1-11
1.2.5. Optical Functions ..........................1-11
1.2.6. Electrical Function .........................1-12
CHAPTER 2. ASSEMBLY AND PREPARATION...........2-1
2.1. Preparation ..................................2-2
2.1.1. Preparation for use ..........................2-2
2.1.2. Installation of eyecup ........................2-3
2.1.3. Installation of demist shield....................2-3
2.1.4. Installation and adjustment of headmount ........2-4
2.1.5. Installation of headmount/helmet mount adapter ...2-5
2.1.6. Installation of helmet mount to helmet. . . . . . . . . . . . 2-6
2.1.7. Installation of headmount with protective mask ....2-8
2.1.8. Installation of weapon mount ..................2-9
CHAPTER 3. OPERATION............................3-1
3.1. General Information ...........................3-2
3.1.1. General ...................................3-2
3.1.2. Controls and Indication .......................3-2
3.2. Operating procedure ..........................3-4
3.2.1. Turning On ................................3-4
3.2.2. Menu sets .................................3-4

ii
3.2.3. Hand-held operation ........................3 -11
3.2.4. Head mounted operation ....................3 -11
3.2.5. Helmet mounted operation ...................3-13
3.2.6. Weapon mounted operation ..................3-15
3.2.7. Preparation for storage ......................3-16
CHAPTER 4. MAINTENANCE INSTRUCTIONS...........4-1
4.1. Lubrication Instructions........................4-2
4.2. Troubleshooting procedures....................4-2
4.2.1. Troubleshooting ............................4-2
4.3. Operator’s Maintenance Procedures .............4-5
4.3.1. Cleaning the scope ..........................4-5
4.3.2. Headmount Maintenance .....................4-5
4.3.3. Neck cord maintenance ......................4-7

iii
HOW TO USE THIS MANUAL
• Usage
You must familiarize yourself with the entire manual before operat-
ing the equipment. Read and follow all warning notices.
• Manual Overview
The table of contents includes the paragraph number, paragraph
title, and page number.

1-1
CHAPTER 1
INTRODUCTION

1-2
1.1 GENERAL INFORMATION
1.1.1. SCOPE
This manual contains instructions for use in operating and main-
taining the ATN Odin thermal multi-purpose systems. Throughout
this manual, the ATN Odin will be referred to as the scope or Odin.
1.1.2. REPORTS
Reports from the user on recommendations for improvements are
encouraged. Send reports to the address below.
American Technologies Network Corp.
1341 San Mateo Avenue
South San Francisco, CA 94080
[phone]
[phone]
[phone] fax
[e-mail]
www.atncorp.com
1.1.3. STORAGE
Storage of Odin should be done in the factory packing and after a
thorough PMCS as outlined in Section 4.1. of this manual. This will
ensure the scope remains in mission ready condition during stor-
age. Battery should be stored separately from the scope.
The scope should not be placed on the floor, in any area exposed to
high temperatures or direct sunlight. Presence of acid and alkaline
vapor, as well as of other aggressive admixtures in the air is unac-
ceptable.
1.1.4. WARRANTY INFORMATION
ONE YEAR PRODUCT WARRANTY
This product is guaranteed to be free from manufacturing defects in material
and workmanship under normal use for a period of 1 (one) years from the date
of purchase. In the event a defect that is covered by the foregoing warranty
occurs during the applicable period stated above, ATN, at its option, will either
repair or replace the product, and such action on the part of ATN shall be the
full extent of ATN’s liability, and the Customer’s sole and exclusive remedy.

1-3
This warranty does not cover a product (a) used in other than its normal and
customary manner; (b) subjected to misuse; (c) subjected to alterations, modi-
fications or repairs by the Customer of by any party other than ATN without
prior written consent of ATN; (d) special order or “close-out” merchandise or
merchandise sold “as-is” by either ATN or the ATN dealer; or (e) merchandise
that has been discontinued by the manufacturer and either parts or replace-
ment units are not available due to reasons beyond the control of ATN. ATN
shall not be responsible for any defects or damage that in ATN’s opinion is
a result from the mishandling, abuse, misuse, improper storage or improper
operation, including use in conjunction with equipment which is electrically
or mechanically incompatible with or of inferior quality to the product, as well
as failure to maintain the environmental conditions specified by the manufac-
turer. This warranty is extended only to the original purchaser. Any breach of
this warranty shall be waived unless the customer notifies ATN at the address
noted below within the applicable warranty period.
The customer understands and agrees that except for the foregoing warranty,
no other warranties written or oral, statutory, expressed or implied, including
any implied warranty of merchantability or fitness for a particular purpose,
shall apply to the product. All such implied warranties are hereby and express-
ly disclaimed.
LIMITATION OF LIABILITY
ATN will not be liable for any claims, actions, suits, proceedings, costs,
expenses, damages or liabilities arising out of the use of this product. Op-
eration and use of the product are the sole responsibility of the Customer.
ATN’s sole undertaking is limited to providing the products and services
outlined herein in accordance with the terms and conditions of this Agree-
ment. The provision of products sold and services performed by ATN to
the Customer shall not be interpreted, construed, or regarded, either ex-
pressly or implied, as being for the benefit of or creating any obligation
toward any third party of legal entity outside ATN and the Customer; ATN’s
obligations under this Agreement extend solely to the Customer. ATN’s li-
ability hereunder for damages, regardless of the form or action, shall
not exceed the fees or other charges paid to ATN by the customer or
customer’s dealer. ATN shall not, in any event, be liable for special,
indirect, incidental, or consequential damages, including, but not
limited to, lost income, lost revenue, or lost profit, whether such dam-
ages were foreseeable or not at the time of purchase, and whether
or not such damages arise out of a breach of warranty, a breach of
agreement, negligence, strict liability or any other theory of liability.

1-4
PRODUCT WARRANTY REGISTRATION
In order to validate the warranty on your product, ATN must receive a
completed Product Warranty Registration Card for each unit or complete
warranty registration on our website at www.atncorp.com. Please com-
plete the included form and immediately mail it to our Service Center: ATN
Corporation, 1341 San Mateo Avenue, South San Francisco, CA 94080.
OBTAINING WARRANTY SERVICE
To obtain warranty service on your unit, End-user must notify ATN ser-
vice department by calling 800-910-2862 or 650-989-5100 or via e-mail
[e-mail] to receive a Return Merchandise Authorization
number (RMA). When returning please take or send the product, postage
paid, with a copy of your sales receipt to our service center, ATN Corpora-
tion at the address noted above. All merchandise must be fully insured
with the correct postage; ATN will not be responsible for improper post-
age or, missing or damaged merchandise during shipment. When sending
product back, please clearly mark the RMA# on the outside of the ship-
ping box. Please include a letter that indicates your RMA#, Name, Return
Address, reason for service return, Contact information such as valid tele-
phone numbers and/or e-mail address and proof of purchases that will help
us to establish the valid start date of the warranty. Product merchandise
returns that do not have an RMA listed may be refused or a signifi-
cant delay in processing may occur. Estimated Warranty service time is
10-20 business days. End-user/customer is responsible for postage to
ATN for warranty service. ATN will cover return postage/shipping after
warranty repair to end-user/customer only if product is covered by afore-
mentioned warranty. ATN will return product after warranty service by do-
mestic UPS ground and/or domestic mail. Any other requested, required
or international shipping method the postage/shipping fee will be the re-
sponsibility of the end-user/customer.

1-5
1.2 EQUIPMENT DESCRIPTION
1.2.1. EQUIPMENT CHARACTERISTICS,
CAPABILITIES AND FEATURES
The Odin Series is one of the smallest Thermal Imaging Monocu-
lar Systems today. It features extremely small size and low weight
because of its advanced construction and characteristics using the
latest technologies in high grade polymers to make a Mil. Spec,
system that is identical in size, weight and shape to a AN/PVS-14.
The Odin series is a multi-purpose system using the latest in minia-
ture thermal sensor technology combined with an advanced OLED
Display to provide a superior stable image in a compact and rugged
package. The system also includes an array of features that help
the user to enhance the sight to meet all of their requirements.
The Odin system is designed for hand held, head mounted and
weapon mounted operations. It uses most of the same accessories
as the AN/PVS-14 Night Vision Monocular System.
The Odin is one of the most capable thermal monocular systems
on the market.
The Odin-W Series has the ability to be rail mounted to a light cali-
ber weapon such as a M16 or M4 using the accessory weapon rail
interface adapter.
As with the standard Odin series has the With the ability to use
most accessories for the AN/PVS-14 with the added benefit to be
weapon mounted as well. The Odin-W is user friendly and easy to
learn to use. The system design has been proven effective and reli-
able as well as functional. The Odin-W is a perfect complement to
any user of night vision monocular systems.

1-6
1.2.2. LOCATION AND DESCRIPTION
OF MAJOR COMPONENTS
Included and optional items are shown in Figure 1.1. The major
components are the headmount, helmet mount, monocular, carry-
ing case, and the shipping and storage case.
FIGURE 1.1. COMPONENTS OF ODIN
HEAD/HELMET MOUNT
ADAPTER
HEADMOUNT
THIN
BROWPAD
HELMET MOUNT
(OPTIONAL)
WEAPON MOUNT
(OPTIONAL)
CARRYING
CASE
OPERATOR’S
MANUAL
MEDIUM
AND THICK
BROWPADS
LENS
CLEANING
CLOTH
CARRYING
CASE STRAP
DEMIST
SHIELD
EYEGUARD
BATTERY
NECK CORD
OBJECTIVE
LENS CAP
MONOCULAR

1-7
a. Monocular
The monocular (see Figure 1.2.) consists of various components
such as an objective lens, a thermal core (not shown), an eyepiece
lens and a battery cap.
FIGURE 1.2. MULTI-PURPOSE THERMAL SYSTEM
The monocular also uses the accessories listed below:
Demist Shield – The demist shield (Figure 1.1.) is used to
prevent the eyepiece lenses from becoming fogged.
Sacrificial Window – Please note the PVS14 sacrificial window
will not work with the Odin. Do not attempt to use will not get an
image.
b. Headmount
The headmount (Figure 1.1.) secures the monocular to the opera-
tor’s head for night viewing and provides freehand support for use
with a weapon, protective mask or other purposes. It is adjustable
and cushioned. The thin browpad used for large heads, comes at-
tached to the headmount; the thick and medium browpads, used for
smaller heads are stored in the carrying case.
c. Helmet Mount
This item (Figure 1.1.), secures the monocular to the Personal Ar-
mor System Ground Troops (PASGT) helmet allowing freehand
support for use with a weapon, protective mask and/or other pur-
poses. The new helmet mount is made of a ruggedized metal. The
old one is made of plastic.
OBJECTIVE
LENS
EYEPIECE
LENS
ON-OFF
SWITCH
BATTERY
CAP

1-8
d. Headmount/Helmet Mount Adapter
This item (Figure 1.1.) is attached to the monocular to allow its use
with the headmount or helmet mount. It allows mounting in front of
the left or right eye.
e. Weapon Mount
The weapon mount (Figure 1.1.) adapts the monocular to the re-
ceiver rail as configured for the modular weapon system kit.
f. Carrying Case
The carrying case (Figure 1.1.) is provided for transportation and
protection of the monocular, headmount, battery and accesso-
ries. Two slide keepers are provided for belt attachment and three
D-rings for shoulder and leg strap attachment. A carrying case
strap is also provided which can be attached to the two D-rings on
the back of the carrying case.

1-9
1.2.3. SPECIFICATIONS
The following tables provide information pertaining to the operational, electrical, mechanical, optical and environmental characteristics for the monocular.
Table 1-1. Specifications
ITEM ODIN-31C
ODIN-31CW
ODIN-31D
ODIN-31DW
ODIN-32C
ODIN-32CW
ODIN-32D
ODIN-32DW
ODIN-6WB
ODIN-6WBW
ODIN-61B
ODIN-61BW
Sensor (micro- bolometer)
320 x 240 px 640 x 480 px
Type
Uncooled
Material
Vanadium oxide (VOx)
Frame Rate
30 Hz 60 Hz 30 Hz 60 Hz 30 Hz 30 Hz
Pixel Size
17 mm 35 mm 17 mm 35 mm
Spectral Response
7-14 µm
Pixel Size
17 µm
Optical Magnification
1x 2x 0.5x 1x
E-Zoom
2x, 4x 4x, 8x 1x, 2x, 4x 2x, 4x, 8x
FOV
24° x 18° 15° x 11° 48° x 36° 24° x 18°
Focus Range
0.25 m to infinity
Diopter Adjustment
-6 to +4
Eye Relief 27 mm

1-10
ITEM ODIN-31C
ODIN-31CW
ODIN-31D
ODIN-31DW
ODIN-32C
ODIN-32CW
ODIN-32D
ODIN-32DW
ODIN-6WB
ODIN-6WBW
ODIN-61B
ODIN-61BW
Human Detection 500 m 750 m 500 m 750 m Human Recognition 225 m 300 m 225 m 300 m Human Identification 135 m 180 m 135 m 180 m Vehicle Detection 1100 m 1650 m 550 m 1650 m Vehicle Recognition 495 m 660 m 495 m 660 m Vehicle Identification 300 m 400 m 300 m 400 m Multiple Reticles to Choose From
ODIN-31CW
only ODIN-31DW
only ODIN-32CW
only ODIN-32DW
only ODIN-6WBW
only ODIN-61BW
only
Image Size (output resolution) 800 x 600 px Polarity control White hot / Black hot / Multiple Color Modes Start up time <4 s Waterproof Waterproof / Dustproof Battery type 1 x 3V, CR123A Lithium battery type Battery Life >2 hrs Weight 0.77 lb /0.35 kg
Dimensions 3.40” x 2.20” x 1.95” / 87 mm x 56 mm x 50 mm
* ATN reserves the right to change the above specifications at any time without notice

1-11
1.2.4. MECHANICAL FUNCTION
The mechanical adjustments of the Odin sights allow for physical
differences between individual operators using the system. The
scope functions include the ON-OFF switch, UP button, ENTER
button, DOWN button, video-out, eyepiece diopter adjustment ring,
battery compartment cover, mounting thread. The mechanical con-
trols are identified in Figure 1.3.
FIGURE 1.3. MECHANICAL CONTROLS
1.2.5. OPTICAL FUNCTIONS
The optical functions include an objective lens, thermal imaging
detector and eyepiece. Infrared energy is emitted proportionally
to the temperature of an object. The warmer the object, the more
energy it emits. The infrared energy from the objects is focused by
the optics, onto an infrared detector. The information from infrared
detector is passed to electronics for image processing. The signal
processing circuitry translates the infrared detector data into an im-
age that can be viewed on the built-in OLED display. The image is
observed through an eyepiece by operator.
EYEPIECE DIOPTER
ADJUSTMENT RING
FRONT LENS
ASSEMBLY/
VARIABLE PIVOT
TECHNOLOGY
ON-OFF SWITCH
VIDEO-OUT
MOUNTING THREAD
BATTERY CAP ENTER BUTTON
RUBBER
EYECUP
UP BUTTON
DOWN BUTTON

1-12
1.2.6. ELECTRICAL FUNCTION
The electronic circuit is powered by replaceable battery – one 3 V
Lithium battery (CR123A type battery).
Power from the battery is supplied to the components through the
OFF-ON switch.
