PS-7 WITH ATN FLIP-UP HEAD MOUNT PS-7 WITH MIL-SPEC HEADGEAR PS-7 WITH MICH HELMET MOUNT PS-7 WITH 3X AFOCAL LENS
NIGHT VISION GOGGLES
HEAD/HELMET MOUNTED FOR HANDS-FREE USE
COMPACT AND LIGHTWEIGHT
BUILT-IN INFRA-RED ILLUMINATOR
ATN PS-7 is a full robust, dependable, high performance night vision goggles.
This model is designed to assist viewing and provide reliable service in the most
unfavorable conditions. High-resolution image intensifier, auto-brightness, and
bright light shut-off. Dual focus built-in IR allows operator instantaneously adjust
from map/document reading mode to indoor/cave flood mode. Infrared operation
and low battery indicators are displayed within the user’s field of view. The ATN
PS-7 comes complete with a lightweight, fully adjustable military head strap that
allows for comfortable long-term use.
STANDARD ACCESSORIES include:
Flip-up Head Mount Assembly - Allows for hands-free operation
Eye Cups - Prevents the emission of stray light or facial reflections
Soft Carrying Case - Provides convenient storage
Microfiber Lens Cleaning Cloth - Used to safely clean the objective and
eyepiece glass surfaces
Day Light Filter - Filters excessive light. Protects objective lens from the
elements
Sacrificial Window - Shields the optics from sand, air particles, or anything
that may scratch the lens
Demist Shields - Snaps onto the eyepiece to prevent condensation from
forming on the optics
Operator’s Manual - Instructional user’s guide
Batteriy - One (1) 3V Lithium CR123A or one (1) 1.5V AA type
Lightweight, compact rugged goggle system
Multi-purpose: hand-held, head-mounted, helmet-mounted
Comfortable, flip-up headgear
Multi-coated all-glass optics
Dual Focus infrared illuminator
Wide angle infrared illuminator
Waterproof
Manual gain control (optional)
3x, 5x and 8x lenses available (optional)
Limited Two-Year Warranty
Export Warning: These products are subject to one or more of the export control laws and regulations of the U.S. Government. Pending the model these products are under the control jurisdiction of
either the US Department of State or the US Bureau of Industry and Security US Department of Commerce. Export without proper licensing or consent is strictly prohibited.
1341 San Mateo Ave,
South San Francisco, CA 94080.
Tel: [phone],
fax: [phone]
www.atncorp.com
e-mail: [email protected], [email protected]
ATN PS-7
Magnification 1x
Lens System F1.2, 27 mm
Exit Pupil 12 mm
Eye Relief 16 mm
Interpupillary distance 58 to 72 mm
FOV 40°
Range of Focus 0.25 m to infinity
Diopter Adjustment -6 to +2
Controls Direct
Automatic Brightness Control Yes
Bright Light Cut-off Yes
Automatic Shut-off System Yes
Infrared Illuminator Built-in, with Flood & Spot modes
IR Indicator Yes (in FOV)
Low Battery Indicator Yes (in FOV)
Power Supply 1 x 1.5 V AA type battery or 1 x 3 V
CR123A type battery
Battery Life 60 hrs
Environmental Rating Waterproof
Operating Temperature -40 to +50 °C
Storage Temperature -50 to +70 °C
Dimensions 165x75x117 mm / 6.5x2.9x4.5”
Weight 0.48 kg / 0.9 lbs
SPECIFICATIONS
