ATN ots-14 User manual

THERMAL IMAGING SYSTEM
1341 San Mateo Ave,
South San Francisco, CA 94080.
Tel: [phone],
fax: [phone]
www.atncorp.com
e-mail: [email protected], [email protected]
OTS14
The OTS-14 is a thermal system intended for law enforcement, military
and commercial uses. It is built around state-of-the-art uncooled thermal
imaging technology, highly integrated DSP-based electronics and a compact,
lightweight system.
The OTS-14 thermal monocular provides excellent image quality which is
unaffected by lights or shadows that seriously hamper the image quality of
image intensifier night vision. Total darkness, camouflage or bright lights will
not affect the sensitivity of these units.
The included and optional accessories provide for the versatility of the
monocular. You can put it on a headset or on a helmet, it can be connected
to another monocular to build a binocular system etc.
The ATN OTS-14’s superior performance, compact size, comfort of wear
and cost efficiency make it the perfect thermal imaging device.
High resolution digital thermal imaging
Compact, lightweight and durable housing
Head/helmet mountable for hands-free use
Video and computer output
Black/white and color modes
LCD Recorder (optional)
Waterproof
One-Year Warranty
Export Warning: These products are subject to one or more of the export control laws and regulations of the U.S. Government. Pending the model these products are under the control jurisdiction of
either the US Department of State or the US Bureau of Industry and Security US Department of Commerce. Export without proper licensing or consent is strictly prohibited.
OTS14 BASIC KIT
HAND HELDMONOCULAR
WITH LCD RECORDER
HEAD MOUNTASSEMBLY
BINOCULAR
Magnification 1.8X
Objective Focal Length 25 mm
FOV 11° x 8°
Focus Range from 1m to infinity
Focus Adjustment Manual
Exit Pupil 14mm
Eye Relief 25mm
Detector Type Uncooled Microbolometer
Spectral Response 7-14 μm
Pixels 160 x 120
Pixel Size 30 x 30 μm
Angular Resolution, mrad 1.2
Thermal Sensitivity < 0,1°C
Range to Detect a Human 475 m
Output Format Analog PAL / NTSC
Display Color OLED matrix
Display Format SVGA, 852 x 600 pxl
Digital ZOOM Fixed 2x (optional 5x)
Brightness Adjustment Manual
Contrast Adjustment Automatic
Available User Interfaces From outside PC through USB
interface
Power Supply 2 x 3 V CR123A type battery
Start-Up Time < 3 sec
Operating Time w/one battery pack 4 hrs
External Power Supply DC 6V, 500 mA
Operating Temperature Range from -20°C to +50°C
Waterproof Yes, up to 10m submersion
Dimensions 118 x 81 x 52 mm
Weight (w/batteries) 0.34 kg
SPECIFICATIONS
OTS-14
Hard Storage Case
Soft Carry Case
Head Gear
RCA Video/power adapter
2 x 3V CR123A type battery
Manual
