ATN FIITS14 User manual

FIITS14 SYSTEM
COMPONENTS
1341 San Mateo Ave,
South San Francisco, CA 94080.
Tel: [phone],
fax: [phone]
The FIITS system by ATN combines Image
Intensification and Infrared Thermal Imaging technologies
for night time low light and adverse weather conditions
observation. This is achieved by combining an advanced
image intensification system with a thermal imaging
system.
The combination of the channels allows the user to
take full advantage of both technologies by dichoptically
creating a “Fused” image for enhanced night vision
observation.
The results are a fused image that allows you the
benefits and capabilities of both technologies. You will be
able to detect both the Image Intensified Night Vision
scene and the Thermal Imaging scene so you will not miss
anything that you would have been unable to see by either
technology separately.
The FIITS is lightweight, portable, and can be used as
a handheld binocular or a dual eye goggle.
Export Warning: These products are subject to one or more of the export control laws and regulations of the U.S. Government. Pending the model these products are under the control jurisdiction of
either the US Department of State or the US Bureau of Industry and Security US Department of Commerce. Export without proper licensing or consent is strictly prohibited.
www.atncorp.com
e-mail: [email protected], [email protected]
High resolution imaging
Compact, light weight and durable housing
Head/helmet mountable for hands free
usage
High Quality optics
“Fused” image for enhanced night vision
observation
Handheld binocular or a dual eye goggle
usage
Waterproof
FIITS14 w/HPT IIT
FUSION THERMAL/NIGHT VISION SYSTEM
HELMET MOUNT
ASSEMBLY
HEAD MOUNT
ASSEMBLY

1341 San Mateo Ave,
South San Francisco, CA 94080.
Tel: [phone],
fax: [phone]
Export Warning: These products are subject to one or more of the export control laws and regulations of the U.S. Government. Pending the model these products are under the control jurisdiction of
either the US Department of State or the US Bureau of Industry and Security US Department of Commerce. Export without proper licensing or consent is strictly prohibited.
www.atncorp.com
e-mail: [email protected], [email protected]
FIITS14 w/HPT IIT
FUSION THERMAL/NIGHT VISION SYSTEM
THERMAL SPECIFICATIONS
Magnification 1X
Objective Focal Length 25 mm
FOV 11° x 8°
Focus Range from 1m to infinity
Focus Adjustment Manual
Exit Pupil 14 mm
Eye Relief 25 mm
Detector Type Uncooled Microbolometer
Spectral Response 7-14 µm
Pixels 160 x 120
Pixel Size 30 x 30 µm
Angular Resolution, mrad 1,2
Thermal Sensitivity < 0,1°C
Range to Detect a Human 475 m
Output Format Analog PAL / NTSC
Display OLED matrix
Display Format SVGA, 852 x 600 pxl
Color Monochrome
Digital ZOOM Fixed 2x (optional 5x)
Brightness Adjustment Manual
Contrast Adjustment Automatic
Available User Interfaces From outside PC through
USB interface
Power Supply 2 x 3V, 123Atype
Start-Up Time < 3 sec
Operating Time
w/one battery pack 4 hrs
External Power Supply DC 6V, 500 mA
Operating Temperature
Range from -20°C to +50°C
Waterproof Yes, up to 10 m submersion
Dimensions 195 x 78 x 100 mm
Weight (w/batteries) 0,74 kg
1X
F1.2, 25 mm
14 mm
25 mm
Left or Right
40 deg.
0,25 m to infinity
from -6 to +6
Yes
Yes
Digital
Built-in Rotary Select -
Flood & Spot
20 meters
Led On/ Battery Low
0.34 kg
120 x 49 x 69 mm
Waterproof 20 m, 1 hr.
-40 to +50°C
-50 to +70°C
YES
30 hrs. (AA), 60 hrs.
(3 V, Lithium)
30 hrs. (3 V, Lithium)
(1) 3 V Lithium, or (1) AA
Alkaline
Complies
20 m for 1 hr
NIGHT VISION SPECIFICATIONS
Magnification
Lens System Element
Exit Pupil
Eye Relief
Eye Use
FOV
Range Of Focus
Diopter Adjustment
ABC- Automatic Brightness
Control CUT-OFF To Protect
Image Intensifier Tube
Bright Light Indicator
Controls
Infra-red Illuminator
IR Illumination Range
IR Indicator
Weight w/ Battery
Dimensions
Environmental Rating
Operation Temperature
Storage Temperature
Flip Up Headset w/
Automatic System Off
Battery Life w/o IR ON
Battery Life w/ IR ON
Power Supply
MIL-SPEC 810 Standards
Waterproof
FUSION SYSTEM SPECIFICATIONS
Magnification 1X
Focus Adjustment Manual
Eye Relief 25mm
Dimensions 130 x 130 x 78 mm
Weight (w/batteries) 0,75 kg
TUBE SPECIFICATIONS
HIGH QUALITY HPT GEN IMAGE INTENSIFIER TUBE
Photocathode Type
Generation
Resolution, lp/mm*
Signal to Noise Ratio*
Figure of Merit
MTTF - Mean Time Before
Failure, hours
Export
Multi - Alkali
HPT
54-72
16-24
1600 Typical
10,000
N/A for Export
* Specifications are provided for informational purposes only.
Actual values may vary
