ATN IR850 Supernova User manual

user’s guide
Important Export Restrictions! Commodities, products, tech-
nologies and services contained in this manual are subject to
one or more of the export control laws and regulations of the US
BIS-Department of Commerce, Export Administration Regula-
tions. It is unlawful and strictly prohibited to export, or attempt to
export or otherwise transfer or sell any hardware or technical data
or furnish any service to any foreign person, whether abroad or in
the United States, for which a license or written approval of the U.S.
Government is required, without first obtaining the required license
or written approval from the Department of the U.S. Government
having jurisdiction. Diversion contrary to U.S. law is prohibited.
LONG RANGE INFRA-RED ILLUMINATOR
USER’S GUIDE (IR850 SUPERNOVA) REVISION 1 – FEBRUARY, 2018
ATN IR850 Supernova

INTRODUCTION
Congratulations on choosing the ATN IR850 Supernova; an extremely power-
ful, long range infra-red illuminator that is perfect for hunting, law enforcement,
search and rescue, and military use.
Before using your IR850 Supernova, please read this manual carefully. Also,
refer to the troubleshooting tips for any issues/problems.
Windage
adjustment
dial
Brightness
control ring Adjustable
Mount
Elevation
adjustment
dial
Neck
Battery
tube Tail cap
Grip
ring
Head
Bezel
SPECIFICATIONS
Wavelength, nm 850
Beam Angle, deg 5
Operating Tempe-
rature Range, °C –20° to +40
Battery type
18650R rechargeable; 3,7 V Lithium Ion
Output Four levels (mW): 5% 90, 30% 660,
70% 1540, 100% 2200
Runtime 5% at 60 h, 30% at 28 h, 70% at 7 h, 100% at 3.5 h
Lens Aspherical glass
Material Constructed using aircraft grade aluminum
Surface Hard anodized finish, highly durable
Waterproof IPX8 standard
Dimensions, mm 176 (length) x 70 (head) x 27 (tail)
Weight, g 335
Color Black
* ATN reserves the right to change the above specifications at any time without notice.

FEATURES
• Constructed from aircraft grade aluminium.
• Surface: hard anodized finish, highly durable.
• LED: Using high power emitter with a long lifetime.
• Waterproof to IPX8 standard.
• Four modes of operation.
• Flawless white beam.
• Uses single lithium 18650 battery.
• Removable grip ring.
• Easy rail mounting system.
• Accessories: battery charger.
• One-year Warranty.
TIPS WHEN FIRST USING
Remove the tailcap, insert a 18650 battery, positive of the battery towards
the head.
NOTE: Please hold the battery tube (not the brightness control ring
or neck) when tightening/loosing the tail-cap.
BATTERY
The IR850 Supernova is available use single 18650.
1. Unscrew the Tail cap from the Battery Tube, until it is free.
2. Place Battery within the Battery Tube, observing proper battery polarity.
3. Screw the Tail cap to the right.
NOTE: Do not use two or more rechargeable lithium batteries in series.
Tail cap
Battery tube Battery (18650)

M O D E S
The IR850 Supernova has 4 stage output-Low at 5%-30%-70%-100%.
These modes can be accessed by turning the brightness control ring.
Low output setting Medium output setting High output setting
FOCUS
Turn the light to maximum out-
put and shine it on a wall 8~10 m
away. To focus the beam, hold the
lens head in one hand and turn the
battery tube with your other hand.
Turn clockwise or counter-clock-
wise till the focus is to your liking.
ADJUSTABLE
MOUNT
Attach the IR850 Supernova,
adjust the mount as follows:
1. Unscrew the four screws [1]
securing the top of the bracket [2]
and the bottom [3] half of the ad-
justable mount.
2. Place the top and lower parts
of the adjustable mount around
the IR850 Supernova.
3. Using an Allen wrench, se-
cure the four screws [1]. Do not
apply excessive torque.
1
2
3

ADJUSTMENT
To adjust the windage and ele-
vation, the two round dials must
be turned/adjusted.
The round dial on the left is
your elevation adjustment. The
flat dial is your windage adjust-
ment.
Adjust each dial until your IR
light is centered with your pic-
ture.
MAINTENANCE
To prevent wear and retain water-resistance it is a good idea to lubricate
the threads and o-rings if they become dry.
CHANGE SWITCH COVER
Unscrew the switch cover retaining ring use a forceps (or round nose pli-
ers). Then replace the switch cover and replace the retaining ring.
TROUBLESHOOTING
Light Doesn’t Turn On
Battery tube does not tightened against the Neck or the tail-cap does not
tightened.
Light Dimming
1. Battery may be faulty. Try another fully charged battery.
2. Battery may need charging. Charge your battery, and retry.
Elevation
adjustment
dial
Adjustable
Mount
Windage
adjustment
dial

For customer service and technical support, please contact
American Technologies Network Corp.
1341 San Mateo Avenue, South San Francisco, CA 94080
phone: [phone]
e-mail: [e-mail]
www.atncorp.com
©2018 ATN Corporation
