Larson Electronics SLEDB-110V-M User manual

SLEDB-110V-M
Larson Electronics, LLC Phone: [phone] Fax: [phone] www.larsonelectronics.com
1of 2
Magnetic Mount 110 Volt Strobe Light
88 Flashes per Minute - 360° Illumination - 5' Cord w/ Plug
Instruction Manual
Thank you for your purchase of the Larson Electronics SLEDB-110V-M series Strobe Light. This strobe light is completely
assembled, tested and ready for installation when shipped from the factory. Please follow the steps below in order to
operate and maintain this product.
IMPORTANT
READ CAREFULLY BEFORE OPERATING THIS FIXTURE. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE. IF UNSURE ABOUT ANY
PART OF THESE INSTRUCTIONS, CONSULT A QUALIFIED ELECTRICAL PROFESSIONAL.
WARNING: OPERATE ONLY AT THE VOLTAGE LISTED ON THE PRODUCT. DO NOT OPERATE IN CLOSE PROXIMITY OF COMBUSTIBLE
OR FLAMMABLE MATERIALS. NEVER LOOK DIRECTLY AT LIGHT WHEN ON.
WARNING: CONSULT A QUALIFIED ELECTRICAL PROFESSIONAL/ELECTRICIAN TO INSTALL THIS DEVICE IN ACCORDANCE WITH
APPROPRIATE LOCAL AND NEC CODES AND REGULATIONS.
WARNING: TO BE INSTALLED AND/OR USED IN ACCORDANCE WITH APPROPRIATE ELECTRICAL CODES AND REGULATIONS.
WARNING: DEVICE IS SUITABLE FOR INSTALLATION IN WET LOCATIONS; GFCI PROTECTION RECOMMENDED.
WARNING: ALTHOUGH FIXTURE IS WATERPROOF, IT IS NOT DESIGNED OR INTENDED TO BE SUBMERGED.
WARNING: DO NOT ALLOW LINE VOLTAGE WIRES TO BECOME SUBMERGED!
•ALL OUTDOOR INSTALLATIONS AND INDOOR INSTALLATIONS NEAR A WET LOCATION REQUIRE THE USE OF A GFCI DEVICE FOR
SAFETY, ACCORDING TO THE NATIONAL ELECTRICAL CODE® (NEC).
•KEEP AWAY FROM FLAMMABLE OBJECTS. DO NOT POSITION WITHIN ONE (1) INCH OF ANY COMBUSTIBLE MATERIALS.
•IF DROPPED OR DAMAGED, THE UNIT MAY NO LONGER BE WATERPROOF AND SHOULD BE REPLACED.
•TO AVOID HAZARDS TO CHILDREN, ACCOUNT FOR ALL PARTS AND DESTROY PACKING MATERIALS.
INSTALLATION
This unit comes pre-assembled with the selected color from factory. Follow the steps below for installing and
maintaining the strobe light.
MOUNTING
Mount beacon to any flat surface capable of holding its weight utilizing the preinstalled 200 lb. grip magnetic
base. Mount in any direction. Run cable and connect to compatible power source following all local, state,
national NEC codes.
WIRING
Cord cap is configured during purchase. For units configured with flying
leads, we strongly encourage a licensed electrician install this product,
especially in outdoor locations where weatherproofing may be required.
Voltage driver permits operation at 110-120V AC 60Hz.
Make sure deutsch plugs are connected from power cord to light.
Warning: Check product label for correct input voltage!
Attach supply line wires to the appropriate light fixture
wires as shown in the diagram
Take precautionary steps for weatherproofing all
connections if installed in a location where water may
come in contact with the unit. Ensure the unit is properly
grounded.
If top light output is not required, a circular piece of reflective tape is included to increase visibility to the sides.
Simply remove colored lens held in place by four screws, peel off paper revealing the adhesive side, and stick
reflective tape to the top of lens from the inside with the reflective side facing down, toward the light.
COLOR MAY VARY
DEUTSCH CONNECTOR

SLEDB-110V-M
Larson Electronics, LLC Phone: [phone] Fax: [phone] www.larsonelectronics.com
2of 2
FLASH TUBE REMOVAL
WARNING: Risk of Electric Shock. Lamp MUST be removed from power source and discharged prior to
performing maintenance!
Flash tube is easily removed by inserting a flat blade screwdriver between socket and tube and prying upward,
working around the base of the tube.
MAINTENANCE
If the lens becomes dirty, wipe down with a mild soap and water solution.
It is recommended to occasionally inspect the unit for any defects and to ensure the cable is not frayed and is
gripping tightly in all points of cable contact.
WARRANTY
These instructions may not cover all details or variations of this product for your equipment or installation requirements.
Should further information not covered by these instructions be required, please contact Larson Electronics at
1-800-369-6671 or email [e-mail] for further assistance.
Please visit larsonelectronics.com for Warranty and Return information.
