Atoll Electronique AM400 User manual

CONNECTINGS :
Rear view of Appliance :
1) Left Speaker Output 7) Left Analog Input
2) Right Speaker Output 8) Input type elector :
3) On/Off Switsh and general - Line : button pushed off
plug In (with protection fuse) - XLR : button pushed on
4) Left Analog Output 9) Left XLR Input
5) Right Analog Output 10) Right XLR Input
6) Right Analog Input 11)Switsh for Mono bridge
DETAILS OF FUNCTIONS :
Front view of Appliance :
12) Led indicator of switsh On/Off.
13) Led indicator of mono bridge : Led is ON when the power Amp have been
activated on MONO before general switsh on.
14) Led indicator of XLR Input mode : the LED switshes on if the button (8) on the
rear of the AM is on XLR position.
ADVISES :
-To optimise the performances of your amplifier, you should switch it on at least
half an hour before any listening, the time for power stage to reach their ideal
working temperature. Between two uses, it is better to let it on stand-by position, so
that the power stages remains at their optimal temperatures.
-We advise you to use good wires to link with the other elements (CD player,
loudspeakers…). Don't hesitate to take advisesfrom your dealer.
MODE BRIDGE MONO
Careful : Switsh OFF your appliance before using this mode.
You can transform your AM400 power amplifier as a mono bridge amplifier.
Activate the Switsh (11) at the rear of the appliance on MONO. PRE-OUT Outputs
of the preamp must be connected to the Right Inputs of each Amplifier.
For each Amplifier, terminal + (red) of the Right Output (1) has to be connected to
the terminal + (red) of the speaker and terminal + (red) of the Left Output (2) to the
terminal – (black) of the speaker.
Wiring of the speakers will be the same while using RCA or XLR cables.
INTER-CONNECT
(Configuration : 1 Preamp and 2 power Amplifiers mono bridged)
1
4
5
3
2
6
8
9
11
7
10
1
2
1
3
1
4
Amplifier
for Left
channel
Amplifier
for Right
channel
Left
Speaker
Right
Speaker
RCA links
XLR links
Switch sur MONO

E.C. MARKING :
E.C. marking certified the conformity with low tension directive 73/23/CEE, directive
CEM 89/336/CEE and national transpositions.
CLEANING:
Before any cleaning, switch off your amplifier (9). Use a soft and dry rag to clean up
the appliance. Never use acetone, white-spirit, ammoniac, or any kind of product
containing abrasive agent. Never try to clean up inside the appliance.
GUARANTEE :
The guarantee is two years long from date of purchase. We recommend you to ask
your dealer to fill the guarantee and to conserve it. The guarantee is only available for
appliance which have been use correctly.
TECHNICAL DATAS AM400
Efficacypower Wrms / chanel / 8 • (230v)
Efficacy power Wrms / chanel / 4 • (230v)
Efficacy power on bridge mono/ 8 •
Supplies :
Total of capacitors :
Number of Inputs :
Input Impedance :
Sensibility :
signal/noise ratio :
Distortion at 1kHz :
Bandwidth:
Rising time :
Dimensions :
Weight :
160 W
300 W
600 W
1015 VA
111 300 µF
1 line (+ 1 out)
1 XLR
220 k•
1,7 V
100 dB
0,005%
5Hz-200kHz
1,5µs
440*130*370mm
19 Kg
ATOLL ELECTRONIQUE®is a French Company who conceive, manufacture and
commercialise all its products.
You have just bought an amplifier with exceptional audiophile
performance. We really thank you for your confidence in our
products. To get the best part of your amplifier, please read
carefully this manual.
CAUTIONS :
-Put your amplifier in a dry and well ventilated place, far from
source of heat;
-Do not put something on your amplifier;
-Do not make any plug in when the amplifier is on;
-Avoid any short-cut;
-Respect polarity + & -and switch left & right;
-Do not plug in two speakers in parallel on the same output.
You will find enclosed :
-a power amplifier AM400 ;
-one powerlead;
-this manual with the certificate of guarantee.

"GUARANTEE
To present to your dealer with the invoice when returning back the
appliance:
Model AM400
ATOLL ELECTRONIQUE®
Bd des Merisiers
50370 BRECEY
FRANCE
Dealer Stamp
Date of purchase :
Place of purchase :
Buyer signature :
OWNER’S MANUAL
Stereo Power Amplifier
AM400
ELECTRONIQUE
