Atoll Electronique MA100 User manual

CONNECTING:
Rear view of appliance:
1- Speakers Output (Right) 5- Analog Output
2- Speakers Output (Left) 6- Trigger 12V Input
3- Mono switch 7- Power plug
4- Analog Input 8- On/Off Power Switch
Front view of appliance:
9- Mode Mono led indicator
10- Power On/Off led indicator
MONO MODE:
Your appliance can be switch on a mono power amplifier. Here are the steps
to switch it on mono:
-Switch off and unplugged all cables of your amplifier;
-(a) Put the Switch (3) to MONO (on the Left)
-(b) Plug the signal (from preamp.) into the AMPLI IN (White)
-(c) Make a link (cable) between Line In (4) (red) and Line Out (5) (white);
-Link the Speaker as shown below:
(d) Left Red Output to Black Input of the speaker.
(e) Right Red Output to Red Input of the speaker;
-Do the same way for the second Mono amplifier for the other speaker;
TRIGGER INPUT:
This input allows the control ON/OFF of your amplifier simultaneously to
any device with a 12V trigger outlet. To make the system operating, the
ON/OFF switch of your MA100 must remain OFF (position (0)). If the
switch is ON (position I), the amplifier will work but not the trigger function.
Trigger cable must be a Male to Male STEREO jack plug 3.5mm (1/8”)
1 2
3 4 5 6 7 8
Speaker (a) (c)
(e)
(d) (b)
9 10

E.C. MARKING:
E.C. marking certified the conformity with low tension directive
73/23/CEE, directive CEM 89/336/CEE and national transpositions.
CLEANING:
Before any cleaning, switch off your amplifier. Use a soft and dry rag to
clean up the appliance. Never use acetone, white-spirit, ammoniac, or any
kind of product containing abrasive agent. Never try to clean up inside the
appliance.
GUARANTEE:
The guarantee is two years long from date of purchase. We recommend
you to ask your dealer to fill the guarantee and to conserve it. The
guarantee is only available for appliance which has been use correctly.
TECHNICAL DATAS:
(Datas are subjects to changes)
You have just bought a power Amplifier MA100, with exceptional
audiophile performances. We really thank you for your confidence in our
products. To get the best part of this product, please read carefully this
manual.
CAUTIONS:
- Put your amplifier in a dry and well ventilated place, far from
source of heat;
- Do not put something on your amplifier;
- Do not make any plug in when the amplifier is on;
- Avoid any short-cut;
GENERAL ADVISES:
-To optimise the performances of your amplifier, you should switch it on at
least half an hour before any listening, the time for power stage to reach
their ideal working temperature. Between two uses, it is better to put the
stand-by position, so that the power stages remains at their optimal
temperatures.
-We advise you to use good wires to link with the other components
(preamplifiers…). Don't hesitate to take advises from your dealer.
-Your Amplifier is equipped with a temporised switch on. A relay protects
loudspeakers on output power stage from over-voltage.
You’ll find enclosed:
- A power amplifier MA100 ;
- a powerlead ;
- this manual with the certificate of guarantee.
Datas
MA100
Power Watts RMS / 8 ohms (230V):
Power Watts RMS / 4 ohms (230V):
Impulse Power:
Power Supply:
Total of capacitors:
Number of inputs:
Input Impedance:
Sensitivity:
Rate signal/noise:
Distortion at 1 kHz:
Frequency response:
Rise time:
Dimensions:
Net Weight:
2x60 W (Mono : 1x150W)
2x80 W (Mono : 1x165W)
100 W
170 VA
16 600 µF
2
110 kOhms
1,68 V
100 dB
0,05 % / 10W
5 Hz –200 kHz
2 µs
320x230x83 mm
4 kg


G U A R A N T E E - MA100
To present to your dealer with the invoice when returning back the
appliance:
ATOLL ELECTRONIQUE®
Bd des Merisiers
50370 BRECEY
FRANCE
Dealer Stamp
Date of purchase:
Place of purchase:
Buyer signature:
OWNER'S MANUAL
POWER AMPLIFIER
MA100
