Atomos X-Rite User manual

QUICK START GUIDE
X-RITE CALIBRATOR

CALIBRATING THE DISPLAY
Downloading and using the software
1. Download the Atomos Calibrator software from our support site.
> www.atomos.com/support
2. Unzip the software and open the installer program.
3. Click Next on the welcome screen. Tick the check box to agree to the terms of the
software and press Install. Click Finish once the software is installed.
4. Ensure the Xrite devices is connected before you start the calibration software.
5. Open the software from the Application folder or the Desktop Shortcut.
6. When the X-Rite i1 is detected, press calibrate to start the process.
7. The Status will change from Idle to reect the progress of the calibration.
8. Once complete a message box will appear, press OK and close the installer.
9. Calibration process now complete.
QUICK START GUIDE
X-RITE CALIBRATOR

CHEKLIST
Supported Atomos Devices:
www.atomos.com/where-to-buy
q Ninja V
q Shogun 7
q Shogun Studio 2
q Shinobi / Shinobi SDI
q Sumo19
q Ninja / Samurai Blade
q Ninja Assassin / Shogun
q Ninja / Shogun Flame
q Shogun Inferno
q Shogun Studio
DOWNLOAD THE FULL ATOMOS CALIBRATION SOFTWARE
www.atomos.com/support
QUICK START GUIDE
X-RITE CALIBRATOR
q X-Rite i1 Display Pro or Pro Plus Calibrator unit
(Only the full retail version of the i1 Display Pro / plus are supported)
Important Note: Rev.A-02 of the i1Display Pro Calibrator unit is not
supported by Atomos Calibrator 2 software.
q Atomos USB to Serial LANC cable (ATOMCAB004)
(Available separately from your Atomos Local Reseller)

GETTING STARTED
Setting up the connections
Turn on the Atomos unit and connect the USB to Serial LANC cable into the
LANC/REMOTE port and the USB plug into a Windows PC or Mac.
LANC
USB
QUICK START GUIDE
X-RITE CALIBRATOR
Locate the remote port
on your device (Ninja V
and Shogun 7 shown
here). Position of Remote/
LANC port varies for other
Atomos devices. Look for
the remote label or LANC
symbol.
Ninja V Shogun 7

CONNECTING THE X-RITE I1 DISPLAY PRO:
• Plug the USB cable from the i1 into a
Windows PC or Mac before stating the
calibration software.
• Rotate the protective cover of the X-Rite
i1 Display Pro to reveal the glass.
• Place the X-Rite i1Display Pro on the
LCD display of the Atomos device.
• The round foam pad around the i1’s
sensor must sit at on the LCD to ensure
that no light can enter.
NOTE: The X-Rite i1Display Pro must
remain stationary while the calibration
process is occurring.
USB
QUICK START GUIDE
X-RITE CALIBRATOR

For detailed instructions and important up-to-date information regarding the calibration please visit the Atomos support site.
www.atomos.com/support
