Atop Fast Ethernet Media Converter series User manual

Fast Ethernet Media Converter
1 UTP Port & 1 Optical Port
User’s Manual
ATOP TECHNOLOGY
Tel: [phone]
Fax: [phone]
Email: [e-mail]
Web: www.atoptechnology.com
FCC Warning
The 10/100M Fast Ethernet Media Converter series
have been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC
Rules. These standards are designed to provide
reasonable protection against harmful interference when
these devices are operated in a commercial environment.
These devices can generate, use, and radiate radio
frequency energy and may cause harmful interference to
radio communications unless installed in accordance with
this User’s Guide. Operation of these devices in a
residential area is likely to cause harmful interference
which will make the user responsible for the appropriate
remedial action at his/her own expense.
CE Mark Warning
These are Class A products. In a domestic
environment these products may cause radio
interference in which case the user will need to consider
adequate preventative methods.
1. Packing list
The box should contain the following items:
- The Media Converter
- AC-DC Power Adapter
- The User’s Manual
- Warranty Card
Please notify your sales representative immediately if any
items are missing or damaged.
2. Overview
The 10/100M Fast Ethernet Media Converter series are
designed to meet the massive needs for network
deployment and able to extend a copper based fast
network via fiber cable to a maximum distance up to
120km.
Our 10/100M Fast Ethernet Media Converter series are
fully compliant with IEEE802.3, IEEE802.3U,
10/100Base-TX, 100Base-FX, standards. They can be
installed into a Standard Converter Chassis. The
installation & operation procedures are simple &
straightforward. Operation status can be locally monitored
through a set of Diagnostic LED located in the front panel.
Features:
10/100Base-TX to 100Base-FX Converter
Standards: IEEE802.3 10Base-T ,
IEEE802.3u 100Base-TX/FX
Interface: 1 RJ-45 Port & 1 Optical Port (SFP or 1X9)
Flow Control: IEEE802.3x flow control for full duplex
mode. Back-pressure flow control for half duplex mode.
LED: Fiber-Link, Fiber-Duplex, Fiber-Fault, T.P.-Link,
T.P.-Duplex, T.P.-100/10M

3. Installation
Attach fiber cable from the media converter to the
fiber network. The fiber connections must be matched
between transmit socket and receive socket, the TX,
RX fiber cable must be paired at both ends.
Attach a UTP cable from the 10/100BASE-T network
to the RJ-45 port on the media converter.
Connect the power adapter to the media converter.
The Fiber-Link and T.P.-Link LEDs will light up when
all the cable connections are satisfactory.
4. LED Description
LED Status Description
ON Linked on fiber port
FLASH Activity
Fiber-Link
OFF Not linked
ON Linked on UTP port
FLASH Activity
T.P.-Link
OFF Not linked
ON Fiber port works in full duplex
mode
OFF Fiber port works in half duplex
mode
Fiber-Duplex
FLASH Half & collision happens
ON UTP port works in full duplex
mode
OFF UTP port works in half duplex
mode
T.P.-Duplex
FLASH Half & collision happens
FLASH Far end fault pattern received
Fiber-Fault OFF Far end fault pattern not
received
ON 100Base-TX
T.P.-100/10M OFF 10Base-T
5. Technical Specifications
zStandard Protocol: IEEE802.3 10Base-T
IEEE802.3u 100Base-TX/FX
zConnector: 1 RJ-45 & 1 optical port ( SFP or 1X9)
zOperation mode: full duplex or half duplex
zPower supply: 5V DC 1A
zEnvironmental temperature: 0℃-60℃
zRelative humidity: 5%-90%
zUTP cable: Cat5 UTP cable
zFiber: 50/125um, 62.5/125um multi-mode fiber
or 9/125um single-mode fiber
zDimensions: 26mm x 71mm x 94mm
Cautions:
1. This product is suitable for indoor application.
2. Put on the dust cover of fiber interface when not used.
3. It is forbidden to stare at the TX fiber-transfer end with
naked eyes.
