RAGNAR RED CANISTER VACUUM
OWNER’S MANUAL
Model: RGR6CV
120V, 1400W
Atrix
1350 Larc Industrial Blvd.
Burnsville, MN 55337
www.atrix.com
[e-mail]
Telephone: [phone]
Toll Free Telephone: [phone]
Fax: [phone]

2
IMPORTANT SAFETY INSTRUCTIONS
When using an electrical appliance, basic precautions should always be
followed, including the following:
READ ALL INSTRUCTIONS BEFORE USING APPLIANCE
WARNING:
TO REDUCE THE RISK OF FIRE, ELECTRICAL SHOCK OR
INJURY:
1. Do not leave appliance when plugged in. Unplug from outlet
when not in use and before servicing.
2. Electrical shock may occur if used outdoors or on wet surfaces.
3. Do not allow vacuum to be used as a toy. Pay close attention
when vacuum is used by or near children.
4. Use only as described in this manual. Use only manufacturer’s
recommended instructions.
5. Do not use with damaged cord or plug. If appliance is not
working as it should, has been dropped, damaged, left outdoors,
or dropped into water, return it to Atrix International to be
evaluated (refer to warranty policy).
6. Do not pull or carry by cord, use cord as a handle, close a door
on cord, or pull cord around sharp edges of corners. Do not run
appliance over cord. Keep cord away from heated surfaces.
7. Do not unplug by pulling on cord. To unplug, grasp plug, not the
cord.
8. Do not handle plug or appliance with wet hands.
9. Do not put any object into openings. Do not use with any
opening blocked; keep free of dust, lint, hair, and anything that
may reduce airflow.
10. Keep hair, loose clothing, fingers and all body parts away from
openings and moving parts.

3
11. Do not pick up anything that is burning or smoking such as
cigarettes, matches or hot ashes.
12. Do not use without filter in place.
13. Turn off all controls before unplugging.
14. Use extra care when cleaning on stairs.
15. Do not use to pick up any liquids, including flammable or
combustible liquids such as gasoline or use in areas where they
may be present.
16. Connect to a properly grounded outlet only.
17. This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance
by a person responsible for their safety.
18. Children should be supervised to ensure that they do not play
with the vacuum.
SAVE THESE INTRUCTIONS!

4
1. Hard Floor Brush (AHC-70)
2. Telescopic Extension Wand (AHC61-63)
3. Air Slide-Power Adjuster
4. Hose (AHC-65)
5. Suction Hose Connection
6. Full Bag Indicator
7. Cord Rewind Button
8. Suction Control Regulator/Power Adjustment
9. ON/OFF Button
10. Front Cover Lock
11. Upholstery Nozzle(AHC-59)
12. Accessories Holder (AHC-64)
13. 3-in-1 Tool (RC31)
14. Handheld Mini Turbo Brush (RCMTB)
15. Air Driven Turbo Brush (WWRKPT560)
16. Filter Bags (AHC-2)
Components and Equipment

5
Switch off the vacuum cleaner immediately if the air intakes, the
floor brushes or the telescopic wand become blocked. Before
starting the vacuum cleaner up again remove the substance
causing the blockage:
1.
Never use the vacuum cleaner in the immediate vicinity of
hot objects and do not suck up hot objects such as cigarette
ends or ashes.
2. Only insert the plug in the outlet when your hands are dry.
3. Remove large sharp objects from the floor before using the
vacuum cleaner to avoid any possible damage to it.
4. Do not pull by the vacuum cord when pulling out the plug.
Prevention

6
1. Fit the hose on the vacuum
cleaner by inserting the
rotating hose connection into
the vacuum cleaner until you
hear a click. To remove t he
hose,
press the button at the
side of the hose connection and
pull it out.
2. Assembling the telescopic wand and accessories
2.1:
Fit the telescopic wand into
the other end of the hose.
2.2: Adjust the length of
the telescopic wand by
pushing the locking
mechanism down and
pulling out the bottom
section of the wand to a
suitable length. When
parking, shorten the wand
as far as possible.
2.3: Fit the floor brush or
other accessory into the
telescopic wand.
Preparing and Assembling the Vacuum

7
Vacuum cleaning
1. Before using the device first pull out a sufficient length of
electric power cord and plug into the outlet. The yellow
mark on the electric power cord is the maximum length that
should not be exceeded. To switch on the device, press the
foot pedal button .
2. To rewind the power cord, press the button with one
hand and guide the cord with the other hand to ensure that
it does not whip causing damage.
Caution:
Never operate the vacuum cleaner without the HEPA filter
bag or motor filter, otherwise the device could be
damaged.
Vacuum Cleaner Use

8
Changing the HEPA filter bag
If the vacuum’s suction is reduced, this may be because the HEPA filter
bag needs changing. Raise the floor brush off the floor, set the suction
force regulation to MAX, switch on vacuum cleaner using the on/off
button, and keep an eye on the bag change indicator. If it is red, the
HEPA filter bag should be changed.
1. Turn off and unplug cleaner.
2. Remove the hose, open the
HEPA filter bag cover by
pushing latch up with fingers
and lifting cover.
3. Grasp the cardboard at the top
of the HEPA filter bag and
carefully remove the bag from
the vacuum cleaner.
4. Dispose of the HEPA filter bag.
5. Insert a new HEPA filter bag in
the vacuum cleaner. The vacuum
cleaner must never be used
without the HEPA bag.
6. Close the vacuum cleaner.
7. Always replace the HEPA filter bag after
sweeping up large quantities of fine
material.
Cleaning the motor filter
1. The motor filter can be found in
the dust bag container. It
protects the motor from dust
and should be cleaned
periodically or when it is dirty,
or if suction force is reduced.
2. Pull the filter holder up out of the
vacuum cleaner.
3. Open the filter holder, and remove the filter. Rinse the filter in
warm water, and allow it to dry completely. Do not use a hair
dryer or similar to dry the filter.

9
4. Return the filter to the holder and replace the filter holder in the
vacuum cleaner.
IMPORTANT! Never use the vacuum cleaner without a motor filter.
Cleaning the exhaust air filter
The exhaust air filter cleans the air a final time before it leaves the
vacuum cleaner. You can clean the exhaust air filter as follows:
1. Switch off the vacuum cleaner and disconnect the plug from the
outlet. To do this, always pull on the plug and not on the cord.
2. Open the exhaust air grill (this is at the rear and top of vacuum
cleaner).
3. The exhaust air filter is visible when the grill has been opened.
4. Rinse the filter under cold running water and allow dry.
5. Put the exhaust air filter back into place (or replace with a new
one) and place in the grill.
6. Close the exhaust air filter grill.

10
1. You can lift and carry the vacuum cleaner using the carrying
handle. Never pull or lift the vacuum cleaner by the cord.
2. Before putting the vacuum away turn vacuum off, unplug, and
press the cord rewind button until the cord is fully rewound.
3. To save space, the vacuum can be stored upright on its end
cover. The telescopic wand can be hung on the vacuum cleaner
by inserting the parking fixture into the vertical parking holder.
Clean the vacuum cleaner by wiping it with a damp cloth. You must not
use any solvents or abrasive cleaning agents.
Once any electronic product is no longer functional, it
should be disposed of in such a way as to cause minimum
environmental impact, in accordance with the regulations
of your local authority. In most cases you can take such
products to your local recycling station.
Transport and Storage
Cleaning
Environmental Tips

11
Atrix Ragnar Red Canister Vacuum
WARRANTY INFORMATION
Warranty/Service Information: For warranty service
information, please contact Atrix or your local Atrix
distributor.
Atrix Ragnar Red Canister Vacuum Limited Warranty: To the original
user purchasing the Atrix Ragnar Red Canister Vacuum, Atrix
warrants that the vacuum will be free of defects in material and
manufacture for a period of one (1) year from the date of purchase.
Should any failure to conform to this warranty appear within this
period, Atrix will, at its option, repair or replace the defective product.
It is the user’s responsibility to return the product, freight prepaid, to
Atrix International. These remedies are the user’s exclusive remedies
for breach of this warranty.
Exclusions to warranty coverage: The above warranty will not
apply to any special configurations or to any units that have been
modified, or damaged by negligence, misuse, accident or failure to
follow Atrix’s Instruction Manual. Consumable supplies, such as
filters, accessories, and motor brushes are not covered by this
warranty.
Disclaimer of Warranty: EXCEPT FOR THE IMPLIED WARRANTIES
OF TITLE AND AGAINST PATENT INFRINGEMENT, ATRIX MAKES NO
OTHER WARRANTIES WITH RESPECT TO THE ATRIX CANISTER
VACUUM CLEANER, EXPRESS OR IMPLIED, INCLUDING BUT NOT
LIMITED TO ANY IMPLIED WARRANTY OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE.
Limitation of Liability: ATRIX WILL NOT BE LIABLE UNDER ANY
CIRCUMSTANCES FOR ANY COINCIDENTAL, SPECIAL, OR
CONSEQUENTIAL DAMAGES OR ECONOMICAL LOSS, BASED UPON
BREACH OF WARRANTY, BREACH OF CONTRACT, NEGLIGENCE,
STRICT LIABILITY IN TORT OR ANY OTHER LEGAL THEORY, EVEN
IF ATRIX HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH
DAMAGES INCLUDING, BUT NOT LIMITED TO LOSS OF PROFITS,
REVENUE, EQUIPMENT USE, DATA OR INFORMATION OF ANY KIND.
THE LIABILITY OF ATRIX SHALL NOT UNDER ANY CIRCUMSTANCE,
EXCEPT AS EXPRESSLY PROVIDED HEREIN, EXCEED THE PRICE OF
THE ATRIX CANISTER VACUUM
.
To Register your Warranty Visit:
www.atrix.com
