Atronix PPS Solar bag Configuration guide

09/2021 Page 1
MOBILE
SOLAR MODULE
User Manuel
PPS Solar bag
Model Article number
a-TroniX PPS Solar bag 2x40W 9885601
a-TroniX PPS Solar bag 3x40W 9885602
a-TroniX PPS Solar bag 4x40W 9885603

Page 2 09/2021
User Manual
a-TroniX PPS solar bag
INTRODUCTION
The publication and copyright of this documentation remain with the company:
AKKU SYS Akkumulator- und Batterietechnik Nord GmbH
Verbindungsweg 23 · 25469 Halstenbek / Hamburg · GERMANY
Phone +49 4101 | 3 76 76-0 / Fax +49 4101 | 3 76 76-66
[email protected] / www.akkusys.de
Thank you very much,
for purchasing our mobile solar module PPS solar bag from the a-TroniX series.
It is a handy, portable solar panel and offers you the possibility for quick battery charging,
e.g. when camping.
Read carefully before use!
Read this manual carefully before installation.
It contains important regulations and instructions for the use of this product and provides
technical support for the operator of the unit.
All rights reserved.
AKKU SYS Akkumulator- und Batterietechnik Nord GmbH cannot be held responsible for
any inaccuracies or inappropriate information in this instruction manual.
The information in this document is subject to change without notice, but there is no
obligation to update it on an ongoing basis.
We reserve the right to make design and equipment changes to improve the production
process or the product. AKKU SYS GmbH accepts no liability for errors in this operating
manual and any consequences resulting therefrom.

09/2021 Page 3
User Manual
a-TroniX PPS solar bag
Table of contents
Page
1. Symbols used in this guide 3
2. Safety instructions 4
3. Common design of the foldable solar panel 5
4. Setup and operation 6
5. Troubleshooting 7
6. Environment 7
7. Specification 7
1. Symbols used in this guide
CAUTION:
General warning of danger.
NOTES:
This symbol indicates texts, notes or tips.
Failure to observe precautions may result in damage to the product and/or its
functions or to something in its vicinity.
ENVIRONMENT:
Indicates recycling information.
Indicates assemblies or parts that must be disposed of properly.
Do not dispose of them with household waste.

Page 4 09/2021
User Manual
a-TroniX PPS solar bag
2. Safety instructions
Please keep this user manual and read it before use. Observe the safety instructions.
■ If the product is damaged or does not work properly, do not use it. Contact your
supplier.
■ Prevent rain, moisture or water from entering the electrical connections.
■ Make sure that no sharp objects damage the surface of the solar module.
■ The product does not contain any parts that require maintenance. Do not disassemble
the module, attempt to repair it or touch exposed electrical conductors.
■ Ensure correct polarity when wiring the connections. To avoid short circuits, make sure
that the battery and load connections are secure.
■ Avoid contact of products with corrosive substances such as acids, alkalis and oils, etc.
■ Charging a battery is only possible with the charge controller connected (not included in
the scope of delivery).
■ The company is not responsible for damage caused by the user‘s failure to follow the
instructions.
CAUTION:
This appliance generates electric current.
Do not leave it in operation unattended.
It can be dangerous for children and adults.
NOTE:
Dust and dirt covering the surface of the solar module should rst be cleaned
with a soft brush. Then wipe the surface of the module with a damp cloth.
Bird droppings and adhesives should be removed from the surface of the
module as soon as possible so as not to impair performance.
CAUTION:
As the system contains sophisticated electronic components, it is essential
to prevent moisture from entering the unit.

09/2021 Page 5
User Manual
a-TroniX PPS solar bag
3. Common design
of the foldable solar panel
(Other applications are possible)

Page 6 09/2021
User Manual
a-TroniX PPS solar bag
4. Setup and operation
Place the a-TroniX PPS solar bag on a at surface with direct sunlight. Make sure that no
branches or other obstacles cast shadows on the solar module.
In order to obtain the greatest possible output, the solar module should be aligned as
perpendicularly as possible to the sun.
NOTE:
■ Make sure that the connected cables do not pose a risk of accident and that
they cannot be damaged by being accidentally stepped on or run over. Avoid
water getting into the connection sockets.
■ Using a suitable charge controller (not included), this solar module can be
used to charge all common batteries.
■ Connect the battery to be charged to the correct outputs of the charge con-
troller. Refer to the corresponding operating instructions of the solar charge
controller.
■ When wiring the connections, ensure that the polarity is correct to avoid short
circuits.
5. Troubleshooting
Error Troubleshooting Solution
The charging indicator does
not light up even though
the module is facing directly
towards the sun.
Problem
with
the connections.
Make sure that the connections have
not been interchanged. Check
whether the solar charge controller is
defective and replace it if necessary.

09/2021 Page 7
User Manual
a-TroniX PPS solar bag
6. Environment
he packaging is recyclable. After unpacking, please keep it for reuse
or dispose of it properly.
Do not dispose of waste electrical and electronic equipment (WEEE)
in household waste. Observe the local regulations for disposal.
For more information, contact us on the hotline [phone],
at [email protected] or use the QR code.
7. Specification
Model a-TroniX PPS Solar bag
Article number 9885601 9885602 9885603
Photovoltaic cell 2x 40W 3x 40W 4x 40W
Cell type sunpower sunpower sunpower
Efciency 22,6 22 22,6
Max. Power (W) 80 120 160
Max. Power voltage (V) 20,88 20,88 20,88
Max. Power current (A) 3,98 5,97 7,66
Open circuit voltage (V) 24,64 24,64 24,64
Short circuit current (A) 4,22 6,32 8,12
Modul size folded (mm) 560 x 440 x 15 560 x 440 x 15 560 x 440 x 15
Modul size unfolded (mm) 1075 x 560 x 4 1525 x 560 x 4 1975 x 560 x 4
Weight (kg) 1,6 2,7 3,2

AKKU SYS Akkumulator- und Batterietechnik Nord GmbH
Verbindungsweg 23 · 25469 Halstenbek / Hamburg · GERMANY
Tel. +49 4101 | 3 76 76-0 / Fax +49 4101 | 3 76 76-66 / [email protected] / www.akkusys.de
