AtVideo BHR7212SR User manual

700TV Lines
Super High Resolution Color Camera
BHR7212SR

LIMITATION OF LIABILITY
THE INFORMATION IN THIS PUBLICATION IS BELIEVED TO BE ACCURATE IN
ALL RESPECTS, HOWEVER, WE CANNOT ASSUME RESPONSIBILITY FOR ANY
CONSEQUENCES RESULTING FROM THE USE THEREOF. THE INFORMATION
CONTAINED HEREIN IS SUBJECT TO CHANGE WITHOUT NOTICE. REVISIONS
OR NEW EDITIONS TO THIS PUBLICATION MAY BE ISSUED TO INCORPORATE
SUCH CHANGES.
ii

iii

iv

IMPORTANT SAFETY INSTRUCTIONS
v

1
INTRODUCTION
The camera provides high-quality images using Sony CCD technology especially
applications.
designed for closed-circuit television (CCTV) and security surveillance
Features:
TM
High resolution and high performance 1/3" Sony Super HAD Technology
Excellent picture quality
700 lines(Color) of resolution
0.1 lux(Color), 0 lux(B/W) @ F1.2 50IRE Sensitivity
Auto electronic shutter [1/60(1/50) ~ 1/10,000]
2D-DNR(Digital Noise Reduction)
Smart IR
Auto white balance modes
AGC (Auto Gain Control)
VIDEO Out (BNC)
Use Certified / Listed Class 2 power source only
Camera Mount : Camera mount directly to the wall or ceiling

22

3
The A-CB7T2812PI camera can be used in video systems with BNC.
The cable on the camera has a BNC connection for video output and a power connector for
a 12V DC power source.
The A-CB7T2812PI Camera comes with the following accessories:
12VDC Adapter
Instruction Manual
Four 3 x 20mm Tapping screws
Sun shield
BNC FEMALE VIDEO OUT
VIDEO IN
DC +12V IN
DC 12V REGULATED
POWER SUPPLY
* Diagram of typical wiring connections
CAMERA CONNECTIONS

4

5

6
DC 12~15V +/- 10%
0.1 Lux(Color), 0 Lux(B/W at IR ON) @ F1.2, 50IRE
700 TV lines (Color)
1020(H) x 596(V)
400mA(4.5 Watts) - IR LED ON
1020(H) x 508(V)

MEMO

MEMO

700TV Lines
Super High Resolution Color Camera
PRINTED IN KOREA
50303394B
