ATZ HDMI-E100W User manual

Model : ATZ HDMI-E100W
Description : HDMI Wireless Extender 100M
pg. 1
Notes : - All brand names and trademarks are properties of their respective holders and are referred to here for descriptive purpose only. Photo attached is for reference only, it may be slightly varied in items of colour,
shape from the actual item delivered from time to time.
All specifications are subject to change without prior notice.
© Copyright A Z
1. INCREASE YOUR VIEWIN RAN E: Transmitter and Receiver wirelessly sends HDMI
A/V signals up to 100m through line-of-sight environments; works with most HDMI-
equipped devices, including blu-ray players, set-top boxes, AV receivers, cable/satellite
boxes, and computer systems.
2. BUILT-IN IR REMOTE CONTROL: Built-in IR signal extension feature allows you to
control the playback device remotely. Imagine you have a DVD player in your media
room and a TV in your living room, while you are in the living room, you can still use
your DVD remote to control the DVD player with IR CONTROL EXTENSION function.

Model : ATZ HDMI-E100W
Description : HDMI Wireless Extender 100M
pg. 2
Notes : - All brand names and trademarks are properties of their respective holders and are referred to here for descriptive purpose only. Photo attached is for reference only, it may be slightly varied in items of colour,
shape from the actual item delivered from time to time.
All specifications are subject to change without prior notice.
© Copyright A Z
3. UNCOMPROMISED VIDEO QUALITY: Supports vivid, high-definition videos up 1080p
@60Hz. Compatible with HDCP 1.2 (High-bandwidth Digital Content Protection); best
used for TV/video applications rather than computers or real-time applications; Note: A
delay of less than 0.5 seconds might occur due to data compression- Not recommended
using for PC gaming.
The extender uses TCP /IP standard Wireless Transport Protocol, so it has high
transmission rate and strong anti-interference capability. It has HDMI loop-out port with
IR capability to control source devices remotely. The HDMI Wireless Extender is widely
applicable for office presentation, lecture, education, conference, family entertainments
etc.
Features:
•HDMI loop output: for local screen monitor
•Support HDMI resolution: 480i/576i~1080P@50/60Hz and SV A~WUX A
•Digital 2.4 & 5 Hz dual frequency wireless A/V transmission, high transmission
rate and strong anti-interference capability
•External dual - gain antennas. Full HD 1080p transmits up to 100 meters wireless
in open space.( May be affected by the use environment)
•Extends wide-band infrared remote to control source device from display side
•Support OSD for device status
•Plug and Play - no software installation required
•Supports both panel settings and Web Configuration Interface, Simple and easy to
use.
Specifications:
Transmitter Unit 1x HDMI input + 1x HDMI loop out
Reciever Unit 1x HDMI output
HDMI resolution
480i/576i...1080P@50/60Hz and
SV A~WUX A
HDMI Audio Format LPCM2.0/48KHz/16Bit
HDMI Max bandwidth 225MHz
HDMI Max baud rate 6.75 bps

Model : ATZ HDMI-E100W
Description : HDMI Wireless Extender 100M
pg. 3
Notes : - All brand names and trademarks are properties of their respective holders and are referred to here for descriptive purpose only. Photo attached is for reference only, it may be slightly varied in items of colour,
shape from the actual item delivered from time to time.
All specifications are subject to change without prior notice.
© Copyright A Z
Input/Output TMDS signal 0.5~1.5Volts p-p(TTL)
Input/Output DDC signal 5Volts p-p (TTL)
HDMI output cable distance ≤15m AW 26 HDMI standard cable
Antenna type External dual 3dBi gain antenna
Wireless standard IEEE 802.11a/b/g/n
Operational frequency 2.4 /5 dual frequency
Operational range Up to 100M in open space
Latency (delay) <200 ms
Infrared retourfunction frequency
range 20-60KHz
Video compression Comparable with H.264
Max Data rates 2T2R up to 300Mbps
Transmit Output Power （ IPEX ） 16±2dBm
Transmission distance up to 100m (in open space)
IR Carrier frequency 20-60KHz
TX/RX Max working current 1A
Power adapter format Input AC 100V
～ 240V 50HZ/60Hz, DC5V/2A
Operating Temperature range -5 to +45
℃
Storage Temperature range -20 to +60
℃
Operating Humidity range 10 to 90%RH (No Condensation)
Storage Humidity range 5 to 95%RH (No Condensation)
Case Dimension (L x W x H) 127.5x127.5x25 (mm)
Weight TX176g/ RX170g

Model : ATZ HDMI-E100W
Description : HDMI Wireless Extender 100M
pg. 4
Notes : - All brand names and trademarks are properties of their respective holders and are referred to here for descriptive purpose only. Photo attached is for reference only, it may be slightly varied in items of colour,
shape from the actual item delivered from time to time.
All specifications are subject to change without prior notice.
© Copyright A Z
FEATURES OF THE INTERFACE:
Transmitter TX)
TX Front Panel View TX Rear Panel View
Receiver RX)
RX Front Panel View RX Rear Panel View
POWER: Power indicator HDMI IN: HDMI INPUT
STATUS: System status indicator HDMI OUT: HDMI OUTPUT
HDMI: HDMI input/output status indicator DC5V: 5V DC in jack
CHANNEL: Wireless channel switch key IR OUT&RESET: Insert IR transmitter cable & Factory Reset
Button
5G-2.4: 5 /2.4 working frequency selection IR IN&RESET: Insert IR receiver cable & Factory Reset Button

Model : ATZ HDMI-E100W
Description : HDMI Wireless Extender 100M
pg. 5
Notes : - All brand names and trademarks are properties of their respective holders and are referred to here for descriptive purpose only. Photo attached is for reference only, it may be slightly varied in items of colour,
shape from the actual item delivered from time to time.
All specifications are subject to change without prior notice.
© Copyright A Z
Panel key operation instructions:
1. Change Wireless Band: Select the switch on the front panel of TX, you can set the
working frequency range to 2.4g/5 .
2. Change Wireless channel: Press the “CHANNEL” key on the front panel of TX to
cyclic switch the multiple wireless channels. If the product works unsteadily or
pictures not fluid, you can try a different working channel.
3. Restore Factory Setting: To press the button for lasting three seconds, then the
HDMI Status Led Light will flash for three times and restart, it shows that Restore
Factory Set is successful.
The Factory Reset Button is located at the bottom of the Hole of the IR IN/OUT. It is
able to work under power on status. To use one long and narrow insulated stick (like
toothpick) to insert the hole end to press the button.
Web settings:
To prevent the interference caused by the same frequency device, the Wireless HDMI
Extender support to set up the working frequency, transmit channel and SSID by the
WEB. For safety, the user should change the SSDI and the password at the first log
in.
Please follow the below steps:
1. Connect 5V power supplies to the TX&RX, and let them be connected.
2. Turn on the WLAN of the mobile phone / PC ， search and connect SSID,
HDMI Wireless, Enter the default password: 00000000.
3. Modify the IP address type of the mobile phone / PC to Auto. When you select
static type, you must be set the IP in 192.168.1.xxx address segment range, e.g.
192.168.1.100.
4. Open the browser and scan the QR code or enter “192.168.1.10”
in the address bar to enter the configuration page.. As shown below:

Model : ATZ HDMI-E100W
Description : HDMI Wireless Extender 100M
pg. 6
Notes : - All brand names and trademarks are properties of their respective holders and are referred to here for descriptive purpose only. Photo attached is for reference only, it may be slightly varied in items of colour,
shape from the actual item delivered from time to time.
All specifications are subject to change without prior notice.
© Copyright A Z
5. Enter the default login password: admin, click “Login” open the Settings Interface.
If you want to modify the login password, please click on the "Modify", after
modified click "save" to save and exit. Restore factory settings when click "reset".
6. If you have an error in setting or forgot the password, you can restore factory
setting.

Model : ATZ HDMI-E100W
Description : HDMI Wireless Extender 100M
pg. 7
Notes : - All brand names and trademarks are properties of their respective holders and are referred to here for descriptive purpose only. Photo attached is for reference only, it may be slightly varied in items of colour,
shape from the actual item delivered from time to time.
All specifications are subject to change without prior notice.
© Copyright A Z
OPERATIONG AND CONNECTION:
•Connect one HDMI cable from the DVD/BD player into the HDMI input port of the
HDMI wireless TX.
•Connect one HDMI cable from TV/Monitor into the HDMI output port of the HDMI
wireless RX.
•Connect the IR Transmitter cable to the HDMI wireless TX and the IR Transmitter
cable must face to the control target device.
•Connect IR Receiver cable to the HDMI wireless RX.
•Connect 5V power supplies to the TX&RX, the POWER indicator will be lit at this
moment.
•The device will automatically connect after power on. The STATUS indicator of TX
and RX will be lit when the connection is successful. If the HDMI input or output
signal is normal, the HDMI indicator light will be lit also. The STATUS indicator
flashes continuously during normal transmission.
FAQ:
Before power on, pls check the connection line carefully. And make sure that all interfaces
are normally connected. The common trouble shooting way shows below:
No. Problem Description Solutions
1 No display
1. Check the TV is on and has been connected with the
machine.
2. Please check the TX power supply
3. Make sure the TV is working regularly
2 Display “Connecting”
1. Please check the RX power supply
2. Please check the WEB are set correctly
3. Co-channel interference. Pls select a new band or
channel
4. Pls reset or turn off the power restart
3 Display “No signal”
1. Check the signal source is power on and output
normal.
2. Check the signal source output resolution.
3. Make sure the HDMI cable is properly connected
4 Transmission
distance is short
1. Please adjust the angle of the antenna or adjust the
placement

Model : ATZ HDMI-E100W
Description : HDMI Wireless Extender 100M
pg. 8
Notes : - All brand names and trademarks are properties of their respective holders and are referred to here for descriptive purpose only. Photo attached is for reference only, it may be slightly varied in items of colour,
shape from the actual item delivered from time to time.
All specifications are subject to change without prior notice.
© Copyright A Z
2. Concrete walls, Brick, Wallpaper, Metal, Bulletproof
glass will shorten the signal cover range or cause big
signal loss.
3. Co-channel interference. Please select a new band or
channel
5 Screen not fluent
1. Please adjust the angle of the antenna or adjust the
placement
2. Co-channel interference. Please select a new band or
channel
6 Can't find the SSID
1. Please check the RX and TX power supply
2. Please check whether the Phone/PC supports 2.4 /5
band
3. Factory default or turn off the power restart
7
Can't login to the
Web settings
interface
1. Please check the RX and TX power supply
2. Please check the IP type of mobile phone/PC is Auto
3. Please check the IP is in 192.168.1. XXX address
range
4. Please try Login again after changed a browser

Model : ATZ HDMI-E100W
Description : HDMI Wireless Extender 100M
pg. 9
Notes : - All brand names and trademarks are properties of their respective holders and are referred to here for descriptive purpose only. Photo attached is for reference only, it may be slightly varied in items of colour,
shape from the actual item delivered from time to time.
All specifications are subject to change without prior notice.
© Copyright A Z
Product Diagram:
Package contents:
1x HDMI Wireless Transmitter
1x HDMI Wireless Receiver
1x IR Transmitter cable
1x IR Receiver cable 1pc
1x User manual
2x DC Power Adapter
Warranty: 2 Years
Warranty is effective from the date of original delivery.
This warranty shall be void if a serial number has been removed from the product.
